- Page 1 3 HP Dust Collector Model: MDC-503L Laguna Tools 744 Refuge Way Grand Prairie, TX lagunatools.com...
-
Page 2: Scope Of This Manual
LAGUNA® and the LAGUNA Logo® are the registered trademarks of Laguna Tools, Inc. DISCLAIMER Laguna Tools is not responsible for errors or omissions. Specifications subject to change. Machines may be shown with optional accessories. Revision 01 (03/18/2024) -
Page 3: Table Of Contents
3 HP Dust Collector Table of Contents General Information and Safety ................ 6 Overview ............................6 Safety Signs and Call-Outs ......................6 Safety Warnings ..........................7 Additional Safety Information ......................8 Proposition 65 Warning of Harmful Exposure ................10 Specifications and Dimensions ............... 11 Specification Table ......................... - Page 4 3 HP Dust Collector Assembly and Setup ..................21 Exploded Diagram & Parts List ............... 25 10.0 Maintenance ...................... 28 11.0 Troubleshooting ....................29 12.0 Warranties ......................31...
- Page 5 3 HP Dust Collector NOTES:...
-
Page 6: General Information And Safety
Improper operation, maintenance, or modification of tools or equipment could result in serious injury or property damage. Laguna Tools equipment is designed for specific and limited applications. This product should neither be modified nor used for any application other than those for which it was designed. -
Page 7: Safety Warnings
3 HP Dust Collector Safety Warnings 1. Failure to comply with safety instructions may lead to personal injury and/or damage to the equipment. Do not operate the machine unless familiar with all safety instructions, warnings, and signs. 2. Do not operate the machine with the electrical cabinet door open–High Voltage Supply Inside. -
Page 8: Additional Safety Information
3 HP Dust Collector Additional Safety Information 1. All motion parameters have been set up by Laguna Tools. If any modifications are required, please have a professional operator perform the changes. 2. Safety Signs should be attached to places that are easy to spot. - Page 9 31. Never stand on the machine. Serious injury may occur if the machine is tipped or if the cutting tool is unintentionally contacted. 32. Consult the Owner’s Manual or Laguna Tools for recommended accessories. Using improper accessories will increase the risk of serious injury or damage.
-
Page 10: Proposition 65 Warning Of Harmful Exposure
American National Safety Institute, the UL Standards of safe tool use, and the IEC standards of safe tool use. Laguna Tools is in no way responsible for injury or death that occurs while using this product. -
Page 11: Specifications And Dimensions
3 HP Dust Collector 2.0 Specifications and Dimensions Specification Table Table 2-1: Specification Table Specifications AMPERAGE 10 AMP FOOTPRINT (L x W x H) 33.5” x 25”x 40” (850mm x 625mm x 1015mm) DUST PORT DIAMETER 4” (inches) MOTOR SPEED 3450 RPM MOTOR 3 HP... -
Page 12: Receiving The Machine
Contact Laguna Tools Customer Service as soon as possible in case of damage. It is advisable to photograph and document any shipping damage. The original packaging is required to return damaged equipment to Laguna Tools. - Page 13 3 HP Dust Collector NOTES: 3.0 Receiving the Machine...
-
Page 14: Components & Hardware
3 HP Dust Collector 4.0 Components & Hardware Figure 4–1: Components & Hardware 4.0 Components & Hardware... - Page 15 3 HP Dust Collector LETTER DESCRIPTION QUANTITY Main Collector Cabinet Debris Drawer Main Housing Cover Fireproof Collecting Bag Main Cabinet Casters Debris Drawer Casters Handle Hose Clamp Flat Head Screw ( ¼ “ x ½ “) Phillips Head Screw (M5 x 10) Flange Bolt ( 5/16 “...
- Page 16 3 HP Dust Collector NOTES: 4.0 Components & Hardware...
-
Page 17: Machine Placement
2. Select a solid level floor rated to hold the weight of the machine and workpieces under both static and dynamic loads. Laguna Tools recommends concrete flooring. Consult a licensed and experienced professional if in doubt. -
Page 18: Unloading & Unpacking The Machine
6.0 Unloading & Unpacking the Machine NOTE All shipping related claims for loss or damaged goods must be made to Laguna Tools within 24 hours of delivery. Contact Laguna Tools customer service department to make claims for any damaged items/parts. - Page 19 3 HP Dust Collector WARNING This machine is heavy. Seek assistance from an experienced professional if you have any doubt about the following unboxing or set up procedures. DO NOT attempt any procedure that you feel is unsafe or you believe you do not have the physical capability of achieving.
