LAUNCH UPRIGHT BIKE

OWNER'S MANUAL AND ASSEMBLY GUIDE

Table of Contents

Need help?

Do you have a question about the LAUNCH UC3-0A-35 and is the answer not in the manual?

Questions and answers

Summary of Contents for True Fitness LAUNCH UC3-0A-35

Page 1 LAUNCH UPRIGHT BIKE OWNER’S MANUAL AND ASSEMBLY GUIDE...
Page 2: Important-Please Read
Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the appropriate sales representative to help answer your questions. • Phone | 800.426.6570 • Email | sales@truefitness.com • Hours | Monday - Friday 8:30am - 5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.
Page 3: Reporting Freight Claims Or Parts Damage
Once you have called the carrier you will need to gather the serial number, model number, description of damage, and photos of damage. Contact TRUE product support (service@truefitness.com | 800.883.8783) or TRUE sales support (sales@truefitness.com | 800.426.6570) Monday-Friday during normal business hours. © 2025 TRUE Fitness All Rights Reserved.
Page 4: Table Of Contents
WARRANTY DETAILS ..............40 WARRANTY REGISTRATION ............41 ASSEMBLY INSTRUCTIONS PREASSEMBLY CHECKLIST............11 ASSEMBLY STEPS.................14 PRODUCT FEATURES BASE OVERVIEW................29 CONSOLE OVERVIEW..............30 CARE AND MAINTENANCE INSPECTION................32 CLEANING THE EQUIPMENT............32 LUBRICATION............32 LEVELING THE MACHINE..............33 PREVENTATIVE MAINTENANCE............34 LONG TERM STORAGE..............34 © 2025 TRUE Fitness All Rights Reserved.
Page 5: Safety Instructions
Do not use this product outdoors, near water, while wet, or in areas of high • Do not move the equipment by lifting the console. Do not use the console as a humidity including extreme temperature changes. handlebar during a workout. © 2025 TRUE Fitness All Rights Reserved.
Page 6 The batteries within self-generated equipment contain materials that are considered used with the optional power supply. Non-LED consoles require hazardous to the environment. Federal law requires proper disposal of these the optional power supply. batteries. © 2025 TRUE Fitness All Rights Reserved.
Page 7: Power Requirements
NOTE: The plug configuration for the power adapter may vary by country. NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply.* © 2025 TRUE Fitness All Rights Reserved.
Page 8: Space Requirements
DIMENSIONS (L X W X H) 44” x 24” x 59” / 111cm x 61cm x 150cm • MACHINE WEIGHT 146 lbs / 66 kg • MAXIMUM USER WEIGHT 400 lbs / 181 kg © 2025 TRUE Fitness All Rights Reserved.
Page 9: Warning Decals
Intertek Testing Services Taiwan Ltd. base serial number location 95.7mm UC900 ETL-Serial Number Sticker 4/6/20 update control # COMPLIANCES This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.truefitness.com. © 2025 TRUE Fitness All Rights Reserved.
Page 10: Proper Use
Home screen in addition to the pedals coming to a complete stop. While firmly grasping the handlebars to maintain balance, slowly slide your body off the seat and feet from the pedals to transition to a standing position free from the bike. © 2025 TRUE Fitness All Rights Reserved.
Page 11: Assembly Instructions
TOOLS NEEDED FOR ASSEMBLY INCLUDED IN BOX TOOLS NEEDED FOR ASSEMBLY INCLUDED IN BOX 3mm Allen Wrench #2 Phillips Screwdriver 6mm Ball Allen Wrench Wire Cutters 13mm/15mm/17mm Combination Wrench Torque Wrench with 15mm Head © 2025 TRUE Fitness All Rights Reserved.
Page 12 BOX CONTENTS ITEM DESCRIPTION BASE LEFT PEDAL RIGHT PEDAL SEAT PAD HANDLEBAR WATER BOTTLE HOLDER CONSOLE MAST MAST BOOT FRONT STABILIZER REAR STABILIZER HARDWARE PACK TOOL BAG MANUAL © 2025 TRUE Fitness All Rights Reserved.
Page 13 CS80112 BHCS, M8 X 16MM, BLK ZP, NYLON PATCH UCS0070002 13MM/15MM/17MM COMBINATION WRENCH VC90142 LOCK WASHER, M8 BLK C1093 WASHER, FLAT, M8, ZP UCS0070003 #2 PHILLIPS SCREWDRIVER UCS20072 BHCS, M5 X 10, BLACK © 2025 TRUE Fitness All Rights Reserved.
Page 14: Assembly Steps
B. Using a 6mm ball end allen wrench, install the rear stabilizer bar into the metal bracket using 2 screws, 2 lock washers, and 2 flat washers. © 2025 TRUE Fitness All Rights Reserved.
Page 17 Optional Step 3—Install Auxiliary Power Supply Continued B. Connect the AC power cord to the power supply. C. Connect the DC power cable to the power supply. Secure the power supply to the frame using 2 zip ties. © 2025 TRUE Fitness All Rights Reserved.
Page 18 Optional Step 3—Install Auxiliary Power Supply Continued D. Using a #2 Phillips screwdriver, reattach the left shroud, the left pedal crank crank cap, and the left pedal crank cover using the 15 screws you removed previously. © 2025 TRUE Fitness All Rights Reserved.
Page 19 IMPORTANT! Make sure cables are clear from screws to avoid damage. E. Slide the mast boost down the console mast over the base. I/O Data Network Coaxial Power © 2025 TRUE Fitness All Rights Reserved.
Page 20 B. Using the 13mm end of the 13mm/15mm/17mm combination wrench, install the seat saddle onto the seat post mounting plate using the 3 nuts and 3 flat washers you removed. NOTE: The threaded rods on the bottom of the seat pad will align with the 3 openings on the seat post mounting plate. © 2025 TRUE Fitness All Rights Reserved.
