APEX RECUMBENT BIKE

OWNER'S MANUAL AND ASSEMBLY GUIDE

Table of Contents

Need help?

Do you have a question about the APEX RC1-0B-35 and is the answer not in the manual?

Questions and answers

Summary of Contents for True Fitness APEX RC1-0B-35

Page 1 APEX RECUMBENT BIKE OWNER’S MANUAL AND ASSEMBLY GUIDE...
Page 2: Important-Please Read
Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the appropriate sales representative to help answer your questions. • Phone | 800.426.6570 • Email | sales@truefitness.com • Hours | Monday - Friday 8:30am - 5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.
Page 3: Reporting Freight Claims Or Parts Damage
Once you have called the carrier you will need to gather the serial number, model number, description of damage, and photos of damage. Contact TRUE product support (service@truefitness.com | 800.883.8783) or TRUE sales support (sales@truefitness.com | 800.426.6570) Monday-Friday during normal business hours. © 2025 TRUE Fitness All Rights Reserved.
Page 4: Table Of Contents
WARRANTY DETAILS ..............44 WARRANTY REGISTRATION ............45 ASSEMBLY INSTRUCTIONS PREASSEMBLY CHECKLIST............11 ASSEMBLY STEPS.................15 PRODUCT FEATURES BASE OVERVIEW................33 CONSOLE OVERVIEW..............34 CARE AND MAINTENANCE INSPECTION................36 CLEANING THE EQUIPMENT............36 LUBRICATION............36 LEVELING THE MACHINE..............37 PREVENTATIVE MAINTENANCE............38 LONG TERM STORAGE..............38 © 2025 TRUE Fitness All Rights Reserved.
Page 5: Safety Instructions
Use this equipment only for its intended use as described in this manual. • Do not use this product in areas where aerosol spray products are being used or where oxygen is being administered. Such substances create the danger of combustion and explosion. © 2025 TRUE Fitness All Rights Reserved.
Page 6 9V DC 1.5 amp output for console operation only. the optional power supply. • The batteries within self-generated equipment contain materials that are considered hazardous to the environment. Federal law requires proper disposal of these batteries. © 2025 TRUE Fitness All Rights Reserved.
Page 7: Power Requirements
NOTE: The plug configuration for the power adapter may vary by country. NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply. © 2025 TRUE Fitness All Rights Reserved.
Page 8: Space Requirements
DIMENSIONS (L X W X H) 58” x 27” x 51” / 147cm x 68cm x 130cm • MACHINE WEIGHT 181 lbs / 82 kg • MAXIMUM USER WEIGHT 400 lbs / 181 kg © 2025 TRUE Fitness All Rights Reserved.
Page 9: Warning Decals
To replace any worn or missing decals contact TRUE product support (service@truefitness.com | 800.883.8783). console serial number location base serial number location COMPLIANCES This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.truefitness.com. © 2025 TRUE Fitness All Rights Reserved.
Page 10: Proper Use
Home screen in addition to the pedals coming to a complete stop. While firmly grasping the handlebars to maintain balance, slowly slide your body off the seat and feet from the pedals to transition to a standing position free from the bike. © 2025 TRUE Fitness All Rights Reserved.
Page 11: Assembly Instructions
INCLUDED IN BOX TOOLS NEEDED FOR ASSEMBLY INCLUDED IN BOX 5mm Allen Wrench #2 Phillips Screwdriver 6mm Allen Wrench Wire Cutters 8mm Allen Wrench Torque Wrench with 15mm Head 15mm Wrench 19mm Wrench © 2025 TRUE Fitness All Rights Reserved.
Page 12 BASE SEAT HANDLEBAR SEAT BACK FRAME COVER SEAT BACK FRAME BOTTOM CONSOLE COVER FRONT MAST REAR CONSOLE COVER LEFT PEDAL RIGHT PEDAL FRONT STABILIZER REAR STABILIZER REAR SEAT PIVOT COVER HARDWARE BAG(S) MANUAL © 2025 TRUE Fitness All Rights Reserved.
Page 13 WASHER, FLAT, 5.5MM X 15MM, T=1MM RCS0382 WASHER, SPRING M8 PS0099 Step 7—Seat Back Frame Cover Hardware FLAT WASHER, 8MM X 19MM X ITEM DESCRIPTION CM8-19FW BHCS, M5-0.85 X 15MM FE0187 BOLT FHCS M8x1.25_20 BZ CM8-125- 20FH © 2025 TRUE Fitness All Rights Reserved.
