user manual
Detailed articles
LCD projector
model:XgA / WXgA /
WuXgA
Pico Genie PG10K
Before using the product, please read these instructions carefully, and kept safely for future
reference.
OSD options and pictures shown in this document may differ slightingly from your product.
Changes to this manual may be made without notice.
engLiSh
Advertisement
Table of Contents
Related Manuals for PICO Genie PG10K
Summary of Contents for PICO Genie PG10K
- Page 1 Detailed articles LCD projector model:XgA / WXgA / WuXgA Pico Genie PG10K Before using the product, please read these instructions carefully, and kept safely for future reference. OSD options and pictures shown in this document may differ slightingly from your product.
-
Page 2: Features And Design
Features and design This projector is designed with the most advanced technology for portability, durability, and ease of use. This projector has built-in multimedia features, and support the LCD technology by using the color depth of 1.07 billion color. Simple Computer System Setting projector. -
Page 3: Table Of Contents
Content Features and design........2 Color adjust ( for pC.) ........43 Color adjust( for Video, S-video or component) 44 Content ............3 Setting ............45 Safety operation guideline ......4 On start ..............45 Safety instruction ........4 Standby mode ............ 45 Chemical Substances table ......5 high land ............ -
Page 4: Safety Operation Guideline
Safety operation guideline Safety instructions This document and your projector employ certain symbols to illustrate how to use your projector safely. They are described below: please get yourself familiar with them before going through this document. ignoring messages indicated by this symbol may lead to personal injuries Caution or deaths due to human errors. -
Page 5: Chemical Substances Table
Safety operation guideline We will persevere in our efforts to keep clean environment. please return the non - repairable components to the sales department or recycling center. Chemical Substances table harmful substances Component name Cd(vi) pBDe ○ ○ ○ ○ ○... -
Page 6: Notes
Safety operation guideline notes Caution Safety precautions: ● gROunD your projector. ● Lens of your projector projects strong light. DO nOT look at the light beam directly. You may get your eyesight hurt. This is especially the case with children. ●... - Page 7 Safety operation guideline note: precautions on location of your projector: ● Place your projector in a proper location or it may result in fire. ● DO NOT expose your projector in rain or high humidity environments or it may result in fire or electric shock.
- Page 8 Safety operation guideline note: precautions on using your projector: ● DO nOT project the same image for long time as residual images may be left in the panel. This is a property of LCD panel. ● use power as indicated in tags attached to your projector. if you have doubts over available power type, consult your dealer or local power company first.
-
Page 9: Air Ventilation
Safety operation guideline Air ventilation place your projector correctly Openings in the casing are designed for use your projector at specified location in ventilation and overheating prevention. DO correct way. invalid projector location may nOT block or cover these openings to keep shorten life-cycle of lamps or even lead to your projector in normal operation and from severe incidents or fire. -
Page 10: Moving Your Projector
Safety operation guideline moving your projector When moving your projector close its adjustment legs as they may damage the lens and casing. Keep your projector in suitable box when it is not to be used for a long time. note: precautions on moving or shipping your projector: ●... -
Page 11: Compliance
Compliance Caution This is A grade product. products may cause radio interference in the living environment, in this case, the user may need to take effective measures to interfere. Description of the term of environmental protection This logo is used for the sale of electronic information products in the pRC, and the number of the central figures for the use of the term of environmental protection. -
Page 12: Accessory
Accessory Accessory for XGA / WXGA / WuXGA series as follows: Remote Control With Owner's manual(CD) AC power Cord Batteries (AAA*2) note: The AC power Cord specification depands on the location of your projector. VgA Cable Quick Start guide... -
Page 13: Name And Function Of Your Projector
name and function of your projector Front/Top ② ③④ ① ① Lens release button ② FiLTeR indicator ③ STATuS indicator ④ pOWeR indicator ⑤ projection lens ⑥ Remote Receiver (Front) ⑦ Air intake with filter ⑤ ⑥ ⑦ Rear ⑧ Rear control panel ⑨... -
Page 14: Terminals
