Sealey SM27.V3 Instruction Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
NOTE: The lathe is fitted with three safety devices. A Emergency Stop Button (fig.1.19) is mounted on the main control panel and
two interlocks operate if either the gear box cover or head stock guard are opened.
1.1. ELECTRICAL SAFETY
WARNING! It is the user's responsibility to check the following:
‰
Check all electrical equipment and appliances to ensure that they are safe before using.
Inspect power supply leads, plugs and all electrical connections for wear and damage.
Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
DO NOT use worn or damaged cables, plugs or connectors.
8
Ensure that any faulty item is repaired or is replaced immediately by a qualified electrician.
9
If the cable or plug is damaged during use, switch off the electricity supply and remove from use.
9
Ensure that repairs are carried out by a qualified electrician.
Sealey recommend that an RCD (Residual Current Device) is used with all electrical products.
9
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is fitted with the
correct fuse.
DO NOT pull or carry the appliance by the power cable.
8
DO NOT pull the plug from the socket by the cable.
8
1.2. GENERAL SAFETY
NOTE: Only trained users to operate the lathe. If inexperienced, seek suitable training.
WARNING! The lathe is heavy (145kg). Ensure either lifting equipment or sufficient handlers are used when installing / manoeuvring.
‰
Handle with care and ensure the load is well balanced.
WARNING! Disconnect the lathe from the mains power and ensure that the chuck is at a complete standstill before attempting to
‰
change accessories, service or perform any maintenance.
WARNING! Before each use check that chuck, cutting tool and tailstock are secure and not worn or damaged. If any part of the lathe
‰
is worn or damaged replace immediately.
WARNING! Keep guard and holding fixings in place, tight and in good working order. Check regularly for damaged parts.
‰
WARNING! Wear approved safety eye protection and, if oil mist is generated, respiratory protection.
‰
WARNING! DO NOT switch on the lathe whilst the cutting tool is in contact with the workpiece. Bring the cutting tool gradually to the
‰
workpiece.
WARNING! DO NOT use the lathe where there are flammable liquids, solids or gases such as petrol, paint solvents, waste wiping rags .
‰
DO NOT use the lathe for a task it is not designed to perform.
8
DO NOT allow untrained persons to operate the lathe.
8
DO NOT get the lathe wet or use in damp or wet locations, or areas where there is condensation.
8
DO NOT operate the lathe if any parts are missing or damaged as this may cause failure and/or personal injury.
8
DO NOT lift or remove the chuck guard whilst the lathe is in use.
8
DO NOT touch the workpiece close to the cut as it will be very hot. Allow it to cool first.
8
DO NOT leave the lathe running unattended.
8
DO NOT operate the lathe when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
Maintain the lathe in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the
9
warranty.
Locate the lathe in a suitable area. Ensure that the mounting surface is flat and firm. Keep the area clean and tidy and free from
9
unrelated materials, and ensure that there is adequate lighting. Allow sufficient space around lathe installation to allow access.
If the lathe is bench mounted fix securely in place using suitable fixings.
9
Keep the lathe clean for best and safest performance.
9
A guard that is damaged or missing must be repaired or replaced before the tool is next used. The safety guard is a mandatory fitting
9
when the lathe is used in premises covered by the Health & Safety at Work Act.
Keep a minimum distance on 1 metre between the operator and the vision panels.
9
Remove adjusting keys and wrenches from the lathe and its vicinity before turning it on.
9
Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and clothing, and contain long hair.
9
© Jack Sealey Limited
METALWORKING LATHE 550MM BETWEEN
CENTRES
MODEL NO:
Wear safety Warning.
gloves Hot surfaces
Original Language Version
SM27.V3
Wear protective Wear Safety
clothing Footwear
Wear ear Warning.
protection Electricity
SM27.V3 Issue 1 9/12/24
