- Page 1 Neousys Technology Inc. FLYC-300 Series Quick Installation Guide Revision 1.0...
-
Page 2: Table Of Contents
Service and Maintenance ...................... 7 ESD Precautions ........................7 About This Quick Installation Guide ..................8 Introduction FLYC-300 Specification .................... 10 Dimensions of FLYC-300 Series ................12 1.2.1 Bottom View ...................... 12 1.2.2 I/O Panel View ....................12 Setting Up Your FLYC-300 Unpacking Your FLYC-300 system ................ -
Page 3: Legal Information
Legal Information Legal Information All Neousys Technology Inc. products shall be subject to the latest Standard Warranty Policy. Neousys Technology Inc. may modify, update or upgrade the software, firmware or any accompanying user documentation without prior notice. Neousys Technology Inc. will provide access to these new software, firmware or documentation releases from download sections of our website or through our service partners. -
Page 4: Contact Information
Neousys Technology Inc. (Taipei, Taiwan) 15F, No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 23586, Taiwan Tel: +886-2-2223-6182 Fax: +886-2-2223-6183 Email, Website Americas Neousys Technology America Inc. (Illinois, USA) 3384 Commercial Avenue, Northbrook, IL 60062, USA Tel: +1-847-656-3298 Email, Website China Neousys Technology (China) Ltd. -
Page 5: Notices
Disclaimer to change without prior notice. It does not represent commitment from Neousys Technology Inc. Neousys Technology Inc. shall not be liable for any direct, indirect, special, incidental, or consequential damages arising from the use of the product or documentation, nor for any infringement on third party rights. -
Page 6: Safety Precautions
Safety Precautions Safety Precautions Read these instructions carefully before you install, operate, or transport the system. ⚫ Install the system or DIN rail associated with, at a sturdy location ⚫ Install the power socket outlet near the system where it is easily accessible ⚫... -
Page 7: Service And Maintenance
Service and Maintenance Service and Maintenance ⚫ ONLY qualified personnel should service the system ⚫ Shutdown the system, disconnect the power cord and all other connections before servicing the system ⚫ When replacing/ installing additional components (expansion card, memory module, etc.), insert them as gently as possible while assuring proper connector engagement ESD Precautions ⚫... -
Page 8: About This Quick Installation Guide
About This Quick Installation Guide About This Quick Installation Guide This quick installation guide introduces the basic input/ output connections of Neousys Technology’s FLYC-300 series, an ultra-light and compact drone computer. Revision History Version Date Description Apr. 2024 Initial release... -
Page 9: Introduction
FLYC-300 Series Introduction Neousys FLYC-300 is an NVIDIA Jetson Orin NX based mission computer tailor-made for drone and UAV applications. Designed to coincide and collaborate with the flight controller that is responsible for stabilizing and controlling drone’s flight, FLYC-300 fuels compelling 100 TOPS AI performance combining versatile sensors to empower true autonomy of drone and advance applications such as autonomous navigation, obstacle avoidance, object detection and tracking. -
Page 10: Flyc-300 Specification
FLYC-300 Series FLYC-300 Specification System Core NVIDIA® Jetson Orin™ NX system-on-module (SOM), comprising NVIDIA® Ampere Processor GPU and ARM Cortex CPU Memory 8GB/ 16GB LPDDR5 @ 3200 MHz on SOM External I/O Interface 2x GMSL2 FAKRA Z connector, supporting 2x 1920x1080 @ 60 FPS or 1x 2880x1860... - Page 11 FLYC-300 Series surface. Storage -40°C to 85°C Temperature Humidity 10%~90%, non-condensing Vibration Operating, MIL-STD-810H, Method 514.6, Category 4 Shock Operating, MIL-STD-810H, Method 516.6, Procedure I, Table 516.6-II CE/FCC Class A, according to EN 55032 & EN 55035 * For sub-zero operating temperature, a wide temperature NVMe is required.
