- Page 1 Neousys Technology Inc. PCIe-PoE572bt/ PCIe-N572 Series User Manual Revision 1.0...
-
Page 2: Table Of Contents
Table of Contents Table of Contents Table of Contents ........................2 Legal Information ........................3 Contact Information ....................... 4 Notices ............................ 5 Safety Precautions ......................... 6 Service and Maintenance ...................... 7 ESD Precautions ........................7 About This Manual ......................... 8 Introduction PCIe-PoE572bt Specifications ................. -
Page 3: Legal Information
Legal Information Legal Information All Neousys Technology Inc. products shall be subject to the latest Standard Warranty Policy. Neousys Technology Inc. may modify, update or upgrade the software, firmware or any accompanying user documentation without prior notice. Neousys Technology Inc. will provide access to these new software, firmware or documentation releases from download sections of our website or through our service partners. -
Page 4: Contact Information
Website Americas Neousys Technology America, Inc. 55 East Hintz Rd Wheeling, IL 60090, USA (Illinois, USA) Tel: +1-847-656-3298 Email, Website China Shanghai Neousys Technology Co., Ltd. Room 429, Building 33, Guiping Road 680, Shanghai 200233, China Tel: +86-2161155366 Email, Website... -
Page 5: Notices
Disclaimer to change without prior notice. It does not represent commitment from Neousys Technology Inc. Neousys Technology Inc. shall not be liable for any direct, indirect, special, incidental, or consequential damages arising from the use of the product or documentation, nor for any infringement on third party rights. -
Page 6: Safety Precautions
Safety Precautions Safety Precautions Read these instructions carefully before you install, operate, or transport the system. ⚫ Install the system or DIN rail associated with, at a sturdy location ⚫ Install the power socket outlet near the system where it is easily accessible ⚫... -
Page 7: Service And Maintenance
Service and Maintenance Service and Maintenance ⚫ ONLY qualified personnel should service the system ⚫ Shutdown the system, disconnect the power cord and all other connections before servicing the system ⚫ When replacing/ installing additional components (expansion card, memory module, etc.), insert them as gently as possible while assuring proper connector engagement ESD Precautions ⚫... -
Page 8: About This Manual
About This Manual About This Manual This manual introduces and describes how to setup/ install Neousys Technology PCIe-PoE527bt and PCIe-N572 10Gb frame grabber cards. The cards offer stable expandability, flexibility and fast Ethernet access to peripheral devices. Revision History Version... -
Page 9: Introduction
PCIe-PoE572bt/ PCIe-N572 Series Introduction The PCIe-PoE572bt is a rugged, wide-temperature dual-port 10G network adapter equipped with Remote Direct Memory Access (RDMA) and IEEE 802.3bt PoE++ support. Powered by the Broadcom® BCM57416 Ethernet controller, it supports jumbo frames up to 9.6 KB, making it ideal for applications such as RDMA-enabled cameras and outdoor Wi-Fi access points (APs). -
Page 10: Pcie-Poe572Bt Specifications
PCIe-PoE572bt/ PCIe-N572 Series PCIe-PoE572bt Specifications Product Model PCIe-PoE572bt Bus Interface x4, Gen3 PCI Express 2x 10 GbE ports by Broadcom 57416 controller, # of 10 GbE Port supporting 9.6 KB jumbo frame Network Protocol IEEE 802.3 Ethernet interface for 10GBASE-T (IEEE 802.3an) and Support 1000BASE-T (IEEE 802.3ab) Support Link Speed... -
Page 11: Pcie-N572 Specifications
PCIe-PoE572bt/ PCIe-N572 Series PCIe-N572 Specifications Product Model PCIe-N572 Bus Interface x4, Gen3 PCI Express 2x 10 GbE ports by Broadcom 57416 controller, # of 10 GbE Port supporting 9.6 KB jumbo frame Network Protocol IEEE 802.3 Ethernet interface for 10GBASE-T (IEEE 802.3an) and Support 1000BASE-T (IEEE 802.3ab) Support Link Speed... -
Page 12: Dimension
PCIe-PoE572bt/ PCIe-N572 Series Dimension NOTE The cards share the same dimensions, therefore PCIe-PoE572bt will be shown here for demonstration purposes. All measurements are in millimeters (mm). -
Page 13: Setting Up Your Card
Unpacking Your PCIe-PoE572bt Upon receiving the PCIe-PoE572bt package, please check immediately if the package contains all the items listed in the following table. If any item is missing or damaged, please contact your local dealer or Neousys Technology. Item Description... -
Page 14: Status Leds