name and function of your projector Terminals ❻ ❷ ❸ ❹ ❺ ❼ ⓯ ⓰ ❶ ❽ nOTe： ● The terminal is shown above when equipped with hDBaseT function. ⓲ ⓬ ❿ ⓭ ⓮ ❾ ⓫ ⓱ to AuDiO in2. AuDiO OuT uSB -A connector Output audio signals to amplifier or other audio... -
Page 15: Top Control Panel And Indicators
name and function of your projector Top control panel and indicators ④ ① ② ③ ⑤ ⑥ ⑧ ⑦ ⑨ ⑩ ① FiLTeR indicator It turns red when the filter needs be replaced. ② STATuS indicator It flashes red when internal temperature of your projector is out of operation range. ③... -
Page 16: Remote Controller
name and function of your projector Remote controller pATTeRn Select built-in test pattern of your projector. ② ① Select VgA input source. ViDeO ⑥ Select ViDeO input source. ⑦ ③ ④ ⑧ RgBhV Select RgBhV input source. ⑤ ⑨ ⑩ S-ViDeO Select S-ViDeO input source. -
Page 17: Remote Controller Operation Range
name and function of your projector TimeR ② ① enable the timer function. LenS ShiFT enter the lens moving mode. ⑥ ③ ⑦ FReeZe Freeze projected images. ④ ⑧ ⑤ ⑨ KeYSTOne ⑩ Keystone calibration. inFO. Display current status information of your projector. -
Page 18: Install Battery Of Remote Controller
name and function of your projector install battery of remote controller Open the battery cover. insert a new battery in it. Two AA batteries place your batteries with its anode and cathode (+ and -) in correct direction. Keep both poles in good connection to the contacts within the compartment. -
Page 19: Installation
installation Lens installation please follow steps given below to install lens after its replacement or when optional ones are employed. please consult your dealers for details on optional lenses. Lens release button Remove the lens Installing lens 1 Center the lens with its movement 1 Align the red mark on your lens and your function. -
Page 20: Set Up Your Projector
300˝ 6462×4039mm installation 200˝ 4308×2692mm 150˝ 3231×2019mm Set up your projector 100˝ 2154×1346mm 30 ˝ 646×404mm ● Ambient brightness may affect your projection image quality. For the optimal image effect, it is recommended to control brightness in your environment. ● Values shown in figure below are approximates only. They may differ from the actual ones. XgA series WXgA / WuXgA series 300˝... -
Page 21: Adjustment Pad
installation Adjustment pad place the projector properly so that it is vertical to the screen. You may use the adjustment leg to raise your projector up to 5.0 degree. Turn the pad to tilt your projector to required height. To raise your projector, turn both pads clockwise. To lower down your projector or close the pad, turn both pads counterclockwise. -
Page 22: Lens Shift Adjustment
installation Lens shift adjustment The electric lens shift function may adjust your lens in all four directions. This function enables easy image position adjustment. The projection location of your image may be moved upward a distance up to 60% (XgA move lens to it top / WXgA / WuXgA) between the upper and position... -
Page 23: Connection To The Pc
installation Connection to the pC (Digital and Analog RgB) Cables for connection: ● VGA cable ● BNC cable* ● HDMI cable* (* This cable is not included. ) ports on your projector Connection cable equipment DVI-D(HDCP) DVI cable HDMI HDMI cable R(PR) / G(Y) / BNC cable B(PB) / H(HV) / V... -
Page 24: Connect To Audio Equipment
installation Connection to audio equipment Cables for connection: Audio cable* ● (* This cable is not included.) ports on your projector Connection cable equipment MoNo l/R Audio cable aUDIo IN Audio cable aUDIo IN / oUT Audio cable RC IN/oUT Audio cable Connect to uSB equipment Cables for connection:... -
Page 25: Connect The Ac Power Cord
installation Connect the AC power cord Standard voltage employed by your projector is AC 100-240V. it adapts to different input voltage automatically. Your projector employs single-phase power cord with neutral ground cable. Do not use any other type of power cords or you may face the risks of electric shock. -
Page 26: Basic Operation
Basic operation power on your projector 1. Connect all external equipment to your projector (e.g. computer or camera) before powering it 2. Connect AC power cord of your projector to an AC power socket. The power indicator turns on in red. 3. -
Page 27: Power Off Your Projector
Basic operation power off your projector 1. press the power button at the top control panel or the remote controller, the “power off?” message displays. 2. press the power button again in 4 seconds power off? after the “power off?” message prompted to you. -
Page 28: How To Use The Osd
