Page 1 USER’S MANUAL CT-XSL01 Series Mini-ITX Industrial Motherboard...
Page 2: Table Of Contents
CT-XSL01 | User’s Manual Table of Contents Prefaces …………………………………………………….……………………………………………. 04 Revision …………………………………………………………………………………………..……………….……….. 04 Disclaimer ………………………………………………………..…….…….………………………….……………….. 04 Copyright Notice …………………………………….…………………….…………………………………………… 04 Trademarks Acknowledgment …………..………………………………………………………....04 Environmental Protection Announcement …………………………….………………….……………….. 04 Safety Precautions ………………………………………….……………………………….…………….………….. 05 Technical Support and Assistance …………………………………….…………….…………….…………….06 Conventions Used in this Manual ………………………………………………………………….….………..06 Package Contents …………………………………………………………………………………………….…………...
Page 3 CT-XSL01 | User’s Manual 4.3.11 Network Stack Configuration ……………………………….……………..……...51 4.3.12 Compatibility Support Module Configuration .……………….……..……... 52 4.3.13 NVMe Configuration …………………………………………………………….……... 53 4.3.14 USB Configuration ………………………….……………………………….…………... 54 Chipset …………...……….………………….…..….…..…………..…………………………..…..55 4.4.1 System Agent Configuration ………………….…………..……………..………….. 55 4.4.2 PCH-IO Configuration ………….…………………………………..…………………….. 59 Security …………...……….………………….…..….…..………………………..……..…………...
Page 4: Prefaces
2016/10/18 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc.
Page 5: Safety Precautions
Preface CT-XSL01 | User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions:  Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage.  The power outlet shall be installed near the equipment and shall be easily accessible. ...
Page 6: Technical Support And Assistance
Preface CT-XSL01 | User’s Manual Technical Support and Assistance 1. Visit the C&T Solution Inc website at www.premioinc.com where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.
Page 7: Package Contents
Preface CT-XSL01 | User’s Manual Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty CT-XSL01 Mini-ITX Industrial Motherboard I/O Port Bracket SATA Cable Ordering Information Model No. Product Description Mini-ITX Industrial Motherboard with LGA 1151 Socket for 6th Gen.
Page 8: Chapter 1 Product Introductions
Chapter 1 Product Introductions...
Page 9: Overview
Chapter 1: Product Introductions CT-XSL01 | User’s Manual 1.1 Overview CT-XSL01 is a mini-ITX industrial motherboard with LGA1151 socket to support Intel 6 Generation Core i7/i5/i3, Celeron, and Pentium Processor. Two DDR4 SODIMM memory sockets enables a maximum of 32GB. The Intel 9 Generation Graphic integrated with the processor supports three independent displays from the DVI, DisplayPort, HDMI, or LVDS onboard.
Page 10: Hardware Specification
Chapter 1: Product Introductions CT-XSL01 | User’s Manual 1.2 Hardware Specification System Rear I/O • Processor: LGA 1151 socket supporting 6th Gen • Display: 1x DVI-D, 1x DisplayPort, 1x HDMI • COM: 1x RS-232/422/485 Intel® Core™ i3/i5/i7 Desktop Processor • USB: 4x USB 3.0, 2x USB 2.0 - Intel®...
Page 11: Block Diagram
Chapter 1: Product Introductions CT-XSL01 | User’s Manual 1.3 Block Diagram...
Page 12: Board Dimensions
Chapter 1: Product Introductions CT-XSL01 | User’s Manual 1.4 Board Dimensions Unit: mm...
Page 13: Chapter 2 Jumper And Connectors
Chapter 2 Jumper and Connectors...
Page 14: Switch And Connector Locations
Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual 2.1 Switch & Connector Locations 2.1.1 Top View...
Page 15: Bottom View
Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual 2.1.2 Bottom View 2.1.3 Back Panel View...
