Fire Alarm Control Panel
NFS-320/E/C, NFS-320SYS/E
Programming Manual
Document 52746 Rev: H7
7/1/19 ECN: 18-305

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NOTIFIER NFS-320/E/C and is the answer not in the manual?

Questions and answers

Iuga Tialino
June 10, 2025

charger fault fail on NFS 320

0

Related Manuals for Honeywell NOTIFIER NFS-320/E/C

Summary of Contents for Honeywell NOTIFIER NFS-320/E/C

  • Page 1 Fire Alarm Control Panel NFS-320/E/C, NFS-320SYS/E Programming Manual Document 52746 Rev: H7 7/1/19 ECN: 18-305...
  • Page 2 Fire Alarm & Emergency Communication System Limitations While a life safety system may lower insurance rates, it is not a substitute for life and property insurance! An automatic fire alarm system—typically made up of smoke Heat detectors do not sense particles of combustion and alarm detectors, heat detectors, manual pull stations, audible warning only when heat on their sensors increases at a predetermined rate devices, and a fire alarm control panel (FACP) with remote notifica-...

  • Page 3: Installation Precautions

    HARSH™, NIS™, and NOTI•FIRE•NET™ are all trademarks; and Acclimate® Plus™, eVance®, FlashScan®, FAAST Fire Alarm Aspiration Sensing Technology®, Honeywell®, Intelligent FAAST®, NOTIFIER®, ONYX®, ONYXWorks®, SWIFT®, VeriFire®, and VIEW® are all registered trademarks of Honeywell International Inc. Microsoft® and Windows® are registered trademarks of the Microsoft Corporation. Chrome™ and Google™ are trademarks of Google Inc. Firefox® is a registered trademark of The Mozilla Foundation.

  • Page 4: Software Downloads

    Brief description of content you think should be improved or corrected • Your suggestion for how to correct/improve documentation Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. NFS-320 Programming — P/N 52746:H7 7/1/19...

  • Page 5: Table Of Contents

    Table of Contents Section 1: General Information....................8 1.1: UL 864 9th and 10th Edition .........................8 1.1.1: Programming Features Subject to AHJ Approval ................8 1.2: About This Manual ............................8 1.2.1: Cautions, Warning, and Notes......................8 1.2.2: Typographic Conventions........................9 1.2.3: Supplemental Information .........................10 1.2.4: Shortcuts to Operating Functions ......................11 1.3: Introduction to the Control Panel ........................11 1.4: Features................................11...
  • Page 6 Table of Contents A.2.5: Using Type Codes for Releasing Zones ...................69 A.3: Initiating Devices ............................84 A.4: Warning Sounders ............................84 A.5: Auxiliary Control Functions........................84 A.6: ACS Annunciation............................84 Appendix B: Special Zone Outputs..................86 B.1: Presignal and Positive Alarm Sequence (PAS) ...................86 B.1.1: What is Presignal and PAS?......................86 B.1.2: Selecting Presignal and PAS Outputs ....................86 B.2: Time Control Zones.............................87...
  • Page 7 Table of Contents F.4: Type Codes for Input Devices........................106 F.4.1: Overview ............................106 F.4.2: Type Codes for Intelligent Detectors ....................106 F.4.3: Type Codes for Monitor Modules ....................108 F.5: Type Codes for Output Devices .........................109 F.5.1: Overview ............................109 F.5.2: Type Codes for Control Modules....................110 F.5.3: NAC Type Codes ..........................111 Appendix G: Region Settings ....................

  • Page 8: Section 1: General Information

    Section 1: General Information 1.1 UL 864 9th and 10th Edition • Per the UL Continuing Certification Program, UL 864 9th edition fire alarm control equipment will retain certification after the rollout of UL 10th edition (12/2/2018). • Installations of UL 864 10th Edition certified equipment are permitted to use UL864 9th Edition certified equipment when approved by the local Authority Having Jurisdiction (AHJ).

  • Page 9: 2: Typographic Conventions

    About This Manual General Information WARNING: INFORMATION ABOUT PROCEDURES THAT COULD CAUSE IRREVERSIBLE DAMAGE TO THE CONTROL PANEL, IRREVERSIBLE LOSS OF PROGRAMMING DATA OR PERSONAL INJURY. NOTE: Information that highlights an important part of the preceding or subsequent text or illustration. 1.2.2 Typographic Conventions This manual uses the following conventions as listed below: When you see...

  • Page 10: 3: Supplemental Information

    General Information About This Manual 1.2.3 Supplemental Information The table below provides a list of documents referenced in this manual, as well as documents for selected other compatible devices. The document series chart (DOC-NOT) provides the current document revision. A copy of this document is included in every shipment. Document Number Compatible Conventional Devices (Non-addressable) Device Compatibility Document...

  • Page 11: 4: Shortcuts To Operating Functions

    Introduction to the Control Panel General Information 1.2.4 Shortcuts to Operating Functions To the left of each program function, you’ll find a keypad shortcut, which contains a series of keypad entries required to access the program function. All shortcuts start with the control panel in normal operation. For example, the keypad shortcut to the left shows how to enter the Read Status function with the control panel in nor- mal operation.
  • Page 12 General Information How to Enter a Password In Program Change or Status Change, the control panel does the following: • Activates the System Trouble relay • Shuts off the panel sounder • Flashes the LED, which continues to flash while programming SYSTEM TROUBLE For security purposes, passwords can be changed.

