imageRUNNER
ADVANCE DX
C3835i C3830i
C3826i
INSTALLATION
MANUAL
Canon
November 18, 2021
Rev. 3
COPYRIGHT
2021 CANON INC.
CANON imageRUNNER ADVANCE DX C3800 Series Rev. 3 PRINTED IN U.S.A.
©

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the imageRUNNER ADVANCE DX C3835i and is the answer not in the manual?

Questions and answers

Related Manuals for Canon imageRUNNER ADVANCE DX C3835i

Summary of Contents for Canon imageRUNNER ADVANCE DX C3835i

  • Page 1 ADVANCE DX C3835i C3830i C3826i INSTALLATION MANUAL Canon November 18, 2021 Rev. 3 COPYRIGHT 2021 CANON INC. CANON imageRUNNER ADVANCE DX C3800 Series Rev. 3 PRINTED IN U.S.A. ©...

  • Page 2: Important Notices

    When changes occur in applicable products or in the contents of this manual, Canon will release technical information as the need arises. In the event of major changes in the contents of this manual over a long or short period, Canon will issue a new edition of this manual.
  • Page 3 Important Notices Symbols The frequently-performed operations are described with symbols in this procedure. Screw Tighten Loosen Packaged Item Unused Parts Remove Install Harness (Common for Guides Connector Power Cord and Clamps) Connect Disconnect Connect Disconnect Remove Install Power Check Push Check the sound Check visually Cleaning...

  • Page 4: Table Of Contents

    Contents Contents Safety Precautions....................1 Toner Safety............................2 About Toner............................2 Handling Adhered Toner........................2 Points to Note at Installation........................2 Checking the Installation Environment....................2 Points to Note Before Servicing......................2 Essential Items to Be Performed Before Installation.................3 Points to Note when turning ON/OFF the main power................3 Checking the Installation Space......................
  • Page 5 Contents 4. Host Machine Options................. 173 Connection Kit-A3 for Bluetooth LE....................174 Checking the included parts....................... 174 Installation Outline Drawing........................175 Points to Note at Installation.......................175 Removing the Covers........................176 Connection Kit-A3 for Bluetooth LE.....................178 Setting after Installation........................183 NFC Kit-E2............................184 Installation Outline Drawing........................184 Points to Note at Installation.......................184 Checking the included parts.......................
  • Page 6 Contents Installation Procedure........................254 IC Card Reader Box for Numeric Keypad-A1/Numeric Keypad-A2..........260 Points to Note at Installation.......................260 Installation Outline Drawing 1/2......................261 Installation Outline Drawing 2/2......................262 Checking the Contents........................263 Installation Procedure........................265 Installing the Card Reader (IC Card Reader Box for Numeric Keypad-A1)........273 IC Card Reader..........................273 Procedure after Work.........................275 Serial Interface Kit-K3, Copy Control Interface Kit-A1..............276...
  • Page 7 Contents Cassette Heater Unit-42........................363 Points to Note at Installation.......................363 Product Name...........................363 Installation Outline Drawing........................363 Checking the Contents........................363 Installation Procedure........................364 Cassette Feeding Unit-AW1......................372 Name of This Machine........................372 Points to Note at Installation ......................372 Installation Outline Drawing........................372 Unpacking............................372 Checking the included parts....................... 376 Installing the 2-stage Cassette Pedestal.....................
  • Page 8 Contents Inner 2/3 2/4 4 Hole Puncher-D1.....................477 Checking before Installation....................... 477 Unpacking Procedure........................478 Checking the Contents........................478 Installation Procedure ........................481 Checking after Installation........................499 Adjustment............................500 APPENDICES....................502 Image position adjustment of Pickup transport system..............503 Adjusting Image Position (Printer).......................503 Revision History....................513...

  • Page 9: Safety Precautions

    Safety Precautions Toner Safety..........2 Points to Note at Installation....2...

  • Page 10: Toner Safety

    Safety Precautions Toner Safety About Toner Toner is a nontoxic matter composed of plastic, iron and a trace of pigments. CAUTION: Never throw toner in flames to avoid explosion. Handling Adhered Toner • Use dry tissue paper to wipe off toner adhered to skin or clothes and wash in water. •...

  • Page 11: Essential Items To Be Performed Before Installation

    Safety Precautions Essential Items to Be Performed Before Installation • Turn OFF the main power of the host machine, and disconnect the power plug from the outlet. WARNING: • If performing work without disconnecting the power plug of the host machine, it may cause electrical shock. •...

  • Page 12: Illustrations

    Safety Precautions • Booklet Finisher-AE1 + 3rd Delivery Tray 4” (100 mm) or more 19 3/4 (500 mm) or more 19 3/4” (500 mm) or more 106 2/4” (2,700 mm) or more illustrations Although pictures or illustrations used for explanationmay differ from the actual things, the procedure is the same.

  • Page 13: Product Lineup

    Product Lineup Image Reading System Options... 6 Function expansion system options..7 Paper Feed / Paper Output Options..9...

  • Page 14: Image Reading System Options

    1. Product Lineup Image Reading System Options Product name Condition “DADF-BA1” on page 81 “Single Pass DADF-C1” on page 112 “Platen Cover-Y3” on page 155 Cannot be installed with the DADF. ADF Access Handle-A1 “Reader Heater Unit-Q1” on page 159...

  • Page 15: Function Expansion System Options

    1. Product Lineup Function expansion system options [16] [15] [18] [17] 12],[13],[14] [10] [11] [19] Product name Condition “NFC Kit-E2” on page 184 “Utility Tray-B1/Option Attachment kit for Reader-A2” on Option Attachment kit for Reader-A2 is required. page 200 Cannot be installed with Voice Guidance Kit-G1. Cannot be installed with Voice Operation Kit-D1.

  • Page 16: Combination Table Of Options

    1. Product Lineup Product name Condition [13] “SSD-related Option” on page 283 It is required when using the mirroring function with Memory Mirroring Kit-A1. [14] “SSD-related Option” on page 283 When executing the mirroring function, either 250GB SSD-A1 or 1TB SSD-A1 is required. [15] “IC Card Reader Box for Numeric Keypad-A1/Numeric Key- Card Reader (sales company's option) is required.

  • Page 17: Paper Feed / Paper Output Options

    1. Product Lineup Paper Feed / Paper Output Options [11] [10] Product name Condition “Cassette Feeding Unit-AW1” on page 372 “ Copy Tray-T1” on page 388 “Inner 2way Tray-M1” on page 393 “Inner Finisher-L1” on page 398 “Staple Finisher-AE1/Booklet Finisher-AE1” on page 416 “Staple Finisher-AE1/Booklet Finisher-AE1”...

  • Page 18: Host Machine

    Host Machine Host machine........11...

  • Page 19: Host Machine

    2. Host Machine Host machine Checking before Installation Following shows requirements for the installation site. Therefore, it is desirable to see the installation site in advance before bringing in the machine to the user's site. ■ Points to Note at Installation CAUTION: Points to Note when Installing Toner Cartridge: •...

  • Page 20: Installation Of The Host Machine

    2. Host Machine • Keep the fixation members and screws that were removed during unpacking or installation as they may be used to transport the machine for relocation or repair. Installation of the Host Machine ■ Unpacking NOTE: The pictures and illustration used may differ from the actual machine, but there is no difference in the procedure. 1.
  • Page 21 2. Host Machine 3. Remove the tapes which is in the interior and exterior of the host machine / ADF. CAUTION: • Be sure not to remove the fixed materials of the Scanner areas until “ Installing the Scanner” on page 26 <...
  • Page 22 2. Host Machine <Left front side> ■ Cassette Pedestal < In case installing the Cassette Pedestal simultaneously > • “Cassette Feeding Unit-AW1” on page 14 < In case not installing the Cassette Pedestal simultaneously > 1. Holding the 4 handles and lift the host machine down from the pallet. CAUTION: •...
  • Page 23 2. Host Machine CAUTION: • When lifting the host machine, be sure to firmly grip the bottom of both sides (left and right). • Holding the machine by any place other than those indicated may result in injury or damage.
  • Page 24 2. Host Machine Remove the tapes stuck inside and outside of the Cassette 3 and the Cassette 4. CAUTION: Do not operate the Trailing Edge Guide Plate / the Side Guide Plate without pulling out the cassette as there is a risk of breakage.
  • Page 25 2. Host Machine Return the cassette to the original position. Checking the Contents (Cassette Feeding Unit-AW1)
  • Page 26 2. Host Machine Installing the 2-stage Cassette Pedestal NOTE: The pictures and illustrations used may differ from the actual product, but the procedures are the same. CAUTION: If the host machine is placed without opening the Right Cover (Bottom), the Right Cover (Bottom) may be damaged.
  • Page 27 2. Host Machine CAUTION: Do not place the host machine with the cable of the machine inside the cover CAUTION: • When placing the host machine onto the 2-stage Cassette Pedestal, be sure to move the host machine as it is a parallel condition and align the holes of the main body bottom plate with two positioning pins which is on the upper surface of the 2-stage Cassette Pedestal, and then put the host machine.
  • Page 28 2. Host Machine NOTE: Remove the cassette.
  • Page 29 2. Host Machine NOTE: Securely tighten the coin screws with a stubby screwdriver or a coin. CAUTION: • When tightening the coin screw, pay attention to the surrounding sheet metal and parts. • When tightening a screw on the rear side, be sure not to drop it. •...
  • Page 30 2. Host Machine NOTE: Install the Cassette 1 with the rail extended.
  • Page 31 2. Host Machine NOTE: The removed Cover will be used in step 9.
  • Page 32 2. Host Machine NOTE: Use the cover which is included in the package of the 2-stage cassette Pedestal and the cover removed in step 7. ■ Checking the included parts CAUTION: As shown below, bundled parts and options cannot be used together. [4] Reverse Trailing Edge Guide •...
  • Page 33 2. Host Machine For Asia/Oceania/ Taiwan/CIPL For USA For EUR [12] [10] [11] [13] [14] [15] 120V [16] 230V 230V For Australia [17] [18] For USA / LTN / EUR For Korea USA / LTN: 3 Stickers EUR: 4 Stickers •...