Basic operation how to operate the OSD You can adjust or set up the projector on the Rear control panel on-screen menu . The menu has a multilayer structure. each pOWeR main menu is divided into several sub-level menus, then each submenus is divided into several submenus. -
Page 29: Menu Item Overview
Basic operation menu item overview mainmenu Submemu ① ② ③ ④ ⑤ ⑥ Display menu ● Select Auto pC adj., Fine sync, h position, V position, h. size to adjust the parameters to match the VgA format. Aspect : normal, Widescreen, Advanced. ●... -
Page 30: Zoom /Focus Function
Basic operation Zoom / focus function Zoom / focus 1. press the ZOOm / FOCuS button on the rear control panel or remote controller for zooming and focusing. ZOOm ▲▼ 2. press button to zoom in and out. FOCuS press button to change focus of FAST... -
Page 31: Keystone Adjustment
Basic operation Keystone adjustment You may adjust keystone distortion of image in your projector with the h/V keystone adjustment.Follow steps below to adjust keystone distortion of projected image manually. INPUT Remote controller ● The curved correction function only for press the KeYSTOne button on your remote controller. -
Page 32: Volume Adjustment
Basic operation Volume adjustment You'd better use the remote control to complete Remote controller INPUT directly. Volume press the remote control Volume +/- buttons to adjust the volume. Volume +/- menu menu operation Sound menu 1. press the menu button on the top control pan- el or remote controller and the OSD displays. -
Page 33: Remote Controller Operation
Basic operation Remote controller operation use your remote controller for common operations. Screen size selection (SCReen) press the SCReen button on remote controller to select required screen size mode. Digital Zoom (D.ZOOm+/-) INPUT press the D.ZOOm+/- button on remote controller to enter the Digital Zoom mode. *Only for input as VgA, RgBhV, and the screen size setting as normal or Wide. -
Page 34: Input Selectiont
Basic operation input selection Basic operation Remote controller press the inpuT button on the control panel or on the romote control to select one of the following input: VgA 1, RgBhV, Component,Video, S-Video, hDmi 1,hDmi Video hDmi 2(mhL), memory Viewer, hDBase T, network, hDBaseT RgBhV uSB Display. - Page 35 Basic operation hDBase T Select input hDBase T if a device is connected to the LAn terminal as for it is optional. Component Select input Component if a pC is connected to the Ypbpr terminal. input menu Video Select input Video if a pC is connected to the Video terminal.
-
Page 36: Display
Display Auto pC adj. Select Auto pC Adj. function can adjusts Fine sync, h position, V position , h size to be compati- ble with the computer automatically. AuTO pC adj. menu menu operation AuTO pC adj. press < menu > button on the remote controller or on the top control panel to display the OSD menu. -
Page 37: Position
Display V position (Only for pC signal input) On the premise that the relative position of both projector and the screen is set up right,you can move the image vertical position,if the position of the projected image on the screen is deviated. 1) press button to select [V position] menu. -
Page 38: Project Way
Display For connection, please refer to the following : ..projector 1 projector 2 projector n hDmi hDmi cable cable hDmi cable hDmi cable Splitter note: RS232 RS232 cable cable RS232 cable RS232 cable ● For the details about the edge blending function, please refer to the attached introduction of edge blending function in the... -
Page 39: Menu Position
Display menu position Select this function to set the menu position . menu position menu press < menu > button on the remote controller or on the top control panel to display the OSD menu.press button to select the Display menu ,then press <OK>... -
Page 40: System
Display System System selection The scanning system and auto computer adjustment function may detect scores of signal format. if a pC is selected as the input signal source, your projector will detect and adapt to its signal for- mat automatically. Correct image can be displayed without any setup operation. Your projector will display one of the following: if your projector failed to identify Auto... -
Page 41: Video / S-Video
Display Video / S-video Computer system menu Select this function to set resolution of input signal is compatible with the pC. Set Video / S-video input signal color system or Component input signal scanning mode. 1) press button to select [System ] menu. 2) press <OK>... -
Page 42: Color Adjust
Color adjust INPUT Select color Adjustment to set the image mode and adjust the quality of the projected image image mode Direct operation Remote controller press the image button Select button on remote controller to select required image mode. menu operation press <... -
Page 43: Color Adjust( For Pc.)
