- Page 1 User Manual Including installation guide for 8730 B S-Link™ interface, bow thruster 8730 S S-Link™ interface, stern thruster DOCUMENT ID: 2071 REVISION: DATE: 2024 LANGUAGE:...
-
Page 2: Table Of Contents
Installation considerations..................................8 Wiring diagram - foot switches or other normally open switches ......................9 Wiring diagram - Sleipner RCR-2x remote control receiver ........................10 Wiring diagram Sleipner ON/OFF control panels ............................. 11 Wiring diagram - combining multiple devices for ON/OFF control ......................12 S-Link system description .................................. -
Page 3: Warnings And Safety
Always plan on how to avoid damage to persons or other objects if the thruster stops giving thrust for while manoeuvring. WARNING Failure to follow any considerations and precautions can lead to serious personal injury, death and/or damage your product. Failure to follow any considerations and precautions will render all warranties given by Sleipner Motor as VOID. MC_0411 8730... -
Page 4: Product Description
S-Link™ interface, stern thruster –Preprogrammed to control S-Link stern thruster Both models can be reconfi gured to operate either bow or stern thrusters. Confi guration must be done by a Sleipner S-Link control panel supporting 8730 or the confi guration tool S-Link Programmer running on a computer. -
Page 5: Layout And Functions
Location parameter confi gured to Bow. Similar 8730 S will only activate AMS and retract controllers with the Location parameter confi gured to Stern. If the Enable Input is connected to the yellow wire from a Sleipner ON/OFF control panel or a Sleipner Remote Control Receiver, 8730 will be enabled if the control panel or Remote Control is turned on. -
Page 6: Ramp Mode
Ramp mode MC_0982 RAMP mode enables variable thrust control when using ON/ OFF control devices. Parameter confi guration for RAMP mode is described in chapter Confi guration. When RAMP mode is disabled a fi xed thrust level is request by 8730 when the Port or Starboard Input Switch is activated. The graph below shows an example where the input switch is activated for 5 seconds, then deactivated for 2 seconds then reactivated for 3 seconds. -
Page 7: Installation Guide
• Any attempt to directly control or connect to the S-Link™ control system without a designated and approved interface from Sleipner will void all warranties and responsibilities of the connected Sleipner products. If you interface the S-Link™ bus by agreement with Sleipner through a designated Sleipner-supplied interface, you are still required to install at least one original Sleipner control panel to enable efficient troubleshooting if necessary. -
Page 8: Installation Considerations
8730 can be interfaced with ON/OFF control devices to enable control of S-Link thrusters. Such control devices could be foot switches or other normally open switches, Sleipner ON/OFF control panels or Sleipner RCR-2x Remote Control Receiver. 8730 can be interfaced with one or several of the above mentioned control devices. -
Page 9: Wiring Diagram - Foot Switches Or Other Normally Open Switches
Wiring diagram - foot switches or other normally open switches Switch on Enable Input Switch on Enable Input is optional. is optional. Foot switch or other Foot switch or other normally open switches normally open switches 8730 B 8730 S MG_993 8730 2071... -
Page 10: Wiring Diagram - Sleipner Rcr-2X Remote Control Receiver
Wiring diagram - Sleipner RCR-2x remote control receiver 8730 B 8730 S MG_985_02 Fuse 5A RCR-2x remote control receiver 12/24VDC 8730 2071 2024... -
Page 11: Wiring Diagram Sleipner On/Off Control Panels
Wiring diagram Sleipner ON/OFF control panels 8730 B 8730 S MG_986_2 Extension cable Extension cable 6 1278 - xx m 6 1278 - xx m Control panel 8730 2071 2024... -
Page 12: Wiring Diagram - Combining Multiple Devices For On/Off Control
Wiring diagram - combining multiple devices for ON/OFF control Control panel Extension cable Extension cable 6 1278-xxM 6 1278-xxM Foot switch or other normally open switches Foot switch or other normally open switches 8730 S 8730 B Fuse 5A RCR-2x remote control receiver 12/24VDC MG_1002_2 8730... -
Page 13: S-Link System Description
MC_0120 S-Link is a CAN-based control system used for communication between Sleipner products installed on a vessel. The system uses BACKBONE Cables as a common power and communication bus with separate SPUR Cables to each connected unit. Only one S-Link POWER cable shall be connected to the BACKBONE Cable. -
Page 14: Sleipner Group Waste Disposal And Recycling Guide
Introduction: At Sleipner Group, we prioritize sustainability and encourage the repair and re-manufacturing of products to extend their life cycles. If disposal is necessary, please follow these guidelines to recycle and manage waste responsibly, ensuring our efforts align with environmental protection efforts. -
Page 15: Service And Support
11. This warranty gives you specific legal rights, and you may also have other rights which vary from country to country. Patents MC_0024 At Sleipner we continually reinvest to develop and offer the latest technology in marine advancements. To see the many unique designs we have patented, visit our website www.sleipnergroup.com/patents 8730... - Page 16 © Sleipner Motor AS, All rights reserved The information given in the document was right at the time it was published. However, Sleipner Motor AS cannot accept liability for any inaccuracies or omissions it may contain. Continuous product improvement may change the product specifi cations without notice.
