TCD230042AC
Digital Counters / Timers
(Indicator)
FXY Series
PRODUCT MANUAL
For your safety, read and follow the considerations written in the instruction
manual, other manuals and Autonics website.
The specifications, dimensions, etc. are subject to change without notice for product
improvement. Some models may be discontinued without notice.
Features
• Counting speeds: 1 cps / 30 cps / 2 kcps / 5 kcps
• Switch between counter and timer operation using DIP switch
• Switch between voltage input (PNP) and no-voltage input (PNP) using DIP switch
• Set decimal point, hr / min / sec display with RESET key
• Operation modes: count-up, count-down, count-up / down (counter)
[Counter]
• 20 input modes
[Timer]
• Various time setting ranges
- 6-digit models: 0.01 sec to 99999.9 hr
- 4-digit models: 0.01 sec to 9999 hr
• Power supply
- 100 - 240 VACᜠ 50 / 60 Hz (AC type)
- 24 VACᜠ 50 / 60 Hz, 24 - 48 VDCᜡ (AC / DC universal type)
ᜢ ᜽ ᜧ ᜫ
Safety Considerations
• Observe all 'Safety Considerations' for safe and proper operation to avoid hazards.
• ᜸ symbol indicates caution due to special circumstances in which hazards may occur.
᜸ Warning
Failure to follow instructions may result in serious injury or death.
01. Fail-safe device must be installed when using the unit with machinery that
may cause serious injury or substantial economic loss. (e.g. nuclear power
control, medical equipment, ships, vehicles, railways, aircraft, combustion
apparatus, safety equipment, crime / disaster prevention devices, etc.)
Failure to follow this instruction may result in personal injury, economic loss or fire.
02. Do not use or store the unit in the place where flammable / explosive /
corrosive gas, humidity, direct sunlight, radiant heat, vibration, impact, or
salinity may be present.
Failure to follow this instruction may result in explosion or fire.
03. Install on a device panel to use.
Failure to follow this instruction may result in fire or electric shock.
04. Do not connect, repair, or inspect the unit while connected to a power
source.
Failure to follow this instruction may result in fire or electric shock.
05. Check 'Connections' before wiring.
Failure to follow this instruction may result in fire.
06. Do not disassemble or modify the unit.
Failure to follow this instruction may result in fire or electric shock.
᜸ Caution
Failure to follow instructions may result in injury or product damage.
01. When connecting the power / sensor input, use AWG 20 (0.50 mm
over, and tighten the terminal screw with a tightening torque of 0.74 to 0.90
N m.
Failure to follow this instruction may result in fire or malfunction due to contact
failure.
02. Use the unit within the rated specifications.
Failure to follow this instruction may result in fire or product damage.
03. Use a dry cloth to clean the unit, and do not use water or organic solvent.
Failure to follow this instruction may result in fire or electric shock.
04. Keep the product away from metal chip, dust, and wire residue which flow
into the unit.
Failure to follow this instruction may result in fire or product damage.
Cautions during Use
• Follow instructions in 'Cautions during Use' .
Otherwise, it may cause unexpected accidents.
• Power supply should be insulated and limited voltage / current or Class 2, SELV power
supply device.
• Use the product, 0.1 sec after supplying power.
• When supplying or turning off the power, use a switch or etc. to avoid chattering.
• Install a power switch or circuit breaker in the easily accessible place for supplying or
disconnecting the power.
• When the counter is operating, in case of contact input, set count speed to low speed
mode (1 cps or 30 cps) to operate. If set to high speed mode (2 k, 5 kcps) counting
error occurs due to chattering.
• Keep away from high voltage lines or power lines to prevent inductive noise. In case
installing power line and input signal line closely, use line filter or varistor at power line
and shielded wire at input signal line.
Do not use near the equipment which generates strong magnetic force or high
frequency noise.
• This unit may be used in the following environments.
- Indoors (in the environment condition rated in 'Specifications')
- Altitude max. 2,000 m
- Pollution degree 2
- Installation category II
) cable or