Page 14 WASHER, SPRING, M10 FE0090 WASHER, FLAT, 10MM X 20MM, 6MM ALLEN WRENCH T=2MM RCS0369 78008949 Step 12—Console Covers Hardware ITEM DESCRIPTION 8MM ALLEN WRENCH PHMS, M4-0.7 X 10MM, PHILLIPS TCS4029 15MM COMBINATION WRENCH RCS004615 © 2025 TRUE Fitness All Rights Reserved.
Page 15: Assembly Steps
NOTE: At least one person should hold the bike frame, while another installs the rear stabilizer. B. Using a 8mm allen wrench, install the rear stabilizer into the metal bracket using 2 hex screws, 2 spring washers, and 2 flat washers. © 2025 TRUE Fitness All Rights Reserved.
Page 16 B. Using a 8mm allen wrench, install the front stabilizer into the metal bracket using 2 hex screws, 2 spring washers, and 2 flat washers. NOTE: Remove any packing debris from the seat rail assembly. © 2025 TRUE Fitness All Rights Reserved.
Page 17 NOTE: If attaching optional armrest handlebar, refer to armrest handlebar assembly guide for steps 3-7. Thumbswitch Thumbswitch Cable Cable Right Contact Right Contact Heart Rate Cable Heart Rate Cable Left Contact Left Contact Heart Rate Cable Heart Rate Cable © 2025 TRUE Fitness All Rights Reserved.
Page 18 C. Using a 6mm allen wrench, finish attaching the seat handlebar bracket to the seat carriage using 2 hex screws, 2 spring washers, and 2 flat washers. NOTE: If attaching optional armrest handlebar, refer to armrest handlebar assembly guide for steps 3-7. © 2025 TRUE Fitness All Rights Reserved.
Page 19 8 hex screws, 8 lock washers, and 8 flat washers. NOTE: Tighten the 4 back hex screws before the 4 side hex screws. NOTE: If attaching optional armrest handlebar, refer to armrest handlebar assembly guide for steps 3-7. © 2025 TRUE Fitness All Rights Reserved.
Page 20 B. Using a #2 Phillips screwdriver, secure the rear seat pivot cover to the seat carriage using 2 screws and 2 flat washers. NOTE: If attaching optional armrest handlebar, refer to armrest handlebar assembly guide for steps 3-7. © 2025 TRUE Fitness All Rights Reserved.
Page 21 Using a #2 Phillips screwdriver, attach the seat back frame cover to the seat back frame using 7 screws. NOTE: If attaching optional armrest handlebar, refer to armrest handlebar assembly guide for steps 3-7. © 2025 TRUE Fitness All Rights Reserved.
Page 22 = 40 N-M (29.5 FT-LB) torque each pedal to 40 N-M (29.5 FT-LB) using an optional but preferred torque wrench with a 15mm head. NOTE: The left pedal is reverse-threaded (turn counter-clockwise to tighten). © 2025 TRUE Fitness All Rights Reserved.
Page 23 IMPORTANT! Do NOT pinch the cables. C. Remove the pull tie from the cables and discard it. I/O Data D. Install the front mast onto the bike frame. Network Coaxial Power Heart Rate Button Control © 2025 TRUE Fitness All Rights Reserved.
Page 24 IMPORTANT! Do NOT pinch the cables. IMPORTANT! Make sure cables are clear from hex screws to avoid damage. B. Slide the bottle holder down over the bottom of the front mast tube. © 2025 TRUE Fitness All Rights Reserved.
Page 26 B. Slide the bottom console cover up the front mast until it meets with the rear console cover. C. Using a #2 Phillips screwdriver, attach the bottom console cover to the front mast using the remaining 2 screws. © 2025 TRUE Fitness All Rights Reserved.
Page 27 Non-LED consoles require the optional power supply. A. Using a #2 Phillips screwdriver, remove the 7 screws from the right rear shroud before removing it. © 2025 TRUE Fitness All Rights Reserved.
Page 29 Optional Step 13-Install Auxiliary Power Supply Continued E. Using a #2 Phillips screwdriver, re-install the right rear shroud to the bike frame using the 7 screws you removed previously. © 2025 TRUE Fitness All Rights Reserved.
Page 31 NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply. Insert the appropriate power cord into the corresponding power inlet. © 2025 TRUE Fitness All Rights Reserved.
