1 About this document
2 User safety instructions
2.1 Instructions for safe operation ...................................................
3 About the system
3.1 Components ..............................................................................
4 Operation
4.1 Operation range.........................................................................
4.2 Operation procedure..................................................................
5 Maintenance and service
5.1 Precautions for maintenance and service .................................
5.2 About the refrigerant..................................................................
5.3 To clean the drain pan...............................................................
5.4 To handle the drain pipe plug ....................................................
5.5 Cleaning the air filter, suction grille, air outlet and outside
panels ........................................................................................
5.5.1 To clean the air outlet and outside panels ..................
5.5.2 To clean the air filter ...................................................
5.6 Maintenance before a long stop period .....................................
5.7 Maintenance after a long stop period ........................................
6 Troubleshooting
7 Disposal
1 About this document
Thank you for purchasing this product. Please:
▪ Read the documentation carefully before operating the user
interface to ensure the best possible performance.
▪ Keep the documentation for future reference.
Target audience
End users
INFORMATION
This appliance is intended to be used by expert or trained
users in shops, in light industry, and on farms, or for
commercial and household use by lay persons.
Documentation set
This document is part of a documentation set. The complete set
consists of:
▪ General safety precautions:
▪ Safety instructions that you must read before operating your
system
▪ Format: Paper (in the box of the indoor unit)
▪ Operation manual:
▪ Quick guide for basic usage
▪ Format: Paper (in the box of the indoor unit)
▪ User reference guide:
▪ Detailed step-by-step instructions and background information
for basic and advanced usage
▪ Format: Digital files on https://www.daikin.eu. Use the search
function to find your model.
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your installer.
The original instructions are written in English. All other languages
are translations of the original instructions.
Operation manual
2
2 User safety instructions
Always observe the following safety instructions and regulations.
2
2.1 Instructions for safe operation
2
WARNING: FLAMMABLE MATERIAL
2
4
The R32 refrigerant (if applicable) in
4
this unit is mildly flammable. Refer to
4
the outdoor unit specifications for the
4
type of refrigerant to be used.
5
WARNING
5
5
▪ Do NOT modify, disassemble,
5
remove, reinstall or repair the unit
6
6
yourself as incorrect dismantling or
installation may cause an electrical
6
6 shock or fire. Contact your dealer.
6
▪ In case of accidental refrigerant
7
7
leaks, make sure there are no naked
7 flames. The refrigerant itself is
entirely safe and non-toxic. R410A is
7
a non-combustible refrigerant, and
R32 is a mildly flammable refrigerant,
but they will generate a toxic gas
when they accidentally leak into a
room where combustible air from fan
heaters, gas cookers, etc. is present.
Always have qualified service
personnel confirm that the point of
leakage has been repaired or
corrected before resuming operation.
CAUTION
Do NOT insert fingers, rods or other
objects into the air inlet or outlet. Do
NOT remove the fan guard. When the
fan is rotating at high speed, it will
cause injury.
CAUTION
▪ NEVER touch the internal parts of the
controller.
▪ Do NOT remove the front panel.
Some parts inside are dangerous to
touch and appliance problems may
happen. For checking and adjusting
the internal parts, contact your
dealer.
ADEA-A
Split system air conditioners
3P551387-1B – 2024.07