Color adjust Color adjust( For pC.) press < menu > button on the remote controller or on Color adjust( For pC) the top control panel to display the OSD menu.press button to select the Color adjust menu , then press <OK> or button. 1) press button to select reqiured item . -
Page 44: Color Adjust( For Video, S-Video Or Component)
Color adjust Color adjust( For Video, S-video or Component) press < menu > button on the remote controller or on Color adjust( For Video, S-video , Component) the top control panel to display the OSD menu.press button to select the Color adjust menu , then press <OK>... -
Page 45: Setting
Setting The projector has Setting fuction, we can select its functions as described below. Setting menu menu operation press < menu > button on the remote controller or on the top control panel to display the OSD menu. press button to select the Setting menu ,then press <OK>... -
Page 46: High Land
Setting high land This projector provides Fan control function in the set- high land tings menu. You can change the setting about speed of cooling fan according to the altitude your projector is operating at. 1) press button to select [high land] menu. 2) press <OK>... -
Page 47: Cooling Fast
Setting Cooling fast After your projector is powered off, select cooling fan Cooling fast speed to shorten the cooling time . 1) press button to select [Cooling fast] menu. 2) press <OK> button. 3) press button to switch required menu. normal.... -
Page 48: Key Lock
Setting Key lock Select this function to lock and unlock the control panel or Key lock remote controller keypad. 1) press button to select [Key lock] menu. 2) press <OK> button. 3) press button to switch required menu. Off....The control panel or remote controller keypad are effective. -
Page 49: Remote Control
Setting Remote control Select this function to prevent the interference from Remote control the remote controller,when multiple projectors or video devices are operated at the same time. press < menu > button on the remote controller or on the top control panel to display the OSD menu.press button to select the Setting menu ,then press <OK>... -
Page 50: Hdmi Setup
Setting hDmi setup When the external device is connected to the hDmi hDmi Setup terminal of the projector, and the images can not be projected normally, please switch on the image or Sound setting. press < menu > button on the remote controller or on the top control panel to display the OSD menu.press button to select the Setting menu ,then press <OK>... -
Page 51: Expand
expand The projector has expand fuction, you can select other functions as described below. expand menu menu operation press < menu > button on the remote controller or on the top control panel to display the OSD menu. press button to select the expand menu ,then press <OK>... -
Page 52: Auto Setup
expand Auto setup press the AuTO button on your remote controller to exe- Auto setup cute the following functions : input search, Auto pC adj. , and Auto keystone. 1) press button to select [Auto setup] menu. 2) press <OK> button. 3) press button to select required items. - Page 53 expand Keystone Select this function to store and reset Keystone after Keystone sub-menu closing the projector or unpluging the AC power . Store..Store Keystone after closing the projector or unpluging the AC power . Reset value..Keystone function will be cancelled after closing the projector or unpluging the AC power directly.
- Page 54 expand Curved correction Select this function to correct the projected images with linearity uneven or vertical and horizontal bending deformation. press button to adjust options. item Operation Adjustment press Adjust right width press Adjust left width Curved correction X/Y gain press ...
