Metalworking mini lathe 250mm & optional drill head

Advertisement

Quick Links

thank you for purchasing a Sealey product. manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Warning:
Warning:
Wear eye
Wear ear
protection
protection
1. Safety
1.1.
electrical Safety
 warning! it is the responsibility of the owner and the operator to read, understand and comply with the following:
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and any other
connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of appropriate safety devices. A
residual current circuit Breaker (rccB) should be incorporated in the main distribution board. We also recommend that a residual current
device (rcd) is used. it is particularly important to use an rcd with portable products that are plugged into a supply which is not protected
by an rccB. if in any doubt consult a qualified electrician. You may obtain a residual current device by contacting your sealey dealer.
you must also read and understand the following instructions concerning electrical safety:
1.1.1.
the electricity at work act 1989 requires all portable electrical appliances, if used on business premises, to be tested by a
qualified electrician, using a Portable Appliance tester (PAt), at least once a year.
1.1.2.
the health & Safety at work act 1974 makes owners of electrical appliances responsible for the safe condition of those
appliances and the safety of the appliance operators. if in any doubt about electrical safety, contact a qualified electrician.
1.1.3.
ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply. see 1.1.1. and 1.1.2.
and use a Portable Appliance tester.
1.1.4.
ensure that cables are always protected against short circuit and overload.
1.1.5.
regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that none are loose.
important: ensure that the voltage marked on the appliance matches the power supply to be used
1.1.6.
and that the plug is fitted with the correct fuse - (see fuse rating right.)
1.1.7.
Do not pull or carry the appliance by the power cable.
1.1.8.
Do not pull the plug from the socket by the cable.
1.1.9.
Do not use worn or damaged cables, plugs or connectors. immediately have any faulty item
repaired or replaced by a qualified electrician. When a Bs 1363/A uK 3 pin plug is damaged, cut
the cable just above the plug and dispose of the plug safely.
fit a new plug according to the following instructions (uK only).
a) Connect the green/yellow earth wire to the earth terminal 'e'.
b) Connect the Brown live wire to the live terminal 'l'.
c) Connect the BlUe neutral wire to the neutral terminal 'n'.
d) after wiring, check that there are no bare wires, that all wires have been correctly
connected, that the cable outer insulation extends beyond the cable restraint and that the
restraint is tight.
double insulated products, which are always marked with this symbol
and neutral (blue) wires only. to rewire, connect the wires as indicated above - Do not connect
either wire to the earth terminal.
1.1.10. Products which require more than 13Amps are supplied without a plug. in this case you must contact a qualified electrician to ensure
that a suitably rated supply is available. We recommend that you discuss the installation of an industrial round pin plug and socket
with your electrician.
1.1.11. if an extension reel is used it should be fully unwound before connection. A reel with an rcd fitted is preferred since any appliance
plugged into it will be protected. the cable core section is important and should be at least 1.5mm², but to be absolutely sure that the
capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we recommend the use
of 2.5mm² section cable.
1.2.
general Safety
 warning! disconnect the lathe and drill head from the mains power and ensure that the chuck or face plate is at a complete standstill
before attempting to change accessories, service or perform any maintenance.
 maintain the lathe and drill head in good condition (use an authorised service agent).
 replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
 locate the lathe and drill head in a suitable area. ensure that the mounting surface is level and firm. Keep the area clean and tidy and free
from unrelated materials, and ensure that there is adequate lighting.
 Keep the lathe and drill head clean for best and safest performance.
 WARNING! Before each use check that face plate/chuck, cutting tool and tailstock are secure and not worn or damaged. If any part of the
lathe or drill head is worn or damaged replace immediately.
© Jack sealey limited
instructions for
metalworking mini lathe 250mm
& optional Drill heaD
Sm2503a & Sm2503B
model no:
Warning:
Warning:
refer to
Wear
instructions
gloves
Original Language Version
Warning:
Warning:
disconnect
electricity,
power before
keep others at
carrying out
a safe distance
maintenance
, are fitted with live (brown)
note: Drill head Sm2503B must be
powered by Sm2503a only. Do not
connect directly to the mains.
reCommenDeD
fUSe rating: 13amp
sm2503A, sm2503B issue:1 - 21/09/15
