OWNER'S MANUAL
MARIKO WOOD QUEEN BED
LIVING SPACES SKU : 365316 / 323026 / 323027
VENDOR ITEM NO. : MWNJH5BH / MWNJM5FB / MWNJM5RS
ASSEMBLY PARTS LIST
SKU #
BOX
365316
#1
BOX
323026
#2
323027-1
323027-2
BOX
323027-3
#3
MWZZBPCS57
MWNJBPLS
FULLY ASSEMBLED
PRE-ASSEMBLED PARTS LIST
SKU # IMAGE
MWZZBPFC
IMAGE DESCRIPTION
HEADBOARD
FOOTBOARD
SLAT ROLL
LEFT
SIDERAIL
RIGHT
SIDERAIL
CENTER
SUPPORT
SUPPORT
LEG
DESCRIPTION
FOOT CAP
HARDWARE KIT PACKED IN BOX # 3
SKU : MWZZBPHWQ
QTY
SKU #
MWZZBPHWQ-1
1
MWZZBPHWQ-2
1
MWZZBPHWQ-3
1
MWZZBPHWQ-4
1
MWZZBPHWQ-5
1
MWZZBPHWQ-6
1
MWZZBPHWQ-7
5
MWZZBPHWQ-8
SKU #
Scan QR code to view assembly video
IMAGE DESCRIPTION
ALLEN BOLT
(M8 X 50MM)
ALLEN BOLT
(M6 X 20MM)
LOCK WASHER
(M9)
FLAT WASHER
(M6 X 13)
FLAT WASHER
(M8 X 20)
ALLEN KEY
WOOD SCREW
(M4 X 50MM)
WOOD SCREW
(M4 X 25MM)
IMAGE DESCRIPTION
QTY
8
2
10
2
8
2
2
9