  • Page 34: Installing The Scanner

    2. Host Machine ■ Installing the Scanner Open the ADF.
  • Page 35 2. Host Machine NOTE: Be sure to keep the Scanner System Fixation Member in a safe place for moving the machine. NOTE: The removed Scanner System Fixation Member will be used at late procedure.
  • Page 36 2. Host Machine NOTE: Be sure to keep the Scanner System Fixation Member in a safe place for moving the host machine. NOTE: The removed Scanner System Fixation Member will be used at late procedure.
  • Page 37 2. Host Machine NOTE: The removed Cover will be used at late procedure.
  • Page 38 2. Host Machine NOTE: Store the Scanner System Fixation Member removed in step 8 into the Cover removed in the step 7.
  • Page 39 2. Host Machine NOTE: Store the Scanner System Fixation Member removed in step 3.
  • Page 40 2. Host Machine...
  • Page 41 2. Host Machine CAUTION: If the White Plate is pressed downward, it is placed on the Index Sheet, so be sure to press it upward.
  • Page 42 2. Host Machine Close the ADF. NOTE: • Be sure that there is no gap (for reference, 0.3 mm or less) between the White Plate and the Index Sheet. • Check that the White Plate is not placed on the Index Sheet. White Plate Index Sheet Reader Unit...
  • Page 43 2. Host Machine ■ Setting the Cassette Peel off the tape stuck inside the Cassette and on the External. Attach the set Paper size label so that the lower edge is aligned and separated from the number label by 5.0 mm. NOTE: •...
  • Page 44 2. Host Machine ■ Setting of the Dehumidification Switch NOTE: If the installation environment is a high humidity environment, be sure to turn ON the Dehumidification Switch. ■ Turning ON the Power CAUTION: In the case of the 1-path ADF •...
  • Page 45 2. Host Machine ■ Starting the Setup Guide ● Starting the Setup Guide After installation of the Main machine, Setup Guide is started at the time of first startup. Follow the instructions displayed on the Touch Panel Display to configure the settings of the Main machine. Initialization of the Developing Unit, initialization of the drum, and color displacement correction are automatically performed while starting the Setup Guide is running.
  • Page 46 2. Host Machine CAUTION: Points to Note when Installing Toner Cartridge: • Do not remove or insert the toner bottle until the initialization for the developing assembly is completed (If not, fogging, scattering and spot may occur.). • When the initialization of the developing assembly is completed, the setting instruction of the toner cartridge is displayed on the UI.
  • Page 47 2. Host Machine • Toner is not included in the host machine package. 9-10 • Toner is not included in the host machine package.(CN,KR,JP) 9-10 <Paper Settings> 1. Select the paper source for which you want to specify the paper type, and press [Set]. 2.
  • Page 48 2. Host Machine • COPIER > ADJUST > DENS > CONT-M • COPIER > ADJUST > DENS > CONT-C • COPIER > ADJUST > DENS > CONT-K • COPIER > ADJUST > DENS > D-Y-LVL • COPIER > ADJUST > DENS > D-M-LVL •...
  • Page 49 2. Host Machine 1. Enter the following service mode, and execute "Batch Set Installation Date Info". COPIER > FUNCTION > INSTALL > INSTDTST NOTE: • Year, month, day, hour, and minute can be edited individually in the following service modes. COPIER >...
  • Page 50 2. Host Machine...
  • Page 51 2. Host Machine...
  • Page 52 2. Host Machine CAUTION: • In the case of the 2-stage Cassette Pedestal was installed, install it to the 2-stage Cassette Pedestal side. • In the case of not installing the 2-stage Cassette Pedestal, install it to the host machine side. CAUTION: When installing on the host machine side, the installing direction differs depending on the shape of the host machine side.
  • Page 53 2. Host Machine <Type 2>...
  • Page 54 2. Host Machine ■ Fixing the Host Machine NOTE: • Move the host machine to the installation position, and fix it in place with the 3 adjusters. • Be sure to fix it in place to prevent overturning. • Fixing of the adjuster is not for earthquake resistance. ■...
  • Page 55 2. Host Machine NOTE: Install/remove the Envelope Attachment A only if requested by the customer.
  • Page 56 2. Host Machine ● When the Envelope Attachment A Is Not Used ● Settings after Installation 1. Select [Settings/Registration] > [Preferences] > [Paper Settings] > [Paper Settings] > [Cassette 1/Cassette 2] > [Envelope] 2. Select the type of envelope to be used and then press [OK] to register it. ●...
  • Page 57 2. Host Machine 2. Check that the envelope is picked up. ■ Checking after Installation 1. Review the Drum Unit initialization results. Check that the display value of each color is "0". COPIER > COUNTER > LIFE > PT-DR-Y COPIER > COUNTER > LIFE > PT-DR-M COPIER >...
  • Page 58 2. Host Machine 1. After setting the service modes as follows, press the Start key to output the test chart. • COPIER > TEST > PG > TYPE = 6 • COPIER > TEST > PG > PG-PICK = To set the Pickup Cassette for test print output. NOTE: •...
  • Page 59 2. Host Machine Adjustment of the White Plate...
  • Page 60 2. Host Machine CAUTION: If the White Plate is pressed downward, it is placed on the Index Sheet, so be sure to press it upward.
  • Page 61 2. Host Machine NOTE: • Be sure that there is no gap (for reference, 0.3 mm or less) between the White Plate and the Index Sheet. • Check that the White Plate is not placed on the Index Sheet. White Plate Index Sheet Reader Unit White Plate...
  • Page 62 2. Host Machine Checking the Height Height Check Sheet Preparation or Creation 1. Prepare the check sheet used for height adjustment. Height check sheet NOTE: Points to Note when Creating the Check Sheet • Output with A4 (paper size) or LTR (paper size). •...
  • Page 63 2. Host Machine Checking the Height of the Height Adjustment Boss 1. Put a sheet of paper on the place where the protrusions touch the Stream Reading Glass, and check whether there is any resistance of the paper when closing the ADF. <The Left Front Side>...
  • Page 64 2. Host Machine <The Left Rear Side> 2. If there is no resistance, perform the height adjustment.
  • Page 65 2. Host Machine Height Adjustment Procedure 1. Adjust by turning the Fixation Screw on the upper side of Hinge. • If both front and rear side (or only front side) are not installed properly: Turn the Right Hinge Fixation Screw clockwise (black arrow) to correctly locate it at the front.
  • Page 66 2. Host Machine Automatic Adjustment of the Stream Reading Position (Automatic Adjustment of the Reading Position at ADF Reading) NOTE: • If the DADF is opened during adjustment, restart the adjustment. • Enter the value after adjustment on the Service Label (on the back of the Reader Front Cover or Printer Front Cover). The adjustment result is reflected to COPIER >...

  • Page 67: Checking Network Connection

    2. Host Machine 1. Use a chart of a service parts of a Automatic Front/Back Side Difference Correction Adjustment, or using A4 or LTR paper, the leading edge and the side edge of the front/back side in the feeding direction are painted black with magic, and a chart for Automatic Front/Back Side Difference Correction Adjustment is prepared.
  • Page 68 2. Host Machine 3. Inform the system administrator at the installation site that the installation of the host machine is complete, and ask for network connection of the host machine. NOTE: Network setting cannot be executed unless logging in as an administrator. Factory default password is as follows.

  • Page 69: Checking Network Function On The Main Controller

    2. Host Machine 2. Select the following: [Settings/Registration] > [Preferences] > [Network] > [TCP/IP Settings] > [IPv4 Settings] > [PING Command], and enter the IP address. • If the display shows "Response from the host", the IP address specified on the host machine is correct. •...
  • Page 70 2. Host Machine...
  • Page 71 2. Host Machine...
  • Page 72 2. Host Machine CAUTION: • Do not cleaning the surface with alcohol after removing the sheet. • If any glue remains in the peeled Surface, remove it with the peeled sheet. ● Installation of IC Card Reader...
  • Page 73 2. Host Machine CAUTION: Do not pinch the Cable when mounting the cover.
  • Page 74 2. Host Machine...
  • Page 75 2. Host Machine ● Installing the Covers...
  • Page 76 2. Host Machine...
  • Page 77 2. Host Machine Connect the power plug to the outlet. Turn ON the main power switch. ■ Operation when using uniFLOW Online When using uniFLOW Online*, follow the setup procedures on the uniFLOW* Online First Steps Guide (http://www.nt-ware.com/ uFO_FS). * China version of "uniFLOW" is called "mdsFLOW". ●...
  • Page 78 2. Host Machine...
  • Page 79 2. Host Machine 8. Secure the Scanner Unit with the Scanner System Fixation Member that have been kept in a safe place since installation. NOTE: Be sure to store the rubber cap for reuse.
  • Page 80 2. Host Machine 13. Put a sheet of paper on the Copyboard Glass.
  • Page 81 2. Host Machine 14. Fix the coin screws for the host machine and 2-stage Cassette Pedestal without having loosening. CAUTION: • When tightening the coin screw, pay attention to the surrounding sheet metal and parts. • When tightening a screw on the rear side, be sure not to drop it. •...
  • Page 82 2. Host Machine 16. When moving the host machine, push the position shown in the figure and move. CAUTION: If the upper part of the host machine is pushed hard, it may tilt to the rear side, so be careful when moving it (Especially in the case where there is carpet, etc.).
  • Page 83 2. Host Machine 17. Proceed with the work shown below before turning ON the power. 1. Remove the paper on the Copyboard Glass. CAUTION: Be sure to keep the Scanner System Fixation Member in a safe place for moving the machine. NOTE: The removed Scanner Fixation Member need to be stored in step 6.
  • Page 84 2. Host Machine NOTE: The removed Scanner Fixation Member need to be stored in step 7.
  • Page 85 2. Host Machine NOTE: Store the Scanner System Fixation Member removed in step 2 in the Cover which was removed in the previous step.
  • Page 86 2. Host Machine NOTE: Store the Scanner System Fixation Member removed in step 3. 10. If the Cassette Pedestal is installed, turn the 3 adjusters of the Cassette Pedestal and fix.
  • Page 87 2. Host Machine 11. If the Cassette Pedestal is installed, fix the coin screws for the host machine and 2-stage Cassette Pedestal without having loosening. CAUTION: • When tightening the coin screw, pay attention to the surrounding sheet metal and parts. •...

  • Page 88: Image Reading System Options

    Image Reading System Options DADF-BA1.......... 81 Single Pass DADF-C1.......112 Platen Cover-Y3........155 Reader Heater Unit-Q1..... 159...

  • Page 89: Dadf-Ba1

    3. Image Reading System Options DADF-BA1 Unpacking Procedure NOTE: It is packaged with tapes and cushioning materials, etc. to protect it from vibrations and impact during transportation. Be sure to remove all packing materials according to the procedure before installing. NOTE: The weight of ADF is approx.
  • Page 90 3. Image Reading System Options CAUTION: Because its balance may be lost when installing this equipment to the host machine, do not remove the tape or cushioning material of the harness, Feeder Cover and Document Pickup Tray when unpacking. Remove in step 12 of "Installing the ADF".

  • Page 91: Checking The Contents

    3. Image Reading System Options Checking the Contents [3*] [3*] Parts name Q'ty ADF Host Machine 1 machine Hinge Cover 2 pieces [3*] Blindfold Seal 2 pieces Stepped Screw (Black); M5X6 2 Screws Flat-head Screw; M4×10 2 Screws TP(Round Tip); M3×8 1 Screw Glass Cleaning Instruction Label 1 sheet...

  • Page 92: Installation Procedure

    3. Image Reading System Options Installation Procedure ■ Installing the ADF NOTE: Only when changing the copyboard cover to the ADF.
  • Page 93 3. Image Reading System Options Stepped Screw (Black); M5x6...
  • Page 94 3. Image Reading System Options CAUTION: • When holding the ADF, be sure not to touch the Platen Roller. Platen Roller • When hooking the ADF's hinge onto the stepped screw, make sure the hinge of the ADF is not on the fixed screw. NOTE: Installing the ADF From the back of the host machine, slide forward after hooking the hinge with the step screw in the order shown in the figure below.
  • Page 95 3. Image Reading System Options NOTE: The right hinge part is fixed so that the end face of the screw is aligned with the scribing line (A). Flat Head Screw; M4x10...
  • Page 96 3. Image Reading System Options...
  • Page 97 3. Image Reading System Options CAUTION: If the White Plate is pressed from top to bottom, it is placed on the Index Sheet, so be sure to press it from bottom to top.
  • Page 98 3. Image Reading System Options CAUTION: • Check that the following parts are not lifted with this machine closed. • Be sure that there is no gap between the White Plate and the Index Sheet. The gap between the White Plate and the Index Sheet must be 0.3 mm or less as a reference.
  • Page 99 3. Image Reading System Options ■ Connecting Cable...
  • Page 100 3. Image Reading System Options CAUTION: The Grounding Wire must be installed in the correct orientation. TP (Round End); M3x8...
  • Page 101 3. Image Reading System Options ■ Affixing the Label...

  • Page 102: Operation Check

    3. Image Reading System Options ■ Cleaning of the Stream Reading Glass NOTE: Clean the Stream Reading Glass with lint-free paper and etc. Operation Check 1. Connect the power plug of the host machine to the outlet. 2. Turn ON the main power of the host machine. 3.

  • Page 103: Adjustment

    3. Image Reading System Options Adjustment ■ Overview of Adjustment The ADF has the following adjustment items. The following is the order of adjustment. Adjustment Items Adjusting the Height Adjusting the Perpendicularity Adjusting the Reading Position Adjusting the Magnification (Sub Scanning Direction) Adjusting the Image Position (Main Scanning Direction) Adjusting the Image Position (Sub Scanning Direction) Adjusting the White Level...
  • Page 104 3. Image Reading System Options ■ Adjusting the Height NOTE: Check following the procedure below and proceed to adjustment if necessary. ● Check the Left Hinge Height When Visual Check 1. Close the ADF and check whether the front and rear Stream Reading glass spacers are in close contact with the Stream Reading glass.
  • Page 105 3. Image Reading System Options When Check with the Paper 1. Check the rear-left height of the ADF. Cut a sheet of paper to make a paper slip with width of 45mm. Set paper against the protrusion in such a manner that the sheet is nearly hidden, and then close the ADF.
  • Page 106 3. Image Reading System Options 3. Check the front-left height of the ADF. Set paper against the protrusion in such a manner that the sheet is nearly hidden, and then close the ADF. CAUTION: Set paper so that it does not reach the document reader. Paper 4.
  • Page 107 3. Image Reading System Options Order of Adjustment When the front or rear side is floating: 1. Adjust the Left Hinge Height. 2. Adjust the Right Hinge Height. 3. Check the Left Hinge Height. (Check the height of the Left Hinge. If the height is inappropriate, adjust it again.) When both sides are floating: 1.
  • Page 108 3. Image Reading System Options ● Adjusting the Left Hinge Height 1. Adjust the height with the left hinge height adjusting screw. CAUTION: Loosen the lock nut before adjustment, and tighten it after adjustment. • If the front spacer is floating, turn the adjusting screw clockwise to bring the front spacer closer to the glass. •...
  • Page 109 3. Image Reading System Options 2. Check the perpendicularity at the leading edges of the test chart and copy. Measure dimensions A and B on the test chart and dimensions A' and B' on the copy. If (A-B) is not same as (A'-B'), go step 3 and following steps.
  • Page 110 3. Image Reading System Options 3. Loosen the screw securing the right hinge, and slide the hinge to the front or rear with reference to the marking-off line to adjust the perpendicularity. • For B'>A' Slide the hinge to rear side. •...
  • Page 111 3. Image Reading System Options 5. Remove the White Plate. 6. Place the White Plate on the Copyboard Glass by aligning it with the Index Sheet. 7. Close the ADF, and then open it again.
  • Page 112 3. Image Reading System Options 8. Press the White Plate upward as shown in the figure below. CAUTION: If the White Plate is pressed downward, it is placed on the Index Sheet, so be sure to press it upward. 9. With the ADF closed, check that the White Plate is not placed on the Index Sheet as shown in the figures. CAUTION: Be sure that there is no gap between the White Plate and the Index Sheet.

