Unicol TM05 Manual

Download this manual

01865 767676

sales@unicol.com

www.unicol.com

TM05

Screen Size: n/a

Guide Max. Weight: 45kg

Revised 30/05/24

*Please check model specific details before installing*

WARNING

Please carefully inspect the product before assembling. If you notice any apparent damage, call your

carrier claims agent and do not continue the installation until it has been reviewed. Please watch for pinch

points. Do not put your fingers between moveable parts. Do not tamper with or disassemble any spring

loaded parts. Before installing, make sure that the supporting surface will support five times the combined

load of the solution and the hardware. Never exceed the maximum load capacity. Please also layout all

components to ensure that you have all of the required parts before proceeding (see BOM list on following

page). Use of this product for anything other than its specified use may result in failure or personal

injury. This product is intended for indoor use only. We recommend using a qualified trades person for

installation. Use an assistant or lifting equipment to lift and position products.

For support, please call: +44 (0)1865 767676 or email: sales@unicol.com

Need help?

Do you have a question about the TM05 and is the answer not in the manual?

Page 1 Use of this product for anything other than its specified use may result in failure or personal injury. This product is intended for indoor use only. We recommend using a qualified trades person for installation. Use an assistant or lifting equipment to lift and position products. For support, please call: +44 (0)1865 767676 or email: sales@unicol.com...
Page 2 01865 767676 sales@unicol.com www.unicol.com TOOLS REQUIRED INSTALLERS REQUIRED 3/16th Allen Key 17mm Spanner COMPONENTS DESCRIPTION TM05 Tube Clamp Safety Through-Bolt Grub Screws Securing Bolt Revised 30/05/24...
Page 3 STEP 2 STEP 1 The TM05 comes fully assembled, so simply place it Once in position, tighten the securing bolt so that it over the tube it is going to be mounted to. is tight against the pole and the tube clamp does not move when knocked or wiggled.
Page 4 Any Questions? +44 (0)1865 767676 sales@unicol.com unicol.com/instructions...
