MPMan MP107 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

MP3 Player

MP107
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP107 and is the answer not in the manual?

Questions and answers

Related Manuals for MPMan MP107

Summary of Contents for MPMan MP107

  • Page 1: Mp3 Player

    MP3 Player MP107 User’s Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Introduction ......................................1 Important Safety Precautions ................................2 Main Features ......................................4 Overview ........................................5 Connecting to the Computer ................................. 6 System requirements ................................... 6 Installing the driver for windows 98 SE ..............................6 Connecting player to computer ................................7 Copy Files from computer ..................................
  • Page 3 Using Music Function Menu ................................12 Lyric Displaying ....................................14 Watching a Video ....................................15 Playing a video ....................................15 Viewing Photos ..................................... 16 Viewing a Photo ....................................16 E-book Reading ....................................17 Save and Load a bookmark ................................18 Voice Recording and Playing ................................
  • Page 4 Specifications ....................................... 29...

  • Page 5: Introduction

    Introduction Thank you for purchasing this MP3 Player. This manual contains important safety information and operation instructions, so please read all these instructions carefully before using the player and keeps it for future reference. This manual will help you use all of the exiting features to make your player view more enjoyable. We have done our best to produce a complete and accurate manual;...

  • Page 6: Important Safety Precautions

    Important Safety Precautions Always follow these basic safety precautions when using your player. This will reduce the risk of product damage and personal injury. Do not disassemble, repair or modify the player by yourself. Refer servicing to qualified personnel. Do not dispose of the player in fire to avoid explosion because the player has built-in battery. Do not touch the player with bare hands if the built-in battery is leaking.
  • Page 7 Precautions in using the headphone Do not use the headphone while driving an automobile or riding a bicycle. It is not only dangerous, but also against the law. To avoid an accident, do not turn up the volume of the headphones too high while walking. It’s not recommended that you use the headphones at a high volume for an extended time as this may cause hearing damage.

  • Page 8: Main Features

    Main Features 1.44” CSTN color display 128*128 Built-in rechargeable lithium battery Using the player even if the player is connected to the computer Playback of MP3, WMA, WAV music files Multiple equalizers (EQ) and 3D sound effects Display titles, artists and albums of music files (ID3 tag) Lyrics synchronization while music is playing Supports JPEG and BMP photo formats Supports MTV video format(converter included)

  • Page 9: Overview

    Overview Earphone jack Mini USB connection MIC Built-in microphone for voice recording ] Power on/off; Record save; Open music/movie/ Voice menu; Return to previous menu RESET hole Display screen [ ] Next track/option. Fast forward search. Open the main menu; Confirm the selection; Starts/Pause playback;...

  • Page 10: Connecting To The Computer

    Connecting to the Computer System requirements Your computer system must meet the following requirements: Pentium 200MHz or above Microsoft Windows 98SE/2000/ME/XP/Vista/7 120MB of available hard disk space USB port supported CD-ROM drive Installing the driver for windows 98 SE If your computer is running Windows ME/2000/XP/Vista, no driver is required to install. If your computer is running Windows 98 SE, you must install the driver provided on the CD before connecting the player to your computer.

  • Page 11: Connecting Player To Computer

    Connecting player to computer Files can be transferred directly into the player by using the USB data cable. Make sure that your computer has been started before you start. Connect the mini plug of the USB cable to the mini USB port on the player, and push the other end into a free USB port on your computer.

  • Page 12: Charging The Battery

    Charging the battery The battery of the player is charging automatically when the player is connected to the computer. Make sure the computer has been started. The battery of the player is 80-percent charged in about two hours and fully charged in about four hours. If you charge the player while downloading files to the player, it might take longer.

  • Page 13: Basic Operation

    Basic operation Turn on/off the Player Make sure the battery is sufficient and the headphone is connected correctly. To turn on the player, press and hold the [ ] button. To turn off the player, press and hold the [ ] button. Note: If it is the first time for you to turn on the player or turn on the player after default settings or resetting, you have to select a display language by pressing[ ] or[ ] buttons and then press...

  • Page 14: Unlock All Buttons

    Unlock All Buttons All buttons of the player will be locked after you do not use it in a certain time (you can set the time in setup menu). This prevents you from accidental pressing the buttons while using the MP3 player on the move. Press and hold the buttons to unlock all buttons.

  • Page 15: Listening To Music

    Listening to Music Playing music Make sure that the battery is enough and the headphone is connected correctly. 1. Press buttom to 2. Select “MUSIC” with enter the main menu. [ ]/[ ], then While music playing, you can: Pause/Resume Playing: Press button to pause playing.

  • Page 16: Display

    Display Mode/File name/ID3 tag Music repeat mode Progress bar Battery status Track No./Total Tracks Volume level Lyrics Time Elapsed Total time Using Music Function Menu While music playing, press the [ ] button, the music function menu appears for you to set the music repeat mode, equalizer, 3D,play rate, file browse and classification.
  • Page 17 c) Repeat All: Repeat all songs. d) Shuffle All：Play all songs in the Player at random. e) Folder Normal: Play all songs in the current folder in order once. f) Folder All Repeat: Repeat all songs in the current folder. g) Folder Shuffle All: Play all songs in the current folder at random.