PCIe-PoE572bt/ PCIe-N572 Series Status LEDs Speed LED (1) LED Color Status Description Green 10000 Mbps Green or Orange 1000 Mbps orange Not connected Active/Link LED (2) LED Color Status Description Ethernet port is disconnected Green Ethernet port is connected and no data transmission Flashing Ethernet port is connected and data is transmitting/ receiving... -
Page 15: Dip Switches
PCIe-PoE572bt/ PCIe-N572 Series DIP Switches PCIe-PoE572bt features individual per-port power on/off control via Neousys’ API so you may manually cut off or resume the power delivery to the connected PoE device. This feature is designed for failure recovery in the field to reset connected devices. In case you have installed multiple cards, there is a set of DIP switches (indicated in blue) for users to configure board ID. -
Page 16: Board Id Settings
PCIe-PoE572bt/ PCIe-N572 Series 2.4.2 Board ID Settings The following illustrations describe DIP switch board ID settings. When installing multiple cards, please remember to set a different ID for each card. Board ID DIP Switch Position (P1 - P3) -
Page 17: Pcie-Poe572Bt/ Pcie-N572 Card Installation
PCIe-PoE572bt/ PCIe-N572 Series PCIe-PoE572bt/ PCIe-N572 Card Installation Once you have set up the DIP switch ID of your card for multi-card installation, then you are ready to install it into the system. Please refer to the following installation procedures. Before disassembling the system enclosure and installing the card, please read the following instructions: ⚫... -
Page 18: Hardware Installation
PCIe-PoE572bt/ PCIe-N572 Series Hardware Installation Save and close all work in progress. Power off and unplug the power cable from the system you wish to install to. Open the chassis (side panel) of the computer you wish to install the PCIe card into. Locate the x4 PCIe slot or a spare and compatible x16/ x8 PCIe slot. - Page 19 PCIe-PoE572bt/ PCIe-N572 Series Secure the PCIe card to the chassis with a screw. If you wish to utilize full power load of PoE (PCIe-PoE572bt only), please refer to the following steps. If not, please reinstall the enclosure when done to complete the installation. To utilize the full power load of PoE (PCIe-PoE572bt only), please connect the 6-pin PCIe power cable to the daughter board.
- Page 20 PCIe-PoE572bt/ PCIe-N572 Series Connect the other end of the 6-pin PCIe power cable to 6-pin connector at the end of PCIe- PoE572bt. It is recommended to tuck the cable underneath the fan to sure the 6-pin power cable is out of way (from fan blades).
-
Page 21: Os Support And Driver Installation
Due to Intel’s policy, the system only provides driver support for Intel® x86 architecture. For Linux support, please use Linux kernel versions no later than 5.15. The following list contains the operating systems which have been tested in Neousys Technology Inc. Microsoft Window 10 LTSC 2021 (x64) Ubuntu 20.04.5 LTS, 22.04 LTS, 22.04.1 LTS or other distribution with kernel version ≥... -
Page 22: Network Settings
PCIe-PoE572bt/ PCIe-N572 Series Network Settings PCIe-PoE572bt offers Gigabit Ethernet connectivity via Broadcom 57416 controller. When connecting to a high-speed PoE device, such as a GigE camera, you can configure driver settings for optimum transmission throughput and connection stability. Jumbo Frame Jumbo frames are Ethernet frames with more than 1500 bytes of payload. - Page 23 PCIe-PoE572bt/ PCIe-N572 Series Right click on the corresponding Local Area Connection and click on Properties.
- Page 24 PCIe-PoE572bt/ PCIe-N572 Series Click on the Configure button, the following dialog appears and click on the Advanced tab. Highlight Jumbo Packet and select a jumbo frame size from the Value drop-down list (9014 Byte is recommended for connecting devices with high data rate).
-
Page 25: Networkdirect Functionality (Rdma)
PCIe-PoE572bt/ PCIe-N572 Series NetworkDirect Functionality (RDMA) NetworkDirect is a high-performance networking interface that enables Remote Direct Memory Access (RDMA) functionality. RDMA allows direct memory access between computers in a network without involving the operating system, minimizing CPU overhead and latency. NetworkDirect supports efficient data transfer by bypassing traditional network stack layers, making it ideal for high-speed, low-latency applications like data centers, HPC (High- Performance Computing), and storage systems. - Page 26 PCIe-PoE572bt/ PCIe-N572 Series Right click on the corresponding Local Area Connection and click on “Properties”.