  • Page 113: Adjustment Procedure

    3. Image Reading System Options 2. Press [OK] or [Yes]. The scanner to start a scan; in several seconds, the ADF will end auto adjustment of the reading position. 3. Select the following item in the service mode to check the value, and write down the new adjustment value on the service label.
  • Page 114 3. Image Reading System Options 2. Change the value as gap A in the figure. • If the printed image is longer: Increase the value. (The image shrinks in the feed direction.) • If the printed image is shorter: Decrease the value. (The image extends in the feed direction.) Setting Value;...
  • Page 115 3. Image Reading System Options 2. Compare the horizontal registration between the copy and the test chart. As necessary, make the following adjustment. ● Adjustment Procedure 1. Select the following item in the service mode. COPIER > ADJUST > ADJ-XY > ADJ-Y-DF 2.
  • Page 116 3. Image Reading System Options 3. When the setting value was changed in step 2, write down the new numerical value in the service label. NOTE: The service label is affixed to the back of the host machine front cover or reader front cover. ■...
  • Page 117 3. Image Reading System Options 2. Change the value as gap A in the figure. • If the image is displaced to the trailing edge: Increase the value. (The image shifts to the leading edge.) • If the image is displaced to the leading edge: Decrease the value. (The image shifts to the trailing edge.) Setting Value;...

  • Page 118: Adjusting The White Level

    3. Image Reading System Options ■ Adjusting the White Level CAUTION: This is a item of adjustment in which the white level of images made in stream reading mode are matched with the white level of images made in book mode. If this adjustment is skiped, the following will likely occur: •...
  • Page 119 3. Image Reading System Options 10. Select the following item in the service mode to check the value, and write down the new adjustment value on the service label. COPIER > ADJUST > CCD > DFTAR-R COPIER > ADJUST > CCD > DFTAR-G COPIER >...

  • Page 120: Single Pass Dadf-C1

    3. Image Reading System Options Single Pass DADF-C1 Checking before Installation ■ Product Name Safety regulations require the product's name to be registered. In some regions where this product is sold, the following name may be registered instead. • F713500 ■...

  • Page 121: Installation Procedure

    3. Image Reading System Options Parts name Q'ty Hinge Cover 2 2 pcs Hinge Stopper (Right) 1 piece Hinge Stopper (Left) 1 piece Round Tip Bind M4X8 3 shafts Black string cleaning label for prohibited documents (For Japan) 1 sheet Remove the Maintenance Cover 1 piece Reader Back Cover Sponge...
  • Page 122 3. Image Reading System Options NOTE: The removed parts will be used in step 14.
  • Page 123 3. Image Reading System Options NOTE: The removed parts will be used in step 11.
  • Page 124 3. Image Reading System Options NOTE: The removed screws will be used in step 12.
  • Page 125 3. Image Reading System Options NOTE: The removed screws will be used in a later step. NOTE: Use the screws removed in the previous step.
  • Page 126 3. Image Reading System Options CAUTION: Install the screws in step 12.
  • Page 127 3. Image Reading System Options CAUTION: • Be sure to hold the side surfaces of the Stream Reading Glass. • Be sure to install the Stream Reading Glass in the correct direction. Installation Installation direction direction...
  • Page 128 3. Image Reading System Options NOTE: Use the parts removed in the step 4. NOTE: Use the screw removed in step 6.
  • Page 129 3. Image Reading System Options NOTE: Use the parts removed in the step 2.
  • Page 130 3. Image Reading System Options NOTE: The removed screw will be used in step 4 of "Connecting the Cable". NOTE: Implement only when there is a blindfold seal.
  • Page 131 3. Image Reading System Options NOTE: Implement only when there is not a blindfold seal. Stepped Screw; M5x13.4 NOTE: The removed screws will be used in step 21.
  • Page 132 3. Image Reading System Options NOTE: Use the screw removed in step 19.
  • Page 133 3. Image Reading System Options CAUTION: When holding this equipment, be sure not to touch the Platen Roller. NOTE: • Hook the hinge of this machine onto the step screw of the host machine and then slide forward. • If the wedge of the left hinge part of the host machine cannot slide because the hinge hits the step screw, turn the left hinge screw of the host machine counterclockwise and slide the wedge backward.
  • Page 134 3. Image Reading System Options Flat Head Screw Platen Roller...
  • Page 135 3. Image Reading System Options CAUTION: This work is required only for the hinge on the left side. Tighten the screw of the hinge on the left side of this machine clockwise, and insert the wedge to the step screw. Tighten the screw until you encounter some resistance.

  • Page 136: Connecting The Cable

    3. Image Reading System Options ■ Connecting the Cable...
  • Page 137 3. Image Reading System Options NOTE: Use the screw removed in "Installation of the unit” step 16.
  • Page 138 3. Image Reading System Options Cleaning the Stream Reading Glass with the glass cleaning sheet attached with the host machine.
  • Page 139 3. Image Reading System Options...
  • Page 140 3. Image Reading System Options NOTE: If the opening angle will be set to 90 degrees in [Adjustment > Eased Angle Guide (Opening Angle of 90 Degrees)], it is not necessary to install the Hinge Stoppers in this step. In that case, be sure to install the Hinge Stoppers after adjustment. Binding;...

  • Page 141: Adjustment

    3. Image Reading System Options Connect the power plug of the host machine to the outlet. Turn ON the Main Power Switch. NOTE: If a message prompting a configuration change appears, turn OFF and then ON the main power switch. If a message prompting the user to update the version appears, press [Update] to automatically update the version of this equipment.
  • Page 142 3. Image Reading System Options 1. After setting the service modes as follows, press the Start key to output the test chart. • COPIER > TEST > PG > TYPE = 6 • COPIER > TEST > PG > PG-PICK = To set the Pickup Cassette for test print output. NOTE: •...
  • Page 143 3. Image Reading System Options ■ Eased Angle Guide (Opening Angle of 90 Degrees) Change the opening angle of the ADF from 70 degrees to 90 degrees. NOTE: Some operation become easier by making the DADF opening angle wider. 1. Open the Hinge cover, and remove the Hinge stopper. •...

  • Page 144: Height Adjustment

    3. Image Reading System Options Inch Configuration Adjustment 1. Select the following service mode. FEEDER > FUNCTION > TRY-LTR 2. Align the Slide Guide with "LTR/11x17". 3. Press the OK key and register the width of Letter. 4. Select the following service mode. FEEDER >...
  • Page 145 3. Image Reading System Options Checking the Height of the Height Adjustment Boss 1. Put a sheet of paper on the place where the protrusions touch the Stream Reading Glass, and check whether there is any resistance of the paper when closing the ADF. <The Left Front Side>...
  • Page 146 3. Image Reading System Options <The Left Rear Side> 2. If there is no resistance, perform the height adjustment.
  • Page 147 3. Image Reading System Options Height Adjustment Procedure 1. Adjust by turning the Fixation Screw on the upper side of Hinge. • If both front and rear side (or only front side) are not installed properly: Turn the Right Hinge Fixation Screw clockwise (black arrow) to correctly locate it at the front.
  • Page 148 3. Image Reading System Options Adjustment of the Paper Front Reading 1. Prepare the test chart prepared below. “Creating the Test Charts for Image Position Adjustment” on page 49 2. Set the value of following service mode to "1". FEEDER > OPTION > SKW-SW 3.
  • Page 149 3. Image Reading System Options CAUTION: After adjustment, be sure to install the Hinge Stoppers. 7. Loosen the 4 Knurled Screws at the front part of the Right and Left Hinge Unit. 8. The fixing member is moved forward and backward by turning the screw by the value of the interval L between the test chart and the copied paper.
  • Page 150 3. Image Reading System Options Adjustment of the Paper Back Reading 1. Place a test chart facing down on the ADF and perform 2-sided copy. 2. Overlap the test chart and the A and B sections of the copied paper. Feed Direction Feed Direction 3.
  • Page 151 3. Image Reading System Options Feed Direction Feed Direction 4. Open the Feeder Cover, and remove the Front Cover of the DADF. • 4 screws...
  • Page 152 3. Image Reading System Options 5. Loosen the adjustment screw. Adjust the position of the guide supporting the Scanner Unit. • L>0 : Move the Guide to the right side (white arrow). • L<0 : Move the Guide to the left side (black arrow). 6.
  • Page 153 3. Image Reading System Options ■ Adjustment of the White Plate...
  • Page 154 3. Image Reading System Options CAUTION: If the White Plate is pressed downward, it is placed on the Index Sheet, so be sure to press it upward.
  • Page 155 3. Image Reading System Options NOTE: • Be sure that there is no gap (for reference, 0.3 mm or less) between the White Plate and the Index Sheet. • Check that the White Plate is not placed on the Index Sheet. White Plate Index Sheet Reader Unit...
  • Page 156 3. Image Reading System Options ■ Light intensity adjustment NOTE: • This mode automatically performs adjustment. • If "NG" is displayed after executing this mode, check that PCB and each connector are properly connected. 1. Execute the following service mode with the ADF closed. COPIER >FUNCTION >CCD >...
  • Page 157 3. Image Reading System Options ■ Side Registration Adjustment NOTE: There are two adjustment methods: One for reading the front side (Scanner Unit on the Reader side) and another for reading the back side (Scanner Unit on the ADF side). Adjustment of the Paper Front Reading 1.
  • Page 158 3. Image Reading System Options NOTE: • If the copied image is displaced toward the rear side: Decrease the value (the image moves toward the front side) • If the copied image is displaced toward the front side: Increase the value (the image moves toward the rear side) •...
  • Page 159 3. Image Reading System Options ■ Leading Edge Margin Adjustment NOTE: There are two adjustment methods: One for reading the front side (Scanner Unit on the Reader side) and another for reading the back side (Scanner Unit on the ADF side). Adjustment of the Paper Front Reading 1.
  • Page 160 3. Image Reading System Options Adjustment range -50 to 50 7. Copy the test chart again, and check that the image is within the ranges of the standard. 8. Write down the adjusted value in the service label (on the back of the Reader front cover back or Printer front cover). Adjustment of the Paper Back Reading 1.

  • Page 161: White Level Adjustment

    3. Image Reading System Options ■ Front/Back Side Difference Correction Adjustment NOTE: • This mode automatically feed the original and performs adjustment. • After executing this mode, enter following adjusted values on the Service Label (on the back of the Reader Front Cover or Printer Front Cover).
  • Page 162 3. Image Reading System Options However, when using 2 or more types of paper, it is necessary to execute all the modes corresponding to each type of paper. CAUTION: Note that if a type of paper to which auto gradation adjustment is not performed is used, it may cause negative effects on image or the host machine.

  • Page 163: Platen Cover-Y3

    3. Image Reading System Options Platen Cover-Y3 Installation Outline Drawing...

  • Page 164: Checking The Included Parts

    3. Image Reading System Options Checking the Included Parts Binding; M4x8 Installation Procedure...
  • Page 165 3. Image Reading System Options CAUTION: If the White Plate is pressed from top to bottom, it is placed on the Index Sheet, so be sure to press it from bottom to top.
  • Page 166 3. Image Reading System Options CAUTION: • Be sure that there is no gap (0.3 mm or less as a guide) between the White Plate and the Index Sheet. • Check that the White Plate is not placed on the Index Sheet. Platen Cover Platen Cover Index Sheet...

  • Page 167: Reader Heater Unit-Q1

    3. Image Reading System Options Reader Heater Unit-Q1 Installation Outline Drawing...

  • Page 168: Checking The Included Items

    3. Image Reading System Options Checking the included items 16.3 mm 17.9 mm Binding; M4x4 D Tightening; M3x8 15.8 mm...

  • Page 169: Installation Procedure

    3. Image Reading System Options Installation Procedure CAUTION: • Soiling on the glass surface and the White Plate affects reading. When removing or installing the Copyboard Glass, be sure not to touch the glass surface and/or the White Plate. • If they are soiled, clean them with lint-free paper. White Plate CAUTION...
  • Page 170 3. Image Reading System Options Binding; M4x4 16.3 mm...
  • Page 171 3. Image Reading System Options CAUTION: Be sure to hold down the Reader Heater Harness because it may interfere with moving of the Scanner Box if it is not connected properly.
  • Page 172 3. Image Reading System Options...
  • Page 173 3. Image Reading System Options CAUTION: Move the optics box all the way to the right and check that the bottom of the optics box, HP sensor flag plate, do not interfere with the leader heater harness.
  • Page 174 3. Image Reading System Options CAUTION: • Soiling on the glass surface and the White Plate affects reading. When removing or installing the Copyboard Glass, be sure not to touch the glass surface and the White Plate. • If soiling is attached, clean it with lint-free paper. White Plate CAUTION...
  • Page 175 3. Image Reading System Options NOTE: In the case of the Reverse ADF, the main controller cover (2) is not removed.
  • Page 176 3. Image Reading System Options <For the 1-Pass ADF> <In the case of the Reverse ADF>...
  • Page 177 3. Image Reading System Options 17.9 mm D Tightening; M3x8...
  • Page 178 3. Image Reading System Options...
  • Page 179 3. Image Reading System Options Install the removed cover.
  • Page 180 3. Image Reading System Options Connect the power plug of the host machine to the power outlet. Turn the main power switch ON.

  • Page 181: Host Machine Options

    Host Machine Options Connection Kit-A3 for Bluetooth LE.. 174 NFC Kit-E2........184 Utility Tray-B1/Option Attachment kit for Reader-A2........ 200 Copy Card Reader-F1/Copy Card Reader Attachment-B7....208 Voice Guidance Kit-G1/Option Attachment kit for Reader-A2..223 Voice Operation Kit-D1/Option Attachment kit for Reader-A2..237 Numeric Keypad-A2......

