- Page 1 USER’S MANUAL CT-XRL02 Mini-ITX Industrial Motherboard with LGA 1700 Socket supporting 13th/14th Gen Intel® Raptor Lake-S i9/i7/i5/i3 Core® /Pentium® /Celeron® IOTG Series Processors, Q670E Chipset...
-
Page 2: Table Of Contents
CT-XRL02 l User’s Manual Table of Contents Prefaces …………………………………………………….……………………………………………. 03 Regulatory Notices …………….…………………………………………………………..……………….……….. 03 Safety Information …………………………..……………..…….…….………………………….……………….. 05 Technical Support and Assistance …………………………………….…………….…………….………….. 06 Conventions Used in this Manual ………………………………………………………………….….………. 06 Chapter 1 Product Introductions ………………………………………………………..… 07 Product Description ……….………………………………..………….………………..………. 08 Specifications ………………..…………………………..…………….…………..…..…………... -
Page 3: Prefaces
CT-XRL02 l User’s Manual Preface Prefaces Revision Revision Description Date Initial release 2024/11/13 Regulatory Notices FCC - Class A Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. - Page 4 CT-XRL02 l User’s Manual Preface Battery Information Please take special precautions if this product comes with a battery. • Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.
-
Page 5: Safety Information
CT-XRL02 l User’s Manual Preface Safety Information • The components included in this package are prone to damage from electrostatic discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. • Ensure that all components are securely connected. Loose connections may cause the computer to not recognize a component or fail to start. -
Page 6: Technical Support And Assistance
CT-XRL02 l User’s Manual Preface Technical Support and Assistance 1. Visit the Premio website at www.premioinc.com where you can find the latest information about the product. 2. Contact your distributors, our technical support team or sales representative for technical support if you need additional assistance. -
Page 7: Chapter 1 Product Introductions
Chapter 1 Product Introductions... -
Page 8: Product Description
Chapter 1: Product Introductions CT-XRL02 l User’s Manual 1.1 Product Description The CT-XRL02 Mini-ITX Industrial Motherboard with LGA 1700 Socket supporting 13th/14th Gen Intel® Raptor Lake-S i9/i7/i5/i3 Core®/Pentium®/ Celeron® IOTG Series Processors, Q670E Chipset... -
Page 9: Specifications
Chapter 1: Product Introductions CT-XRL02 l User’s Manual 1.2 Specifications Form factor Mini-ITX • 13th/14th Gen Intel® Raptor Lake-S i9/i7/i5/i3 Core®/Pentium®/ Celeron® IOTG Series Processor, Max 65W - 1.6 GHz~5.1 GHz (depends on CPU) - Socket LGA 1700 Processor • 12th Gen Intel® Alder Lake-S i9/i7/i5/i3 Core®/Pentium®/ Celeron® IOTG Series Processor, Max - 1.6 GHz~5.1 GHz (depends on CPU) - Page 10 Chapter 1: Product Introductions CT-XRL02 l User’s Manual • 1 x 24-pin ATX power connector Power • 1 x 4-pin 12V CPU power connector • 1 x 4-pin PWM CPU fan connector Cooling • 6 x 4-pin PWM system fan connectors •...
-
Page 11: Chapter 2 Mechanical Specifications
Chapter 2 Mechanical Specifications... -
Page 12: Switch And Connector Locations
Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual 2.1 Switch and Connector Locations Top View... - Page 13 Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual Rear I/O Panel RJ-45 LAN Jacks Line-Out COM2 Jack HDMI LAN_USB1 LAN_USB2 LAN_USB3 DP_1/2 Mic-in COM1 USB 3.2 Gen2 Ports Jack DisplayPorts RS232/422/485 Serial Ports...
- Page 14 Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual • Line-Out Jack This connector is provided for external headphones or speakers. • Mic-In Jack This connector is provided for external microphones. • 2.5 GbE RJ-45 LAN Jacks Three standard single RJ45 LAN jacks are provided for connections to the Local Area Network (LAN).
- Page 15 Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual • RS232/422/485 Serial Port The serial port is a 16550A high speed communication port that sends/receives 16 bytes FIFOs. It supports barcode scanners, barcode printers, bill printers, credit card machine, etc. RS232...
