TL1 - PZX
Screen Size: 33 - 70"
Guide Max. Weight: 80kg
Revised 13/08/24
*Please check model specific details before installing*
WARNING
Please carefully inspect the product before assembling. If you notice any apparent damage, call your
carrier claims agent and do not continue the installation until it has been reviewed. Please watch for pinch
points. Do not put your fingers between moveable parts. Do not tamper with or disassemble any spring
loaded parts. Before installing, make sure that the supporting surface will support five times the combined
load of the solution and the hardware. Never exceed the maximum load capacity. Please also layout all
components to ensure that you have all of the required parts before proceeding (see BOM list on following
page). Use of this product for anything other than its specified use may result in failure or personal
injury. This product is intended for indoor use only. We recommend using a qualified trades person for
installation. Use an assistant or lifting equipment to lift and position products.
For support, please call: +44 (0)1865 767676 or email: sales@unicol.com
Advertisement
Related Manuals for Unicol TL1-PZX
Summary of Contents for Unicol TL1-PZX
- Page 1 Use of this product for anything other than its specified use may result in failure or personal injury. This product is intended for indoor use only. We recommend using a qualified trades person for installation. Use an assistant or lifting equipment to lift and position products. For support, please call: +44 (0)1865 767676 or email: sales@unicol.com...
- Page 2 01865 767676 sales@unicol.com www.unicol.com TOOLS REQUIRED INSTALLERS REQUIRED 4mm & 5mm Allen Keys Pozi Head Screwdriver 17mm Spanner COMPONENTS DESCRIPTION Base Mast Unit Screen Mount Backplate Screen Mount Arms Revised 13/08/24...
- Page 3 01865 767676 sales@unicol.com www.unicol.com STEP 2 STEP 1 Identify base and mast. The base is heavy so you Stand the assembly upright and remove rear cover might want another person to support it. Allow the by loosening the 6 x M6 allen screws sufficiently in floor to take the weight of the base and mast and order to lift the rear cover and pull towards you.
- Page 4 01865 767676 sales@unicol.com www.unicol.com STEP 6 STEP 5 Utilising the tag locks and fixing pack provided with Using another team member, lift the screen up and your mount, attach the arms to the back of your gradually offer it up to the back plate. Gently tilting screen.
