Daikin ADEA35A2VEB Operation Manual page 5

For combination with R410A outdoor unit, refer to the following
table:
ARXS35~71
Outdoor temperature
Indoor temperature
Indoor humidity
(a)
To avoid condensation and water dripping out of the unit. If the
temperature or the humidity is beyond these conditions, safety
devices may be put in action and the air conditioner may not
operate.
AZQS71~125
Outdoor temperature
Indoor temperature
Indoor humidity
(a)
To avoid condensation and water dripping out of the unit. If the
temperature or the humidity is beyond these conditions, safety
devices may be put in action and the air conditioner may not
operate.
For combination with R32 outdoor unit, refer to the following table:
ARXM35~71
Outdoor temperature –10~46°C DB
Indoor temperature
Indoor humidity
(a)
To avoid condensation and water dripping out of the unit. If the
temperature or the humidity is beyond these conditions, safety
devices may be put in action and the air conditioner may not
operate.
AZAS71~125
Outdoor temperature
Indoor temperature
Indoor humidity
(a) To avoid condensation and water dripping out of the unit. If the
temperature or the humidity is beyond these conditions, safety
devices may be put in action and the air conditioner may not
operate.
Setting temperature range of the user interface:
Cooling
17~32°C
4.2 Operation procedure
▪ Turn on the power at least 6 hours before operating the unit in
order to ensure smoother operation. As soon as the power is
turned on, the user interface display appears.
▪ If there was a power failure during operation, the system
automatically restarts immediately after the power supply is
recovered.
▪ The setting temperature range of the user interface is described in
chapter "Operation range".
▪ If you select a function which is not available, the message
appears on the user interface.
▪ The operation procedure depends on the model (heat pump or
cooling only). Contact your dealer to confirm which model you are
using.
ADEA-A
Split system air conditioners
3P551387-1B – 2024.07
Cooling Heating
10~46°C DB –15~18°C WB
14~28°C WB 10~30°C DB
(a)
≤80% —
Cooling Heating
–5~46°C DB –15~15.5°C WB
14~28°C WB 10~27°C DB
(a)
≤80% —
Cooling Heating
–15~24°C DB
–16~18°C WB
21~37°C DB 10~30°C DB
14~28°C WB
(a)
≤80% —
Cooling Heating
–5~46°C DB –15~21°C DB
–15~15.5°C WB
20~38°C DB 10~27°C DB
14~28°C WB
(a)
≤80% —
Heating
16~31°C
5 Maintenance and service
▪ Read the documentation carefully before operating the user
interface to ensure the best possible performance.
5 Maintenance and service
5.1 Precautions for maintenance and
service
CAUTION
instructions" [ 4 2] to acknowledge all
See "2 User safety
related safety instructions.
NOTICE
Maintenance MUST be done by an authorised installer or
service agent.
We recommend performing maintenance at least once a
year. However, applicable legislation might require shorter
maintenance intervals.
NOTICE
When cleaning the heat exchanger, make sure to remove
the switch box and fan motor. Water or detergent might
deteriorate the insulation of electronic components and
result in burnout of these components.
5.2 About the refrigerant
This product contains fluorinated greenhouse gases. Do NOT vent
gases into the atmosphere.
Refrigerant type: R32
Global warming potential (GWP) value: 675
Refrigerant type: R410A
Global warming potential (GWP) value: 2087.5
NOTICE
Applicable legislation on fluorinated greenhouse gases
requires that the refrigerant charge of the unit is indicated
both in weight and CO
2
Formula to calculate the quantity in CO
tonnes: GWP value of the refrigerant × total refrigerant
charge [in kg]/1000
Contact your installer for more information.
WARNING: FLAMMABLE MATERIAL
The R32 refrigerant (if applicable) in this unit is mildly
flammable. Refer to the outdoor unit specifications for the
type of refrigerant to be used.
WARNING
▪ Do NOT pierce or burn refrigerant cycle parts.
▪ Do NOT use cleaning materials or means to accelerate
the defrosting process other than those recommended
by the manufacturer.
▪ Be aware that the refrigerant inside the system is
odourless.
equivalent.
equivalent
2
Operation manual
5
