Page 1: Table Of Contents
85116 Rev. M QUADRO HORIZONTAL LIFELINE Part # 30800 Instruction Manual Product Specific Applications Worker Classifications Applicable Safety Standards Permitted User Weight Limitations Compatibility Components and Specifications Materials Installation and Use Safety Information Labels Diagrams 9-10 Inspection Inspection Log Do not throw instructions away. -
Page 2: Product Specific Applications
English Product Specific Applications Worker Classifications Fall Arrest: May be used to support a Qualified Person: person with MAXIMUM 4 Personal Fall Arrest accredited degree or certification, and with System (PFAS) for use in Fall Arrest extensive experience or sufficient professional applications. -
Page 3: Limitations
English Limitations Fall Clearance: There must be sufficient clearance below the work surface to arrest a fall before the user strikes the ground or an obstruction. When calculating fall clearance, account for a MINIMUM 2 ft (0,6 m) safety factor, deceleration distance, user height, length of connecting devices, harness stretch, free fall, and all other applicable factors. -
Page 4: Components And Specifications
WARNING! Never pull tensioning lever Polyester, galvanized steel, and away from device. powder-coated aluminum. Part # Length Contents O-rings (4), Cross Arm Straps (2), Carabiners (2), 30800 82 ft (25 m) Rope Vise Tensioner, Double-braided Rope, Carrying Bag... -
Page 5: Installation And Use
English Installation and Use Prior to use, plan your system: WARNING! For use in personal fall protection systems only. NEVER use for material handling and/or lifting. Do not install at any angle other than horizontal. Do not use in combination with pass- ... - Page 6 Step 5 Step 8 Install compatible anchorage connector at To confirm proper tension, locate midpoint of horizontal lifeline span. Rope sag must first horizontal lifeline span termination point. Then, connect anchor (live) end of the Quadro match data specified graph and table on Horizontal Lifeline to anchorage connector pages 10-11.
-
Page 7: Safety Information
English Safety Information Harnesses and connectors selected must be compliant with manufacturer’s instructions, and WARNING! Failure to understand and must be of compatible size and configuration. comply with safety regulations may result Snap hooks, carabiners, and other connectors in serious injury or death. Regulations must be selected and applied in a compatible included herein are not all-inclusive, are fashion. -
Page 8: Labels
English 0 Rev. C Labels .125” Guardian Quadro Horizontal Lifeline OSHA 1910.140 & 1926.502 U.S. Patent No. D819,429 S Part # 30800 Serial # XX- 90780 Rev. C XXXXX DOM MM/YYYY Max # of Users: 4 Anchorages must be Max User Weight: 310 lb (per user) suff... -
Page 9: Diagrams
English Diagram A - Diagram A - Fall Clearance Fall Clearance Fall clearance calculation shown below is an example ONLY. Fall clearance calculation shown below is an example ONLY. 4-Person Quadro HLL Lifeline 10 ft 20 ft 30 ft 40 ft 50 ft 60 ft 70 ft... - Page 10 English Diagram C - Span Sag Calculation Anchor Point Anchor Point Midpoint Span Length Diagram D - Span Sag Graph Quadro Horizontal Lifeline Tension Guide EXCESS SAG DO NOT USE FOR USE Span Length (feet)
-
Page 11: Inspection
If webbing shows signs of wear, please replace only with Guardian-supplied webbing. IMMEDIATELY remove Quadro HLL from service if defects or damage are found, or if exposed to forces of fall arrest. -
Page 12: Inspection Log
This warranty is not transferable to any other Guardian service and does not apply to product that is resold after having been put into service. No other person,firm, entity, or the like is authorized to assume or assign for Guardian any other liability in connection with the sale or use of Guardian’s products.