Page 16: Connector Definition
Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual 2.2 Connectors Definition List of Connectors Connectors Location Definition KBMS1_USB910 PS/2 and USB2.0 Ports HDMI1_DP1 HDMI and DisplayPort Ports DVI-D1 DVI-D Connector COM1 Serial Port LAN1_USB12 LAN1 and USB3.0 Ports LAN2_USB34 LAN2 and USB3.0 Ports AUDIO1 Line-out Jack and Microphone Jack...
Page 17 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual KBMS1_USB910: PS/2 and USB2.0 Ports Connector Type: 6-pin Mini-DIN and dual USB 2.0 ports Definition Definition Definition +5V_DUAL +5V_DUAL USB2_D10- USB2_D9- KB_DATA USB2_D10+ USB2_D9+ MS_DATA +5V_DUAL KB_CLK MS_CLK HDMI1_DP1: HDMI and DisplayPort Ports Definition Definition DP_DP0...
Page 18 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual DVI-D1: DVI-D Connector Definition Definition DVI_TX2- DVI Hot Plug DVI_TX2+ DVI_TX0- DVI_TX0+ DVI_DDC_CLOCK DVI_DDC_DATA DVI_CLK+ DVI_TX1- DVI_CLK- DVI_TX1+ COM1: Serial Port Connector Type: 9-pin D-Sub Definition DCD1 RXD1 TXD1 DTR1 DSR1 RTS1 CTS1...
Page 19 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual LAN1_USB12: LAN1 and USB3.0 Ports Connector Type: RJ45 port with LEDs and dual USB3.0 ports Definition Definition Definition LAN1_MDI0P USB2_D1- USB2_D2- LAN1_MDI0N USB2_D1+ USB2_D2+ LAN1_MDI1P LAN1_MDI2P USB3_RX1- USB3_RX2- LAN1_MDI2N USB3_RX1+ USB3_RX2+ LAN1_MDI1N LAN1_MDI3P USB3_TX1-...
Page 20 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual PCIEX16_1: PCI-Express X16 Socket Connector Type: PCI-Express X16 Slot Definition Definition Definition Definition PRSNT#1 +12v HSOn(6) +12v HSIp(6) +12v +12v HSIn(6) +12v HSOp(7) JTAG2 SMCLK HSOn(7) JTAG3 HSIp(7) SMDAT JTAG4 HSIn(7) PRSNT#2 JTAG5 +3.3v...
Page 21 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual JLVDS1: LVDS Connector Connector Type: 2x20-pin pitch1.25mm LVDS connector Definition Definition VDD_LVDS VDD_LVDS VDD_LVDS VDD_LVDS LVDS_A0- LVDS_B0- LVDS_A0+ LVDS_B0+ LVDS_A1- LVDS_B1- LVDS_A1+ LVDS_B1+ LVDS_A2- LVDS_B2- LVDS_A2+ LVDS_B2+ LVDS_A_CLK- LVDS_B_CLK- LVDS_A_CLK+ LVDS_B_CLK+ DDC_CLK DDC_DATA LVDS_A3-...
Page 22 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual USB78: Front Panel USB2.0 Header Pin Header Type: 2X5-pin header, 2.54mm pitch Definition Definition USB2_D7- USB2_D8- USB2_D7+ USB2_D8+ SATA1, SATA2, SATA3, SATA4: SATA Connector SATA1 SATA2 SATA3 SATA4 Definition Definition Definition Definition SATA_TXP0 SATA_TXP1...
Page 23 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual Definition Definition MIC2-IN_L PRESENCE# MIC2-IN_R (Dongle present) MIC2-IN LINE2-IN_R SENSE_RETURN Jack Detect LINE2-IN LINE2-IN_L SENSE_RETURN CPU_FAN1, SYS_FAN1: FAN Connector Definition +12V FAN Tachometer FAN PWM F_PANEL1: Front Panel Header Pin Header Type: 2X5-pin header, 2.54mm pitch Definition Definition RESET...