-
Page 12: Dimensions Of Flyc-300 Series
FLYC-300 Series Dimensions of FLYC-300 Series NOTE All measurements are in millimeters (mm). 1.2.1 Bottom View With enclosure Without enclosure 1.2.2 I/O Panel View NOTE All measurements are in millimeters (mm). The 32.0mm height (with enclosure) does not include the thickness of the thermal pad. -
Page 13: Setting Up Your Flyc-300
Unpacking Your FLYC-300 system Upon receiving the FLYC-300 system, please check immediately if the package contains all the items listed in the following table. If any item is missing or damaged, please contact your local dealer or Neousys Technology. Item Description... -
Page 14: I/O Panel
FLYC-300 Series I/O Panel Item Description XT-30 DC input A compact and high-power efficient transfer connection often applicable in drone electronics. Gigabit Ethernet The Gigabit Ethernet port is provided by the NVIDIA SoM. 2.5Gb Ethernet The 2.5Gb Ethernet port by is provided by Intel® I225-IT. -
Page 15: Dc Input
FLYC-300 Series 2.2.1 XC-30 DC Input The XT-30 DC input connector supports 12V to 60V and is compatible with a 4S – 14S battery pack. The XT-30 is a popular and common choice in the realm of drone electronics and remote- controlled vehicles for its compact size and efficient power transfer capabilities. -
Page 16: Gigabit Ethernet Port
FLYC-300 Series 2.2.2 Gigabit Ethernet Port The system offers a Gigabit Ethernet port on its I/O panel. When an Ethernet connection is established, the LED indicators on the RJ45 connector represents the following connection statuses: Active/Link LED (Right) LED Color... -
Page 17: Gb Ethernet
FLYC-300 Series 2.2.3 2.5Gb Ethernet The system offers two 2.5Gb Ethernet ports using Intel® I225-IT controller. When plugged in and connected via the Ethernet cable, the LEDs on the RJ45 connector indicate connection status and speed. Active/Link LED (Right) LED Color... -
Page 18: Usb 3.2 Gen 1 Port
FLYC-300 Series 2.2.4 USB 3.2 Gen 1 Port The system’s USB 3.2 Gen1x1 port (5Gbps) is backward compatible with USB 2.0, USB 1.1 and USB 1.0 devices. 2.2.5 USB 3.2 Gen 2 Port The system’s USB 3.2 Gen2x1 port (10Gbps) is backward compatible with USB3.2 Gen1, USB 2.0,... -
Page 19: Fakra Z Connector
FLYC-300 Series 2.2.6 FAKRA Z Connector Fachkreis Automobil (FAKRA) connector is a German standard for SubMiniature version B based automotive-grade connectors. There are two FAKRA Z connectors on the front side of FLYC-300 to connect to automotive GMSL2 cameras. Due to their advanced features such as IP67 waterproof, high dynamic range (120dB HDR), auto white balance (AWB), and LED flicker mitigation (LFM), automotive GMSL2 cameras are ideal for autonomous vehicle applications. -
Page 20: Displayport
FLYC-300 Series 2.2.7 DisplayPort The system has a DisplayPort (DP) output which is a digital display interface that mainly connect video source and carry audio to a display device. It can deliver up to 3840 x 2160 in resolution and is designed to support active DP adapter/ cable. -
Page 21: Microsd Card Slot
FLYC-300 Series 2.2.8 microSD Card Slot The microSD card slot (indicated in blue) is located on the side. To insert or remove the microSD card, you will have to remove the screw (indicated in red) to gain access. -
Page 22: Onboard I/O
FLYC-300 Series Onboard I/O Connection type 1x USB2.0 1x CAN bus 2.0 1x UART 2x DI 2x DO 2x DO Power Switch + Power LED... -
Page 23: Onboard I/O Connectors 1 & 2 Pin Definition
FLYC-300 Series 2.3.1 Onboard I/O Connectors 1 & 2 Pin Definition... -
Page 24: Onboard I/O Connectors 3 & 4 Pin Definition
FLYC-300 Series 2.3.2 Onboard I/O Connectors 3 & 4 Pin Definition... -
Page 25: Onboard I/O Connectors 5 & 6 Pin Definition
FLYC-300 Series 2.3.3 Onboard I/O Connectors 5 & 6 Pin Definition... -
Page 26: Onboard I/O Connectors 7 & 8 Pin Definition
FLYC-300 Series 2.3.4 Onboard I/O Connectors 7 & 8 Pin Definition... -
Page 27: Can Termination
FLYC-300 Series CAN Termination CAN Termination ON CAN Termination OFF (Default) -
Page 28: Dip Switch
FLYC-300 Series DIP Switch Switch Mode Auto power on (default) Power button Auto power on + recovery mode (for reflashing Orin NX) Power button + recovery mode (for reflashing Orin NX)