  • Page 182: Connection Kit-A3 For Bluetooth Le

    4. Host Machine Options Connection Kit-A3 for Bluetooth LE Checking the included parts 17.9 mm W Sems; P Tightening; P Tightening; TP; M3x6 M3x6 M3x8 M3x8 CN,KR...

  • Page 183: Installation Outline Drawing

    4. Host Machine Options Installation Outline Drawing Points to Note at Installation • When installing the Connection Kit for Bluetooth LE and the NFC Kit at the same time, be sure to install the Connection Kit for Bluetooth LE first.

  • Page 184: Removing The Covers

    4. Host Machine Options Removing the Covers...
  • Page 185 4. Host Machine Options...

  • Page 186: Connection Kit-A3 For Bluetooth Le

    4. Host Machine Options Connection Kit-A3 for Bluetooth LE NOTE: • To be fastened together with the Board • Use P Tight Screw. 17.9 mm TP; M3x6 P Tightening; M3x8 NOTE...
  • Page 187 4. Host Machine Options NOTE: The Cable process forms an even loop and fixes the Wire saddle in three turns as shown.
  • Page 188 4. Host Machine Options <For Connection Kit for Bluetooth LE Only>...
  • Page 189 4. Host Machine Options <When installing with the NFC Kit at the same time>...
  • Page 190 4. Host Machine Options NOTE: In countries other than the following countries, it is not necessary to affix the Approval Label. < For US > < For KR, and TW > CN,KR Install the Cover removed in the previous step...

  • Page 191: Setting After Installation

    4. Host Machine Options Setting after Installation 1. Connect the power plug of the host machine to the outlet. 2. Turn ON the main power switch. 3. Enter service mode, and set the value to "1". COPIER >FUNCTION > INSTALL > BLE-USE NOTE: When [System Manager Information Settings] is set, it is required to log in as a system manager in accordance with instructions of the user administrator.

  • Page 192: Nfc Kit-E2

    4. Host Machine Options NFC Kit-E2 Installation Outline Drawing Points to Note at Installation • Do not touch the sensor and PCB components of the Control panel. • When installing the Connection Kit for Bluetooth LE and the NFC Kit at the same time, be sure to install the Connection Kit for Bluetooth LE first.

  • Page 193: Checking The Included Parts

    4. Host Machine Options Checking the included parts Long1x TP; M3x6 TP; M3x6 Small 1x Small 1x Large 1x Short 1x <Others> Guides are included...

  • Page 194: Removing The Covers

    4. Host Machine Options Removing the Covers...
  • Page 195 4. Host Machine Options...

  • Page 196: Removing The Control Panel

    4. Host Machine Options Removing the Control Panel...
  • Page 197 4. Host Machine Options...
  • Page 198 4. Host Machine Options...

  • Page 199: Installing The Nfc Kit

    4. Host Machine Options Installing the NFC Kit Short 1x Small 1x TP; M3x6...
  • Page 200 4. Host Machine Options NOTE: • Connect the orange colored connector. • Be sure to fix the Harness Band at the position in the below figure. NOTE NOTE Install the Control Panel.
  • Page 201 4. Host Machine Options NOTE: Adjust the excess length of the cable.
  • Page 202 4. Host Machine Options NOTE...
  • Page 203 4. Host Machine Options <In case of NFC Kit>...
  • Page 204 4. Host Machine Options <When installing with the Connection Kit-A2 for Bluetooth LE at the same time>...
  • Page 205 4. Host Machine Options...

  • Page 206: Setting After Installation

    4. Host Machine Options Setting after Installation 1. Connect the power plug of the host machine to the outlet. 2. Turn ON the main power switch. 3. Eenter service mode and set the value to "1". COPIER > FUNCTION > INSTALL > NFC-USE NOTE: When [System Manager Information Settings] is set, it is required to log in as a system manager in accordance with instructions of the user administrator.
  • Page 207 4. Host Machine Options 5. Turn OFF and then ON the main power switch. 6. When a message prompting the version update is displayed, press [Update] and automatically update the version of this equipment. CAUTION: It may take time to display the update screen. (Approx. 1 to 2 min.) During this time, do not operate the screen. 7.

  • Page 208: Utility Tray-B1/Option Attachment Kit For Reader-A2

    4. Host Machine Options Utility Tray-B1/Option Attachment kit for Reader-A2 Points to Note at Installation • The option "Option Attachment kit for Reader" is needed to install this equipment. • When using this equipment together with the Copy Tray, install this equipment first. •...
  • Page 209 4. Host Machine Options ■ Option Attachment kit for Reader-A2 Binding; M4x4...

  • Page 210: Installation Procedure

    4. Host Machine Options Installation Procedure ■ Removing the Covers NOTE NOTE NOTE: The removed screws will be used in a later step.
  • Page 211 4. Host Machine Options ■ Installing the Option Attachment Kit for Reader NOTE: • Use the screws removed in the previous step. • Cases screw holes [A] may or may not be present. • This screw holes [A] is not used. Binding;...
  • Page 212 4. Host Machine Options ■ Installing the Utility Tray...
  • Page 213 4. Host Machine Options CAUTION: Do not open it too wide, or it may be broken. CAUTION...
  • Page 214 4. Host Machine Options CAUTION: If the below stamping is existing, align the holes marked with D, G, J, and P and then install. TP(Black); M4x8...
  • Page 215 4. Host Machine Options NOTE: The following steps are used only when installing the USB keyboard. 19.6 mm...

  • Page 216: Copy Card Reader-F1/Copy Card Reader Attachment-B7

    4. Host Machine Options Copy Card Reader-F1/Copy Card Reader Attachment-B7 Points to Note at Installation • To install this equipment, the Copy Card Reader Attachment Kit is required. • Refer to "Table of Options Combination" when installing this equipment before operation. •...

  • Page 217: Checking The Contents

    4. Host Machine Options Checking the Contents ■ Copy Card Reader-F1 RS Tightening; M4x10...
  • Page 218 4. Host Machine Options ■ Copy Card Reader Attachment-B7 W Sems;M3x14 TP;M3x6 TP;M3x12 Binding; M4x4 Binding;M4x6 TP;M4x12 W Sems;M3x14...

  • Page 219: Installation Procedure

    4. Host Machine Options Installation Procedure CAUTION: After installing the Copy Card Reader, enter the card number to be used in the following service mode: COPIER > FUNCTION > INSTALL > CARD. Otherwise, the card will not be recognized even if inserting it. ■...
  • Page 220 4. Host Machine Options ■ Option Attachment kit for Reader-A2 NOTE: • Installing the covers removed in the previous step. • Screw holes [A] may or may not be present. • Do not use this screw hole [A]. Binding; M4x4 NOTE [A] NOTE NOTE...
  • Page 221 4. Host Machine Options ■ Removing the Covers NOTE NOTE: The removed screws will be used in a later step.
  • Page 222 4. Host Machine Options ■ Installing the Copy Card Reader...
  • Page 223 4. Host Machine Options...
  • Page 224 4. Host Machine Options NOTE: Use the screws removed in the previous step. TP;M3x6 NOTE...
  • Page 225 4. Host Machine Options...
  • Page 226 4. Host Machine Options RS Tightening; M4x10...
  • Page 227 4. Host Machine Options TP;M3x12 TP;M3x6 Install the Cover removed in the previous step.
  • Page 228 4. Host Machine Options W Sems;M3x14...

  • Page 229: Checking After Installation

    4. Host Machine Options CAUTION: • Do not stick the guide to the air vent. • Do not route the code at the air vent. Checking after Installation 1. Connect the power plug of the host machine to the power outlet. 2.
  • Page 230 4. Host Machine Options 3. Set the number of card (number of department ID) that can be used with the Card Reader in service mode.(Lv.2). COPIER > OPTION > FNC-SW > CARD-RNG 4. Use Service Mode to enter the minimum card number to be used by a user (1 to 2001). COPIER >...

  • Page 231: Voice Guidance Kit-G1/Option Attachment Kit For Reader-A2

    4. Host Machine Options Voice Guidance Kit-G1/Option Attachment kit for Reader-A2 Points to Note at Installation • When installing this equipment, the another option "Option Attachment kit for Reader” is needed. • When installing this equipment, the another option “Numeric Keypad” is required. Refer to the Installation Procedure for the Numeric Keypad when installing the Numeric Keypad.

  • Page 232: Checking The Contents

    4. Host Machine Options Checking the Contents ■ Option Attachment kit for Reader-A2 Binding; M4x4 ■ Voice Guidance Kit-G1 Binding; Binding; Binding; M4x16 M3x16 M4x6 M3x6 Binding; Binding; M4x20 M4x16 M3x6...

  • Page 233: Installation Procedure

    4. Host Machine Options Installation Procedure ■ Removing the Covers NOTE NOTE NOTE: The removed screws will be used in a later step.
  • Page 234 4. Host Machine Options ■ Installing the Option Attachment Kit for Reader NOTE: • Use the screws removed in the previous step. • Cases screw holes [A] may or may not be present. • This screw holes [A] is not used. Binding;...

  • Page 235: Removing The Covers

    4. Host Machine Options Removing the Covers NOTE NOTE: The removed screws will be used Step2 of Voice Guidance Kit installation.

  • Page 236: Installing The Voice Guidance Kit

    4. Host Machine Options Installing the Voice Guidance Kit...
  • Page 237 4. Host Machine Options CAUTION: • Be sure not to be pressed an end face of an FFC cable by the edge of the board when installing and fixing the voice guidance board. • Install the FFC cable away from the edge of the board.
  • Page 238 4. Host Machine Options NOTE: Removing the Covers > Use the screws removed in step 1 M3x6 NOTE Install the cover removed in the previous step.
  • Page 239 4. Host Machine Options Binding; Binding; Binding; M4x16 M3x16 M4x6 M4x14 M3x14...
  • Page 240 4. Host Machine Options CAUTION: Make sure that the installation location for the Ring Cores should be within 50 mm from the end of the Speaker Cable. 50mm CAUTION...
  • Page 241 4. Host Machine Options...
  • Page 242 4. Host Machine Options CAUTION: • Do not stick the guide to the air vent. • Do not route the code at the air vent.

  • Page 243: Checking The Settings

    4. Host Machine Options NOTE: When used with the Copy Card Reader Checking the Settings NOTE: When changing the settings upon user’s request, it is required to log in as a system manager in accordance with instructions from the user administrator. 1.

  • Page 244: Operation Check

    4. Host Machine Options 2. Turn ON the main power switch. 3. Select Settings/Registration > Preferences > Accessibility > Voice Navigation Settings > Use Voice Navigation, and check that the setting is ON. 4. Select Settings/Registration > Preferences > Accessibility > Voice Navigation Settings > Voice Guide from Speakers, and check that the setting is ON.

  • Page 245: Voice Operation Kit-D1/Option Attachment Kit For Reader-A2

    4. Host Machine Options Voice Operation Kit-D1/Option Attachment kit for Reader-A2 Points to Note at Installation • When installing this equipment, the another option "Option Attachment kit for Reader” is needed. • When installing this equipment, the another option “Numeric Keypad” is required. Refer to the Installation Procedure for the Numeric Keypad when installing the Numeric Keypad.

  • Page 246: Checking The Contents

    4. Host Machine Options Checking the Contents ■ Option Attachment kit for Reader-A2 Binding; M4x4 ■ Voice Operation Kit-D1 Binding; Binding; M4x14 M3x14 M3x6 19.8 mm Binding; Binding; M3x6 M4x20 M4x14...

  • Page 247: Installation Procedure

    4. Host Machine Options Installation Procedure ■ Removing the Covers NOTE NOTE NOTE: The removed screws will be used in a later step.
  • Page 248 4. Host Machine Options ■ Installing the Option Attachment Kit for Reader NOTE: • Use the screws removed in the previous step. • Cases screw holes [A] may or may not be present. • This screw holes [A] is not used. Binding;...

  • Page 249: Removing The Covers

    4. Host Machine Options Removing the Covers NOTE NOTE: The removed screws will be used Step2 of Voice Operation Kit installation.

  • Page 250: Installing The Voice Operation Kit

    4. Host Machine Options Installing the Voice Operation Kit...
  • Page 251 4. Host Machine Options CAUTION: • Be sure not to be pressed an end face of an FFC cable by the edge of the board when installing and fixing the voice recognition board. • Install the FFC cable away from the edge of the board.
  • Page 252 4. Host Machine Options NOTE: Removing the Covers > Use the screws removed in step 1 M3x6 NOTE Install the cover removed in the previous step.
  • Page 253 4. Host Machine Options Binding; M4x14 Binding; M3x14 M4x14 M3x14...
  • Page 254 4. Host Machine Options...
  • Page 255 4. Host Machine Options CAUTION: • Do not stick the guide to the air vent. • Do not route the code at the air vent.

  • Page 256: Checking After Installation

    4. Host Machine Options NOTE: When used with the Copy Card Reader Checking after Installation NOTE: When changing the settings upon user’s request, it is required to log in as a system manager in accordance with instructions from the user administrator.