-
Page 16: Connector / Switch Definition
Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual 2.2 Connector / Switch Definition Connector Location CPU Socket CPU & Heatsink Installation Memory DIMM1~2: DDR4 SODIMM Slots Storage JSATA1: SATA 3.0 6Gb/s Ports M2_M1: M.2 Slot (M Key, 2242, 2280) Expansion Slots... -
Page 17: I/O Interface Descriptions
Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual 2.3 I/O Interface Descriptions 2.3.1 CPU Socket • Introduction to the LGA1700 CPU The surface of the LGA1700 CPU has four notches and a golden triangle to assist in correctly lining up the CPU for motherboard placement. The golden triangle is the Pin 1 indicator. - Page 18 Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual • CPU & Heatsink Installation Use appropriate ground straps, gloves and ESD mats to protect yourself from electrostatic discharge (ESD) while installing the processor. Important • Images are for illustration purposes only; actual parts may vary.
-
Page 19: Memory
Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual 2.3.2 Memory DIMM1 DIMM2 • DIMM1~2: DDR4 SO DIMM Slots The SO-DIMM slots are intended for memory modules. 1. Open the side clips to unlock the DIMM slot. 2. Insert the DIMM vertically into the slot, ensuring that the off-center notch at the bottom aligns with the slot. -
Page 20: Storage
Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual 2.3.3 Storage JSATA2 JSATA3 JSATA1 • JSATA1: SATA 3.0 6Gb/s Ports This connector is SATA 6Gb/s interface port, it can connect to one SATA device. Important • • This SATA port supports hot plug. -
Page 21: M2_M1: M.2 Slot
Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual 2.3.4 M2_M1: M.2 Slot (M Key, 2242, 2280) Please install the M.2 solid-state drive (SSD) into the M.2 slot as shown below. Video Demonstration • Watch the video to learn how to Install M.2 SSD. -
Page 22: Expansion Slots
Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual 2.3.5 Expansion Slots Please install the M.2 solid-state drive (SSD) into the M.2 slot as shown below. M2_B1 (Nano SIM) PCIe X16 Gen4 (200-Pin Gold Fingers) for Risers M2_E1 • PCIE1: PCIe Expansion Slots The PCI Express(Peripheral Component Interconnect Express) slots support PCIe interface expansion cards. - Page 23 Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual • M2_E1: M.2 Slot (E Key, 2230) Please install the Wi-Fi/ Bluetooth card into the M.2 slot as shown below. Feature • Supports PCIe x 1 & USB 2.0 signal. • Supports CNVi.
-
Page 24: Connectors
Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual 2.3.6 Connectors Power Connectors JPWR1 JPWR3 • JPWR1: ATX 24-Pin Power Connector This connector allows you to connect an ATX power supply. +3.3V +3.3V PWR OK 5VSB +12V +12V +3.3V +3.3V -12V P-ON# •... -
Page 25: Other Connectors
Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual 2.3.7 Other Connectors CPUFAN1 SYSFAN 1_6 • CPUFAN1, SYSFAN1_6: CPU/ System Fan Box Headers The fan power connector supports CPU/ system cooling fans with +12V. When connecting the wire to the connectors, always note that the red wire is the positive and should be connected to the +12V;... - Page 26 Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual • JFP1: Front Panel Connector This front-panel connector is provided for electrical connection to the front panel switches & LEDs and is compliant with Intel Front Panel I/O Connectivity Design Guide. JFP1...
- Page 27 Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual • JCOM3_4: COM Port Box Header This connector is a 16550A high speed communications port that sends/ receives 16 bytes FIFOs. You can attach a serial device to it. JCOM3_4 NDCD3# NDCD4#...
- Page 28 Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual Feature RS232 • Support True RS-232 SIGNAL DESCRIPTION • Support TTL RS-232 NDCD Data Carrier Detect • Support Auto flow control NSIN Signal In • RS- 422/ 485 support TR 1000+ Meter...
- Page 29 Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual • JGPIO1: GPIO (DIO) Box Header This connector is provided for the General-Purpose Input/Output (GPIO) peripheral module. JI2C1 JGPIO1 JGPIO1 N_GPO0 N_GPI0 N_GPO1 N_GPI1 N_GPO2 N_GPI2 N_GPO3 N_GPI3 N_GPO4 N_GPI4 N_GPO5 N_GPI5...
