- Page 1 Ver. 09.27.2024 Miro 13 Max Operation Manual Maintenance & Essential Materials Troubleshooting Videos Software, Guides, Warranty & More © 2024 DTF Station. All rights reserved. WWW.DTFSTATION.COM...
-
Page 2: Safety Instructions
Safety Instructions When using your Miro 13 Max, basic precautions should always be followed, including the following: 1. Read all instructions. 2. Use smoke purifier only for its intended use. 3. To reduce the risk of electric shock, do not immerse the smoke purifier in water or other liquids. -
Page 3: Table Of Contents
Contents Safety Instructions Technical Parameters Machine View Control Panel Guide Operating Instructions © 2024 DTF Station. All rights reserved. WWW.DTFSTATION.COM... -
Page 4: Technical Parameters
5.3A, 220V 1170W, 10.6A, 110V 39.94”x23.62”x18.5” Product Size: 101.45×60×47cm 26.1”x22.95”x20.67” Packing Size: 66.3 x58.3 x 52.5cm Packing Weight: 81.57 lbs, 37kg Certificate: CE,FCC Warranty: One year warranty on all the electronic parts © 2024 DTF Station. All rights reserved. WWW.DTFSTATION.COM... -
Page 5: Machine View
Machine View Front View Top View Internal View © 2024 DTF Station. All rights reserved. WWW.DTFSTATION.COM... -
Page 6: Control Panel Guide
Install the film take up system Install theleft and right brackets Install the take-up reel motor and rods, install the rods to the brackets, tigeten it with the screw underneath the brackets © 2024 DTF Station. All rights reserved. WWW.DTFSTATION.COM... - Page 7 Please refer to the following photo for the right connection. After the connection, put the media wheel back. Make sure that the media wheel fits in the edge of the film. © 2024 DTF Station. All rights reserved. WWW.DTFSTATION.COM...
- Page 8 1. SP1 / SP2. SP1 = Main Heating, SP2 = Pre Heating 2. Temperature 3. Temperature Panel Switch (Between SP1 Main / SP2 Pre Heating) 4. Left (Use for select the number digit to modified) 5. Decrease Temperature 6. Increase Temperature © 2024 DTF Station. All rights reserved. WWW.DTFSTATION.COM...
- Page 9 80°C; ‘Main Heating’ (SP01) temperature set to 130°C. When the machine is in a special environment with low ambient temperature or high altitude, the temperature needs to be appropriately adjusted 5. Rotation Direction Setting © 2024 DTF Station. All rights reserved. WWW.DTFSTATION.COM...
- Page 10 6. Consumable Replacement and Addition Replace the filter on a monthly basis. Check and add an appropriate amount of powder every 1 hour or so. © 2024 DTF Station. All rights reserved. WWW.DTFSTATION.COM...