-
Page 55: Logo
expand Logo menu Logo You may use this function to set up the Logo screen by Logo select, capture, Logo pin code lock and Logo pin code lock. 1) press button to select [Logo] menu. 2) press <OK> button. 3) press button to select required items. -
Page 56: Security
expand Security Security menu Set a password to lock the control panel or remote controller keypad to prevent unauthorized personnel from operating your projector. Once the projector is on, the [enter Logo password] screen will be displayed. 1) press button to select [Security] menu. 2) press <OK>... -
Page 57: Power Management
expand power management menu power management To reduce power consumption and maintain life cycle of lamp, the power management function will turn off the projection lamp if your projector has no signals for a period of time. 1) press button to select [power management] menu. -
Page 58: Filter Counter
expand Filter counter Set this function to reset the filter usage time and set up Filter counter menu warning display. 1) press button to select [Filter counter] menu. 2) press <OK> button. 3) press button to switch required item. When the projector reaches the user-set cleaning time, filter warning icon will appear on the screen to notify the user needs to clean the projector filter. -
Page 59: Factory Default
expand Factory default This function resets all your settings to factory default . 1) press button to select [Factory default] menu. 2) press <OK or > button. 3) press button to select YeS ,then press <OK> button. Lamp counter make sure to reset the lamp counter, when replacing the Filter counter menu lamp. -
Page 60: Memory Viewer
memory Viewer Select memory Viewer function can project images stored in uSB memory,when you insert the uSB memory into the projector. press < menu > button on the remote controller to display the OSD menu.press button to select the memory Viewer menu ,then press <OK> or button. 1) press button to select reqiured item. -
Page 61: Rotate
memory Viewer Rotate Set the rotation direction of images. 1) press button to select [Rotate] menu. 2) press < OK > button. 3) press button to switch required item. no rotate ..Rotation is invalid. 270 degree rotate..Rotate counterclockwise by 270 degrees. 180 degree rotate..Rotate clockwise by 180 degrees. -
Page 62: Info
info. Select info. function to detect the projected image signal and the projector operating status. menu operation info. menu press <inFO. > button on the remote controller to display the OSD menu.press button to select the info. menu, then press <OK> or button. info. -
Page 63: Hdbase T Function
hD-Base T function hD-Base T function operation Function: it uses RJ45 interface (commonly known as crystal head or ethernet connector). using the special Cat. 6 cable as the transmission cable, with a maximum transmission distance of 100 meters to transmit video signals; meanwhile it has both the two fuction: network connection and signal transmission function. -
Page 64: Network Control
network control network control operation Function: This function is designed to remote control computer in the same LAn. preparation 1 Required equipment: projector, computer, network cable 2 Connection: Connect your projector to a router or switch in the LAn with normal or jumper network cable. - Page 65 network control Wi-Fi display(For pC.) Wi-Fi display enable to connect pC with the projector wirelessly to realize high-speed transmission between devices, allowing users to enjoy high-definition video display without the need for cables circumstances. Wireless network setup 1. inset the supplied WiFi dongle into the uSB-A port. ●...
- Page 66 network control installation procedure: 1) Type the Wireless SSiD/eSSiD address (172.28.120.1) of the projector in the address bar of the web browser. (Please find the SSiD/eSSiD address from the network information in the OSD.) 2) Click Download button. 3) pwpresenter Software: After entering the ip address of the projector in the web page to the main interface, click "Download", and download the corresponding pwpresebter software with your projector.
- Page 67 network control Wi-Fi display( For mobile devices ) Wi-Fi display enable to connect any mobile devices with the projector wirelessly to realize high- speed transmission between devices, allowing users to enjoy high-definition video display without the need for cables circumstances. Wireless network setup 1.
- Page 68 network control installation procedure: 1) Type the Wireless address (https://www.pixelworks.com/?q=node/19) of the projector in the address bar of the web browser. 2) Click Download button. 3) Vuemagic Software: Choose to download the appropriate Vuemagic software system based on the mobile device and install it. 4) Click icon to enter Vuemagic software, then select the appropriate screen display menu location, and click on the top left icon...
-
Page 69: Enter Through A Web Browser
network control enter through a Web browser 1) Start the computer's Web browser. 2) Enter the IP address on the projector set in the URL input field of the Web browser. 3) enter the password in the [password]，then click [Login]. "* "the factory default setting is the user name: "admin"... -
Page 70: System Status Page
network control [System Status] page Versions: Displays the firmware version of the projector. ① LAn Status: Displays the LAn. connection status . ② [general Setup] page enter old password: enter the password for the configuration. ① enter new password: enter a new password. ②... - Page 71 network control [image Setup] page Aspect ratio: Switch the aspect ratio of the projected image. ① phase: Adjust the phase of the projected image. ② horizontal position: Adjust the horizontal position of the projected image. ③ Vertical position: Adjust the vertical position of the projected image. ④...
- Page 72 network control [network Setup] page network Setup ① if you want to enable the DhCp client, select the ip address automatically. ip address: please enter the ip address when you do not use the DhCp server. Subnet : please enter a subnet shield,when you do not use the DhCp server . gateway: please enter the gateway ,when you do not use the DhCp server.
- Page 73 network control 5) pwpresenter Software: when the input signal source is chosen as the network, the network will be used to project computer image. After entering the ip address of the projector in the web page to the main interface, click "Down- load", and download the corresponding pwpresebter software with your projector.