- Page 30 Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual • JUSB1: USB 2.0 Box Header These connectors are ideal for connecting USB devices such as keyboard, mouse, or other USB- compatible devices. JUSB2 JUSB1 JUSB1 USB_D- USB_D- USB_D+ USB_D+ No pin •...
- Page 31 Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual • JBAT1: CMOS Battery Header If the CMOS battery is out of charge, the time in the BIOS will be reset and the data of system configuration will be lost. In this case, you need to replace the CMOS battery.
-
Page 32: Jumpers
Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual 2.3.8 Jumpers JCASE5 JAUD1 Important • Avoid adjusting jumpers when the system is on; it will damage the motherboard. Jumper Name Default Setting Description COM Voltage Select Jumper 1-2: 5V Power JCOMP1... - Page 33 Chapter 2: Mechanical Specifications CT-XRL02 l User’s Manual Jumper Name Default Setting Description AT/ ATX Mode Select Jumper JATX1 1-2: ATX (Default) 2-3: AT LVDS Power Jumper JVDD1 1-2: 3.3V (Default) 2-3: 5V Chassis Intrusion Jumper This connector connects to the chassis intrusion switch cable.
-
Page 34: Chapter 3 System Bios
Chapter 3 System BIOS... -
Page 35: Bios Introduction
Chapter 3: BIOS Setup CT-XRL02 l User’s Manual 3.1 BIOS Introduction This chapter provides information on the BIOS Setup program and allows users to configure the system for optimal use. BIOS Setup Users may need to run the Setup program when: •... - Page 36 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual Control Keys ← → Select Screen ↑ ↓ Select Item Enter Select Change Value Exit General Help Previous Values Optimized Defaults Save & Reset* Screenshot capture <K> Scroll help area upwards <M>...
-
Page 37: The Menu Bar
Chapter 3: BIOS Setup CT-XRL02 l User’s Manual 3.2 The Menu Bar Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu. -
Page 38: Main
Chapter 3: BIOS Setup CT-XRL02 l User’s Manual 3.3 Main ∙ HDD Information ∙ RAID (VMD) Disabled: Display HDD information as plugging in status. RAID (VMD) Enabled: Display "Not Present" only. System Date This setting allows you to set the system date. -
Page 39: Advanced
Chapter 3: BIOS Setup CT-XRL02 l User’s Manual 3.4 Advanced Full Screen Logo Display This BIOS feature determines if the BIOS should hide the normal POST messages with the motherboard or system manufacturer’s full-screen logo. BIOS will display the full-screen logo during the boot-up sequence, hiding [Enabled] normal POST messages. - Page 40 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual CPU Configuration Intel Virtualization Technology Enables or disables Intel Virtualization technology. Enables Intel Virtualization technology and allows a platform to run multiple [Enabled] operating systems in independent partitions. The system can function as multiple systems virtually.
- Page 41 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual Intel(R) Speed Shift Technology Intel® Speed Shift Technology is an energy-efficient method that allows frequency control by hardware rather than the OS. When enabled, Intel® Speed Shift Technology is activated. The technology...
- Page 42 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual Super IO Configuration Serial Port 1/ 2/ 3/ 4 This setting enables or disables the specified serial port. » Change Settings This setting is used to change the address & IRQ settings of the specified serial port.
- Page 43 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual H/W Monitor (PC Health Status) These items display the status of all monitored hardware devices/ components such as voltages, temperatures and all fans’ speeds.. Thermal Shutdown This setting determines the behavior of the system when the CPU temperature reaches a predefined threshold.
- Page 44 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual PCI/PCIE Device Configuration These items display the status of all monitored hardware devices/ components such as voltages, temperatures and all fans’ speeds.. Audio Controller This setting enables or disables the detection of the onboard audio controller.
- Page 45 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual GPIO Group Configuration GPO0 ~ GPO7 These settings control the operation mode of the specified GPIO. Intel(R) RST Enables or disables Intel® RST. Intel® Rapid Storage Technology (Intel® RST) is a feature that combines the capabilities of both hardware and software to enhance storage performance, data protection, and flexibility.