  • Page 18: Lyric Displaying

    and then press to play it. Note: The play rate function is not available for WMA music format. Lyric Displaying This player supports lyrics display while music playing. Only the lyrics in LRC format can be displayed. To add lyrics to the music, take “love music. Mp3” for example: Download the corresponding lyrics with extension “.lrc”...

  • Page 19: Watching A Video

    Watching a Video Playing a video Press and hold to access the main menu. Use[ ]or[ ]to select VIDEO and press . The video list appears on the screen. Use[ ]or[ ]to select a folder or a video and press to open the folder or play the selected video.

  • Page 20: Viewing Photos

    Viewing Photos Viewing a Photo Press and hold to access the main menu. Use[ ]or[ ]to select PHOTO and press . The photo list appears on the screen. Use[ ]or[ ]to select a folder or photo and press to open the folder or view the selected photo.

  • Page 21: E-Book Reading

    E-book Reading This player only supports E-Book in TXT format. Other formats must be saved as TXT format before transfer. Press and hold to access the main menu. Use[ ]or[ ]to select E-BOOK and press . The E-Book list appears on the screen. Use[ ]or[ ]to select a folder or file and press to open the folder or view the selected file.

  • Page 22: Save And Load A Bookmark

    Save and Load a bookmark This function helps you to save the page you have read and recall it to continue reading next time. While reading an E-Book, press and hold [ ]button to enter “Bookmark List”. Save a Bookmark: Press[ ]or[ ]button to select “New Bookmark”, and the press .

  • Page 23: Voice Recording And Playing

    delete a bookmark here. Voice Recording and Playing Recording a Voice 1. Access Main menu by 2. Select “VOICE” with[ ]/[ ] holding then While recording a voice, you can: To pause the playback, press button again. To resume the playback, press the button.

  • Page 24: Setup The Recording Quality

    Press [ ] button to save the recording and return to voice recording interface. Save the Recording: Press [ ] button to save the recording and return to voice recording interface. Note: The recorded voice files are saved in the VOICE folder of the MP3 player as WAV files (format: MIC00001.WAV, MIC00002.WAV).
  • Page 25 Press[ ]or[ ]button to select among Repeat Mode, Equalizer, 3D, Play rate, File Browse, Record Press button to enter. Press [ ] button to exit. Record: start recording. Use[ ]or[ ]button to select “Record”, and then press button to start recording. File Browse: select a voice and play it.

  • Page 26: Managing Files

    Managing Files Browsing all files and deleting a file Press and hold to access the main menu. Use[ ]or[ ]to select FILE BROWSE and press . The file list appears on the screen. Press[ ]or[ ]to navigate between files or folders. To open a folder, select the folder and press Use[ ]or[ ]to highlight a file, and then press [ ] button, there will pop up a DELETE option menu.

  • Page 27: Changing Player Setups

    Changing Player Setups The system setups let you customize and configure your MP3 player. In standby or playing mode, press and hold to access the main menu. Use[ ]or[ ]to select SETUP and press .The setup menu appears on the screen. Use[ ]or[ ]button to select a setup item.

  • Page 28: Setup Items

    Setup items Setup Items Description Power Set how long it will power off automatically after it is not used for a certain time. The available options include: 15 Minutes,30 Minutes,60 Minutes,90 Minutes,120 Minutes, Close Language Set up the display language. Display Setting Set the brightness and backlight time.

  • Page 29: Adjust The Brightness

    standby mode if no button is pressed after the set time. No: The player will power off automatically if no button is pressed after the set time. Adjust the brightness Press[ ]or[ ]to select “Display setting” in SETUP menu, and then press to confirm.

  • Page 30: Converting Video To Mtv Format

    Converting Video to MTV Format This player supports the playback of videos in MTV format. Other formats (AVI, WMV, MEPG1, Quick Time, MPEG2, RealMedia, MPEG4, 3GP) must be converted to MTV format. The “MTV Video Converter” is supplied on the CD to enable you to convert the other formats to MTV format.
  • Page 31 Video Converter Open dialog box Click Input Video, and then select the input source from the Open dialog box. Note: To input MP4 files, select All Files (*.*) in the File of type box so that the MP4 files can be found in the Open dialog box.

  • Page 32: Troubleshooting

    Troubleshooting If you have problems in operating your player, please check the points below before sending it to service center. Cannot power on The battery may be exhausted. Please recharge the battery. Files cannot be downloaded Check if the driver is installed correctly in the computer. Check the connection between the player and PC.

  • Page 33: Specifications

    Specifications Audio Format MP3/WMA/WAV Size Photo Format JPEG/BMP weight Video Format Frequency response 20Hz~20KHz MP3 bit Rate 8Kbps ~320Kbps Dynamic current 15mA WMA bit rate 5Kbps ~320Kbps Storage condition Humidity <90%, Normal temperature S/N rate 80db (30K filter) Working condition Humidity <85%,-10~40℃...
