LAUNCH RECUMBENT BIKE
OWNER'S MANUAL AND ASSEMBLY GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAUNCH RC3-0B-35 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for True Fitness LAUNCH RC3-0B-35

Summary of Contents for True Fitness LAUNCH RC3-0B-35

  • Page 1 LAUNCH RECUMBENT BIKE OWNER’S MANUAL AND ASSEMBLY GUIDE...

  • Page 2: Important-Please Read

    Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the appropriate sales representative to help answer your questions. • Phone | 800.426.6570 • Email | sales@truefitness.com • Hours | Monday - Friday 8:30am - 5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.

  • Page 3: Reporting Freight Claims Or Parts Damage

    Once you have called the carrier you will need to gather the serial number, model number, description of damage, and photos of damage. Contact TRUE product support (service@truefitness.com | 800.883.8783) or TRUE sales support (sales@truefitness.com | 800.426.6570) Monday-Friday during normal business hours. © 2025 TRUE Fitness All Rights Reserved.

  • Page 4: Table Of Contents

    WARRANTY DETAILS ..............46 WARRANTY REGISTRATION ............47 ASSEMBLY INSTRUCTIONS PREASSEMBLY CHECKLIST............11 ASSEMBLY STEPS.................15 PRODUCT FEATURES BASE OVERVIEW................35 CONSOLE OVERVIEW..............36 CARE AND MAINTENANCE INSPECTION................38 CLEANING THE EQUIPMENT............38 LUBRICATION............38 LEVELING THE MACHINE..............39 PREVENTATIVE MAINTENANCE............40 LONG TERM STORAGE..............40 © 2025 TRUE Fitness All Rights Reserved.

  • Page 5: Safety Instructions

    Use this equipment only for its intended use as described in this manual. combustion and explosion. • Do not move the equipment by lifting the console. Do not use the console as a handlebar during a workout. © 2025 TRUE Fitness All Rights Reserved.
  • Page 6 9V DC 1.5 amp output for console operation only. the optional power supply. • The batteries within self-generated equipment contain materials that are considered hazardous to the environment. Federal law requires proper disposal of these batteries. © 2025 TRUE Fitness All Rights Reserved.

  • Page 7: Power Requirements

    NOTE: The plug configuration for the power adapter may vary by country. NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply. © 2025 TRUE Fitness All Rights Reserved.

  • Page 8: Space Requirements

    DIMENSIONS (L X W X H) 63” x 30” x 54” / 160cm x 76cm x 137cm • MACHINE WEIGHT 165 lbs / 76 kg • MAXIMUM USER WEIGHT 400 lbs / 181 kg © 2025 TRUE Fitness All Rights Reserved.

  • Page 9: Warning Decals

    To replace any worn or missing decals contact TRUE product support (service@truefitness.com | 800.883.8783). console serial number location base serial number location COMPLIANCES This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.truefitness.com. © 2025 TRUE Fitness All Rights Reserved.

  • Page 10: Proper Use

    NOTE: The braking system is speed independent. © 2025 TRUE Fitness All Rights Reserved.

  • Page 11: Assembly Instructions

    INCLUDED IN BOX 4mm Ball End Allen Wrench 13mm Wrench 5mm Ball End Allen Wrench #2 Phillips Screwdriver 6mm Ball End Allen Wrench Wire Cutters 15mm/17mm Combination Wrench Torque Wrench with 15mm Head © 2025 TRUE Fitness All Rights Reserved.
  • Page 12 SEAT ADJUSTMENT HANDLE SEAT CUSHION SEAT BACK COVER SEAT BACK PAD WATER BOTTLE HOLDER FRONT MAST MAST BOOT BOTTOM CONSOLE COVER REAR CONSOLE COVER LEFT PEDAL RIGHT PEDAL FRONT STABILIZER REAR STABILIZER HARDWARE BAG(S) MANUAL © 2025 TRUE Fitness All Rights Reserved.
  • Page 13 (ZP,BO) SEAT BACK ITEM DESCRIPTION CBW0015 WASHER, M8X16X1.2T, PSB0170 SHCS, M6 X 55, BO BLACK STEP 5 SEAT HANDLEBAR ITEM DESCRIPTION PSB0173 FHCS, LP, M8 X 15MM (ZP,BO) RCS0545 WASHER SPLITLOCK M6 (ZP,BO) © 2025 TRUE Fitness All Rights Reserved.
  • Page 14 TOOLS CONSOLE COVERS ITEM DESCRIPTION ITEM DESCRIPTION XM0139_004 4MM BALL END ALLEN CS80131 SCREW M5X15L (BLACK) WRENCH TC6085_004 5MM BALL END ALLEN WRENCH 78008949 6MM BALL END ALLEN WRENCH RCS0045016 15MM/17MM COMBINATION WRENCH © 2025 TRUE Fitness All Rights Reserved.

