Page 2: For Your Safety
For your safety ─ Read this user guide carefully to ensure proper use of the product and to avoid any danger of physical damage. Use Safely... - Page 3 Note: Please recharge the digital player before using it! Function features The player supports MP3/WMA/WAV/OGG/APE/AIFF/MS_ADPCM/MPC/FLAC format music files. Support USB 2.0 capability, much faster than USB 1.1, to enable faster communication with your PC. The player can record outside voice and FM radio. The player has repeat functions.
- Page 4 Components and Button functions Power on/off or play/pause Forward/Volume up Backward/Volume down MENU button Record/Volume LCD display Micro SD/T-flash card slot USB port Earphone jack HOLD button RESET hole/Microphone Hang strip hole...
- Page 5 NOTE: You need a card which has songs and videos in it to play, this player can’t save data without card. Charging Li –polymer battery safely Connect the PC USB port and the MP3 USB port with the provided USB cable. The power sign is shown dynamic when charging, once full charged, the power sign will stop moving, power is full, please shut off the power.
- Page 6 Insert the card into Micro SD/T-Flash card slot in power off mode. Press and hold button to turn on and enter main menu. To return main menu: Press and hold 【M】 button. To Pause/Play: Short press button. 】button. To change tracks: Short press【 To turn unit off: Press and hold button.
- Page 7 Delete files from the removable USB storage (use the "Delete" command). Remove the player from PC – please follow the steps in case of damaging the player or data loss. Click the left mouse button on the icon that is on the taskbar at the bottom right corner of the desktop.
- Page 8 CAUTION: Do not remove the player while files within the USB Mass Storage are being played on your computer. Do not disconnect the player from your computer or press M / button while transferring files, or it will cause damage to the player or data loss. Menu Navigation M button: Enter main menu, submenu, confirm, long press return to main menu.
- Page 9 choose these items, it shows “playlist” on the top, user can update the playlist. After plug out the USB, player creates the playlist automatically. Now playing 1. Press M to play . All songs 1. Press【M】 to show all songs in card 2.
- Page 10 】buttons to select the item 2. Short press【 Ⅰ.View favourite II.Add favourite III.Delete favourite IV.Exit Card folder 1.Short press 【M】 to show all the folders in card 】buttons to select the folder 2. Short press【 3.Short press 【M】 to show the files in the folder Create playlist Short press 【M】...
- Page 11 SRS WOW(﹡)HD: Select SRS WOW(﹡)HD and short press M button to enter. Short press 【 】 buttons to select your desired option (e.g.SRS WOW(﹡)HD,SRS WOW, User setting, Disable SRS WOW(﹡)HD). 】to select: SRS 3D, TruBass, FOCUS, CENTER, User setting: Short press【 】...
- Page 12 Replay Select Replay mode and short press 【M】 button to enter. short press to select A point, short press again to select B point and replay the music playback period. Short press 【M】 button to cancel . Bookmark Select Bookmark and short press 【M】 button to enter. 】buttons to select: Bookmark select, Bookmark delete, Short press【...
- Page 13 Play 】button to select “Play “ mode and enter by In main menu, short press【 pressing 【M】 button. Press 【 】 button to select the recorded file and short press 【 】 button to play, 】button to pause. short press【 In playback mode, short press【M】button to enter submenu: Now playing, Card folder, Setting.
- Page 14 Delete all: Select Delete all and press button to delete all saved band. Auto search: Short press 【M】 button to enter submenu. Short press 【 】 and 【M】 button to start “Auto Search”. You may need to wait several minutes to let all detectable stations be found and saved.
- Page 15 TEXT 】buttons to select TEXT mode and enter by In main menu, short press【 pressing M button. 】to select: Local folder, Playback set, Delete file, Delete all, Exit. Press【 short press M to enter. Local folder: Short press 【 】button to select your desired text file and press 】to turn to previous or next page.
- Page 16 Short press 【 】 to choose your desired file(including Video files, music files, photo files, recorded files and TXT files, etc) Short press 【M】 button to confirm and play the selected file. Press and hold【M】button to return to main menu. Setting In main menu, short press 【...
- Page 17 Tools 】buttons to select “Tools“ mode and enter by 1. In main menu, short press【 pressing M button. 】buttons to select the submenu: Set calendar, System time, Short press【 Stopwatch, Memory info, Key tone. Short press M button to enter the next submenu.
- Page 18 USB Driver Installation The player will be recognized automatically under Windows Me, 2000, XP and Vista. You will need to install a driver for Win98 SE. (1) Put CD disk to CD driver. (2) Double click” setup” to install the driver automatically. (3) Close the DOS window, then you can use the player.
- Page 19 Notice Be careful using the player while raining outdoor. Attention should be drawn to the environmental aspects of battery disposal. Please use provided USB cable to connect the player with PC directly. The user guide is only for reference. It is standard by the sample.
- Page 20 The contents of our Installation CD had been detected by the following anti-virus software: Norton Antivirus VER:15.0.0.58 Kaspersky VER:7.0.0.125 PC-Cillin VER:16.00.1671 McAfee VirusScan Plus VER:12.0 Symantec Antivirus VER:10.0.1.1000...
- Page 21 Video Conversion For movie and music synchronisation and conversion, please use MPMANAGER software supplied in the CD ROM. This software can be used also for UPDATE of your player MPMANAGER manual is included in your CDROM...
- Page 22 Technical Specification Name Description USB Interface USB2.0 (High Speed) LCD Display 1.5’’ CSTN(128x128) Power supply Li-Polymer ≥80dB S/N ratio Audio Frequency Range 20Hz – 20kHz Natural, Rock, Pop, Classic, Soft, Jazz, DBB, SRS WOW(﹡)HD Audio:MP3/WMA/WAV/OGG/APE/MS_ADPCM/ MPC/AIFF/FLAC Support file format Video: AMV Picture: BMP/JPG/GIF Normal band:87.50 -- 108.00MHz File System...
- Page 23 For more information please check our website www.mpmaneurope.com...
- Page 24 MADE IN CHINA...