Page 32 Please follow the instructions included with your console for important configuration and calibration steps. Please contact product support right away if you run into issues setting up the machine: 800.883.8783 | service@truefitness.com | Monday–Friday 8:30am–5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.
Page 33: Product Features Base Overview
L. Power Supply Inlet are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply. Delivers power from the wall outlet to the bike. © 2025 TRUE Fitness All Rights Reserved.
Page 34: Console Overview
CONSOLE OVERVIEW UNITE TOUCHSCREENS (16” SHOWN) Android OS Touchscreen Choose Workout Bluetooth Compatible Apple Watch Compatible Choose Language Galaxy Watch Compatible Lock Screen for Cleaning Tap to Pair Wireless Charging HDMI 3.5mm Headphone Jack © 2025 TRUE Fitness All Rights Reserved.
Page 36: Care And Maintenance
CARE AND MAINTENANCE It is important to perform the minor maintenance tasks described in this section. Failure to maintain the bike as described here could void the TRUE Fitness Warranty. To reduce the risk of electrical shock, always unplug the unit from its power source before cleaning or performing any maintenance tasks.
Page 38: Preventative Maintenance
TRUE recommends that quarterly scheduled maintenance be performed by a qualified service technician. Please contact your dealer or visit www.truefitness.com to contact a local TRUE authorized service technician. IMPORTANT! Use only TRUE Fitness certified service providers. Using non-authorized service providers could void the TRUE Warranty. Frequency...
Page 39: Additional Information Troubleshooting
Error code is displayed on console Contact TRUE product support Pinched or loose main communication cable No User Present displayed on screen User weight must be over 90lbs. Verify No User Present settings in console. © 2025 TRUE Fitness All Rights Reserved.
Page 40 Cables are pinched or damaged Contact TRUE product support Contact Heart Rate not displaying Nucleus board may be damaged Contact TRUE product support Heart Rate Grips may be damaged Contact TRUE product support © 2025 TRUE Fitness All Rights Reserved.
Page 41: Wiring Diagrams
Heart Rate Grip Right - RCS0612 Combo HR/TS - RCS0617 Brake - RCS0009 Lower Control Board - RCS0621 Generator - RCS0015 Brake - RCS0009 oard - RCS0621 Generator - RCS0015 Power Supply - RCS0018 Power Supply - RCS0018 © 2025 TRUE Fitness All Rights Reserved.
Page 42: Warranty Information Commercial Warranty
Coax/TV, HDMI, USB, mirroring or Bearings Ethernet connections, and safety key. Labor** 1 Year See Warranty Details for terms, conditions, and complete coverage details. Wear Items*** 90 Days © 2025 TRUE Fitness All Rights Reserved.
Page 43: Limited-Use Commercial Warranty
LIMITED-USE COMMERCIAL WARRANTY* TRUE Fitness may offer alternative warranties to purchasers of CARDIO commercial equipment for limited-use commercial* or in-home use.** This policy ensures that customers who use commercial LAUNCH equipment for limited-use commercial or in-home use may WARRANTY GRAVITY...
Page 44: Warranty Details
WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original registered product purchaser and the parts of the TRUE product (the “Product”) listed below, under normal use and service, shall be free of manufacturing defects in workmanship and materials only for the specified period of time.
Page 45: Warranty Registration
WARRANTY REGISTRATION Base Serial Number Console Serial Number Purchase Date Company (if applicable) Customer Name (First and Last) Email Address Phone Number Street Address City State Postal Code Country © 2025 TRUE Fitness All Rights Reserved.
Page 46 CONTACT US service@truefitness.com 800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-RC1-0B-35 Owner’s Manual and Assembly Guide REV03 © 2025 TRUE Fitness All Rights Reserved.
