Goodman GMH8 Installation Instructions Manual

Gas-fired warm air furnace
Hide thumbs Also See for GMH8:
Table of Contents

Advertisement

Quick Links

See also: Technical Manual
GMH8
GDH8
&
G
-F
W
A
F
AS
IRED
ARM
IR
URNACE
I
I
NSTALLATION
NSTRUCTIONS
Installer: Affix all manuals adjacent to the unit.
(CATEGORY 1)
These furnaces comply with requirements
embodied in the American National
®
Standard / National Standard of Canada
ANSI Z21.47·CSA-2.3 Gas Fired Central
C
US
Furnaces.
RECOGNIZE THIS SYMBOL AS A SAFETY PRECAUTION.
ATTENTION INSTALLING PERSONNEL
As a professional installer, you have an obligation to know the product better than the customer.
This includes all safety precautions and related items.
Prior to actual installation, thoroughly familiarize yourself with this Instruction Manual.
Pay special attention to all safety warnings. Often during installation or repair, it is possible to place yourself
in a position which is more hazardous than when the unit is in operation.
Remember, it is your responsibility to install the product safely and to know it well enough
to be able to instruct a customer in its safe use.
Safety is a matter of common sense...a matter of thinking before acting.
Most dealers have a list of specific, good safety practices...follow them.
The precautions listed in this Installation Manual are intended as supplemental to existing practices.
However, if there is a direct conflict between existing practices and the content of this manual,
the precautions listed here take precedence.
*NOTE: Please contact your distributor
or our website for the applicable product data book
referred to in this manual.
Goodman Manufacturing Company, L.P.
2550 North Loop West, Suite 400, Houston, TX 77092
www.goodmanmfg.com
IO-295B
©2006 Goodman Manufacturing Company, L.P.
9/06