- Page 27 PCIe-PoE572bt/ PCIe-N572 Series Click on the Configure button, the following dialog appears and click on the Advanced tab. Scroll down the Property list and highlight NetworkDirect Functionality, select Enabled/ Disenabled. Scroll down to NetworkDirect Technology, you should see RoCEv2 in the Value column has been activated.
-
Page 28: Receive Buffers
PCIe-PoE572bt/ PCIe-N572 Series Receive Buffers Receive Buffers is another option which can affect data throughput. It determines the size of memory buffer allocated for receiving data. Increasing the size of Receive Buffers can improve the performance of receiving data. The default setting of Receive Buffers is 256 bytes. When connecting to an Ethernet device that generates large amount of data, you can set this option to a larger value (maximum 2048 bytes) for better performance. - Page 29 PCIe-PoE572bt/ PCIe-N572 Series Click on the Configure button, the following dialog appears and click on the Advanced tab. Scroll down the Property list and highlight Receive Buffers and enter a setting into the Value column (2048 Bytes is recommended for connecting devices with high data rate).
-
Page 30: Transmit Buffers
PCIe-PoE572bt/ PCIe-N572 Series Transmit Buffers Like Receive Buffers, Transmit Buffers can affect the transmission performance. The default setting of Transmit Buffers is 1024 bytes. If you encounter a performance issue while transmitting data, you can adjust the size of Transmit Buffers to a larger value (maximum 2048 bytes) for better performance. - Page 31 PCIe-PoE572bt/ PCIe-N572 Series Click Configure button, the following dialog appears and click on the Advanced tab. Scroll down and highlight Transmit Buffers and enter a setting into the Value column (2048 Bytes is recommended for connecting devices with high data rate).
-
Page 32: Port Speed Configuration
PCIe-PoE572bt/ PCIe-N572 Series Port Speed Configuration The 10Gbps card is backwards compatible with 1Gbps speeds in half or full duplex mode. To configure speed settings, please refer to the following steps: On your keyboard, press Windows key + E, right click on Network and select Properties. - Page 33 PCIe-PoE572bt/ PCIe-N572 Series Click Configure button, the following dialog appears and click on the Advanced tab. Scroll down and highlight Speed & Duplex and in the Value dropdown column, select a preferred speed.
-
Page 34: Appendix A Using Per-Port Poe On/Off Control
PCIe-PoE572bt/ PCIe-N572 Series Appendix A Using Per-Port PoE On/Off Control PCIe-PoE572bt supports power on/off control for each of its PoE ports. With provided function APIs, users can turn on or turn off the power of each PoE port manually for fault-recovery or device power reset purpose. - Page 35 PCIe-PoE572bt/ PCIe-N572 Series 2. Click “Next >” and you may specify a directory you would like to install the files to or you can install to the default directory “C:\Neousys\WDT_DIO”.
- Page 36 PCIe-PoE572bt/ PCIe-N572 Series 3. Once the installation is finished, a dialog appears to prompt you to reboot the system. The WDT & DIO library will take effect after the system rebooted. 4. When you programming your program, the related files are located in Header File: \Include Library File:...
-
Page 37: Per-Port On/Off Control Function Reference
PCIe-PoE572bt/ PCIe-N572 Series Per-Port On/Off Control Function Reference PCI_GetStatusPoEPort Syntax BYTE PCI_GetStatusPoEPort(DWORD boardId, DWORD port); Description Acquire current power on/off status of designated PoE port. boardId DWORD value (0 - 3) to indicate board ID set for your card. Please refer to DIP switch settings for your PCIe-PoE card. -
Page 38: Pci_Enablepoeport
PCIe-PoE572bt/ PCIe-N572 Series PCI_EnablePoEPort Syntax BOOL PCI_EnablePoEPort(DWORD boardId, DWORD port); Description Enable (turn on) PoE power for designated PoE port. boardId DWORD value (0 - 3) to indicate board ID set for your card. Parameter Please refer to DIP switch settings for your PCIe-PoE card. -
Page 39: Pci_Disablepoeport
PCIe-PoE572bt/ PCIe-N572 Series PCI_DisablePoEPort BOOL PCI_DisablePoEPort(DWORD boardId, DWORD port); Syntax Description Disable (turn off) PoE power for designated PoE port. boardId DWORD value (0 - 3) to indicate board ID set for your card. Parameter Please refer to DIP switch settings for your PCIe-PoE card.
