Delta Children BB81554GN Manual

Delta Children BB81554GN Manual

Sleep n store sleep n store toddler bed
Hide thumbs

Advertisement

Quick Links

Download this manual
Read all instructions
before assembly and use.
KEEP INSTRUCTIONS FOR
FUTURE USE.
Style #:
___________
Lot:
___________
A
REV
Date:
___________
Before contacting Delta Consumer
Experience Center please ensure this
information matches the information
matches the information found on the
label on the Headboard Panel.
To Make Assembly Even
Easier Watch Video Here!
ADULT ASSEMBLY REQUIRED
Due to the presence of small parts during assembly,
keep out of reach of children until assembly is complete.
This product is not intended for institutional or commercial use.
Sleep N Store
Toddler Bed
For Questions or
to Contact Us:
DeltaChildren.com/Help
If unable to access website, please email
tcs@DeltaChildren.com
Expect longer response times via email.
August 24, 2023, BB81554GN, R0

Advertisement

loading
Need help?

Need help?

Do you have a question about the BB81554GN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Delta Children BB81554GN

Summary of Contents for Delta Children BB81554GN

  • Page 1 Before contacting Delta Consumer Experience Center please ensure this This product is not intended for institutional or commercial use. information matches the information matches the information found on the August 24, 2023, BB81554GN, R0 label on the Headboard Panel.
  • Page 2 NEED A MATTRESS? ORDER NOW AND SAVE 15%, FROM THE BRANDS YOU TRUST USE CODE: MATTRESS15 @deltachildren | DeltaChildren.com | 114 W26th St. New York. NY 10001...

  • Page 3: Notes On Assembly

    NOTES ON CARE AND MAINTENANCE: - Do not - Inspect the product periodically, contact Delta Children's Products for replacement parts or questions. - Do not store the product or any parts in extreme temperatures and conditions such as a hot attic or a damp, cold basement.
  • Page 4 PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT Make sure all parts are in perfect condition before assembly Middle Leg x2 Head side Rail - Right x1 Headboard x1 Slat x10 Bottom Ledge x2 Footboard x1 Bottom Shelf x1 Foot Side Rail - Left x1 Center Slat x1 Storage Support Left x1...
  • Page 5 PARTS: HARDWARE KITS PART BOOK STORAGE BED NOTE: FASTENERS ARE SHOWN FULL SIZE M6x25 Screw x14 M4x40 Screw x27 M4x38 Screw x8 Cam Screw M6x32.5 x4 d5x30 mm Wood Dowel x2 M4x8 mm Barrell Nut x27 Leg x4 Leg Plate x4 Cam Connector D15*9.5 mm x4 M4 Allen + phillips Wrench (included) x1 Color Sticker...
  • Page 6 STEP 1: Align Foot Side Rail Left (C) with Head Side Rail Left (E). STEP 2: M6x25 Screw x4 Connect Foot Side Rail Left (C) with Head Side Rail Left (E) using Bottom Ledge (G) and securing it with screws BB.
  • Page 7 STEP 3: Align Foot Side Rail Right (D) with Head Side Rail Right (F). STEP 4: M6x25 Screw x4 Connect Foot Side Rail Right (D) with Head Side Rail Right (F) using Bottom Ledge (G) and securing it with screws BB.
  • Page 8 STEP 5: M4x8 mm Barrell Nut x2 M4x40 Screw x2 Insert Barrell Nut (EE)in the holes of Head Side Rail Right (F), bring the Headboard (A) perpendicularly to the side rail and attach both panels with screws AA.
  • Page 9 STEP 6: M4x8 mm Barrell Nut x2 M4x40 Bolt x2 Insert Barrell Nut (EE)in the holes of Head Side Rail Left (E), bring to the Headboard (A) and attach both panels with screws AA.
  • Page 10 STEP : PULL GENTLY M4x38 Screw x2 Gently pull the left side of the bed, place Outer Slats (O) in the holes near the Headboard (A) and fasten to both sides of the frame with screws CC. Then, place Slats (M) in their corresponding position holes of the frame.
  • Page 11 STEP : PULL GENTLY M4x38 Screw x6 Gently pull the left side of the bed, place Center Slats (N) in the center of the bed and fasten to both Outer Slats (O) and fasten to both sides of the frame with screws CC.
  • Page 12 STEP 9: d5x30 mm Wood Dowel x2 M4x8 mm Barrell Nut x2 M4x40 Bolt x2 Insert Barrell Nut (EE) and Dowels (FF) in Foot Side Rail Left (C) and Foot Side Rail Right (D) to attached Footboard (B) with screws AA.
  • Page 13 STEP 10:...
  • Page 14 STEP 11: M6x25 Screw x2...
  • Page 15 STEP 12: M4x8 mm Barrell Nut x16 M4x40 Screw x16 Attache each Leg GG to a Leg Plate HH with Screw BB, then attach each plate to a corner of the bed with Barrel Nut (EE) and Screws AA...
  • Page 16 STEP 13: Shelf Side x3 CHOOSE WHICH PANEL TO INSTALL Cam Screw M6x32.5 x4 Attach cam screws (DD) to the desired shelf side (K)
  • Page 17 STEP 14: Cam Connector D15*9.5 mm x4 Insert cam connectors (JJ) into the larger holes on the bottom shelf (H) and the inside panels of Storage Supports Left (I) and Right (J). Next, connect the pieces with shelf side (K). Finally, turn the cam connectors (JJ) to lock the shelf pieces in place.
  • Page 18 STEP 15: M4x8 mm Barrell Nut x2 M4x40 Screw x2 Insert barrel nut (EE) into the small holes on the bottom of shelf (H), then attach Storage Supports Left (I) and Right (J) using screws AA...
  • Page 19 2-side option Book Shelf installation...
  • Page 20 STEP 16: M4x8 mm Barrell Nut x3 M4x40 Screw x3 back view Left & Right inside view Insert a barrel nut into the hole at the center of the shelf (H) and into the inside panels of Storage Supports Left (I) and Right (J). Attach the Book Shelf to either side of the bed using screws AA.
  • Page 21 Color Sticker...

  • Page 22: Limited Warranty

    Para reportarcualquier problema por favor entre a www.DeltaChildren.com/help Fecha de Compra: _____________ (debe además mantener su recibo) Delta Children’s Products Corp |114 West 26th Street New York, NY 10001...
  • Page 23 WHY CHOOSE Visit for more information Over GIVES CARES WITH YOU Our Family-Run 1 Out Of 2 Children We Test Above & We Have Products Safety, Style Company Has Been In The U.S. Sleep In Go Toward Improving Beyond Industry For Every Age &...