Page 24 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual EATXPWR1: Main Power Supply Connector (24pin) Definition Definition +3.3V +3.3V +3.3V -12V PS-ON PWRGD +5VSB +12V +12V +3.3V ATX12V1: Processor Power Supply Connector (4pin) Definition +12V +12V JLPC1: Debug Header Pin Header Type: 2X5-pin header, 2.0mm pitch Definition Definition +3.3V...
Page 25 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual SPI1: SPI Header Pin Header Type: 2X4-pin header, 2.0mm pitch Definition Definition +3.3V SPI_CS# SPI_CLK SPI_MISO SPI_MOSI HOLD# JDIO1: GPIO Connector (8 bits) Connector Type: Connector Type: 2X5-pin Wafer, 2.0mm pitch Definition Definition GPO0...
Page 26 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual MINI_CARD1_1: Mini PCI-Express / mSATA Socket Definition Definition WAKE# +3.3VSB +1.5V SMB_CLK MINIPCIE_TXN (SATA_TXN4) +1.5V SMB_DATA CLKREQ# MINIPCIE_TXP (SATA_TXP4) USB2_D11- MINIPCIE_CLKN USB2_D11+ MINIPCIE_CLKP +3.3V +3.3V RESET +1.5V MINIPCIE_RXN (SATA_RXN4) +3.3V MINIPCIE_RXP (SATA_RXP4) Presence Detection +3.3V...
Page 27 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual NGFF1: M.2 Socket Definition Definition +3.3V +3.3V +3.3V +3.3V +3.3V +3.3V SATA_DEVSLP SATA_RXP5 SATA_RXN5 SATA_TXN5 SATA_TXP5 RESET M2_CLKREQ# M2_CLKN WAKE# M2_CLKP PCH_SUSCLK +3.3V SATA/PCIE_Detection +3.3V +3.3V...
Page 28 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual USB56: USB3.0 Connector Connector Type: 2X10 20-pin box header, 2.0mm pitch Definition Definition +5V_DUAL USB2_D6+ USB3_RX5- USB2_D6- USB3_RX5+ USB3_TX6+ USB3_TX5- USB3_TX6- USB3_TX5+ USB3_RX6+ USB2_D5- USB3_RX6- USB_D5+ +5V_DUAL...
Page 29: Jumpers Definition
Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual 2.3 Jumpers Definition When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open.
Page 30 Chapter 2: Jumper & Connectors CT-XSL01 | User’s Manual JLVDS2: Backlight Power Select Header Pin Header Type: 2X3-pin header, 2.0mm pitch Definition 1-3 (Short) 3-5 (Short) +3.3V 3-4 (Short) +12V JPSON1: AT / ATX Mode Select Header Pin Header Type: 1X3-pin header, 2.54mm pitch Definition 1-2 (Short) ATX Mode...
Page 31: Chapter 3 Features & Interface
Chapter 3 Features & Interface...
Page 32: General Purpose Input & Output (Gpio)
Chapter 3: Features & Interface CT-XSL01 | User’s Manual 3.1 General Purpose Input Output (GPIO) GPI and GPO pins may be implemented as GPIO. GPI and GPO pins may be implemented as SDIO. Signal Description General purpose output pins. Upon a hardware reset, these GPO[0:3] outputs should be low.
Page 33: Watchdog Timer
Chapter 3: Features & Interface CT-XSL01 | User’s Manual Registers Description GPIO I/O Select I/O Register: 0xEC Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 GPO3 GPO2 GPO1 GPO0 GPI3 GPI2 GPI1 GPI0 Note.
Page 34: Psuedo Code
Chapter 3: Features & Interface CT-XSL01 | User’s Manual 3.2.2 Psuedo Code  Enter_Config Step1: outportb(0x2e, 0x87); Step2: outportb(0x2e, 0x87);  Select Logical Device: 8 Step1: outportb(0x2e, 0x07); Step2: outportb(0x2e, 0x07);  Set WDT Time Unit (Second Unit) Step1: outportb(0x2e, 0xf0); Step2: buf2 = inportb(0x2f) &...
