Two-stage, variable-speed ecm gas furnace up to 96% afue

Advertisement

Heating Input: 40,000-120,000 BTU/h
Standard Features
• Integrated communicating ComfortBridge
• Commissioning and diagnostics via on board Bluetooth
with the CoolCloud phone and tablet application
• Heavy-duty aluminized-steel tubular heat exchanger
• Stainless-steel secondary heat exchanger
• Two-stage gas valve provides quiet, economical heating
• Durable Silicon Nitride igniter
• Quiet two-speed induced draft blower
• Compatible with any single-stage thermostat
• Self-diagnostic control board with constant memory
fault code history output to a triple 7-segment display
• Color-coded low-voltage terminals with provisions for
electronic air cleaner
• Efficient and quiet variable-speed airflow system gently
ramps up or down according to heating or cooling demand
• Multiple continuous fan speed options offer quiet air circulation
• Auto-Comfort and enhanced dehumidification modes available
• All models comply with California 40 ng/J
Low NOx emissions standard
• Can no longer be installed in California's South Coast
Air Quality Management District (SCAQMD)
on or after October 1, 2019.
* Complete warranty details available from your local dealer or at www.goodmanmfg.com. To receive the Lifetime Heat Exchanger Limited Warranty (good for as long as you own
your home), 10-Year Unit Replacement Limited Warranty and 10-Year Parts Limited Warranty, online registration must be completed within 60 days of installation. Online
registration and some of the additional requirements are not required in Florida, California, or Québec. The duration of warranty coverage in Texas and Florida differs in some cases.
Other limitations and exclusions apply; refer to complete warranty details for a full list of limitations and exclusions
SS-GRVT96_GDVT96-R32
GRVT96 / GDVT96
Cabinet Features
Technology
• Designed for multi-position installation -
upflow, horizontal left or right
• Certified for direct vent (2-pipe)
or non-direct vent (1-pipe)
• Easy to install top venting with optional side venting
• Convenient left or right connection
for gas and electrical service
• Cabinet air leakage (Q
• Heavy-gauge steel cabinet with
durable baked-enamel finish
• Fully insulated heat exchanger and blower section
• Airtight solid bottom or side-return with easy-cut tabs
for effortless removal in bottom air-inlet applications
www.goodmanmfg.com
Two-Stage, Variable-Speed
ECM Gas Furnace
Up to 96% AFUE
Contents
Nomenclature ........................................ 2
Product Specifications ........................... 3
Dimensions ............................................ 5
Airflow Specifications ............................ 7
Wiring Diagrams .................................... 9
Accessories .......................................... 10
) ≤ 2%
Leak
12/24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRVT96 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Goodman GRVT96

  • Page 1: Table Of Contents

    GRVT96 / GDVT96 Two-Stage, Variable-Speed Heating Input: 40,000–120,000 BTU/h ECM Gas Furnace Up to 96% AFUE Contents Nomenclature ........2 Product Specifications ......3 Dimensions ..........5 Airflow Specifications ......7 Wiring Diagrams ........9 Accessories .......... 10 Standard Features Cabinet Features •...
  • Page 2: Nomenclature

    Nomenclature 7,8,9 Brand Minor Revision G - Goodman Brand A - Initial Release B - 1st Revision Configuration Major Revision R - Upflow/Horizontal A - Initial Release D - Downflow/Horizontal B - 1st Revision N - Natural Gas ≥ 40 NG/J NOx N - Low NOx (90%+) ≥...
  • Page 3: Product Specifications

    GRVT96 Product Specifications GRVT96 GRVT96 GRVT96 GRVT96 GRVT96 GRVT96 GRVT96 0403BN 0603BN 0803BN 0804CN 1005CN 1005DN 1205DN HEATING DATA High Fire Input1 40,000 60,000 80,000 80,000 100,000 100,000 120,000 High Fire Output1 38,440 57,660 76,880 76,880 96,100 96,100 115,320 Low-Fire Input1...
  • Page 4 GDVT96 Product Specifications GDVT96 GDVT96 GDVT96 GDVT96 GDVT96 0403BN 0603BN 0804CN 1005CN 1205DN Heating Data High Fire Input¹ 40,000 60,000 80,000 100,000 120,000 High Fire Output¹ 38,440 57,660 76,880 96,100 115,320 Low-Fire Input¹ 28,000 42,000 56,000 70,000 84,000 Low-Fire Output¹ 26,908 40,362 53,816...
  • Page 5: Minimum Clearances To Combustible Materials

    GRVT96 Dimensions Discharge Discharge 28¾ 6½ ¾ 2¾ 6½ ¾ Air Intake 2⅝ 1⅞ 2" Pipe 19½ Center Dimple Vent/ Flue Pipe Left-Side Alternate For Alternate 2" PVC Drain Trap Vent/ Flue Air Intake Pipe ¾ Exterior Holes 3" Location...
  • Page 6 GDVT96 Dimensions 6½ 2⅝ 2½ 18¼ 1⅝ 1⅞ 1⅜ 1⅞ Alternate Vent/ Low-Voltage 1½ Electrical Outlet Low-Voltage Electrical Outlet Alternate Gas Alternate Gas Supply High-Voltage Electrical Outlet 25⅛ 34½ 25⅛ 14⅞ 14¾ 14¾ 11⅜ 11⅜ 6⅞ 6⅞ 4⅛ High-Voltage 18⅛ Drain Trap Holes Electrical Outlet Unfolded Flanges...
  • Page 7: Airflow Specifications

    GRVT96_GDVT96 Airflow Data MODEL/TEMP RISE RANGE GDVT960403BNA* GDVT960603BNA* GDVT960804CNA* GDVT961005CNA* GDVT961205DNA* GRVT960403BNA* (MID-RISE) 35-65 (50) 20-50 (35) 35-65 (50) 35-65 (50) 35-65 (50) 20-50 (35) RISE RISE RISE RISE RISE RISE Recommended CFM for High Heat/ 1400 1425 1770 2150 1010 Expected Temperature Rise Lowest Recommended CFM for...
  • Page 8 Temperature Rise Range Chart www.goodmanmfg.com SS-GRVT96_GDVT96-R32...
  • Page 9: Wiring Diagrams

    Wiring Diagram JUNCTION BOX SS-GRVT96_GDVT96-R32 www.goodmanmfg.com...
  • Page 10: Accessories

    Accessories – GRVT96 / GDVT96 GRVT96 GRVT96 GRVT96 GRVT96 GRVT96 GRVT96 GRVT96 Model Description 0403BN 0603BN 0803BN 0804CN 1005CN 1005DN 1205DN 72950 Concentric Vent Kit (2") √ √ ― √ √ √ √ 72951 Concentric Vent Kit (3") √ √...
  • Page 11 Notes SS-GRVT96_GDVT96-R32 www.goodmanmfg.com...
  • Page 12 Notes Our continuing commitment to quality products may mean a change in specifications without notice. ©2024 • Houston, Texas • Printed in the USA. www.goodmanmfg.com SS-GRVT96_GDVT96-R32...