  • Page 13: Section 2: Programming

    Overview Programming Section 2: Programming 2.1 Overview Program Change is the programming level that lets you change the essential control panel functions, such as point programming, changing passwords, changing system functions. Included are four options: Basic Program, Network, FlashScan Poll, and Utility Program.

  • Page 14: How To Enter Programming

    Programming How to Enter Programming 2.2 How to Enter Programming To enter Program Change, follow these steps: At the “SYSTEM NORMAL” screen, press the key. The control panel displays the “Entry” screen, as shown below: ENTER 1 = P R O G R A M M I N G 2 = R E A D S T A T U S E N T R Y ( E S C A P E T O A B O R T ) At the “Entry”...

  • Page 15: 1: Clear Memory (0= Clr )

    Basic Program Programming 2.3.1 Clear Memory (0= The Clear option removes all programming information from control panel memory. If installing the control panel for the first time, use option 0 to clear control panel memory. To do so, follow these steps: Program Change Password 1.From the “Basic Program”...
  • Page 16 Programming Basic Program Use the Clear option to clear program information from memory. For instructions on clearing memory, refer to “How to Clear Memory (0= )” on page page 15. NOTE: Once Step 1 is completed, Step 2 will cause the panel to assess whether a loop is comprised of all FlashScan devices or not.
  • Page 17 Basic Program Programming Press the key to add detector 147 to the program with the default program information. If you want to change the default ENTER information, use the programming keys to do so, then press the key to add detector 147 to the program. ENTER The Autoprogram Summary screen appears.
  • Page 18 Programming Basic Program Table 2.1 Autoprogram Defaults (2 of 2) Function Default Values To Alter, refer to PRG PRESIGNAL FUNCT PRESIGNAL DELAY “F0 (Presignal/PAS) The Presignal screen provides fields for DELAY=180 PAS=NO changing the delay time or PAS. For details on Presignal selections, refer to “Presignal and Positive Alarm Sequence (PAS)”...

  • Page 19: 3: Modify Or Delete A Point (2= Point )

    Basic Program Programming 2.3.3 Modify or Delete a Point (2= POINT After programming all SLC-connected devices into the system, you can modify or delete points. From the “Basic Program” screen, press the 2 key to display the Point Programming screen: Program Change P O I N T P R O G .
  • Page 20 Programming Basic Program To select Do the following Refer to an addressable control “Modify an Addressable Control Press module Module Point” on page 23. Type the module (M) and address (001- 159) Press a NAC “Modify NAC Points” on page 24. Press Type the NAC address (01-04) Press...
  • Page 21 Basic Program Programming Table 2.2 Detector Program Values Field Description Set as Follows Alarm The alarm sensitivity level, Refer to Table C.1 on page 95 for settings. Select by placing the cursor in the Sensitivity with 9 the least sensitive field using the arrow keys, then either pressing the keys to NEXT...
  • Page 22 Table 2.3 Modifying Monitor Module Programming Selections Field Description Set as Follows Type Code Monitor Module function Press the Selection keys to scroll through NEXT PREVIOUS specification - in example. valid monitor module Type Code selections. Lists and MONITOR descriptions are in See F.4 on page 106. Custom Label 20 character custom label.
  • Page 23 Modify an Addressable Control Module Point When you select a point address for modification, the control panel returns a screen that displays information about the point. For example, the illustration below shows sample information for a control module (1M101) in the LCD display. Blinking Type Code selection 20-character user-editable custom label P R O G R A M C O N T R O L...
  • Page 24 Table 2.5 Modifying Control Module Programming Selections (2 of 2) Field Description Set as follows: Walk Test Specifies if outputs sound during Walk Type one of the following entries. Test W = devices sound (Basic Walk Test) * = devices do not sound (Silent Walk Test) (default) When finished modifying a point, press the key;...

  • Page 25: 4: Change A Password (3= Passwd )

    Table 2.6 Modifying NAC Programming Selections (2 of 2) Field Description Set as follows: Silenceable Specifies if an operator can manually Type in one of the following values. silence an activated output * = output nonsilenceable F = silenceable, resound by fire alarm U = silenceable, resound by supervisory alarm B = silenceable, resound by security alarm T = silenceable, resound by trouble...

  • Page 26: 5: Create A System Message (4= Message )

    A Forgotten Password? If a password is entered incorrectly, the panel will respond by displaying an message and a code. The INCORRECT PASSWORD programmer may hit escape and reenter the password correctly. However, if the password has been forgotten, record the code and contact Notifier.

  • Page 27: 6: Create A Custom Zone Label (5= Zone )

    2.3.6 Create a Custom Zone Label (5= ZONE The Zone option lets you change the custom label assigned to zones 1-99. From the “Basic Program” screen, press the 5 key to display the “Zone Change” screen as shown below: Program Change Password blinking cursor prompt C H A N G E Z O N E L A B E L...
  • Page 28 Table 2.10 Summary of Special Zones Special Zone Lets you Select a Presignal Delay Timer and select PAS (Positive Alarm PRESIG Sequence) F5-F6= Specify Time Control functions such as the start time, stop time, or TIME days of the week Specify up to nine holiday dates.
  • Page 29 The control panel also provides four Special Zones, F1-F4, which are outputs that do not appear on the Special Function Change screen. You can program Special Zones F1 to F4 into the CBE of an output device. Descriptions of F1, F2, F3, and F4 are detailed below: To view the status of Special Functions F1-F4, use the Read Status function (refer to the NFS-320 Operations Manual).
  • Page 30 F5-F6 (Time Control Functions) The Time Control screen provides fields for changing the start time, stop time, or days of the week. For details on time selections, refer to “Time Control Zones” on page 87. From the Special Function Change screen, select F5 or F6 to display the Time Control screen: Time Control programming status banner P R G T I M E F U N C T I O N...