  • Page 15: Assembly Steps

    NOTE: At least one person should hold the bike frame, while another installs the rear stabilizer. B. Using a 6mm ball end allen wrench, install the rear stabilizer into the metal bracket using 2 hex screws and 2 flat washers. © 2025 TRUE Fitness All Rights Reserved.
  • Page 16 NOTE: At least one person should hold the bike frame, while another installs the front stabilizer. B. Using a 6mm ball end allen wrench, install the front stabilizer into the metal bracket using 2 hex screws and 2 flat washers. © 2025 TRUE Fitness All Rights Reserved.
  • Page 17 SCREW SHCS M5 X 20MM (ZP,BO) Using a 4mm ball end allen wrench, attach the seat adjustment handle to the seat carriage using 2 hex screws. NOTE: The seat adjustment handle should face the front of the machine. © 2025 TRUE Fitness All Rights Reserved.
  • Page 18 NOTE: At least one person should hold the Left Contact Heart seat handlebar in place while the other Rate Cable makes the cable connections. B. Using wire cutters, cut the 2 zip ties on the seat carriage. © 2025 TRUE Fitness All Rights Reserved.
  • Page 19 FHCS, LP, M8 X 15MM (ZP,BO) A. Slide the seat handlebar bracket into the seat carriage. B. Using a 5mm ball end allen wrench, attach the seat handlebar to the seat carriage using 4 hex screws. © 2025 TRUE Fitness All Rights Reserved.
  • Page 20 WASHER SPLITLOCK M6 (ZP,BO) WASHER, FLAT, M6*OD19*ID6.2*6.2 CS80136 (BLACK) Using a 4mm ball end allen wrench, attach the seat cushion to the seat carriage using 4 hex screws, 4 lock washers, and 4 flat washers. © 2025 TRUE Fitness All Rights Reserved.
  • Page 21 A. Align the seat back pad with the seat back frame. B. Using a 4mm ball end allen wrench, attach the seat back pad to the seat back frame using 4 hex screws and 4 lock washers. © 2025 TRUE Fitness All Rights Reserved.
  • Page 22 RCS0549BK RC400 SEAT BACK A. Align the posts on the seat back cover with the mating features on the seat back pad. B. Snap the seat back cover onto the seat back pad. © 2025 TRUE Fitness All Rights Reserved.
  • Page 23 B. Align the water bottle holder bottom with the water bottle holder top component. C. Using a #2 Phillips screwdriver, attach the water bottle holder to the handlebar tube using 6 screws. © 2025 TRUE Fitness All Rights Reserved.
  • Page 24 = 40 N-M (29.5 FT-LB) an optional but preferred torque wrench with a 15mm head. NOTE: The left pedal is reverse-threaded (turn when using a torque wrench counter-clockwise to tighten). = 40 N-M (29.5 FT-LB) © 2025 TRUE Fitness All Rights Reserved.
  • Page 25 IMPORTANT! Do NOT pinch the cables. C. Remove the pull tie from the cables and discard it. D. Install the front mast onto the bike frame. I/O Data Network Power Coaxial Heart Rate Button Control © 2025 TRUE Fitness All Rights Reserved.
  • Page 26 IMPORTANT! Do NOT pinch the cables. IMPORTANT! Make sure cables are clear from hex screws to avoid damage. B. Slide the mast boot down over the bottom of the front mast tube. © 2025 TRUE Fitness All Rights Reserved.
  • Page 27 (00567800). button heart rate control ground do not connect power here NOTE: Depending on the installation, PVS power may not be used. power I/O data © 2025 TRUE Fitness All Rights Reserved.
  • Page 28 B. Slide the bottom console cover up the front mast until it meets with the rear console cover. C. Using a #2 Phillips screwdriver, attach the bottom console cover to the front mast using the remaining 2 screws. © 2025 TRUE Fitness All Rights Reserved.
  • Page 29 Non- LED consoles require the optional power supply. A. Using a #2 Phillips screwdriver, remove the rear left shroud using 9 screws. © 2025 TRUE Fitness All Rights Reserved.
  • Page 30 C. Connect the AC power cord to the power supply. D. Connect the DC power cable to the power supply. Secure the power supply to the square frame using 2 zip ties. © 2025 TRUE Fitness All Rights Reserved.
  • Page 31 Optional Step 15-Install Auxiliary Power Supply Continued E. Using a #2 Phillips screwdriver, reattach the rear left shroud to the bike frame using the 9 screws you removed previously. © 2025 TRUE Fitness All Rights Reserved.
  • Page 32 B. Verify all four lock nuts are securely tightened and flush against the bottom of the frame. lock nut lock nut leveling feet © 2025 TRUE Fitness All Rights Reserved.
  • Page 33 NOTE: Power warnings, grounding instructions, and power requirements are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply. Insert the appropriate power cord into the corresponding power inlet. © 2025 TRUE Fitness All Rights Reserved.
  • Page 34 Please follow the instructions included with your console for important configuration and calibration steps. Please contact product support right away if you run into issues setting up the machine: 800.883.8783 | service@truefitness.com | Monday–Friday 8:30am–5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.