- Page 74 network control ④ parameter Setting Basic setting: Language, Capture region Advanced setting: Jpeg image setting, size etc. network port setting, White list and Black list etc. global setting: Remote control setting, multicast setting: Volume setting, Sound capture and Screen capture, etc. Bandwidth, Sampling frequency, etc.
- Page 75 network control ⑤ network projector management Set pwpresenter network user name and password etc. ⑥ Cut off projector connection.
-
Page 76: Useful Function
useful function memory Viewer function When the uSB memory inset into the projector, the viewer memory function can projecte the video and pictures stored in the uSB memory. The projected content of memory Viewer function memory Viewer function supports the following picture files. extension name Video Codec Audio Codec... - Page 77 useful function play slide The Slide Show mode in the memory Viewer menu is set to a special setting ,all images in the same folder can play automatically. 1) press button to select a file. 2) press button to select [memory Viewer ] menu,then select [From Scratch] menu. 3) press <OK >...
-
Page 78: Usb Display Function
useful function Caution ● When you insert a uSB memory, please make sure insertion direction to avoid damaging the port i. ● please note the following points when inserting and removing uSB memory: a. The indicator flashes,when the USB memory insert into the projector or the projector is reading data.DO nOT remove the uSB memory When the light is flashing. - Page 79 useful function CAn nOT guarantee that the pC meeting the above conditions can operate normally . project uSB display 1) using uSB-B cable to connect the projector to the uSB display terminals. ● items in grey are not available. 2) press the information source menu on the remote controlor the inpuT button on the control panel, then select [uSB display] in the input source menu.
- Page 80 useful function When using mac OS mac OS operating environment Operating System mac os x 10.5,10.6,10.7 power pC g4 1ghz or faster compatible processors memory Capacity 512mB or above Disk Space Available 20mB or above monitor Resolution 640x480 or above, 1600x1200 or above CAn nOT guarantee that the pC meeting the above conditions can operate normally .
-
Page 81: Maintenance And Cleaning
maintenance and cleaning Status light indicator The status light indicator shows status of projector protection function. Check status and pOWeR light indicator for good maintenance operation. note: Unplug the AC power cord in case of any abnormality as it may lead to fire or electric shock. -
Page 82: Clean The Lens
maintenance and cleaning Clean your projector when it is contaminated by foreign matter or its display effects are getting worse. note: unplug the AC power cord before any cleaning operation. Clean the lens Wipe the lens with clean cloth dampened with non-abrasive camera lens cleaner or clean it with lens cleaning paper or air blower. -
Page 83: Reset The Filter Counter
maintenance and cleaning Reset the filter counter 1 press menu button and the OSD displays. press button to select Setup menu, press button or OK. 2 press button to select "Filter Counter", press button or OK. press button to select “Reset the filter counter” and press OK. - Page 84 maintenance and cleaning note: Do not replace the lamp after it went dark as it may be broken. Always assume the lamp of a ceiling mount your projector is broken when replacing it. Stand beside the lamp cover instead of below it. Remove the lamp cover gently. Small piece of glass debris may fall off when opening the lamp cover.
-
Page 85: Appendix
Appendix Troubleshooting Check the following before calling your dealer or service center: Troubleshooting Solution power on failure – plug the power cord of your projector in an AC socket. – make sure the pOWeR light indicator turns red. – Restart your projector until the pOWeR light indicator turns red. it indicates your projector is ready for power on again. - Page 86 Appendix no image displays – Check for the connection between your projector and computer or image equipment. – Check for correct input signal from computer. Connection with certain notebook computer may mandate changes to its display output settings. See the user manual included with the computer for details on settings.
- Page 87 Appendix Light indicator turns on or – Check status of your projector according to the light indicator flashes status. " X" mark displays – invalid operation, please operate your projector correctly. Control panel does not – Disable the key lock on control panel function in the Safety option function of the Setup menu.
-
Page 88: Menu Tree
Appendix menu tree main menu Sub-menu Setting Remarks Auto pC adj. Fine sync 0-31 h position -5 - +5 V position -5 - +5 h Size -15 - +15 Vary from signals normal Wide WuXgA don't support Aspect Advanced Full function Full Front Rear... - Page 89 Appendix main menu Sub-menu Setting Remarks Contrast 0-63 Brightness 0-63 Color 0-63 Component input Tint 0-63 Color adj. S-Video input 0-63 Video input green 0-63 Blue 0-63 Sharpness 0-15 On start On/Off Standby mode normal/ eco. high land On/Off Lamp control normal/ eco.