  • Page 257: Operation Check

    4. Host Machine Options 1. Connect the power plug of the host machine to the outlet. 2. Turn ON the main power switch. 3. Select Settings/Registration > Preferences > Accessibility > Voice Navigation Settings > Use Voice Navigation, and check that the setting is ON. 4.

  • Page 258: Numeric Keypad-A2

    4. Host Machine Options Numeric Keypad-A2 Points to Note at Installation • When using options and the NFC Kit together, install the NFC Kit first.

  • Page 259: Outline Drawings 1/2

    4. Host Machine Options Outline drawings 1/2...

  • Page 260: Outline Drawings 2/2

    4. Host Machine Options Outline drawings 2/2...

  • Page 261: Checking The Contents

    4. Host Machine Options Checking the Contents P Tightening; TP; M3x16 M3x8 TP; M3x10 TP; M3x6 Large 2x Small 1x Binding; Binding Tapping; M4x16 M3x16 <Others> Guides are included...

  • Page 262: Installation Procedure

    4. Host Machine Options Installation Procedure...
  • Page 263 4. Host Machine Options...
  • Page 264 4. Host Machine Options CAUTION: • Do not cleaning the surface with alcohol after removing the sheet. • If any glue remains in the peeled Surface, remove it with the peeled sheet. NOTE: Be sure to install the cores in the position shown in the following figure. 110 mm 140 mm...
  • Page 265 4. Host Machine Options TP; M3x16 TP; M3x10...
  • Page 266 4. Host Machine Options P Tightening; TP; M3x6 Small M3x8...
  • Page 267 4. Host Machine Options Large Install the Cover removed in the previous step Connect the power plug to the outlet. Turn ON the Main Power Switch.

  • Page 268: Ic Card Reader Box For Numeric Keypad-A1/Numeric Keypad-A2

    4. Host Machine Options IC Card Reader Box for Numeric Keypad-A1/Numeric Keypad-A2 Points to Note at Installation • When using options and the NFC Kit together, install the NFC Kit first.

  • Page 269: Installation Outline Drawing 1/2

    4. Host Machine Options Installation Outline Drawing 1/2...

  • Page 270: Installation Outline Drawing 2/2

    4. Host Machine Options Installation Outline Drawing 2/2...

  • Page 271: Checking The Contents

    4. Host Machine Options Checking the Contents ■ Numeric Keypad-A2 P Tightening; M3x8 TP; M3x10 TP; M3x6 TP; M3x16 Large 2x Small 1x Binding Tapping; Binding; M3x16 M4x16...
  • Page 272 4. Host Machine Options ■ IC Card Reader Box for Numeric Keypad-A1 *1: When installing the IC Card Reader, use it as necessary.

  • Page 273: Installation Procedure

    4. Host Machine Options Installation Procedure ■ Installing the Numeric key...
  • Page 274 4. Host Machine Options...
  • Page 275 4. Host Machine Options CAUTION: • Do not cleaning the surface with alcohol after removing the sheet. • If any glue remains in the peeled Surface, remove it with the peeled sheet. NOTE: Be sure to install the cores in the position shown in the following figure. 110 mm 140 mm...
  • Page 276 4. Host Machine Options TP; M3x16 TP; M3x10...
  • Page 277 4. Host Machine Options P Tightening; TP; M3x6 Small M3x8...
  • Page 278 4. Host Machine Options Large...
  • Page 279 4. Host Machine Options...
  • Page 280 4. Host Machine Options...

  • Page 281: Installing The Card Reader (Ic Card Reader Box For Numeric Keypad-A1)

    4. Host Machine Options Installing the Card Reader (IC Card Reader Box for Numeric Keypad-A1) IC Card Reader NOTE: Store the excess length of the cable in the position as shown in the figure.
  • Page 282 4. Host Machine Options NOTE: Be sure to adjust the number of cushions according to the thickness of the Card Reader.

  • Page 283: Procedure After Work

    4. Host Machine Options Procedure after Work Installing the covers removed in the previous step. Connect the power plug to the outlet. Turn ON the main power switch.

  • Page 284: Serial Interface Kit-K3, Copy Control Interface Kit-A1

    4. Host Machine Options Serial Interface Kit-K3, Copy Control Interface Kit-A1 Points to Note at Installation Refer to "Table of Options Combination" when installing this equipment before operation. Installation Outline Drawing Serial Interface Kit...
  • Page 285 4. Host Machine Options Control Interface Kit...

  • Page 286: Checking The Contents

    4. Host Machine Options Checking the Contents ■ Serial Interface Kit TP; M3x6 TP; M3x6 ■ Copy Control Interface Kit...

  • Page 287: Installation Procedure

    4. Host Machine Options Installation Procedure ■ Removing the Covers...
  • Page 288 4. Host Machine Options ■ Installing the Serial Interface Kit TP; M3x6...
  • Page 289 4. Host Machine Options ■ Installing the Control Interface Kit...
  • Page 290 4. Host Machine Options ■ Subsequent Work Installing the covers removed in the previous step. Connect the power plug of the host machine to the power outlet. Turn the main power switch ON.

  • Page 291: Ssd-Related Option

    4. Host Machine Options SSD-related Option Pre-checks ■ Points to Note at Installation CAUTION: • When using the mirroring function, be sure to install 2 SSDs of the same capacity. • If the SSD is replaced with a high-capacity SSD, the SSD needs to be initialized. •...
  • Page 292 4. Host Machine Options...

  • Page 293: [Type-1] Option Ssd (1Tb)

    4. Host Machine Options NOTE: When replacing to the Option SSD (1TB), the removed SSD will not be used. [TYPE-1] Option SSD (1TB) ■ Checking the Contents ■ Installation Procedure CAUTION: “Removing the SSD (Preparation)” on page 283Be sure to perform ☆ before performing the following work.
  • Page 294 4. Host Machine Options CAUTION: Be sure to push the SSD hard to install otherwise it may result in poor contact of the connector. ■ SSD Initialization Procedure 1. Requirements 1. PC Service Support Tool in the version that supports this host machine must be installed.rror during the rebuild process that is executed during operation is not included in the consideration.
  • Page 295 4. Host Machine Options 2. Preparing for the Installation of the System Software of Host machine 1. If both PC and the machine are on, turn them off. 2. Connect the PC and the host machine using an Cross Ethernet cable. (when SST is used) 3.

  • Page 296: [Type-2] Standard Ssd + Option Ssd (250Gb) + Ssd Mirroring Kit

    4. Host Machine Options [TYPE-2] Standard SSD + Option SSD (250GB) + SSD Mirroring Kit ■ Checking the Contents <Option SSD (250 GB)> <SSD Mirroring Kit> CAUTION: Although the red cable shown below may sometimes be supplied in lieu of the SSD Cable 2 (Blue), the procedure for connecting the red cable is the same as that for the blue cable.
  • Page 297 4. Host Machine Options ■ Installation Procedure ● Installing the SDD Mirroring Kit / Option SSD...
  • Page 298 4. Host Machine Options NOTE: The shape of the guide differs depending on the model, but the removal method is the same. <For the 1-Pass ADF>...
  • Page 299 4. Host Machine Options <In the case of the Reverse ADF>...
  • Page 300 4. Host Machine Options...
  • Page 301 4. Host Machine Options SSD Cable 2 (Blue) TP ; M3x8 Black...
  • Page 302 4. Host Machine Options CAUTION: • Be sure to push the SSD hard to install otherwise it may result in poor contact of the connector. • Be sure to connect the communication cable to the correct port. • Connect the SSD Cable 2 (Blue) or SSD Cable 2 (Red) with the label [B] attached, to the [B] of the Controller PCB. NOTE TP ;...

  • Page 303: [Type-3] 2 Option Ssds + Ssd Mirroring Kit

    4. Host Machine Options 3. Make sure that the UI screen is activated correctly. 4. Open the Cover, and make sure that the LED blinks. NOTE: Rebuilding starts approximately after 60 seconds after turning OFF and then ON the power. •...
  • Page 304 4. Host Machine Options <SSD Mirroring Kit> CAUTION: The red cable shown below may be included in the package instead of the SSD Cable2 (Blue), however, the same procedures as the blue cable applies. Be sure to confirm that the label [B] is attached to the cable before connecting it to [B] of the Controller PCB. SSD Cable 2 (Red) SSD Cable 2 (Blue) TP ;...
  • Page 305 4. Host Machine Options ■ Installing the SDD Mirroring Kit / Option SSD...
  • Page 306 4. Host Machine Options NOTE: The shape of the guide differs depending on the model, but the removal method is the same. <For the 1-Pass ADF>...
  • Page 307 4. Host Machine Options <In the case of the Reverse ADF>...
  • Page 308 4. Host Machine Options...
  • Page 309 4. Host Machine Options SSD Cable 2 (Blue) TP ; M3x8 Black...
  • Page 310 4. Host Machine Options CAUTION: • Be sure to push the SSD hard to install otherwise it may result in poor contact of the connector. • Be sure to connect the communication cable to the correct port. • Connect the SSD Cable 2 (Blue) or SSD Cable 2 (Red) with the label [B] attached, to the [B] of the Controller PCB. NOTE TP ;...
  • Page 311 4. Host Machine Options 2. Preparing for the Installation of the System Software of Host machine 1. If both PC and the machine are on, turn them off. 2. Connect the PC and the host machine using an Cross Ethernet cable. (when SST is used) 3.

  • Page 312: Executing Auto Gradation Adjustment

    4. Host Machine Options 4. Open the Cover, and make sure that the LED blinks. NOTE: Rebuilding starts approximately after 60 seconds after turning OFF and then ON the power. • SSD 1 (Slot 1): The green LED blinks. • SSD 2 (Slot 2): The green and red LEDs blink. CAUTION: Perform the W/RAID setting 3 minutes after the power is turned on.

  • Page 313: Super G3 Fax Board-Bh1

    4. Host Machine Options Super G3 FAX Board-BH1 Product Name Safety regulations require the product's name to be registered. In some regions where this product is sold, the following name may be registered instead. • F326904 Installation Outline Drawing...

  • Page 314: Checking The Contents

    4. Host Machine Options Checking the Contents Only for Europe 2 Contact type Only for Germany 6 Contact type Only for France Only for U.K Only for Asia Excluding EUR Only for US and AS Included for USA, Taiwan and China D Tightening;...

  • Page 315: Installation Procedure

    4. Host Machine Options Installation Procedure CAUTION: <Installing 1 line Only> • Other than Brazil: Steps 2 through 12 of this procedure are not required. • Brazil: Steps 2 through 12 of this procedure are required. <Installing line 1 and line 2 at the same> •...
  • Page 316 4. Host Machine Options CAUTION: Remove the rear bottom cover of 4 only for Brazil. NOTE: Steps 2 through 12 are required steps for Brazil only.
  • Page 317 4. Host Machine Options...
  • Page 318 4. Host Machine Options...
  • Page 319 4. Host Machine Options...
  • Page 320 4. Host Machine Options...
  • Page 321 4. Host Machine Options...
  • Page 322 4. Host Machine Options...
  • Page 323 4. Host Machine Options D Tightening; M3x8 Install the removed cover.
  • Page 324 4. Host Machine Options NOTE: • This procedure applies to Europe only. • Do not connect the telephone cords (2 core) to PTT plugs. • PTT plugs are connected to PTT cables (6 core) of the corresponding place/area.
  • Page 325 4. Host Machine Options NOTE: Insert one of the telephone cords into a line modular jack (LINE) of the host machine, and the other into a wall side modular jack. 2 Contact type 6 Contact type Only for Asia Excluding EUR Included for EUR...
  • Page 326 4. Host Machine Options CAUTION: • This step is only available in USA, Canada, Latin America, Korea and Australia. • If the cord guide is not included, this step is not necessary. • Do not stick the code guide to the air vent. •...

  • Page 327: Checking The Operation

    4. Host Machine Options NOTE: • This procedure applies to USA, Taiwan and China only. Connect the power plug to the outlet. Turn ON the main power switch. Checking the Operation ■ Type Setting 1. Select the country/region of the FAX Board in Service Mode: Set the TYPE of country/region to install this machine, and then press OK.
  • Page 328 4. Host Machine Options ■ Basic Setting NOTE: • When "System Manager Information Settings" is set, be sure to follow the direction of user administrator in order to log in as an administrator. • This setting can also be set from the Setup Guide ([Settings/Registration] > [Management Settings] > [License/Other] > [Start Setup Guide]).

  • Page 329: Super G3 2Nd Line Fax Board-Bh1

    4. Host Machine Options Super G3 2nd Line Fax Board-BH1 Product Name Safety regulations require the product's name to be registered. In some regions where this product is sold, the following name may be registered instead. • F326905...

  • Page 330: Installation Outline Drawing

    4. Host Machine Options Installation Outline Drawing...

  • Page 331: Checking The Included Parts

    4. Host Machine Options Checking the included parts Only for Europe Only for Germany 6 Contact type Only for France Only for U.K 2 Contact type Only for Asia W Sems; M3x8 9.7 mm Only for Taiwan FAX Approval Label...