  • Page 31: 8: Change Global System Functions (7= System )

    NOTE: During local or network Walk Test, activating a Mass Notification device will activate associated special function zones according to CBE programming and simulate a Mass Notification event. Any network nodes, zones, or devices not participating in Walk Test will not participate in the simulated Mass Notification event. ACTION or ALERT Pre-Alarm level: press the NEXT PREVIOUS...
  • Page 32 Table 2.12 Settings for Global Systems Functions (2 of 2) Defau System Function Setting LocX - One of three operating modes of PC or LocT -(terminal connected to control panel and located in LocT terminal connected to the control panel through same room).

  • Page 33: Annunciator Options

    Annunciator Options NOTE: An ACM-24AT or AEM-24AT LED point must be programmed as a dedicated visual indicator for a mass notification or CO event. This is not required for displayless systems. Use Annunciator Selection screens to select information that will display on the ACS annunciators. (Table 2.13 on page 34 contains the ACS display selections.) Setting from the “System Function”...
  • Page 34 Annunciation Points The control panel’s annunciation points are divided into 23 ACS selection groups of 64 points each. The table below contains a list of these groups, what an annunciator displays when a group is selected, and where to locate a definition of the 64 points within the group.
  • Page 35 Table 2.13 ACS Selection Groups (2 of 2) ACS Selection Group Annunciator Display Refer to Programmable Annunciator #10 See Note NOTE: Refer to the VeriFire™ Tools programming utility for programming these annunciators. ACS Selection Group A: Table 2.14 ACS Group A Point Type Red LED...
  • Page 36 ACS Selection Group B: Table 2.15 ACS Group B Point Type Red LED Yellow LED Switch Function* Input Zone 57 Active Zone 57 Trouble Not Used Input Zone 58 Active Zone 58 Trouble Not Used Input Zone 59 Active Zone 59 Trouble Not Used to (see note 1) to (see note 1)
  • Page 37 NOTE: Point number to Module number relationship is sequential; therefore, point 48 is Module 048. NFS-320 Programming — P/N 52746:H7 7/1/19...
  • Page 38 ACS Selection Group E (SLC #1, Modules 65-128): Table 2.17 ACS Group E Point Type Red LED Yellow LED Switch Function Input or Output Module 065 Active Module 065 Trouble Controls Output Module Input or Output Module 066 Active Module 066 Trouble Controls Output Module Input or Output...
  • Page 39 Table 2.19 ACS Group H (2 of 2) Point Type Red LED Yellow LED Switch Function* * Pressing the switch button when the Switch Function is “Not Used” will cause the associated LED to stop blinking. This is a local acknowledgement at the annunciator only: no message is sent to the panel.

  • Page 40: Panel Programming

    To use ACS for controlling the FirstCommand/FireVoice, install by programming Annunciator A1 as Group M through panel or VeriFire Tools programming. Refer to the FireVoice manual to properly configure the FACP. VeriFire Tools Programming  Annunciator programming must be performed as follows: •...
  • Page 41 ACS Selection Group P (SLC #1, Modules 65-100 and Detectors 1-14): Point Type Red LED Yellow LED Switch Function Input SLC 1, Module 65 Alarm SLC 1, Module 65 Trouble Not Used Input SLC 1, Module 66 Alarm SLC 1, Module 66 Trouble Not Used Input SLC 1, Module 67 Alarm...
  • Page 42 ACS Selection Group R (SLC #1, Detectors 15-46): Point Type Red LED Yellow LED Switch Function Input Detector 015 Alarm Detector 015 Trouble Not Used Input Detector 015 Trouble Detector 015 Trouble Not Used Maintenance Urgent Maintenance Alert Input Detector 016 Alarm Detector 016 Trouble Not Used Input...

  • Page 43: 9: How To Check The Program For Errors

    ACS Selection Group V (SLC #1, Detectors 79-100): Point Type Red LED Yellow LED Switch Function Input Detector 079 Alarm Detector 079 Trouble Not Used Input Detector 079 Trouble Detector 079 Trouble Not Used Maintenance Urgent Maintenance Alert Input Detector 080 Alarm Detector 080 Trouble Not Used Input...

  • Page 44: The Network Program

    2.4 The Network Program From the “Program Change Selection” screen, press the 2 key to display the “Network” screen, which displays as follows: Program Change T H R E S H O L D C H . A : H , T H R E S H O L D C H .
  • Page 45 Table 2.27 Utility Program Options (2 of 2) Utility Option Description TBL.REMIND This option provides trouble reannunciation selections to meet the requirements of NFPA 72- TBL Reminder* 2002, which you can select as follows: • Select * if you don’t want a trouble reminder •...

  • Page 46: Flashscan Poll

    2.6 FlashScan Poll From the “Program Change Selection” screen, press the 4 key to access the “FlashScan Poll” selection screen as shown below: Program Change Password F L A S H S C A N L 1 D E T L 1 M O D This menu allows the selection of CLIP (Classic Loop Interface Protocol) or FlashScan detectors and modules for the loop.

