MODEL: 3859-03 & 3859NAT-03 ( COVE CUSHION BACK CHAIR)
Please read instructions carefully
Remove all wrapping materials, staples and packing straps from the carton.
Refer to Parts List and Hardware List and ensure they are complete before you start assembling.
Place all wooden parts on a clean, flat and soft surface (e.g carpet or rug) to prevent parts from being scratched.
CAUTIONS:1) DO NOT FULLY TIGHTEN BOLTS AND NUTS UNTIL ALL PARTS HAVE BEEN ASSEMBLED.
2) DO NOT OVER-TIGHTEN BOLTS AND NUTS .
3) KEEP ALL HARDWARE PARTS OUT OF REACH OF CHILDREN.
Designation
Part
CHAIR ARM
CHAIR SEAT
P2
CHAIR LEGS
P3
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
Qty
P1
1PC
1PC
2PCS
Part List
Hardware
Page 1 of 2
Qty
BOLT
H1
4PCS
Ø1/4'' x 50mm
BOLT
H2
4PCS
Ø1/4'' x 35mm
SPRING WASHER
H3
4PCS
Ø5/16'' x 13mm
FLAT WASHER
H4
4PCS
Ø5/16'' x 19mm
ALLEN KEY
H5
1PC
M4 x 59mm
COMPLETE ASSEMBLY
Hardware List
Advertisement
Related Manuals for Living Spaces Cleeve 3859-03
Summary of Contents for Living Spaces Cleeve 3859-03
- Page 1 ASSEMBLY INSTRUCTIONS MODEL: 3859-03 & 3859NAT-03 ( COVE CUSHION BACK CHAIR) Please read instructions carefully Remove all wrapping materials, staples and packing straps from the carton. Refer to Parts List and Hardware List and ensure they are complete before you start assembling. Place all wooden parts on a clean, flat and soft surface (e.g carpet or rug) to prevent parts from being scratched.
- Page 2 ASSEMBLY INSTRUCTIONS MODEL: 3859-03 & 3859NAT-03 ( COVE CUSHION BACK CHAIR) STEP 1 Prepare the CHAIR SEAT (P2) by placing it upside-down. Assemble CHAIR LEGS (P3) by attaching it to the connecting blocks in the CHAIR SEAT (P2). Align BOLT (H2) fitted with a SPRING WASHER (H3) &...