Page 35 Chapter 3: Features & Interface CT-XSL01 | User’s Manual Watchdog Timer: Logical Device: 8 CR F0h. Watchdog Timer I (WDT1) and KBC P20 Control Mode Register Location: Address F0h Attribute: Read/Write Power Well: VCC Reset by: LRESET# or PWROK Default: 00h Size: 8 bits READ / WRITE DESCRIPTION...
Page 36: Chapter 4 Bios Setup
Chapter 4 BIOS Setup...
Page 37: Bios Introduction
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.1 BIOS Introduction The system BIOS software is stored on EEPROM. The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del>...
Page 38: Main Setup
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu. 4.2.1 System Date Set the system date.
Page 39: Advanced Setup
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.3 Advanced Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Chipset configuration, to go to the sub menu for that item.
Page 40: Trusted Computing
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.3.1 Trusted Computing ■ Security Device Support This item allows you to enable or disable BIOS support for security device.
Page 41: Acpi Settings
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.3.2 ACPI Settings ■ Enable Hibernation Enable or Disable system ability to Hibernation. Configuration options: [Enable] [Disable] ■ ACPI Sleep State Select the highest ACPI sleep state the system will enter the SUSPEND button is press. Configuration options: [Suspend Disable] [S3 only(suspend to RAM )] ■...
Page 42: Amt Configuration
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.3.3 AMT Configuration ■ Intel AMT Enable or Disable Intel AMT BIOS extension Configuration options: [Disabled] [Enabled] ■ Un-configure ME Un-configure ME with Password Configuration options: [Disabled] [Enabled] 4.3.4 PCH FW Configuration...
Page 43: Super Io Configuration
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.3.5 Super IO Configuration This setting allows you to select options for the NCT6106D Super IO Configuration, and change the value of the selected option. ■ Serial Port 1 Configuration  Serial Port This item allows you to enable or disable serial port.
Page 44 Chapter 4: BIOS Setup CT-XSL01 | User’s Manual ■ Serial Port 2 Configuration  Serial Port This item allows you to enable or disable serial port.  Change Settings This item allows you to change the address & IRQ settings of the specified serial port. ...
Page 45 Chapter 4: BIOS Setup CT-XSL01 | User’s Manual ■ Serial Port 4 Configuration  Serial Port This item allows you to enable or disable serial port.  Change Settings This item allows you to change the address & IRQ settings of the specified serial port. ...
Page 46: Hardware Monitor
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual ■ Watch Dog Function This setting allows you to setup the system watch-dog timer, a hardware timer that generates a reset when the software that it monitors does not respond as expected each time the watch dog polls it. ...
Page 47: Serial Port Console Redirection
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.3.7 Serial Port Console Redirection ■ Console Redirection These items allows you to enable or disable COM1~COM5 console redirection. 4.3.8 CPU Configuration...
Page 48 Chapter 4: BIOS Setup CT-XSL01 | User’s Manual ■ Hyper-Threading [Enabled] Enabled or Disabled the hyper threading of Intel CPU Configuration options: [Disabled][Enabled] This depends on CPU sku. ■ Active Processor Core [All] Number of Cores to enable in each processor package Configuration options: [all] [1][2][3][4] This depends on CPU sku.
Page 49: Intel Txt Information
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.3.9 Intel TXT Information Display Intel TXT information...
Page 50: Sata Configuration
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.3.10 SATA Configuration ■ SATA Controller [Enabled] Enable or Disable SATA device Configuration options: [Enabled][Disabled] ■ SATA Mode Selection [AHCI] Determines how SATA controller operate Configuration options: [AHCI][RAID] ■ Serial – ATA Port 1 This item allows you to enable or disable Serial-ATA Port 1.
Page 51: Network Stack Configuration
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.3.11 Network Stack Configuration ■ Network Stack [Disabled] Enabled or disabled UEFI Network Stack Configuration options: [Disabled] [Enabled]...
