- Page 1 Neousys Technology Inc. PCIe-PoE454at User Manual Revision 1.0...
-
Page 2: Table Of Contents
ESD Precautions ........................7 About This Manual ......................... 8 Introduction PCIe-PoE454at Specification ................... 10 Dimension ......................... 11 Setting Up Your PCIe-PoE454at Card Unpacking Your PCIe-PoE454at ................12 Status LEDs ......................13 DIP Switches ......................14 2.3.1 Switching Between INT and EXT Mode ............14 2.3.2... -
Page 3: Legal Information
Legal Information Legal Information All Neousys Technology Inc. products shall be subject to the latest Standard Warranty Policy. Neousys Technology Inc. may modify, update or upgrade the software, firmware or any accompanying user documentation without prior notice. Neousys Technology Inc. will provide access to these new software, firmware or documentation releases from download sections of our website or through our service partners. -
Page 4: Contact Information
Neousys Technology Inc. (Taipei, Taiwan) 15F, No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 23586, Taiwan Tel: +886-2-2223-6182 Fax: +886-2-2223-6183 Email, Website Americas Neousys Technology America Inc. 3384 Commercial Avenue, Northbrook, IL 60062, USA (Illinois, USA) Tel: +1-847-656-3298 Email, Website China Neousys Technology (China) Ltd. -
Page 5: Notices
Disclaimer to change without prior notice. It does not represent commitment from Neousys Technology Inc. Neousys Technology Inc. shall not be liable for any direct, indirect, special, incidental, or consequential damages arising from the use of the product or documentation, nor for any infringement on third party rights. -
Page 6: Safety Precautions
Safety Precautions Safety Precautions Read these instructions carefully before you install, operate, or transport the system. Install the system or DIN rail associated with, at a sturdy location Install the power socket outlet near the system where it is easily accessible ... -
Page 7: Service And Maintenance
Service and Maintenance Service and Maintenance ONLY qualified personnel should service the system Shutdown the system, disconnect the power cord and all other connections before servicing the system When replacing/ installing additional components (expansion card, memory module, etc.), insert them as gently as possible while assuring proper connector engagement ESD Precautions ... -
Page 8: About This Manual
About This Manual About This Manual This manual introduces and describes how to setup/ install Neousys Technology PCIe-PoE454at. As one of the first 5GBASE-T industrial Power over Ethernet frame grabber cards on the market, it offers expandability, stability, flexibility and fast Ethernet access to peripheral devices. -
Page 9: Introduction
PCIe-PoE454at Introduction PCIe-PoE454at is an industrial-grade 4-port 5GBASE-T frame grabber card with 802.3at PoE+ capability for advanced machine vision applications. It leverages Marvel AQC111C 5GBASE-T Ethernet controller to offer dedicated 5 Gb/s Ethernet bandwidth for each port. Furthermore, it is backward compatible with 2.5G, 1G, 100M link speeds to support legacy Ethernet devices and can... -
Page 10: Pcie-Poe454At Specification
PCIe-PoE454at PCIe-PoE454at Specification Bus interface 4-lanes, Gen3 PCI Express interface 4x 5GBASE-T Ethernet ports by four Marvel AQC111C 5G controllers, Gigabit Ethernet Port supporting 5G, 2.5G, 1G, 100M link speeds PoE Capability In compliant with IEEE 802.3at-2009 (PoE+), each port delivers up to 25.5 W... -
Page 11: Dimension
PCIe-PoE454at Dimension NOTE All measurements are in millimeters (mm). -
Page 12: Setting Up Your Pcie-Poe454At Card
Setting Up Your PCIe-PoE454at Card Unpacking Your PCIe-PoE454at Upon receiving the PCIe-PoE454at package, please check immediately if the package contains all the items listed in the following table. If any item is missing or damaged, please contact your local dealer or Neousys Technology. -
Page 13: Status Leds
PCIe-PoE454at Status LEDs Speed LED (1) LED Color Status Description Green 5000 Mbps Orange 2500 Mbps Green or Orange Orange 1000 Mbps Orange 100 Mbps Active/Link LED (2) LED Color Status Description Ethernet port is disconnected Orange Ethernet port is connected and no data transmission... -
Page 14: Dip Switches
PCIe-PoE454at DIP Switches PCIe-PoE454at features individual per-port power on/off control via Neousys’ API so you may manually cut off or resume the power delivery to the connected PoE device. This feature is designed for failure recovery in the field to reset connected devices. In case you have installed multiple cards, there is a set of DIP switches (indicated in blue) for users to configure board ID. -
Page 15: Board Id Settings
PCIe-PoE454at 2.3.2 Board ID Settings The following illustrations describe DIP switch board ID settings. When installing multiple cards, please remember to set a different ID for each card. Board ID DIP Switch Position (P1 ~ P3) -
Page 16: Pcie-Poe454At Card Installation
PCIe-PoE454at PCIe-PoE454at Card Installation Once you have set up the DIP switch ID of your PCIe-PoE454at for multi-card installation, then you are ready to install the PCIe-PoE454at into the system. Please refer to the following installation procedures. Before disassembling the system enclosure and installing the card, please read the following instructions: ... -
Page 17: Hardware Installation
Power off and unplug the power cable from the system you wish to install to. Open the chassis (side panel) of the computer you wish to install the PCIe-PoE454at into. Locate the x4 PCIe slot or a spare and compatible x16/ x8 PCIe slot. - Page 18 PCIe-PoE454at Secure the PCIe-PoE454at to the chassis with a screw. Connect the 6-pin PCIe power cable if need be. Reinstall the system’s chassis (panel) to complete the hardware installation process.
