Quick Start Guide
40V
STRING TRIMMER
& BRUSH CUTTER
Depending on the model purchased, packaging will contain
different accessories and parts.
Refer to the package for more details.
Europe
www.greenworkstools.eu
USA
www.greenworkstools.com
Canada
www.greenworkstools.ca
P0804476-00 Rev B
KNOW YOUR MACHINE
2
4
3
5
1
6
7
8
12
9
11
10
1.
Trigger
7.
Lower shaft
2.
Lock-out button
8.
Guard cap
3.
Upper shaft
9.
Trimmer head
4.
Carrying ring
10. Cut-off blade
5.
Auxiliary handle
11. Guard
6.
Coupler
12. Cutting blade
OPERATION
Install the battery
Start the machine
1. Press
2. Pull
INSTALLATION
1
Attach the guard
Assemble the shaft
6
Operation tips
7
Keep a firm hold with two hands
on the machine.
2
Attach the auxiliary handle
Attach the shoulder strap
3
8
Adjust the length of the cutting line
Cut tall grass
from the top down.
Adjust the cutting diameter
4
5
9
10