Page 21 6—Route Handlbear Cables While one person holds the handlebar securely in place, route the handlebar cables through the front mast. IMPORTANT! DO NOT pinch the cables. I/O Data Network Coaxial Power Heart Rate © 2025 TRUE Fitness All Rights Reserved.
Page 22 LOCK WASHER, M8 BLK ZP Using a 6mm allen wrench, attach the handlebar to the C1093 WASHER, FLAT, M8, ZP front mast using 4 hex screws, 4 lock washers, and 4 flat washers. © 2025 TRUE Fitness All Rights Reserved.
Page 23 Item Part Description 3mm Allen Wrench CB8U012 TUBE, CUP HOLDER UCS20072 BHCS, M5 X 10, BLACK Using a 3mm allen wrench, attach the water bottle holder to the console mast using 2 hex screws. © 2025 TRUE Fitness All Rights Reserved.
Page 24 15mm head. NOTE: The left pedal is reverse-threaded (turn counter-clockwise to tighten). when using a torque wrench = 40 N-M (29.5 FT-LB) when using a torque wrench = 40 N-M (29.5 FT-LB) © 2025 TRUE Fitness All Rights Reserved.
Page 26 NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non- LED consoles require the optional power supply. Insert the appropriate power cord into the corresponding power inlet. © 2025 TRUE Fitness All Rights Reserved.
Page 28 Please follow the instructions included with your console for important configuration and calibration steps. Please contact product support right away if you run into issues setting up the machine: 800.883.8783 | service@truefitness.com | Monday–Friday 8:30am–5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.
Page 29: Product Features Base Overview
Delivers power from the wall outlet to the bike. NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non- LED consoles require the optional power supply. © 2025 TRUE Fitness All Rights Reserved.
Page 30: Console Overview
CONSOLE OVERVIEW UNITE TOUCHSCREENS (16” SHOWN) Android OS Touchscreen Choose Workout Bluetooth Compatible Apple Watch Compatible Choose Language Galaxy Watch Compatible Lock Screen for Cleaning Tap to Pair Wireless Charging HDMI 3.5mm Headphone Jack © 2025 TRUE Fitness All Rights Reserved.
Page 32: Care And Maintenance
CARE AND MAINTENANCE It is important to perform the minor maintenance tasks described in this section. Failure to maintain the bike as described here could void the TRUE Fitness Warranty. To reduce the risk of electrical shock, always unplug the unit from its power source before cleaning or performing any maintenance tasks.
Page 34: Preventative Maintenance
TRUE recommends that quarterly scheduled maintenance be performed by a qualified service technician. Please contact your dealer or visit www.truefitness.com to contact a local TRUE authorized service technician. IMPORTANT! Use only TRUE Fitness certified service providers. Using non-authorized service providers could void the TRUE Warranty. Frequency...
Page 35: Additional Information Troubleshooting
Error code is displayed on console Contact TRUE product support Pinched or loose main communication cable No User Present displayed on screen User weight must be over 90lbs. Verify No User Present settings in console. © 2025 TRUE Fitness All Rights Reserved.
Page 36 Cables are pinched or damaged Contact TRUE product support Contact Heart Rate not displaying Nucleus board may be damaged Contact TRUE product support Heart Rate Grips may be damaged Contact TRUE product support © 2025 TRUE Fitness All Rights Reserved.
Page 37: Wiring Diagrams
WIRING DIAGRAMS UCS0074 UCS0074 HRL/HRR UCS0072 COAX UCS0073 ETHERNET UC0014 I/O-PWDC UC0015 PWDC UC0015 (PWR MODE) PWDC UCS0071 UCS0011 PWDC BARREL 00588900 SRS0030 SRS0029 CB8U016 AC PWR © 2025 TRUE Fitness All Rights Reserved.
Page 38: Warranty Information Commercial Warranty
Coax/TV, HDMI, USB, mirroring or Bearings Ethernet connections, and safety key. Labor** 1 Year See Warranty Details for terms, conditions, and complete coverage details. Wear Items*** 90 Days © 2025 TRUE Fitness All Rights Reserved.
Page 39: Limited-Use Commercial Warranty
LIMITED-USE COMMERCIAL WARRANTY* TRUE Fitness may offer alternative warranties to purchasers of CARDIO commercial equipment for limited-use commercial* or in-home use.** This policy ensures that customers who use commercial LAUNCH equipment for limited-use commercial or in-home use may WARRANTY GRAVITY...
Page 40: Warranty Details
WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original registered product purchaser and the parts of the TRUE product (the “Product”) listed below, under normal use and service, shall be free of manufacturing defects in workmanship and materials only for the specified period of time.
Page 41: Warranty Registration
4/6/20 update control # number location WARRANTY REGISTRATION Base Serial Number Console Serial Number Purchase Date Company (if applicable) Customer Name (First and Last) Email Address Phone Number Street Address City State Postal Code Country © 2025 TRUE Fitness All Rights Reserved.
Page 42 CONTACT US service@truefitness.com 800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-UC3-0A-35 Owner’s Manual and Assembly Guide REV05 © 2025 TRUE Fitness All Rights Reserved.
