- Page 1 Aries 113 UV DTF Maintenance Guide v120823 For your safety, we recommend wearing protective gloves when handling this equipment or these materials to minimize the risk of injury or contamination.
- Page 2 Maintenance Chart Tasks Daily Beginning Daily End of the Day Weekly Monthly As Needed Agitate White and Varnish Bottles Perform Nozzle Check Perform Head Cleaning/ Load/ Fill Ink Check the Media (A film and B film) Clean Around Head Clean Wiper Blade/Cap Top Empty Waste Ink tank Clean Encoder Strip Clean UV Lamps Glass...
- Page 3 Daily Beginning Agitate White and Varnish Bottles To prevent white and varnish ink from settling, please agitate the ink bottle every day. If it’s used, please remove the paper cover on the cap to prevent any paper from mixing with the white ink. Shake the bottles for at least 20 seconds. Perform Nozzle Check Perform a nozzle test before sending a print job to ensure that you get good quality prints every time.
- Page 4 Daily End of the Day Clean Around Head It’s important to clean around the head for any build-up inks at the end of every day. Build-up inks can get on to the printhead from the wiper and can potentially damage the printhead. Clean Wiper Blade/Cap Top Wiper Blade: Same as cleaning around the head, making sure the wiper blade is cleaned is very important to obtain a good nozzle check.
- Page 5 Weekly Empty Waste Ink tank A waste tank alarm is available however it’s recommended that this be replaced every week to ensure that ink does not dry up inside the tank and the tube. Clean Encoder Strip The encoder strip can be cleaned with isopropyl alcohol, simply wipe both sides/ check for any dents or ink splash.
- Page 6 Monthly Clean Heating Roller Regularly maintain the heating roller to ensure the proper advancement of the film. Neglecting the maintenance of the heating roller can lead to problems such as head strikes and film bunching. Avoid using alcohol for cleaning; instead, utilize a lint-free wipe or a water-based cleaner when necessary.
- Page 7 As Needed Clean Printing Bed & Film Sensor See “Monthly” for more details. Replace Wiper Blade/ Cap Top Typically, wiper blades and cap top should be replaced when they show signs of wear or damage. Ink and or cleaning solution contains alcohol which naturally dissolves the rubbers. You may expect to replace them often depending on usage.