  • Page 332: Installation Procedure

    4. Host Machine Options Installation Procedure NOTE: Be sure to remove the telephone code when removing the Rear Cover.
  • Page 333 4. Host Machine Options CAUTION: Be sure to install the Insulating sheet in the correct orientation. 9.7 mm W Sems; M3x8 CAUTION...
  • Page 334 4. Host Machine Options 9.7 mm...
  • Page 335 4. Host Machine Options W Sems; M3x8...
  • Page 336 4. Host Machine Options...
  • Page 337 4. Host Machine Options Install the removed cover and the telephone code. NOTE: • This procedure applies to Europe only. • Do not connect the telephone cords (2 core) to PTT plugs. • PTT plugs are connected to PTT cables (6 core) of the corresponding place/area.
  • Page 338 4. Host Machine Options NOTE: Connect the one telephone cord of lines 2 to a line modular jack on the host machine and connect the other to the modular jack on the wall.
  • Page 339 4. Host Machine Options CAUTION: • This procedure applies to USA, Canada, LatainAmerica, korea and Australia only. • If the cord guide is attached to the host machine, pass the lines 2 of the telephone cord through the cord guide. •...
  • Page 340 4. Host Machine Options NOTE: This procedure applies to Taiwan only. Connect the power plug to the outlet. Turn ON the main power switch.

  • Page 341: Line 1 And Line 2 Simultaneous Installation Procedure

    4. Host Machine Options Line 1 and Line 2 Simultaneous Installation Procedure...
  • Page 342 4. Host Machine Options CAUTION: Be sure to install the Insulating sheet in the correct orientation. 9.7 mm W Sems; M3x8 CAUTION...
  • Page 343 4. Host Machine Options 9.7 mm...
  • Page 344 4. Host Machine Options W Sems; M3x8...
  • Page 345 4. Host Machine Options D Tightening; M3x8...
  • Page 346 4. Host Machine Options...
  • Page 347 4. Host Machine Options Install the removed cover. NOTE: • This procedure applies to Europe only. • Do not connect the telephone cords (2 core) to PTT plugs. • PTT plugs are connected to PTT cables (6 core) of the corresponding place/area.
  • Page 348 4. Host Machine Options NOTE: Connect the line 1 telephone cord to a line modular jack on the host machine and connect the other to the modular jack on the wall. 6 Contact type 2 Contact type Only for Asia Excluding EUR Included for EUR...
  • Page 349 4. Host Machine Options NOTE: Connect the one telephone cord of lines 2 to a line modular jack on the host machine and connect the other to the modular jack on the wall.
  • Page 350 4. Host Machine Options CAUTION: • This procedure applies to USA, Canada, LatainAmerica, korea and Australia only. • If a code guide is not included in the package of the Super G3 fax board, this step is not required. • Do not stick the code guide to the air vent. •...
  • Page 351 4. Host Machine Options NOTE: Parts come with the line 1 :This procedure is for USA, Taiwan and China only. NOTE: Parts come with the line 2 :This procedure applies to Taiwan only. Connect the power plug to the outlet. Turn ON the main power switch.

  • Page 352: Checking The Operation

    4. Host Machine Options Checking the Operation ■ Type Setting Select the country/region of the FAX Board in Service Mode: FAX > Type > TYPE This setting performs the parameter settings to match the communication specification of the country/region. 1. From the following service mode, set the TYPE of country/region to install this machine, and then press OK. FAX >...
  • Page 353 4. Host Machine Options NOTE: If E744-5000 error code (Fax software version mismatch error) occurred while sending or receiving fax, upgrade the firmware of 2-line Fax to the latest version.

  • Page 354: Protection Profile For Hardcopy Devices Adaptive Installation Procedure

    "Protection Profile for Hardcopy Devices" in the state at the time of CC certification (HCD-PP) evaluation (firmware). • "Canon imageRUNNER ADVANCE DX C3800 series" is described as the targeted product in this setting procedure. Detailed targeted product is shown in the "imageRUNNER ADVANCE DX C3800 series is a necessary product to provide in the state at the time of CC certification (HCD-PP) evaluation."...
  • Page 355 4. Host Machine Options CAUTION: The device is reset to the initial state with the CC certification firmware installed and information set to the device is initialized. 2. Execute initialization of HDD and setting values. 1. Set to prepare for initialization of HDD. •...
  • Page 356 This host machine was installed according to the configuration evaluated and certified by CC certification. This host machine is a CC-certified MFP host machine of Canon imageRUNNER DX C38xx with FAX & PDL. * Please inform the model name parchased such as C3835i/C3822.
  • Page 357 4. Host Machine Options • Input "System Manager ID” “ System Manager PIN" when transferring to the service mode. After the service person's work, be sure to change back the settings for Restrict Services Operations and Restrict Special Mode Operations, and also be sure to check if the setting in the administration guide is changed or not.” ■...

  • Page 358: Paper Feed Options

    Paper Feed Options Main Body Heater Unit - A2....351 Media Adjustment kit-A1....356 Cassette Heater Unit-42....363 Cassette Feeding Unit-AW1....372...

  • Page 359: Main Body Heater Unit - A2

    5. Paper Feed Options Main Body Heater Unit - A2 Installation Outline Drawing Checking the Contents Installation Procedure...
  • Page 360 5. Paper Feed Options...
  • Page 361 5. Paper Feed Options NOTE: Place the main body heater along the rail and push it in until it clicks after passing through the protruding part.
  • Page 362 5. Paper Feed Options...
  • Page 363 5. Paper Feed Options Connect the power plug of the host machine to the outlet. Turn ON the Main Power Switch.

  • Page 364: Media Adjustment Kit-A1

    5. Paper Feed Options Media Adjustment kit-A1 Points to Note when Installing • Use paper whose weight is 60 to 300 g/m2 at pickup from the Multi-purpose Tray. • Do not close the Multi-purpose Tray Pickup Tray Assembly while the Media Adjustment Kit is installed. •...
  • Page 365 5. Paper Feed Options 2. Lift the Right Door , and slide the Right Door Guide (Front) and the Right Door Guide (Rear) in the direction shown in the figure below to fully open it. CAUTION: Moving the Lever Assembly to the following position changes the open/close status of the host machine's Right Door.
  • Page 366 5. Paper Feed Options 4. Remove the 3 springs from the guide removed in step 3, and install the 3 springs included in the package. Black...
  • Page 367 5. Paper Feed Options 5. Return the guide. • 2 Bosses • 2 Screws CAUTION: Do not bend the sheet when returning the guide.

  • Page 368: Settings After Installation

    5. Paper Feed Options 6. Close the Right Door. 7. Open the Multi-purpose Tray Pickup Tray Assembly. 8. Open the Multi-purpose Tray Pickup Side Guide Plate, and install the Media Adjustment kit. • 1 Protrusion Settings after installation 1. Connect the power plug of the host machine to the outlet. 2.

  • Page 369: Auto Adjust Gradation

    5. Paper Feed Options 3. Enter service mode, and change the values of the following 2 items to "1". • COPIER > OPTION > DSPLY-SW > EXTH-SW • COPIER > OPTION > FEED-SW > REGASST CAUTION: Points to Note when Removing This Kit When removing this kit, be sure to change the values of the foregoing 2 items to "0".
  • Page 370 5. Paper Feed Options 1. Load paper, and adjust the Multi-purpose Tray Pickup Side Guide Plate. 2. Press [Change Ppr. Type] on the screen shown below, and select the type of heavy paper to use. NOTE: Check that the changed Paper Type is displayed.

  • Page 371: Cassette Heater Unit-42

    5. Paper Feed Options Cassette Heater Unit-42 Points to Note at Installation Since the host machine contains heat at its bottom if this equipment is installed, be sure to avoid installation at locations where heat resistance is low in case the 2-stage Cassette Pedestal is not installed. Product Name Safety regulations require the product's name to be registered.

  • Page 372: Installation Procedure

    5. Paper Feed Options Installation Procedure ■ Removing the Cassette ● In the Case of Host Machine/Cassette Feeding Unit NOTE: • In the case of host machine, remove the Cassette 1 and 2. • In the case of the Cassette Feeding Unit, remove the Cassette 3 and 4.

  • Page 373: Installing The Cassette Heater

    5. Paper Feed Options ■ Installing the Cassette Heater NOTE: In case for 2-stage Cassette Pedestal, implement the same way.
  • Page 374 5. Paper Feed Options...
  • Page 375 5. Paper Feed Options <Host machine> TP Round End; M3x6 < In case for 2-stage Cassette Pedestal> TP Round End; M3x6...
  • Page 376 5. Paper Feed Options...
  • Page 377 5. Paper Feed Options NOTE: In case for 2-stage Cassette Pedestal, implement the same way. CAUTION: • Install the heater connector cover after routing the cables as shown in the figure below.
  • Page 378 5. Paper Feed Options ■ Installing the Cassette ● In the Case of Host Machine/Cassette Feeding Unit NOTE: In the case of the Cassette 1, pull out the rail and slide it into the host machine.
  • Page 379 5. Paper Feed Options ■ Confirmation for the Dehumidification Switch Connect the power plug of the host machine to the outlet. Turn ON the Main Power Switch.

  • Page 380: Cassette Feeding Unit-Aw1

    5. Paper Feed Options Cassette Feeding Unit-AW1 Name of This Machine This product may be registered under the following name according to the safety standard of the region where it is sold. • F326200 Points to Note at Installation • Although pictures or illustrations used for explanation may differ from the actual things, the procedure is the same. Installation Outline Drawing Unpacking Unpack this machine.
  • Page 381 5. Paper Feed Options CAUTION: • When lifting the host machine, be sure to firmly grip the bottom of both sides (left and right). • Holding the machine by any place other than those indicated may result in injury or damage.
  • Page 382 5. Paper Feed Options Remove the tapes stuck inside and outside of the Cassette 3 and the Cassette 4. CAUTION: Do not operate the Trailing Edge Guide Plate / the Side Guide Plate without pulling out the cassette as there is a risk of breakage.
  • Page 383 5. Paper Feed Options Return the cassette to the original position.

  • Page 384: Checking The Included Parts

    5. Paper Feed Options Checking the included parts Installing the 2-stage Cassette Pedestal CAUTION: • If there is a Right Lower Cover (Bottom), remove it. • Remove the Right cover (lower) from the side with the triangular mark. NOTE: The removed Cover will be used in step 12.
  • Page 385 5. Paper Feed Options NOTE: If there is a Handle Cover, remove it. NOTE: Removed the Handle cover was used in step 13. CAUTION: If the host machine is placed without opening the Right Cover (Bottom), the Right Cover (Bottom) may be damaged.
  • Page 386 5. Paper Feed Options CAUTION: Do not place the host machine with the cable of the machine inside the cover CAUTION: • When placing the host machine onto the 2-stage Cassette Pedestal, be sure to move the host machine as it is a parallel condition and align the holes of the main body bottom plate with two positioning pins which is on the upper surface of the 2-stage Cassette Pedestal, and then put the host machine.
  • Page 387 5. Paper Feed Options NOTE: Remove the cassette.
  • Page 388 5. Paper Feed Options NOTE: Securely tighten the coin screws with a stubby screwdriver or a coin. CAUTION: • When tightening the coin screw, pay attention to the surrounding sheet metal and parts. • When tightening a screw on the rear side, be sure not to drop it. •...
  • Page 389 5. Paper Feed Options NOTE: Install the Cassette 1 with the rail extended.
  • Page 390 5. Paper Feed Options NOTE: The removed Cover will be used in step 11.
  • Page 391 5. Paper Feed Options NOTE: Use the parts removed in the step 9 and the parts included. NOTE: Use the Cover removed in step 1, or the Cover included in the host machine.
  • Page 392 5. Paper Feed Options NOTE: Use the Cover removed in step 2, or the Cover included in the host machine. NOTE: • Move the host machine to the installation position, and fix it in place with the 3 adjusters. • Be sure to secure it in place to prevent overturning. •...

  • Page 393: Setting The Cassette

    5. Paper Feed Options Setting the Cassette NOTE: • Holding the Guide Plate Lever, adjust each Guide Plate to the specified size. • Adjust the position of each Guide Plate according to the paper size.
  • Page 394 5. Paper Feed Options NOTE: • Keep the Paper Size Label for use when changing paper size. • Affix the Cassette Size Label matching to the loaded paper size. • Store the Paper Size Label as it is used when paper is changed. 5.0 mm...

  • Page 395: Paper Output Options

    Paper Output Options Copy Tray-T1........388 Inner 2way Tray-M1......393 Inner Finisher-L1....... 398 Staple Finisher-AE1/Booklet Finisher- AE1..........416 2/3 2/4 4 Hole Puncher Unit-A1..452 Inner 2/3 2/4 4 Hole Puncher-D1..477...

  • Page 396: Copy Tray-T1

    6. Paper Output Options Copy Tray-T1 Installation Outline Drawing...

  • Page 397: Checking The Included Items

    6. Paper Output Options Checking the included items TP; M3x8 Installation procedure Open the Right Door. NOTE NOTE NOTE: Use the removed Screw in the following steps.
  • Page 398 6. Paper Output Options NOTE: Use the Screw removed in the previous step. NOTE NOTE...
  • Page 399 6. Paper Output Options TP; M3x8 Close the Right Door.

  • Page 400: Settings After Installation

    6. Paper Output Options Settings after installation 1. Set the value of the following service mode to "1". COPIER > OPTION > ACC > OUT-TRAY 2. Turn OFF and then ON the main power. 3. Check that the following menu has been added. •...