-
Page 19: Software Installation
PCIe-PoE454at Software Installation Some operating systems may have built-in drivers included and automatically complete the installation upon entering the system. However, it is still recommended to run and install drivers provided by Neousys to take advantage of all the functions offered. To install the software... -
Page 20: Driver And Network Settings
PCIe-PoE454at Driver and Network Settings PCIe-PoE454at offers Gigabit Ethernet connectivity via AQC111C controller. When connecting to a high-speed PoE device, such as a GigE camera, you can configure driver settings for optimum transmission throughput and connection stability. Jumbo Frame Jumbo frames are Ethernet frames with more than 1500 bytes of payload. By increasing the payload size, large data packets can be transferred with less interruption, which reduces CPU utilization and increases overall data throughput. - Page 21 PCIe-PoE454at Right click on the corresponding Local Area Connection (Marvell FastLinQ Edge 5Gbit Network …) and click on Properties.
- Page 22 PCIe-PoE454at Click on the Configure button, the following dialog appears and click on the Advanced tab.
- Page 23 PCIe-PoE454at Highlight Jumbo Packet and select a jumbo frame size from the Value drop-down list (16348 Byte is recommended for connecting devices with high data rate).
-
Page 24: Receive Buffers
PCIe-PoE454at Receive Buffers Receive Buffers is another option which can affect data throughput. It determines the size of memory buffer allocated for receiving data. Increasing the size of Receive Buffers can improve the performance of receiving data. The default setting of Receive Buffers is 256 bytes. When connecting to an Ethernet device that generates large amount of data, you can set this option to a larger value (maximum 4096 bytes) for better performance. - Page 25 PCIe-PoE454at Click on the Configure button, the following dialog appears and click on the Advanced tab.
- Page 26 PCIe-PoE454at Scroll down the Property list and highlight Receive Buffers and enter a setting into the Value column (4096 Bytes is recommended for connecting devices with high data rate).
-
Page 27: Transmit Buffers
PCIe-PoE454at Transmit Buffers Like Receive Buffers, Transmit Buffers can affect the transmission performance. The default setting of Transmit Buffers is 512 bytes. If you encounter a performance issue while transmitting data, you can adjust the size of Transmit Buffers to a larger value (maximum 8184 bytes) for better performance. - Page 28 PCIe-PoE454at Click Configure button, the following dialog appears and click on the Advanced tab.
- Page 29 PCIe-PoE454at Scroll down and highlight Transmit Buffers and enter a setting into the Value column (8184 Bytes is recommended for connecting devices with high data rate).
-
Page 30: Appendix A Using Per-Port Poe On/Off Control
Appendix A Using Per-Port PoE On/Off Control PCIe-PoE454at supports power on/off control for each of its PoE ports. With provided function APIs, users can turn on or turn off the power of each PoE port manually for fault-recovery or device power reset purpose. To use the function, you need to install the WDT_DIO_Setup.exe driver package. - Page 31 PCIe-PoE454at 2. Click “Next >” and you may specify a directory you would like to install the files to or you can install to the default directory “C:\Neousys\WDT_DIO”.
- Page 32 PCIe-PoE454at 3. Once the installation is finished, a dialog appears to prompt you to reboot the system. The WDT & DIO library will take effect after the system rebooted. 4. When you programming your program, the related files are located in...
-
Page 33: Per-Port On/Off Control Function Reference
PCIe-PoE454at Per-Port On/Off Control Function Reference PCI_GetStatusPoEPort Syntax BYTE PCI_GetStatusPoEPort(DWORD boardId, DWORD port); Description Acquire current power on/off status of designated PoE port. boardId DWORD value (0 ~ 7) to indicate board ID set for your card. Please refer to DIP switch settings for your PCIe-PoE card. -
Page 34: Pci_Enablepoeport
PCIe-PoE454at PCI_EnablePoEPort Syntax BOOL PCI_EnablePoEPort(DWORD boardId, DWORD port); Description Enable (turn on) PoE power for designated PoE port. boardId DWORD value (0 ~ 7) to indicate board ID set for your card. Parameter Please refer to DIP switch settings for your PCIe-PoE card. -
Page 35: Pci_Disablepoeport
PCIe-PoE454at PCI_DisablePoEPort BOOL PCI_DisablePoEPort(DWORD boardId, DWORD port); Syntax Description Disable (turn off) PoE power for designated PoE port. boardId DWORD value (0 ~ 7) to indicate board ID set for your card. Parameter Please refer to DIP switch settings for your PCIe-PoE card.
