  • Page 1 Owner's Manual VBPEX5 VBPEX5 VBPEX5 VBPEX5 VBPEX5 5" LCD MONITOR...

  • Page 2: Important Notice

    In the interest of safety, the VBPEX5 should never be installed where it will be visible, directly or indirectly, by the operator of the motor vehicle.
  • Page 3 A. Introduction Thank you for selecting the VBPEX5, 5 inch Liquid Crystal Display (LCD ) Monitor. The VBPEX5 can be connected to the VBP3000 and VBP4000, (Please contact Audiovox's retailers). The connection of the Monitor is plug and play. The Monitor utilizes the latest state of the art electronics and is designed for use in vehicles, hotels, offices or your home and is constructed to provide years of reliable, trouble-free service.
  • Page 4 D. Positioning the Monitor Option 1 Vehicle Headrest (Refer to Figure 1) Loop the strap of the pouch around the headrest in the vehicle, and pull the end of the strap while holding the buckle until the pouch is tightly secured. Option 2 Flat Surface (Refer to Figure 2) Rotate the base of Monitor backward and place it on a flat surface.
  • Page 5 E. Controls/Indicators/Connectors (Refer to Figure 3) Figure 3 1. Headphone Jack 2. 12V DC Input Jack 3. Remote Control Sensor: The sensor will relay commands to the either the VPB3000 or VBP4000. 4. Power LED Indicator 5. Power Switch 6. TV/VCP (Video Cassette Player) Select Switch 7.
  • Page 6 F. Powering the Unit NOTE: When the VBPEX5 is connected to either a VBP3000 or VBP4000 using the supplied DIN cable, there is no need for a power source to be connected to the DC 12V IN jack. Option 1 Indoor Power (Refer to Figure 4)
  • Page 7 DIN CABLE Figure 7 Using the DIN cable supplied with the VBPEX5, connect one end of the DIN cable to the Monitor Port (Input) located on the side of the Monitor. Connect the other end of the DIN cable to the either of the Monitor Ports (Output) on the rear of the VBP3000 or the side of the VBP4000.
  • Page 8 Monitor to the VCP position. H. Using External Audio/Video Sources (Refer to Figure 8) Connect the VBPEX5 to an external power source. Refer to Figure 4 and Figure 5. Plug the external source audio/video signals into the appropriate jacks on the side of the Monitor.
  • Page 9 VCP switch to the VCP position. 4. When connecting an external signal source to the VIDEO IN, AUDIO L IN, AUDIO R IN jacks on the VBPEX5, the TV/VCP switch can be set to either the TV or VCP position.

  • Page 10: 90-Day Limited Warranty

    This Warranty gives you specific legal rights and you may also have other rights, which vary from state to state. U.S.A.: AUDIOVOX ELECTRONICS CORP., 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788 ! 1-800-645-4994 CANADA: CALL 1-800-645-4994 FOR LOCATION OF WARRANTY STATION SERVING YOUR AREA 7 7 7 7 7 ©...
  • Page 11 NOTES...
  • Page 12 For Customer Service Visit Our Website At .audiovox.com Product Information, Photos, FAQ’s Owner’s Manuals 128-6325 © 2002 Audiovox Electronics Corp., Hauppauge, NY 11788...