- Page 46 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual PCIE ASPM settings This menu provides settings for PCIe ASPM (Active State Power Management) level for different installed devices. M2_B1/ M2_E1/ M2_M1/ PCIE1 Sets PCI Express ASPM (Active State Power Management) state for power saving.
-
Page 47: Boot
Chapter 3: BIOS Setup CT-XRL02 l User’s Manual 3.5 Boot Boot Option #1-2 This setting allows users to set the sequence of boot devices where BIOS attempts to load the disk operating system. -
Page 48: Security
Chapter 3: BIOS Setup CT-XRL02 l User’s Manual 3.6 Security Administrator Password Administrator Password controls access to the BIOS Setup utility. User Password User Password controls access to the system at boot and to the BIOS Setup utility. - Page 49 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual PCH-FW Configuration This menu allows you to configure settings related to the PCH firmware. Firmware Information These settings show the ME Firmware Version ME Firmware SKU firmware information of the Intel ME (Management...
- Page 50 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual Firmware Update Configuration » ME FW Image Re-Flash Enables or disables the ME Firmware Image Re-flashing. » Local FW Update Enables or disables the capability to perform a firmware update of the ME locally.
- Page 51 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual ME Debug Configuration This menu allows you to configure debug-related options for the Intel® Management Engine (ME). » HECI Timeouts This setting enables/ disables the HECI (Host Embedded Controller Interface) send/ receive timeouts.
- Page 52 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual Anti-Rollback SVN Configuration » Automatic HW-Enforced Anti-Rollback SVN Setting this item enables will automatically activate the hardware-enforced anti-rollback protection based on the Secure Version Number (SVN). Once enabled, the hardware will enforce that only firmware updates with an SVN equal to or higher than the current SVN can be installed.
- Page 53 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual AMT Configuration Intel® Active Management Technology (Intel® AMT) is hardware-based technology for remotely managing and securing PCs out-of-band (OOB). USB Provisioning of AMT Enables or disables the ability to provision AMT using a USB device.
- Page 54 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual Secure Erase Configuration » Secure Erase Mode This setting changes Secure Erase module behavior. [Simulated] Performs SE flow without erasing SSD. [Real] Erase SSD. » Force Secure Erase Enables or disables to force Secure Erase on next boot.
- Page 55 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual » Intel(R) AMT Configuration » Redirection features • SOL Enables or disables SOL (Serial Over LAN). • Storage Redirection Enables or disables Storage Redirection. • KVM Feature Selection Enables or disables the ability to remotely control a system’s keyboard, video, and mouse (KVM) by a distant management console.
- Page 56 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual » Password Policy This feature determines when the user is allowed to change the Intel® MEBX password through the network. [Default Allows changing the Intel® MEBx password through the network interface only if the default password has not been changed yet.
- Page 57 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual • TCP/IP Settings • Wired Lan IPV4 Configuration • DHCP Mode Enables or disables the DHCP (Dynamic Host Configuration Protocol) mode. The items shown above will display when DHCP Mode is set to disabled.
- Page 58 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual » Power control This menu configures the Intel ME platform power-related policies, and the configurations are effective only after ME provisioning has started. • One Click Recovery (OCR) Configuration » OCR Https Boot Enables or disables the use of HTTPS (Hypertext Transfer Protocol Secure) for the OCR boot process.
- Page 59 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual • Remote Platform Erase Configuration Intel® Remote Platform Erase (Intel® RPE) Configuration provides settings for the remote erasure of the platform information or specific storage devices connected to the system. » Enable Remote Platform Erase Feature Enables or disables the ability to initiate the remote erasure process for the system or selected storage devices.
- Page 60 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual Trusted Computing Security Device Support This item enables or disables BIOS support for security device. When set to [Disable], the OS will not show security device. SHA256 PCR Bank These settings enable or disable the SHA-1 PCR Bank and SHA256 PCR Bank.
- Page 61 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual Serial Port Console Redirection Console Redirection Console Redirection operates in host systems that do not have a monitor and keyboard attached. This setting enables or disables the operation of console redirection. When set to [Enabled], BIOS redirects and sends all contents that should be displayed on the screen to the serial COM port for display on the terminal screen.