  • Page 47: Setting The Baud Rate Of Serial Ports

    2.7 Setting the Baud Rate of Serial Ports 2.7.1 Printer Serial Port The default baud rate of the EIA-232 Printer connection (serial printer port) is 9600. To change baud rate to 2400 or 4800, follow these steps: From the “SYSTEM NORMAL” screen, press the key to display the Program Entry screen, as shown below: ENTER 1 = P R O G R A M M I N G...
  • Page 48 NFS-320 Programming — P/N 52746:H7 7/1/19...
  • Page 49 NFS-320 Programming — P/N 52746:H7 7/1/19...

  • Page 50: Section 3: Status Change

    Status Change Overview Section 3: Status Change 3.1 Overview Status Change provides a second programming level - accessed by an assigned password - for changing operating parameters. (These operating parameters do not affect control program settings.) For example, the Status Change password lets you change settings such as detector sensitivity and system time and date.

  • Page 51: Disable Or Enable A Point

    3.3 Disable or Enable a Point WARNING: Do not rely on disable/enable software settings to lock out releasing devices. Releasing devices must be physically disconnected. NOTE: When an input or output point associated with releasing functions is disabled, a single supervisory trouble will be generated.

  • Page 52: Changing Detector Sensitivity

    Table 3.1 Changing the Status Banner (2 of 2) Press Go to the next or previous point address (Next Selection) or (Previous Selection) 3.4 Changing Detector Sensitivity The Detector Sensitivity option lets you change the Alarm and Pre-Alarm (sensitivity) level for an installed detector.

  • Page 53: Clearing Alarm Verification Counters

    3.5 Clearing Alarm Verification Counters The Clear Verification screen lets you clear all counters for detectors selected for Alarm Verification. From the “Status Change Selection” screen, press the 3 key to display the “Clear Verification” screen as shown below: Status Change P R E S S E N T E R T O C L E A R V E R I F I C A T I O N C O U N T S Password O R E S C A P E T O A B O R T...

  • Page 54: 1: Basic Walk Test

    Before entering Walk Test, note the following: • For each individual activation, the control panel sends “TEST Axx”(for alarm testing) or TEST Txx (for trouble testing) to the History buffer, installed printers and CRT-2s so results can be reviewed. • Basic Walk Test, Silent –...

  • Page 55: 2: Advanced Walk Test

    From the “Status Change Selection” screen, press the 6 key. The control panel displays the “Walk Test” screen as shown below: Status Change W A L K T E S T P R E S S E N T E R T O S T A R T Password E S C A P E T O A B O R T Operate the control panel in Walk Test as follows...

  • Page 56: 3: Walk Test Activation Indications

    • alarm and trouble messages are sent to the printer, not test messages. (These Walk Test messages can be distinguished from others at the printer because they begin with the trouble message generated when Walk Test is entered, and end with the cleared trouble when Walk Test is exited.) •...

  • Page 57: Appendix A: Releasing Applications

    Overview Releasing Applications Appendix A: Releasing Applications WARNING: When used for CO releasing applications, observe proper precautions as stated in NFPA 12. Do not enter the protected space unless physical lockout and other safety procedures are fully completed. Do not use software disable functions in the panel as lockout. Do not enable the BACKUP option switch for any of the four Notification Appliance Circuits (NACs) if they are used for releasing functions.

  • Page 58: A.1.2: Nfpa Releasing Applications

    Releasing Applications How to Program a Releasing Zone A.1.2 NFPA Releasing Applications This control panel can be used for agent release or preaction/deluge control applications. In a properly configured system with compatible, listed actuating and initiating devices, this control panel complies with the following NFPA standards for installation in accordance with the acceptable standard: Table A.2 NFPA Standards for Releasing Applications Standard...

  • Page 59: A.2.2: Abort Switches

    How to Program a Releasing Zone Releasing Applications A.2.2 Abort Switches Definition of Abort Switches The control panel provides for four (4) types of Abort Switches (ULI, IRI, NYC, and AHJ) that you can use, that will affect the operation of a Delay Timer mapped to the same Releasing Zone. For example, an Abort Switch selected for Releasing Zone R05 only affects the Delay Timer selected for R05.
  • Page 60 Releasing Applications How to Program a Releasing Zone When an initiating device activates, you must press and hold the Abort Switch or the control panel will send the command to dump releasing agents when the Delay time (15 seconds shown) expires. The Abort selection (ULI, IRI, NYC, or AHJ) determines the function of the Abort Switch.

  • Page 61: How To Program

    How to Program a Releasing Zone Releasing Applications Programming a ULI Abort Switch The following contains information needed to program a ULI Abort Switch. Description  Requires a standard UL-type delay timer that complies with UL Standard 864. How to Program ...
  • Page 62 Releasing Applications How to Program a Releasing Zone Programming an IRI Abort Switch The following contains information needed to program an IRI Abort Switch. Description  A standard UL-type delay timer (complies with UL Standard 864) that operates like ULI, but with additional functions for Cross Zones.
  • Page 63 How to Program a Releasing Zone Releasing Applications Programming a NYC Abort Switch The following contains information needed to program an NYC Abort Switch. Description  A standard NYC delay timer that adds 90 seconds to the programmed Delay Timer. NOTE: NYC timers do not comply with UL Standard 864.
  • Page 64 Releasing Applications How to Program a Releasing Zone Example 1 - Delay Time Does Not Exceed 120 Seconds  Select a Delay Timer value for R05 of 15 seconds. The Releasing Zone activates and the 15-second Delay Timer starts. Ten seconds into the Delay Timer countdown, press and hold the Abort Switch for 30 seconds, then release the Abort Switch.