Page 52: Compatibility Support Module Configuration
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.3.12 Compatibility Support Module Configuration ■ CSM Support Enabled or disabled CSM Support Configuration options: [Disabled] [Enabled] ■ Boot option filter This option controls Legacy/UEFI ROMs Priority Configuration options: [UEFI and Legacy] [Legacy Only][UEFI Only] ■...
Page 53: Nvme Configuration
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.3.13 NVMe Configuration...
Page 54: Usb Configuration
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.3.14 USB Configuration ■ Legacy USB Support [Enabled] Enabled Legacy USB Support. Auto Option disables legacy support if no USB devices are connected. Disabled option will keep USB devices available only for EFI application. Configuration options: [Disabled] [Enabled][Auto] ■...
Page 55: Chipset
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.4 Chipset 4.4.1 System Agent Configuration This section provides configure options for on-graphic, PEG port, and installed memory.
Page 56 Chapter 4: BIOS Setup CT-XSL01 | User’s Manual ■ Graphic Configuration This section provides onboard graphics-related configuration options.  Primary Display Select which of IGFX/PEG/PCI graphic device should be primary display or select SG for switchable GFx. Configuration options: [Auto] [IGFX][PEG][PCIE] ...
Page 57 Chapter 4: BIOS Setup CT-XSL01 | User’s Manual ■ PEG Port Configuration This section provides PEG Port configuration options.  Enable root Port [Auto] Enable or Disable the root port Configuration options: [Disabled][Enabled][Auto]  Max Link Speed [Auto] Configure PEG 0:1:0 Max Speed Configuration options: [Auto][Gen1][Gen2][Gen3] ...
Page 58 Chapter 4: BIOS Setup CT-XSL01 | User’s Manual ■ Memory Configuration This section provides installed memory information.
Page 59: Pch-Io Configuration
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.4.2 PCH-IO Configuration ■ Lan1 Controller [Enabled] Enable or Disable onboard Lan1 Configuration options: [Disabled][Enabled] ■ Wake on lan [Auto] Enable or Disable integrated LAN to wake the system Configuration options: [Disabled][Enabled] ■...
Page 60 Chapter 4: BIOS Setup CT-XSL01 | User’s Manual ■ PCI Express Configuration  PCI Express Root Port 9 [Enabled] Control the PCI Express Port Configuration options: [Disabled][Enabled]  ASPM Support [Disabled] Set the ASPM level: Force L0s- Force all links to L0s State; Auto- BIOS auto configure; Disabled- Disables ASPM Configuration options: [Disabled][L0s][L1][L0sL2][Auto] ...
Page 61 Chapter 4: BIOS Setup CT-XSL01 | User’s Manual ■ USB Configuration  USB Precondition[Disabled] Precondition work on USB host controller and root ports for faster enumeration Configuration options: [Disabled] [Enabled]  XHCI Disabled Compliance Mode [False] Options to disable compliance mode. Configuration options: [False][true] ...
Page 62: Security
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual ■ HD Audio Configuration Control Detection of the HD-Audio device. Configuration options: [Disabled] [Enabled][Auto] 4.5 Security Security menu allow you to change administrator password and user password settings. 4.5.1 Administrator Password This item allows you to set Administrator Password. 4.5.2 User Password This item allows you to set User Password.
Page 63: Boot
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.6 Boot This menu allows you to setup the system boot options. 4.6.1 Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. 4.6.2 Bootup NumLock State This item selects the keyboard NumLock state.
Page 64: Save & Exit
Chapter 4: BIOS Setup CT-XSL01 | User’s Manual 4.7 Save & Exit This setting allows you to configure the boot settings. 4.7.1 Save Changes and Exit This item allows you exit BIOS Setup after saving the changes. 4.7.2 Discard Changes and Exit Select this option to quit Setup without making any permanent changes to the system configuration.