  • Page 401: Inner 2Way Tray-M1

    6. Paper Output Options Inner 2way Tray-M1 Installation Outline Drawing...

  • Page 402: Checking The Contents

    6. Paper Output Options Checking the Contents TP; M3x6...

  • Page 403: Installation Procedure

    6. Paper Output Options Installation Procedure CAUTION: When the Reverse Trailing Edge Guide has been installed to the host machine, remove it. TP; M3x6...
  • Page 404 6. Paper Output Options CAUTION: Make sure that the Boss of Inner 2way Tray is properly inserted into the Reverse Guide Cover and the Second Delivery Tray Support Plate. Connect the power plug to the outlet. Turn ON the main power switch.

  • Page 405: Settings After Installation

    6. Paper Output Options Settings after installation 1. Set the value of the following service mode to "1". COPIER > OPTION > ACC > IN-TRAY 2. Turn OFF and then ON the main power. 3. Check that the following menu has been added. •...

  • Page 406: Inner Finisher-L1

    6. Paper Output Options Inner Finisher-L1 Checking before Installation ■ Points to Note at Installation • This installation procedure is written only about the installation of the inner finisher. When installing the inner puncher together with the finisher, refer to the inner puncher installation procedure instead of referring this installation procedure. (reference: “Inner 2/3 2/4 4 Hole Puncher-D1”...

  • Page 407: Unpacking Procedure

    6. Paper Output Options Unpacking Procedure NOTE: This equipment is packed using tapes, fixings and cushioning materials to be protected vibration and shock during transportation. Be sure to remove all the fixing materials and the tapes before starting to install this equipment. 1.

  • Page 408: Installation Procedure

    6. Paper Output Options [1] Inner Finisher 1x [2] Stack Tray 1x [3] Wire Sub Tray 1x [4] Harness Cover 1 1x [5] Harness Cover 2 1x [6] Rail Cover 1x [7] Sensor Flag (Gray) 1x [8] Screw [9] Staple Cartridge 1x (Binding (black);...
  • Page 409 6. Paper Output Options NOTE: When the Reverse Trailing Edge Guide is installed, remove it. NOTE: Check that the Sensor Flag operates smoothly.
  • Page 410 6. Paper Output Options...
  • Page 411 6. Paper Output Options...
  • Page 412 6. Paper Output Options CAUTION: Do not drop the screw into the Host Machine.
  • Page 413 6. Paper Output Options CAUTION: Do not drop the screw into the Host Machine. ■ Installing This Equipment NOTE: The removed impact absorbing materials shall be stored to reuse for transportation in case of transference and the repair of this equipment.
  • Page 414 6. Paper Output Options...
  • Page 415 6. Paper Output Options CAUTION: When installing the Inner Finisher to the Host Machine, be careful of the following points. • Do not slide the Inner Finisher on the inner part of the Host Machine nor bump the Inner Finisher to the covers of the Host Machine.
  • Page 416 6. Paper Output Options Screws (Binding (black); M3x8)
  • Page 417 6. Paper Output Options NOTE: Secure the Harness Band to the position in the figure below.
  • Page 418 6. Paper Output Options NOTE: Install the cover removed at Step 5 in "Preparation for Host Machine". CAUTION: Confirm that the 2 hooks are fitted as shown in the figure.
  • Page 419 6. Paper Output Options...
  • Page 420 6. Paper Output Options CAUTION: Before installing the Harness Cover 2, check that the connector is positioned as shown in the figure. Screws (Binding (black); M3x8)
  • Page 421 6. Paper Output Options Claw Hook Hook Claw CAUTION: Check that the Stack Tray is properly installed. If the installation fails, error; E540-8001/8002 may occur at power ON. Hook Hook Hook Claw Claw Claw...
  • Page 422 6. Paper Output Options...

  • Page 423: Checking After Installation

    6. Paper Output Options Checking after Installation ■ Disposal Parts 1. Following disposal parts are remained after the installation. (Installed in the host machine) Screw （TP; M3x8） ■ Operation Checks 1. Connect the power plug of the Host Machine in the outlet. 2.

  • Page 424: Staple Finisher-Ae1/Booklet Finisher-Ae1

    6. Paper Output Options Staple Finisher-AE1/Booklet Finisher-AE1 Checking Before Installation The following conditions are required for the installation site. Therefore, it is recommended to see the installation site in advance before delivering this Equipment to the user's site. ■ Checking the Unpacking Space Be sure to unpack this equipment according to the illustrations in a wide area where there is enough space around it.

  • Page 425: Unpacking

    6. Paper Output Options ■ Order of Installation of Options When installing this equipment together with the other options, first install the host machine and then install options in the following order: 1. Buffer Pass Unit 2. Puncher Unit 3. Staple Finisher / Booklet Finisher ■...
  • Page 426 6. Paper Output Options...
  • Page 427 6. Paper Output Options...
  • Page 428 6. Paper Output Options Hold the specified parts as shown and unload the Finisher. - For Staple Finisher - For Booklet Finisher CAUTION: Hold the specified parts as shown and do not hold the other parts to lift up the finisher. - For Staple Finisher - For Booklet Finisher CAUTION:...

  • Page 429: Checking The Contents

    6. Paper Output Options Remove all the tapes and cushioning materials outside this equipment. Checking the Contents Check that none of the included parts is missing.

  • Page 430: Installation Procedure

    6. Paper Output Options TP ; M3 x 6 W Sems ; M3 x 6 Binding ; M3 x 25 [11] [12] [13] [10] NOTE: *1 :Booklet Finisher only <Others> Other bundled items such as leaflets, etc. Installation Procedure CAUTION: Check that the main power switch is OFF and the power plug is disconnected from the outlet.
  • Page 431 6. Paper Output Options ■ Preparing the Host Machine for Installation When the tray is installed, remove it.
  • Page 432 6. Paper Output Options TP;M3x6 NOTE: Check that the Sensor Flag operates smoothly.
  • Page 433 6. Paper Output Options...
  • Page 434 6. Paper Output Options...
  • Page 435 6. Paper Output Options CAUTION: Do not drop the screw into the host machine. CAUTION: Do not drop the screw into the host machine.
  • Page 436 6. Paper Output Options ■ Installation of Buffer Pass Unit CAUTION: Do not give a damage on delivery area of the host machine. Space NOTE: Make sure there is enough space to connect the connector. TP;M3x6...
  • Page 437 6. Paper Output Options NOTE: The removed screw will be used in a later step.
  • Page 438 6. Paper Output Options Fix the screw removed in previous step to the original position. TP; M3 x 6 W Sems; M3 x 6 Binding; M3 x 25...

  • Page 439: Preparing The Finisher For Installation

    6. Paper Output Options ■ Preparing The Finisher for Installation (M3 6) NOTE: Install the Ground rail to the position [B].
  • Page 440 6. Paper Output Options When the Service Book Holder has already been installed in the host machine, relocate it to the Finisher. ■ Connecting to Host Machine CAUTION: When connecting the Interface Cable, be sure to turn off the host machine and disconnect its power cable from the outlet.
  • Page 441 6. Paper Output Options NOTE: If the positioning pin of the Buffer Pass Unit is not fitted the positioning hole on the Finisher, carry out the adjustment described in “Adjusting the Height” on page 440. CAUTION: Handle the interface cable so that it does not sag to prevent accidental catching.
  • Page 442 6. Paper Output Options TP ; M3x6 Pull out the Saddle Unit about 150mm. (Booklet Finisher only)
  • Page 443 6. Paper Output Options Loosen 2 screws, and then fix the Saddle Unit Auxiliary Caster so that its Caster can touch the floor. (Booklet Finisher only) Close the Saddle Unit. (Booklet Finisher only)

  • Page 444: Affixing The Labels

    6. Paper Output Options Affixing the Labels ■ Affixing the Jam Label / Saddle Caution Label (Booklet Finisher only)
  • Page 445 6. Paper Output Options Affix the label in the appropriate language. Affix the label in the appropriate language.

  • Page 446: Making Adjustments

    6. Paper Output Options ■ Tray Setting Labels Affix the supplied which is specified by user in the frame line of Tray Labels. Making Adjustments The difference in height between the Finisher and the Host Machine and the tilt of the Finisher and the host machine need to be adjusted depending on the installation site floor condition.
  • Page 447 6. Paper Output Options ■ Checking the Height 1. Check the difference in height between the Finisher and the host machine. Make sure that the pin of the Buffer Pass Unit inserts into the hole of the Finisher. 2. When the adjustment of height is necessary, make adjustment by referring the “Adjusting the Height”...
  • Page 448 6. Paper Output Options ■ Adjusting the Height 1. When it is fixed to the host machine, it is detached by approx. 150 mm. CAUTION: Be careful with the interface cable when detaching. 2. Remove the Caster Covers (front/ rear).
  • Page 449 6. Paper Output Options 3. Turn the adjustment dial of the caster in the direction of the arrow by lifting the dial upward a little to adjust the height. NOTE: Adjust the height at 4 casters. • To increase the height of the Finisher, turn the dial in the direction of arrow [A]. •...
  • Page 450 6. Paper Output Options 4. Install the Caster Covers (Front / Rear). 5. Install the Finisher to the host machine. 6. Fix to the host machine.
  • Page 451 6. Paper Output Options ■ Checking the Difference in Tilt 1. Check the relational tilting amount of the Finisher and the host machine. Make sure that the gap between the right side of the Finisher and the left side of the host machine is within the standard shown in the figure. In the case the gaps are within the specification, this adjustment is not required.
  • Page 452 6. Paper Output Options ■ Adjusting the Tilt 1. When it is fixed to the host machine, it is detached by approx. 150 mm. CAUTION: Be careful with the interface cable when detaching. 2. Remove the Caster Covers (Front/ Rear).
  • Page 453 6. Paper Output Options 3. Turn the adjustment dial of the caster in the direction of the arrow by lifting the dial upward a little to adjust the tilt. NOTE: Adjust the tilt at 2 left casters. • To tilt the Finisher to the right, turn the dial in the direction of arrow [A]. •...
  • Page 454 6. Paper Output Options 4. Install the Caster Covers (Front / Rear). 5. Install the host machine. 6. Fix to the host machine.

  • Page 455: Making Checks After Completion Of Installation Work

    6. Paper Output Options Making Checks After Completion of Installation Work ■ Disposal Parts Check Following disposal parts are remained after the installation. (Installed the host machine) TP; M3 x 8 ■ Operation Check 1. Turn ON the main power of the host machine. 2.

  • Page 456: Detaching From The Host Machine

    6. Paper Output Options 4. If a message appears prompting the user to update the firmware, press [Update] to automatically update the firmware of this equipment. NOTE: If [Skip] is selected, a message will appear every time when the Host Machine turns ON prompting the user to update the firmware. In the service mode (Level 2) shown below, behavior of the message can be changed to be no longer displayed.

  • Page 457: Buffer Pass Unit

    6. Paper Output Options CAUTION: When disconnecting the Interface Cable, be sure to turn off the host machine. ■ Buffer Pass Unit...
  • Page 458 6. Paper Output Options...
  • Page 459 6. Paper Output Options...

  • Page 460: 2/3 2/4 4 Hole Puncher Unit-A1

    6. Paper Output Options 2/3 2/4 4 Hole Puncher Unit-A1 Checking Before Installation ■ Checking Before Installation When installing this Equipment together with the Finisher, install this Equipment before installing the Finisher to the Upstream Connection Machine. ■ Product Name Safety regulations require the product's name to be registered.
  • Page 461 6. Paper Output Options 3. Remove the 2 fixtures. • 3 Screws NOTE: Removed screws are used in latter steps.