  • Page 35: Product Features Base Overview

    L. Power Supply Inlet are only applicable when this product is being used with the optional power supply. Non-LED consoles require the optional power supply. Delivers power from the wall outlet to the bike. © 2025 TRUE Fitness All Rights Reserved.

  • Page 36: Console Overview

    CONSOLE OVERVIEW UNITE TOUCHSCREENS (16” SHOWN) Android OS Touchscreen Choose Workout Bluetooth Compatible Apple Watch Compatible Choose Language Galaxy Watch Compatible Lock Screen for Cleaning Tap to Pair Wireless Charging HDMI 3.5mm Headphone Jack © 2025 TRUE Fitness All Rights Reserved.
  • Page 37 UNITE LED Eight Dedicated Data Points Manually Adjust Level Dedicated Message Center Bright White LEDs Keypad Choose Workout © 2025 TRUE Fitness All Rights Reserved.

  • Page 38: Care And Maintenance

    CARE AND MAINTENANCE It is important to perform the minor maintenance tasks described in this section. Failure to maintain the bike as described here could void the TRUE Fitness Warranty. To reduce the risk of electrical shock, always unplug the unit from its power source before cleaning or performing any maintenance tasks.

  • Page 39: Leveling The Machine

    B. Verify all four lock nuts are securely tightened and flush against the bottom of the frame. lock nut lock nut leveling feet © 2025 TRUE Fitness All Rights Reserved.

  • Page 40: Preventative Maintenance

    TRUE recommends that quarterly scheduled maintenance be performed by a qualified service technician. Please contact your dealer or visit www.truefitness.com to contact a local TRUE authorized service technician. IMPORTANT! Use only TRUE Fitness certified service providers. Using non-authorized service providers could void the TRUE Warranty. Frequency...

  • Page 41: Additional Information Troubleshooting

    Error code is displayed on console Contact TRUE product support Pinched or loose main communication cable No User Present displayed on screen User weight must be over 90lbs. Verify No User Present settings in console. © 2025 TRUE Fitness All Rights Reserved.
  • Page 42 Cables are pinched or damaged Contact TRUE product support Contact Heart Rate not displaying Nucleus board may be damaged Contact TRUE product support Heart Rate Grips may be damaged Contact TRUE product support © 2025 TRUE Fitness All Rights Reserved.

  • Page 43: Wiring Diagrams

    Brake - CBW0103 Heart Rate Grip Right - RCS0612 Generator - RCS0075 Combo HR - RCS0627 Battery Charge Port - RCS0044 Lower Control Board - RCS0621 Power Supply - RCS0078 Battery Fuse - 00588900 © 2025 TRUE Fitness All Rights Reserved.

  • Page 44: Warranty Information Commercial Warranty

    Coax/TV, HDMI, USB, mirroring or Bearings Ethernet connections, and safety key. Labor** 1 Year See Warranty Details for terms, conditions, and complete coverage details. Wear Items*** 90 Days © 2025 TRUE Fitness All Rights Reserved.

  • Page 45: Limited-Use Commercial Warranty

    LIMITED-USE COMMERCIAL WARRANTY* TRUE Fitness may offer alternative warranties to purchasers of CARDIO commercial equipment for limited-use commercial* or in-home use.** This policy ensures that customers who use commercial LAUNCH equipment for limited-use commercial or in-home use may WARRANTY GRAVITY...

  • Page 46: Warranty Details

    WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original registered product purchaser and the parts of the TRUE product (the “Product”) listed below, under normal use and service, shall be free of manufacturing defects in workmanship and materials only for the specified period of time.

  • Page 47: Warranty Registration

    WARRANTY REGISTRATION Base Serial Number Console Serial Number Purchase Date Company (if applicable) Customer Name (First and Last) Email Address Phone Number Street Address City State Postal Code Country © 2025 TRUE Fitness All Rights Reserved.
  • Page 48 CONTACT US service@truefitness.com 800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-RC3-0B-35 Owner’s Manual and Assembly Guide REV02 © 2025 TRUE Fitness All Rights Reserved.
