Flex FXA1451 Operator's Manual

24v brushless impact wrench
Hide thumbs

Advertisement

Table of Contents

OPERATOR'S MANUAL
Model:
FXA1451
24V BRUSHLESS IMPACT WRENCH
WARNING: To reduce the risk of injury, the user must read and understand the
Owner's Manual before using this product. Save these instructions for future reference.
Please contact FLEX customer service in Australia 1300 000 346 or
New Zealand 0508 000 346 any time you have questions or warranty claims.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FXA1451 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Flex FXA1451

Summary of Contents for Flex FXA1451

  • Page 1 WARNING: To reduce the risk of injury, the user must read and understand the Owner’s Manual before using this product. Save these instructions for future reference. Please contact FLEX customer service in Australia 1300 000 346 or New Zealand 0508 000 346 any time you have questions or warranty claims.

  • Page 2: Safety Symbols

    SAFETY SYMBOLS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.

  • Page 3: General Power Tool Safety Warnings

    GENERAL POWER TOOL SAFETY WARNINGS Read all safety warnings, instructions, illustrations and specifications WARNING provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE. The term “power tool”...
  • Page 4 Power tool use and care Battery tool use and care Do not force the power tool. Use the correct Recharge only with the charger specified by power tool for your application. The correct the manufacturer. A charger that is suitable for power tool will do the job better and safer at the one type of battery pack may create a risk of fire rate for which it was designed.
  • Page 5 SAFETY WARNINGS FOR IMPACT WRENCH Hold the power tool by insulated gripping surfaces, when performing an operation where the fastener may contact hidden wiring. Fasteners contacting a “live” wire may make exposed metal parts of the power tool “live” and could give the operator an electric shock.
  • Page 6 SYMBOLS IMPORTANT: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. Symbol Name Designation/Explanation Volts Voltage Amperes Current Hertz...
  • Page 7 Symbol Name Designation/Explanation Wear ear protection symbol Alerts user to wear ear protection This product complies with applicable Regulatory compliance mark Australian standards.
  • Page 8 Strap Fixing Removable For attaching a wrist strap (not Belt Clip included) in order to reduce the chances of dropping your tool. Model no. FXA1451 Rated voltage 24 V d. c. Square drive 12.7 mm (1/2'') No-load speed 0-450/1600/2700 /min (RPM)
  • Page 9 ASSEMBLY Detach the battery pack WARNING Fig. 2 from the tool before making any assembly, adjustments or Attach changing accessories. Such preventive safety measures reduce the risk of starting the tool accidentally. TO ATTACH/DETACH BATTERY PACK (FIG. 2) Lock the variable-speed trigger switch “OFF” on the tool by placing the direction-of-rotation (forward/centre-lock/reverse) selector in the centre position before attaching or detaching...
  • Page 10 INSTALL AND REMOVE THE IMPACT Fig. 4 SOCKET (FIG. 4) Make sure that the impact CAUTION socket and the mounting portion are not damaged before installing Impact socket the impact socket. To install the impact socket: a. Align the square of the impact socket with the square drive and push the impact socket onto the square drive as far as it will go.
  • Page 11 ADJUSTMENTS Fig. 5 DIRECTION-OF-ROTATION (FORWARD/ CENTRE-LOCK/REVERSE) SELECTOR After tool use, lock the WARNING direction-of-rotation selector in the “OFF” position (centre-lock) to help prevent accidental starts and possible injury. Your tool is equipped with a direction-of-rotation selector, located above the variable-speed trigger switch.
  • Page 12 LED LIGHT (FIG. 7) Fig. 7 Your tool is equipped with the LED work light. This provides additional light on the surface of the workpiece for operation in lower-light areas. The LED work light will automatically turn on with a slight squeeze on the trigger switch before the tool starts running.
  • Page 13 To select the “A” mode: touching the trigger switch. The LED indicator beside the “A” button will illuminate to indicate First, check the active mode. Either depress the current mode setting. See more details in and release the trigger switch or press the the chart below: drive control button or the “A”...
  • Page 14 This brushless impact wrench must be used this product until the parts are replaced. Use only with the FLEX 24V series battery packs of this product with damaged or missing parts and chargers could result in serious personal injury.
  • Page 15 TO LOOSEN NUTS AND BOLTS b. Hold the tool firmly and place the socket over the bolt or nut. Ensure that full length of the Use either mode 1, 2, 3 or “A” mode to loosen bolt head or nut is fully engaged into socket. nuts and bolts depending on the application.

  • Page 16: Maintenance

    We recommend that compressed air. Ventilation openings and all tool service be performed by a FLEX Factory switch levers must be kept clean and free of Service Centre or Authorized FLEX Service foreign matter.

  • Page 17: Warranty Statement

    If the Customer registers its purchase of the Product online at www.flex-tools.com.au or by calling • 1300 000 346 in Australia or www.flex-tools.co.nz or by calling 0508 000 346 in New Zealand within 30 days of the date of its purchase (Registration), the Warranty Period for the following Products is as follows: FLEX 24V Tools: 5 years;...

  • Page 18: Warranty Claims

    The Warranty does not apply if: a) the Product is not supplied in its final shape and form by Chervon or an authorised FLEX Dealer, which can be confirmed on the website store locator (for avoidance of doubt, third party online stores such as eBay, Gumtree, Amazon, etc.
  • Page 19 *Original purchaser must register the product(s) within 30 days of purchase and retain their receipt as proof of purchase. This warranty applies only to the original purchaser from an authorised FLEX dealer and may not be transferred. If original purchaser does not register their product within 30 days, the warranty will apply for the duration set out in table above in column ‘LIMITED...