  • Page 462: Checking The Contents

    6. Paper Output Options Checking the Contents [1] Punch Unit x1 [2] Punch Waste Tray x1 [3] Punch Waste Full Sensor Unit x1 [4] Punch Unit [5] Relay Harness x1 [6] Punch Front Cover x1 Positioning Guide x1 [7] Punch Unit [8] Punch Unit Fixing Pin [9] Face Seal x1 Open/ Close Guide x1...
  • Page 463 6. Paper Output Options ■ Preparation of the Punch Unit 1. Remove the Punch Lever Unit of the Punch Unit. • 2 Screws NOTE: Removed screws are used in the purocedure later. 2. Install the Punch Front Cover. • 2 Screws (P Tightening ; M3x6) NOTE: Use the screws removed in step 1.
  • Page 464 6. Paper Output Options ■ Installing the Punch Unit 1. Open the Front Cover of the Finisher. 2. Remove the Rear Cover of the Finisher. • 2 Screws • 2 Claws 3. Remove the Right Cover of the Finisher. • 3 Screws •...
  • Page 465 6. Paper Output Options 4. Remove the Hinge Unit (rear) from the Upper Cover. NOTE: There is a case using 5 Screws for by a model. • 4(5) Screws 5. Remove the Hinge Unit (front) from the Upper Cover. • 2 Screws...
  • Page 466 6. Paper Output Options 6. Open the Upper Cover. 7. Holding the Central Part of the Upper Cover, lift the cover until it stops. NOTE: This work is carried out to secure space to remove the Inlet Feed Guide. Inlet Feed Guide 8.
  • Page 467 6. Paper Output Options NOTE: Confirm the Upper Cover and the Inlet Feed Guide are in condition as shown in the figure below. 9. Remove the Inlet Feed Guide. • 1 Screw • 1 Connector • 1 Wire saddle • 2 Harness guides •...
  • Page 468 6. Paper Output Options 10. Install the Punch Waste Full Sensor Unit. • 3 Hooks • Sensor Cover • 1 Screw (TP ; M3x6) NOTE: Use the screw removed in Unpacking Procedure.
  • Page 469 6. Paper Output Options 11. Cut out the Face Cover of the Inner Cover by using the side cutters. CAUTION: Be sure to remove the Face Cover properly so that no burr is formed.
  • Page 470 6. Paper Output Options 12. Install the Punch Unit Positioning Guide so that the right edge of the guide can match the center of scale. • 1 Screw (TP ; M3x6) NOTE: Use the screw removed in Unpacking Procedure. Scale...
  • Page 471 6. Paper Output Options 13. Put the Punch Unit while the Upper Cover is open. CAUTION: When having the Punch Unit, be careful not to have the PCB unit and its surrounding area.
  • Page 472 6. Paper Output Options 14. Install the Punch Unit. • 1 Screw (TP ; M3x6) NOTE: Use the screw removed in Unpacking Procedure. CAUTION: • When having the Punch Unit, be careful not to have the PCB unit and its surrounding area. •...
  • Page 473 6. Paper Output Options 16. Connect the Relay Harness as shown in the figure. • 2 Connectors • 1 Reuse Band • 4 Wire saddles 17. Open the Upper Cover.
  • Page 474 6. Paper Output Options 18. Holding the Central Part of the Upper Cover, lower the cover until it stops. 19. Close the Upper Cover.
  • Page 475 6. Paper Output Options 20. Install the Hinge Unit (front) in the Upper Cover. • 2 Screws (TP ; M3x6)
  • Page 476 6. Paper Output Options 21. Install the Hinge Unit (rear) in the Upper Cover. • 4 Screws (TP ; M3x6) NOTE: There is a case using 5 Screws for by a model. • 4 Screws (TP ; M3x6) • 1 Screw (TP(Black) ; M3x6)
  • Page 477 6. Paper Output Options 22. Install the Right Cover of the Finisher. • 2 Claws • 1 Screw (Stepped Screw ; M3x5) • 2 Screws (TP ; M3x6) Claw 23. Insert the Punch Waste Tray in the direction of the arrow from the front. 24.

  • Page 478: Disposal Parts Check

    6. Paper Output Options 25. Install the Rear Cover of the Finisher. • 2 Claws • 2 Screws (TP ; M3x6) 26. Refer to the installation procedure of the Finisher to Install the Finisher in the Host Machine. Disposal Parts Check 1.

  • Page 479: Adjusting The Output Level Of The Punch Waste Full Sensor

    6. Paper Output Options 3. Check the operation such as paper feed and punch operation to make sure that problems such as a jam or malfunction do not occur. NOTE: If the punch hole position of this Equipment needs to be adjusted, go to the "Checking and Adjusting the Punch Hole Position". Adjusting the Output Level of the Punch Waste Full Sensor After installing this Equipment, adjust the output level of the Punch Waste Full Sensor as follows.

  • Page 480: Checking And Adjusting The Punch Hole Position

    6. Paper Output Options Checking and Adjusting the Punch Hole Position ■ Checking the Punch Hole Position 1. Make a print with the punch mode and check whether the skew and side registration and the paper stop position are within the standard. 2 Hole feed direction <front>...
  • Page 481 6. Paper Output Options <Standard> • 2/3 Hole Puncher Unit L1 , L2 12 ± 1.5 mm 2 holes : • 73 ± 1.5 mm (11"x17"/ LTRR) 3 holes : • 31.5 ± 1.5 mm (11"x17"/ LTR) • 40.5 ± 1.5 mm (A3/ A4) •...
  • Page 482 6. Paper Output Options 3. Mark the installation position of the Punch Unit Positioning Guide.
  • Page 483 6. Paper Output Options 4. Loosen the screw fixing the Punch Unit positioning Guide, and then move the guide to adjust by referring the line marked in step 3. After adjusting, tighten the screw. NOTE: When L1 > L2: Move the guide to the right. When L1 <...
  • Page 484 6. Paper Output Options ■ Side Registration Adjustment (Service mode adjustment) When the side registration is not within the standard (when L3 is not within the standard), make the adjustment according to the following procedure. 1. Enter the following service mode to adjust the side registration. Service Mode (Level 1) >...

  • Page 485: Inner 2/3 2/4 4 Hole Puncher-D1

    6. Paper Output Options Inner 2/3 2/4 4 Hole Puncher-D1 Checking before Installation ■ Points to Note at Installation • This installation procedure is described about the installation both of this equipment and the Inner Finisher. When installing the Inner Finisher, refer to this installation procedure instead of the Inner Finisher-only installation procedure. CAUTION: Marked portion: •...

  • Page 486: Unpacking Procedure

    6. Paper Output Options Unpacking Procedure NOTE: This equipment is packed using tapes, fixings and cushioning materials to be protected vibration and shock during transportation. Be sure to remove all the fixing materials and the tapes before starting to install this equipment. ■...
  • Page 487 6. Paper Output Options ■ The Contents of This Equipment [1] Inner Puncher 1x [2] Connector Cover 1x [3] Harness Holder 1x [4] Screw [5] Interface Cover 1x [6] Rail Mounting Cover (Binding (black); M3x8) 1x [7] Screw (Binding; M3x14) 2x NOTE: When this equipment is installed, [3] part not used.
  • Page 488 6. Paper Output Options ■ The Contents of Inner Finisher [1] Inner Finisher 1x [2] Stack Tray 1x [3] Wire Sub Tray 1x [4] Harness [5] Harness Cover 2 1x [6] Rail Cover 1x Cover [7] Sensor Flag (Gray) 1x [8] Screw [9] Staple Cartridge 1x (Binding (black);...

  • Page 489: Installation Procedure

    6. Paper Output Options Installation Procedure ■ Preparation for Host Machine NOTE: When the Reverse Trailing Edge Guide is installed, remove it. NOTE: • Installing the part included with the Inner Finisher. • Check that the Sensor Flag operates smoothly.
  • Page 490 6. Paper Output Options...
  • Page 491 6. Paper Output Options CAUTION: When removing the face seals, be careful that the Delivery Assembly Cover of the Host Machine is not damaged.
  • Page 492 6. Paper Output Options CAUTION: Do not drop the screw into the Host Machine. CAUTION: Do not drop the screw into the Host Machine.
  • Page 493 6. Paper Output Options NOTE: Installing the parts included with the Inner Puncher. Screw (Binding; M3x14) ■ Installing This Equipment NOTE: The removed impact absorbing materials shall be stored to reuse for transportation in case of transference and the repair of this equipment.
  • Page 494 6. Paper Output Options CAUTION: When installing this equipment to the Host Machine, be careful not put the Sensor Flag between this equipment and the Host Machine.
  • Page 495 6. Paper Output Options NOTE: Installing the part included with the Inner Puncher. Screw (Binding (black); M3x8) ■ Installing the Inner Finisher NOTE: The removed impact absorbing materials shall be stored to reuse for transportation in case of transference and the repair of the Inner Finisher.
  • Page 496 6. Paper Output Options CAUTION: When put the Inner Finisher on the Host Machine, be careful of the following points. • Do not slide the Inner Finisher on the inner part of the Host Machine nor bump the Inner Finisher to the covers of the Host Machine.
  • Page 497 6. Paper Output Options NOTE: Secure enough space between the Inner Finisher and the Inner Rear Cover of the Host Machine. About 100mm NOTE: • Secure the Harness Band to the position in the figure below. • Installing the part included with the Inner Finisher.
  • Page 498 6. Paper Output Options NOTE: Installing the parts included with the Inner Finisher. Screws (Binding (black); M3x8)
  • Page 499 6. Paper Output Options...
  • Page 500 6. Paper Output Options NOTE: Installing the part included with the Inner Puncher.
  • Page 501 6. Paper Output Options CAUTION: Before installing the Harness Cover 2, check that the connector is positioned as shown in the figure. NOTE: Installing the parts included with the Inner Finisher. Screws (Binding (black); M3x8)
  • Page 502 6. Paper Output Options...
  • Page 503 6. Paper Output Options NOTE: Installing the part included with the Inner Puncher.
  • Page 504 6. Paper Output Options NOTE: Installing the part included with the Inner Finisher.
  • Page 505 6. Paper Output Options NOTE: Installing the part included with the Inner Finisher. Claw Hook Hook Claw...
  • Page 506 6. Paper Output Options CAUTION: Check that the Stack Tray is properly installed. If the installation fails, error; E540-8001/8002 may occur at power ON. Hook Hook Hook Claw Claw Claw NOTE: Installing the part included with the Inner Finisher.

  • Page 507: Checking After Installation

    6. Paper Output Options Checking after Installation ■ Disposal Parts 1. Following disposal parts are remained after the installation procedure. (Installed in the host machine) Screw （TP; M3x8） ■ Operation Checks 1. Connect the power plug of the Host Machine in the outlet. 2.

  • Page 508: Adjustment

    6. Paper Output Options 3. If a message appears prompting the user to update the firmware, press [Update] to automatically update the firmware of this equipment. NOTE: If [Skip] is selected, a message will appear every time when the Host Machine turns ON prompting the user to update the firmware. In the service mode (Level 2) shown below, behavior of the message can be changed to be no longer displayed.
  • Page 509 6. Paper Output Options • 2/4 Hole Puncher Unit L1, L2 12±1.5mm 2 holes: 108.5±1.5mm (A3/ A4) 99.7±1.5mm (11"x17"/ LTR) 4 holes: 28.5±1.5mm (A3/ A4) 19.7±1.5mm (11"x17"/ LTR) • 4 Hole Puncher Unit L1, L2 12mm±1.5mm 92.5±1.5mm (A3/ A4) 83.7±1.5mm (11"x17"/ LTR) ●...

  • Page 510: Appendices

    APPENDICES Image position adjustment of Pickup transport system......503...

  • Page 511: Image Position Adjustment Of Pickup Transport System

    Image position adjustment of Pickup transport system Image position adjustment of Pickup transport system Adjusting Image Position (Printer) NOTE: • In duplex printing, the first side is the front side and the second side is the back side. • The Host Machine prints the first image on the back and the second on the front. ■...
  • Page 512 Image position adjustment of Pickup transport system ＜ Cassette 1 out of Specification ＞ 2. Change the left edge margin adjustment value for the 1st side of the Cassette 1. As the service mode value is changed by 1, the left margin is changed by 0.1 mm. COPIER >...
  • Page 513 Image position adjustment of Pickup transport system ＜ In Case of Out of Range ＞ NOTE: • Pull out the cassette. • Check the value of the scale on the Adjustment Plate. Scale Loosen the 1 Fixed Screw.
  • Page 514 Image position adjustment of Pickup transport system Move the Adjustment Plate left or right based on the scale value checked in step 2. (As the Adjustment Plate is moved toward the left of the machine by 1 tooth, the left edge margin is increased by 0.5 mm.) Scale Teeth Tighten the Fixation Screws.
  • Page 515 Image position adjustment of Pickup transport system Pull out the next upper cassette, and check if the Adjustment Plate is correctly pushed against the frame. CAUTION: If the Adjustment Plate is not correctly pushed against the frame, image cannot be correctly adjusted. When the cassette 3 is used for checking, it is necessary to remove the cassette front cover.
  • Page 516 Image position adjustment of Pickup transport system ■ Cassette Left Edge Margin Adjustment (2nd Side) 1. Perform a test print from Cassette 1 (2-sided print), and confirm that the left edge margin is 2.5 +/- 2.0 mm. Feeding direction of paper image ＜...
  • Page 517 Image position adjustment of Pickup transport system 3. Write the new adjustment value on the service label. • ADJ-MFRE ■ Leading Edge Margin Adjustment (1st side) 1. Perform a test print from Cassette 1, and confirm that the leading margin is L1 = 4.0 + 1.5/-1.0 mm. Feeding direction of paper image...
  • Page 518 Image position adjustment of Pickup transport system <When installing only the Host Machine> “Image Position Adjustment (Single Pass ADF)” on page 49 ● 2-Stage Cassette Pedestal - AW1 Hardware adjustment 1. Pull out the cassette. 2. Check the value of the scale on the Adjustment Plate. Scale 3.
  • Page 519 Image position adjustment of Pickup transport system 5. Tighten the Fixation Screws. NOTE: If you move the Adjustment Plate, it may cause the difference in level of the cassettes. If you are concerned with the difference in level of the cassettes, adjust it by loosening the 2 screws on the side. 6.
  • Page 520 Image position adjustment of Pickup transport system 3. If the service mode setting value has been changed, write down the new adjustment value on the service label. Standard value • Leading edge: 4.0 + 1.5/ -1.0mm (front side, back side) •...

  • Page 521: Revision History

    Revision History Revision History Chapter Category Product Name Reference Remarks First Edition Installation manual Host Machine Add Con- Installing the Scanner “ Installing the Scan- tents ner” on page 26 Host Machine Add Con- Super G3 FAX Board-AX1 “Super G3 FAX Board- Options tents BH1”...

This manual is also suitable for:

Imagerunner advance dx c3830iImagerunner advance dx c3826i

Table of Contents

Save PDF