-
Page 20: Grounding Instructions
3 HP Dust Collector 7.0 Grounding Instructions The appliance must be grounded, if it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having equipment-ground conductor and grounding plug. The plug must be inserted into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 21: Assembly And Setup
3 HP Dust Collector 8.0 Assembly and Setup WARNING Do not connect to a power supply until set-up is complete. Do not perform any of the following steps, installations, or adjustments with the machine connected to a power source unless directed to do so. Tools &... - Page 22 3 HP Dust Collector NOTE All shipping related claims for loss or damaged goods must be made to Laguna Tools within 24 hours of delivery. Contact Laguna Tools customer service department to make claims for any damaged items/parts. The original packaging is required to return damaged goods within the warranty period.
- Page 23 3 HP Dust Collector 1. Turn the main housing (NO.38) upside down. 2. Install the main cabinet casters (NO. 40) onto four corners of the main cabinet and secure them by tightening the flange bolts (NO. 41) with the supplied wrench. 3.
- Page 24 3 HP Dust Collector 9. Install the handle (NO.30) on the debris drawer (NO.43) using a flat head screwdriver to tighten the flat head screw (NO.31). Figure 8–3: Cabinet Assembly Cont'd 10. Assembly is complete Figure 8–4: Cabinet Completely Assembled 8.0 Assembly &...
-
Page 25: Exploded Diagram & Parts List
3 HP Dust Collector 9.0 Exploded Diagram & Parts List 9.0 Exploded Diagram & Parts List... - Page 26 3 HP Dust Collector Table 9-1: Parts List Description Specification Front Cover Hook Base Countersunk Phillips Head Screw M4*8 Rivet Fixed plate buckle Filters Power Cord Bushing PG20 Hex. Head Bolts M6*20 Motor Plate Bar Washer 1/4”x16 Lock Nut Hex Cap Screw 5/16”*1 Flat Washer 5/16”*23*2...
- Page 27 3 HP Dust Collector Hex Cap Screw 3/8”*1/2” Washer Socket Head Cap Screw M6*20 Hose Clamp Fireproof Collecting Bag Swivel Buckle Handle Flat Head Screw 1/4”*1/2” Plastic Hinge Phillips Head Screw M4*12 Switch Plate Panel Handle Control Box Assembly Power Cord Buckle SB8R-1 Main Collector Cabinet Main Cabinet Casters...
-
Page 28: Maintenance
3 HP Dust Collector 10.0 Maintenance The SmartShop Auto Loader requires the operator to perform basic regular maintenance to ensure the normal operation of the equipment, reduce possible failures, and prolong the service life of the equipment. Follow this maintenance table to ensure proper use of the machine. Table 10-1: Maintenance Table Every Every six... -
Page 29: Troubleshooting
3 HP Dust Collector 11.0 Troubleshooting Table 11-1: Troubleshooting Table Symptom Possible Cause Possible Solution Machine does not start or Power supply switched OFF or is Ensure power supply is ON and has a breaker trips. faulty. the correct voltage. Wall fuse/circuit breaker is Ensure adequate circuit size;... - Page 30 3 HP Dust Collector Check fan and cover; replace as needed. Bad motor bearings. Rotate shaft manually, check for grinding or loose shaft, replace bearings if needed. Loud, repetitive noise, or Machine is on uneven surface. Stabilize on a flat surface. excessive vibration coming from cyclone Damaged/Unbalanced impeller.
-
Page 31: Warranties
Laguna Tools Customer Support Website. The labor required to install replacement parts is the responsibility of the user. Laguna Tools is not responsible for damage or loss caused by a freight company or other circumstances not in our control. All claims for loss or damaged goods must be notified to Laguna Tools within twenty-four (24) hours of delivery. - Page 32 3 HP Dust Collector Laguna Tools Warranty 12.0 Warranties...
- Page 33 Laguna Tools, Inc. 744 Refuge Way Grand Prairie, TX 75050 800-234-1976 www.lagunatools.com Copyright © 2023 Laguna Tools, Inc. All rights reserved.