  • Page 65: Example 2 - Delay Time Exceeds 120 Seconds

    How to Program a Releasing Zone Releasing Applications Example 2 - Delay Time Exceeds 120 Seconds  Select a Delay Timer value for R05 of 60 seconds. The Releasing Zone activates and the 60-second Delay Timer starts. Ten seconds into the Delay Timer countdown, press and hold the Abort Switch for 30 seconds, then release the Abort Switch. The control panel restarts the Delay Timer at 60 seconds and adds the NYC delay of 90 seconds.
  • Page 66 Releasing Applications How to Program a Releasing Zone How It Works  When an alarm initiates, the programmed Delay Timer starts. Press and hold the Abort switch and the control panel suspends the Delay Timer. When you release the Abort Switch, the control panel restores the value of the programmed Delay Timer and the Delay Timer counts down.

  • Page 67: Purpose Of Cross Zones

    How to Program a Releasing Zone Releasing Applications A.2.3 Using Cross Zones Purpose of Cross Zones Using Cross Zones lets you program the control panel to activate a Releasing Zone and any output mapped to the Releasing Zone only after a predetermined sequence of events occurs. (If not using Cross Zones, set CROSS= N.) NOTE: Only the first Software Zone (Z01-Z99) listed in the zone map is used to determine Cross=Z.
  • Page 68 Software Zone Z01 CBE list = Z02 ZR1 Smoke Heat Smoke Smoke Software Detector Detector Detector Detector Zone Z02 2D104 2D103 2D102 2D101 CBE list = Z01 ZR1 CBE list = Z01 ZR1 Releasing Zone ZR1 CBE list = ZR1 Figure A.9 Illustrated Example of Cross Zone Programming A listing of each Cross Zone option and the conditions required to activate the Releasing Zone, according to the example shown above.

  • Page 69: A.2.4: Programming A Soak Timer

    Press at this point to save the Cross Zone value if no other fields on the screen are changing. To change another field on the screen, move the cursor into position by pressing the arrow keys on the keypad. A.2.4 Programming a Soak Timer The Soak Timer specifies the length of time (0001 to 9999 seconds, or 0000 for not used) to dump releasing agents when a Releasing Zone activates.
  • Page 70 Type Codes designed for Releasing Zone outputs (control modules and panel NACs). Type Code What the Type Code does Refer to Activates a NAC audio or visual device “ ” on page 76 REL END BELL RELEASE END BELL when releasing circuits shut off. Directs outputs to perform a release “...
  • Page 71 Example  A programming example of a monitor module programmed as an Abort Switch for Releasing Zone R5. SYSTEM SYSTEM NORMAL ACTIVATED Monitor Detector Module Type Code ABORT SWITCH NBG-12LRA station with Abort Switch Control Module Figure A.10 Monitor Module Configured as an Abort Switch NFS-320 Programming —...
  • Page 72 Type Code RELEASE The following contains information needed to program a Manual Release switch for a monitor module Description  A monitor module—connected to a UL-listed manual station (such as the Notifier NBG-12LRA)—used to manually release agents. A Manual Release switch overrides all timers, such as a Delay Timer or a Soak Timer. You can install multiple monitor modules with a Type Code that work like multiple conventional manual release switches on a conventional zone.
  • Page 73 Type Code MANREL DELAY The following contains information needed to program a Manual Release Delay switch for a monitor module using the MANREL Type Code. DELAY Description  A monitor module—connected to a UL-listed manual station (such as the Notifier NBG-12LRA)—used to initiate a manual release with 30-second delay time.
  • Page 74 Examples  A programming example of a monitor module programmed for switch for Releasing Zone R5. MANREL DELAY SYSTEM SYSTEM NORMAL ACTIVATED Monitor Detector Module Type Code NBG-12LRA MANREL DELAY station with Manual Release Lever Control Module Figure A.12 Monitor Module Configured as a Manual Release Delay Switch For examples 1, 2, and 3, program Releasing Zone R5 with a Manual Release Delay switch and the following releasing selections: P R G R E L E A S E F U N C T I O N R E L E A S E C O N T R O L D E L A Y = 6 0 A B O R T = U L I C R O S S = N S O K = 0 0 3 0 R 0 5...
  • Page 75 Type Code SECOND SHOT NOTE: The Second Shot switch can only be used with the Type Code. MANREL DELAY The following contains information needed to program a Second Shot switch for a monitor module Description  A monitor module—connected to a UL-listed manual station (such as the NBG-12LRA)—used as for a second release of agents. A Second Shot switch overrides a Delay Timer, programmed to the same Releasing Zone.
  • Page 76 RELEASE END BELL NOTE: A releasing circuit with this Type Code requires the following selections: A Releasing Zone selection (R0-R9); An output circuit mapped to the same Releasing Zone; Switch Inhibit selected; Non-Silenceable; No Walk Test. The following contains information needed to program a Release End Bell circuit for a control module or a NAC Description ...
  • Page 77 Type Code REL CKT ULC NOTE: A ULC Release Circuit with this Type Code requires the following selections: A Releasing Zone selection (R0-R9); An output circuit mapped to the same Releasing Zone; Switch Inhibit selected; Non-Silenceable; No Walk Test. The following contains information needed to program a ULC Release Circuit for a control module or a NAC Description ...
  • Page 78 Type Code RELEASE CKT NOTE: A Release Circuit with this Type Code requires the following selections: A Releasing Zone selection (R0-R9); An output circuit mapped to the same Releasing Zone; Switch Inhibit selected; Non-Silenceable; No Walk Test. NOTE: Do not use a Release Circuit for the following: An application requiring ULC Listing; An application requiring power-limited energy cable.
  • Page 79 Example  A programming example of a control module programmed as a Release Circuit for Releasing Zone R5. Monitor Detector Detector Detector Module Type Code Type Code RELEASE CKT RELEASE CKT Control Control Module Module For example, all control modules programmed with the RELEASE Type Code activate simultaneously with other outputs programmed for R5 (B01, B02).
  • Page 80 Relea. Form-C Type Code NOTE: An output with a relea.form c Type Code requires the following selections: A Releasing Zone selection (R0-R9); An output circuit mapped to the same Releasing Zone; Switch Inhibit selected; Non-Silenceable; No Walk Test. The following contains information needed to program a Release Form-C circuit for an output circuit Description ...
  • Page 81 Type Code REL AUDIBLE NOTE: An output with a Type Code requires the following selections: A Releasing REL AUDIBLE Zone selection (R0-R9); An output circuit mapped to the same Releasing Zone; Switch Inhibit selected. The following contains information needed to program a Release Audible circuit for an output circuit (control module or NAC) Description ...
  • Page 82 Type Code INSTANT RELE NOTE: An output with an Type Code requires the following selections: a zone INSTANT RELE selection (a releasing zone may be used, but is not required); an output circuit mapped to the same zone; Switch Inhibit selected; Non-Silenceable; No Walk Test. The following contains information needed to program an Instant Release circuit for an output circuit (control module or NAC) Description ...
  • Page 83 Type Code REL CODE BELL NOTE: An output with a Type Code requires the following selections: A REL CODE BELL Releasing Zone selection (R0-R9); An input circuit mapped to the same Releasing Zone. NOTE: For instructions on programming Switch Inhibit, Silenceable, and Walk Test, refer to “Modify NAC Points”...