- Page 90 Appendix main menu Sub-menu Setting Remarks Logo select Default/user/Off WuXgA don't Capture support that Logo fuction Logo pin Code Lock On/Off Logo pin Code Change Ready power Off power management Timer Ready Countdown Filter counter Filter counter Timer Filter counter reset expand Off，gray scale（1-4）...
- Page 91 Appendix main menu Sub-menu Setting Remarks input h- sync. Freq. V- sync. Freq. info. Lamp status Lamp counter power management image mode input VgA 1 RgBhV hDmi1 hDmi2（mhL） hDBaseT Component Video S-Video memory Viewer network uSB Display...
-
Page 92: Light Indicator Status
Appendix Light indicator status Check light indicator to learn status of your projector. Light indicator Status of your projector pOWeR STATUS FILTER green /Red Your projector is in Off status (without AC power supply). Your projector is in standby status. press Standby button to turn it Your projector is in normal status. -
Page 93: Compatible Computer Screen
Appendix Compatible computer screen Your projector is designed to accept every analog computer signal below Dot Clock 160mhz and digital computer signal below Dot Clock 150mhz. See table below for details on resolution and relevant frequency. Signal Frequency Signal Frequency Input Resolution Input... -
Page 94: Terminal Configuration
Appendix Terminal configuration VgA in / mOniTOR OuT Terminal (D-sub 15) Red (input/output) ----- green(input/output) Grounding (field synchronizing) Blue(input/output) grounding ----- DDC data grounding horizontal synchronizing (line synchronizing) (compound sync.)input/output Vertical synchronizing input/ grounding(red) output grounding(green) DDC Clock grounding(blue) SeRiAL Terminal(D-SuB 9) ----- ----- -----... -
Page 95: Dimensions
Appendix Dimensions Dimensions unit: mm Screw holes for Ceiling mount Screw: m6 Depth: 10.0 n145.9 n145.9 181.3 M6×10 181.3 221.3 371.3 221.3 371.3... -
Page 96: Technical Specifications
Appendix Technical Specifications Technical Specifications mechanical properties Dimensions (W×h×D ): 481x179x418 mm net Weight 9.98Kg Adjustable foot 5˚ LCD resolution LCD system 0.79/0.76" TFT, active matrix LCD resolution 1024x768/1280x800/1920x1200 Compatible signals Color standard pAL, SeCAm, nTSC, nTSC4.43, pAL-m and pAL-n,pAL-60 hDTV signal 480i, 480p, 576i, 576p, 720p, 1080i and 1080p Scanning frequency... -
Page 97: Rs232 Control Mode
Appendix RS232 control mode Serial connection 1.1 port setting project Setpoint Communication method Asynchronous communication Communication rate 19200 Length 8-bit parity check Stop position Flow control 1.2 Connection mode Can only use RS232 serial cross connect pC and projector. projector terminal Computer terminal CD 1 1 n.C. - Page 98 Appendix 2. Basic commands Distinguish the letter case.and enter each command ends with [CR] (enter) . Command Option Command Option pOWeR On Video pOWeR OFF(immediatly) Component pOWeR OFF S-Video hDmi1 network hDmi2 (mhL) memory Viewer VgAin 1 uSB Display RgBhV hD-BaseT 2.1 pOWeR On command Command...
- Page 99 Appendix 2.5 VgA in 1 command Command “C05”[CR] Details Select VgAin 1 input Receive Successfully [ACK]［CR］ Return Value Receive unsuccessfully “？” [CR] 2.6 RgBhV command Command “C06”[CR] Details Select RgBhVinput Receive Successfully [ACK]［CR］ Return Value Receive unsuccessfully “？” [CR] 2.7 S-Video command Command “C34”[CR] Details...
- Page 100 Appendix 2.10 hD-BaseT command Command “C32”[CR] Details Select hD-BaseT input . Receive Successfully [ACK]［CR］ Return Value Receive unsuccessfully “？” [CR] 2.11 memory Viewer command Command “C16”[CR] Details Select memory Viewer input . Receive Successfully [ACK]［CR］ Return Value Receive unsuccessfully “？” [CR] 2.12 uSB Display command Command “C17”[CR]...