- Page 62 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual » Bits per second, Data Bits, Parity, Stop Bits These settings specify the transfer rate (bits per second, data bits, parity, stop bits) of Console Redirection. » Flow Control Flow control is the process of managing the rate of data transmission between two nodes. It’s the process of adjusting the flow of data from one device to another to ensure that the receiving device can handle all of the incoming data.
-
Page 63: Secure Boot
Chapter 3: BIOS Setup CT-XRL02 l User’s Manual 3.7 Secure Boot • Secure Boot Secure Boot function can be enabled only when the Platform Key (PK) is enrolled and running accordingly. • Secure Boot Mode Select the secure boot mode. This item appears when Secure Boot is enabled. - Page 64 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual » Platform Key (PK): The Platform Key (PK) can protect the firmware from any un-authenticated changes. The system will verify the PK before your system enters the OS. Platform Key (PK) is used for updating KEK.
- Page 65 Chapter 3: BIOS Setup CT-XRL02 l User’s Manual » Delete Key Deletes the db from your system. » Forbidden Signatures (dbx): Forbidden Signatures (dbx) lists the forbidden signatures that are not trusted and cannot be loaded. » Set New Key Sets a new dbx to your system.
-
Page 66: Chipset
Chapter 3: BIOS Setup CT-XRL02 l User’s Manual 3.8 Chipset • DVMT Total Gfx Mem This setting specifies the total graphics memory size for Dynamic Video Memory Technology (DVMT). • Panel Select Set your video signal interface as LVDs or eDP. -
Page 67: Power
Chapter 3: BIOS Setup CT-XRL02 l User’s Manual 3.9 Power • Restore AC Power Loss This setting specifies whether your system will reboot after a power failure or interrupt occurs. Available settings are: [Power Off] Leaves the computer in the power off state. -
Page 68: Save & Exit
Chapter 3: BIOS Setup CT-XRL02 l User’s Manual 3.10 Save & Exit • Save Changes and Reset Save changes to CMOS and reset the system. • Discard Changes and Exit Abandon all changes and exit the Setup Utility. • Discard Changes Abandon all changes. -
Page 69: Block Diagram
Appendix GPIO WDT BKL Programming Block Diagram This chapter provides WDT (Watch Dog Timer), GPIO (General Purpose Input/ Output) and CT-XRL02 Block Diagram... - Page 70 Appendix – WDT & GPIO CT-XRL02 l User’s Manual Abstract In this section, code examples based on C programming language are provided for customer interest. Inportb, Outportb, Inportl and Outportl are basic functions used for access IO ports and defined as following.
-
Page 71: General Purpose Io
Appendix – WDT & GPIO CT-XRL02 l User’s Manual General Purpose IO 1. General Purposed IO – GPIO/DIO The GPIO port configuration addresses are listed in the following table: Name IO Port IO address Name IO Port IO address N_GPI0... - Page 72 Appendix – WDT & GPIO CT-XRL02 l User’s Manual 1.2 Read input value from GPI: 1. Read the value from GPI port. 2. Get the value of GPI address. Example: Get N_GPI2 input value. val = SMBus_ReadByte (0x6E, 0x22); // Read value from N_GPI2 port through SMBus.
-
Page 73: Watchdog Timer
Appendix – WDT & GPIO CT-XRL02 l User’s Manual Watchdog Timer 2. Watchdog Timer – WDT The base address (WDT_BASE) of WDT configuration registers is 0xA10.2. 2.1 Set WDT Time Unit val = Inportb (WDT_BASE + 0x05); // Read current WDT setting val = val | 0x08;... -
Page 74: Smbusaccess
Appendix – WDT & GPIO CT-XRL02 l User’s Manual SMBus Access 4. SMBus Access The base address of SMBus must know before access. The relevant bus and device information are as following. #define IO_SC 0xCF8 #define IO_DA 0xCFC #define PCIBASEADDRESS... -
Page 75: Ct-Xrl02 Block Diagram
Appendix – Block Diagram CT-XRL02 l User’s Manual CT-XRL02 Block Diagram... - Page 76 © Premio Inc. All Rights Reserved www.premioinc.com...