  • Page 84: A.3: Initiating Devices

    A.3 Initiating Devices Releasing zone initiating devices include the following: • FST-851 intelligent heat detectors • FSI-851, FSP-851, FAPT-851, FSL-751 intelligent smoke detectors • Conventional detection UL-listed devices connected to monitor modules Refer to the SLC manual for the most up-to-date information about initiating devices. You can use multiple initiating devices for the same releasing hazard.
  • Page 85 To Annunciate Do this Individual detectors Select ACS Selection Group H, I, J, K or L. For instructions, refer to “Annunciator Options” on page 33. NFS-320 Programming — P/N 52746:H7 7/1/19...

  • Page 86: Appendix B: Special Zone Outputs

    Special Zone Outputs Presignal and Positive Alarm Sequence (PAS) Appendix B: Special Zone Outputs B.1 Presignal and Positive Alarm Sequence (PAS) B.1.1 What is Presignal and PAS? Purpose Presignal is a feature that initially causes alarm signals to only sound in specific areas, monitored by qualified persons. This allows delay of the alarm up to 180 seconds after the start of alarm processing.

  • Page 87: Positive Alarm Sequence (Pas)

    Positive Alarm Sequence (PAS) Outputs selected for PAS delay for 15 seconds. Pressing the key within the 15-second delay will ACKNOWLEDGE SCROLL DISPLAY set the Presignal Delay Timer to the full programmed value (60-180 seconds, including the PAS delay of 15 seconds). When an alarm comes from an initiating device with a CBE list that includes F0, the control panel delays the following outputs: •...
  • Page 88 Table B.1 Coding Function Selections Coding Function Signal Selection Two-Stage Canada 5 Alert Signal - 20 PPM; Drill Switch activated, 5 minute timer has expired, or device’s CBE Zone activation (Z00 plus Zones 1-99 or Logic Zones 1-20) - Temporal (5 min. timeout) NOTE: In Canadian applications ACM-24AT control point is required for Automatic Alarm Signal Cancel.

  • Page 89: Appendix C: Intelligent Sensing Applications

    Overview Intelligent Sensing Applications Appendix C: Intelligent Sensing Applications C.1 Overview “Intelligent Sensing” is a set of software algorithms that provide the NFS-320 with industry-leading smoke detection capability. You can program Intelligent Sensing functions on a global or on a per-detector basis. Intelligent Sensing topics covered in this appendix: Topic Page...

  • Page 90: C.2.2: Maintenance Warnings - Three Levels

    Intelligent Sensing Applications Features A graphic representation of a detector analog reading using drift compensation and smoothing: Alarm Level without compensation Analog with compensation and Reading smoothing Time Figure C.1 Graphic Representation of Drift Compensation C.2.2 Maintenance Warnings – Three Levels The software determines when the drift compensation for a detector reaches an unacceptable level that can compromise detector performance.

  • Page 91: C.2.3: Self-Optimizing Pre-Alarm

    Features Intelligent Sensing Applications C.2.3 Self-Optimizing Pre-Alarm You can set each detector, except FST-751 (Heat), for Self-Optimizing Pre-Alarm (PA=1). In this Self-Optimizing mode, the software measures the normal peak analog readings and sets the Pre-Alarm level just above these normal peaks. This allows extremely sensitive Pre-Alarm capability with reasonable protection against non-fire signals.

  • Page 92: C.2.5: Cooperative Multi-Detector Sensing

    Intelligent Sensing Applications Features C.2.5 Cooperative Multi-Detector Sensing Cooperative Multi-Detector Sensing is the ability of a smoke detector to consider readings from nearby detectors in making alarm or pre-alarm decisions. Each detector can include up to two other detectors in its decision. Without statistical sacrifice in the ability to resist false alarms, Cooperative Multi-Detector Sensing allows a detector to increase its sensitivity to actual smoke by a factor of almost 2 to 1.

  • Page 93: C.3: Pre-Alarm

    Pre-Alarm Intelligent Sensing Applications C.3 Pre-Alarm C.3.1 Definition The Pre-Alarm function is a programmable option which determines the system’s response to real-time detector sensing values above the programmed setting. Use the Pre-Alarm function if you want to get an early warning of incipient or potential fire conditions.

  • Page 94: C.3.4: How To Select A Pre-Alarm Level

    Intelligent Sensing Applications Pre-Alarm • The Action message is sent to the History buffer and to any installed FDU-80s and printers. The message is sent (and time stamped) only at the time that it first occurred. This historical data could provide valuable information about the progress of a fire.

  • Page 95: C.4: Detector Sensitivity Settings

    Detector Sensitivity Settings Intelligent Sensing Applications C.4 Detector Sensitivity Settings C.4.1 How to Select Pre-Alarm and Alarm Sensitivity Each detector provides a host of selectable intelligent options. The control panel provides nine levels of Pre-Alarm (PA:1–PA:9) and Alarm (AL:1–AL:9) in percent per foot obscuration: •...

  • Page 96: C.4.2: How To Test Detectors Set Below 0.50% Obscuration Per Foot

    Intelligent Sensing Applications Detector Sensitivity Settings Detector Type Alarm (FlashScan) Alarm (CLIP) Pre-Alarm ‡‡‡ FSC-851 IntelliQuad Detector AL:1=1% PA:1=1% AL:2=2% PA:2=1% AL:3=3% PA:3=2% **** AL:4=3% w/ 10 minute confirmation PA:4=3% AL:5=4% w/ 10 minute confirmation PA:5=3% w/ 10 minute confirmation AL:6=Thermal 135 PA:6=4% w/ 10 minute confirmation AL:7=Thermal 135...

  • Page 97: C.5: Detector Maintenance Features

    Detector Maintenance Features Intelligent Sensing Applications C.5 Detector Maintenance Features C.5.1 Overview The NFS-320 provides features to check the maintenance performance level of addressable, intelligent detectors. Detector maintenance features include the following: • View detector maintenance information for an individual detector •...

  • Page 98: C.5.4: Print A Detector Maintenance Report

    Intelligent Sensing Applications Detector Maintenance Features C.5.4 Print a Detector Maintenance Report A Detector Maintenance Report lists detector maintenance status for each installed addressable detector [except FDX-551 (an analog heat detector)]. When you press and enter the P key the control panel sends a Detector Maintenance Report (Figure C.8) to the printer connected to the control panel.
  • Page 99 Detector Maintenance Features Intelligent Sensing Applications Multi-Detector Selection (*) A smoke detector programmed so that it evaluates readings from nearby detectors in making Alarm or Pre-Alarm decisions. Cooperative Multi-Detector sensing also allows the combination of ionization with photoelectric technology in reaching an alarm decision. See “Modify an Addressable Detector Point” on page 20 for instructions on setting Cooperative Multi-Detector Settings.

  • Page 100: Appendix D: Cbe (Control-By-Event)

    CBE (Control-By-Event) Description Appendix D: CBE (Control-By-Event) D.1 Description CBE (Control-By-Event) is a software function that provides a means to program a variety of output responses based on various initiating events. The control panel operates Control-By-Event (CBE) through 99 Software Zones with the following features: •...

  • Page 101: D.4.1: Logic Functions

    Equation Entry CBE (Control-By-Event) D.4.1 Logic Functions The “AND” Operator Requires that each argument be in alarm. Example: AND(Z02,Z05,Z09) All three arguments in the equation must be in alarm for the output point to be activated The “OR” Operator Requires that any argument be in alarm Example: OR(Z02,Z05,Z09) If any one of the three arguments in the equation is in alarm the output point will be activated.

  • Page 102: The "Del" Operator

    CBE (Control-By-Event) Equation Entry Equation begins with a logic or time delay function - OR 67 Characters (maximum of 73) - includes parentheses and commas. 5 Logic Functions (maximum of 10) - OR, AND, AND, NOT and ANY2. 8 Arguments (maximum of 20 per logic function) - L1D1,L1D4,L1D6,L1M3,L1M4..The equation contains no spaces.

  • Page 103: D.5: Cbe Example

    CBE Example CBE (Control-By-Event) • If no duration is specified, then the device will not be deactivated until a reset occurs or the internal equation evaluates false. The “SDEL” Operator A latched version of the DEL operator. Once the equation evaluates true, it remains activated until a reset, even if the internal equation (ZE5) becomes false.

  • Page 104: Appendix E: Detector Initialization

    Detector Initialization Overview Appendix E: Detector Initialization E.1 Overview The control panel automatically performs a detector initialization routine when you add or change a detector, unless the control panel is in Walk Test or Advanced Walk Test. If you change a detector with the control panel in Walk Test or Advanced Walk Test, you must manually initialize the detector as detailed in “How to Manually Initialize a Detector”...

  • Page 105: E.4: How To Manually Initialize A Detector

    How to Manually Initialize a Detector Detector Initialization E.4 How to Manually Initialize a Detector You only need to manually initialize a detector when you change a detector during Walk Test or Advanced Walk Test. If, however, you replace a detector with a different type of detector, you must immediately program the new detector according to the instructions in “How to Replace a Detector”...

  • Page 106: Appendix F: Type Codes

    Type Codes What are Type Codes? Appendix F: Type Codes F.1 What are Type Codes? Type Codes are software selections for initiating devices (detectors and monitor modules) and output devices (control modules and NACs). Some Type Codes are self-explanatory; that is, the Type Code matches the function of the device, such as a “Monitor” for a monitor module, “Photo”...
  • Page 107 Type Codes for Input Devices Type Codes SUP.L(DUCTP) supervisory lights supervisory LED Photoelectric smoke detector used as a duct detector to report supervisory condition rather than alarm. Latching. SUP.T(PHOTO) supervisory lights supervisory LED Photoelectric smoke detector used to report supervisory condition rather than alarm.

  • Page 108: F.4.3: Type Codes For Monitor Modules

    Type Codes Type Codes for Input Devices AIR REF fire alarm lights fire alarm LED and activates CBE Assign to one or more FSL-751 detectors used to monitor the quality of air entering the protected area. The air quality measurement allows the VIEW® system to compensate for vehicle fumes, fog, or other particles brought into the protected area through the ventilation system.

  • Page 109: F.5: Type Codes For Output Devices

    Type Codes for Output Devices Type Codes ACCESS MONTR non-alarm Activates CBE Used for monitoring building access AREA MONITOR security Lights security LED and activates CBE Monitors building access AUDIO SYSTEM trouble Lights trouble LED Not used EQUIP MONITR security Activates CBE Used for recording access to monitored equipment RF SUPERVSRY...

  • Page 110: F.5.2: Type Codes For Control Modules

    Type Codes Type Codes for Output Devices F.5.2 Type Codes for Control Modules A comprehensive list of control module Type Codes, which you can select to change the function of an control module point. Type Code Silenceable (Y/N) Configuration Device Function CONTROL Supervised NAC for notification appliance RELAY...

  • Page 111: F.5.3: Nac Type Codes

    Type Codes for Output Devices Type Codes F.5.3 NAC Type Codes A comprehensive list of Type Codes for panel NACs. For instructions on programming Type Codes, refer to “Modify or Delete a Point (2= )” on page 19. POINT Table F.1 NAC Type Codes Silenceable Type Code Device Function...

  • Page 112: Appendix G: Region Settings

    Region Settings China Appendix G: Region Settings G.1 China The REGION panel programming selection provides a setting for China. (Refer to “The Utility Program” on page 44.) This selection activates the following features: • POM-8A support • Active output events displayed. A counter is displayed for active outputs. •...

  • Page 113: G.2.5: Annunciator Applications

    Canada Region Settings – An ACS point is required to monitor special function zone ZF40. – Activation of Auto Silence will activate the Signal Silence LED on the fire panel display and any ACM LED point programmed for Auto Silence. G.2.5 Annunciator Applications ACM series annunciator modules must be used to annunciate the fire alarm input points/zones only, if no multi-line sequential display is installed.

  • Page 114: Appendix H: Intelligent Sounder Base Programming And Operation

    Intelligent Sounder Base Programming and Operation Appendix H: Intelligent Sounder Base Programming and Operation The NFS-320 is compatible with the B200S Intelligent Sounder Base. The sounder base allows for multiple tone generation that is user programmable via VeriFire™ Tools. Programming the Intelligent Sounder Base into the Control Panel: Once the intelligent sounder base has been installed and a detector has been plugged into the sounder base, you can do one of the following to program the intelligent sounder base into the control panel: •...

  • Page 115: Index

    Index Do not program detectors as CLIP... 46 Do not program more than 99 CLIP... 46 Abort Switch 28 – CBE (Control-By-Event) 100 basic configuration example 60 example 103 configuration example with monitor mod- CBE list 20 ule 71 Check option (program errors) 43 Definition 59 Class A network setting 44 how it works 59...
  • Page 116 E–P Index Equations Labels 20 Argument Entries 102 note about spaces 20 Evaluating 102 Local Control 45 logic and time delay 100 LocM operating mode 32 Logic Functions 101 LocT operating mode 32 rules 100 Logic Functions 101 Time Delay Functions 102 Maintenance Warnings 90 FAAST 10 Manual Release Delay Switch...
  • Page 117 Index R–W to select a level 94 to select sensitivity 95 Temporal Code 28 Pre-Alarm, special zone 18 Terminal mode supervision enable 31 Presignal Delay Timer/PAS 18 Threshold Ch.A/B 44 – Program Change 13 Time Program Errors, check for 43 to set time/date for system clock 50 USA or European 31 Time control, special zones 18...
  • Page 118 Z–Z Index Physically disconnect all releasing devices ..54 The IRI abort switch will only work if..Walk Test mode can deactivate fire protec- tion... 54 When used for CO2 releasing applica- tions... 57 Warning Sounders, releasing applications 84 Wheelock Strobes 28 Wheelock Strobes, special zone 88 Zones Custom label 14...

  • Page 119: Manufacturer Warranties And Limitation Of Liability

    Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan.
  • Page 120 World Headquarters 12 Clintonville Road Northford, CT 06472-1610 USA 203-484-7161 fax 203-484-7118 www.notifier.com...

This manual is also suitable for:

Notifier nfs-320sys/e

Table of Contents

Save PDF
