TECHNICAL DESCRIPTION
5054
DISPLAY UNIT V. 1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5054 and is the answer not in the manual?

Questions and answers

Summary of Contents for Panasonic 5054

  • Page 1 PANASONIC FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 5054 DISPLAY UNIT V. 1.0.0...
  • Page 2 MEW02376 DATE OF ISSUE: 2019-05-27 REV: DATE OF REVISION: 2019-09-12 Panasonic Fire & Security Europe AB Jungmansgatan 12 SE-211 11 Malmö Sweden Tel: +46 (0)40 697 70 00 Internet: www.panasonic-fire-security.com TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 3: Table Of Contents

    EXTERNAL FIRE BRIGADE PANEL 1582 & EXTERNAL PRESENTATION UNIT 1582 ........16 7.1.2. EXTERNAL PRESENTATION UNIT – LIMITED ...................... 16 7.2. COMPATIBILITY TABLE ......................16 7.3. UNIT ADDRESS .......................... 17 7.4. LANGUAGE / AREA ........................17 7.5. DISPLAY BRIGHTNESS ......................17 TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 4 MOUNTING IN DISPLAY UNIT METAL CABINET ..................... 25 12.2. DRILL MEASURES ........................27 INSTALLATION AND WIRING .................. 28 RESTART ......................... 29 COMMISSIONING ....................30 TECHNICAL DATA ....................31 APPROVALS ......................32 TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 5: Introduction

    Zone number and address within the zone (001, 01-999, 99) zone1, addr1 The first zone number and address in the sequence zone2, addr2 The last zone number and address in the sequence TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 6: General Description

    The display unit complies with IP30, in respect of dust and moisture. It is intended for indoor use and in dry premises. (Measures in mm) Colour Indicating Watchdog fault / communication fault Yellow Steady Power Green Steady TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 7: Rs485

    Since the c.i.e power supply output current is limited to 1.6A, up to four display units can be power supplied via the c.i.e. The External power supply 4466, can supply up to five display units per output. 3.3. USB The display unit is equipped with an USB interface (X2). TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 8: Touch Screen

    Resolution: 1024x600 RGB 3.5. ALARM PRESENTATION 1. Displayed alarm in the list 2. Zone in alarm - address 3. Last zone in alarm 4. Number of zones in alarm 5. Free text TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 9: External Presentation Unit

    When all fire alarms are reset, the display unit will return to normal operation. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 10: Buzzer

    20 seconds, if no button is pressed during that time. For pre-warnings the button Alarms queued will not be visible. Th e arrows flashes (0.4/0.4 s), and the pre- warnings will be automatically scrolled (each five seconds) . TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 11: Alert Annunciation Unit

    The button Reset is possible to use. If there are two or more alarms in the system, the button alarms queued will start to flash (0.4/0.4 s), and you can scroll amongst the alarms. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 12: Alert Annunciation Function

    Routing equipment “Fire brigade tx delay” on the c.i.e. front. Normally only one time channel is used for this function but two or more channels can be used. The alert annunciation function can, as an alternative, be continuously on. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 13: Buzzer

    20 seconds, if no button is pressed during that time. For pre-warnings the button Alarms queued will not be visible. Th e arrows flashes (0.4/0.4 s), and the pre- warnings will be automatically scrolled (each five seconds) . TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 14: External Fire Brigade Panel

    The unit has a built-in buzzer that will sound (0.4/0.4 s) when an alarm is activated (0.8/5s for pre-warning or co-incidence). The buzzer will have a steady sound for not acknowledge faults in the system. The buzzer can be silenced. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 15: Fault

    20 seconds, if no button is pressed during that time. For pre-warnings the button Alarms queued will not be visible. Th e arrows flashes (0.4/0.4 s), and the pre- warnings will be automatically scrolled (each five seconds) . TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 16: Service Menu

    - External presentation unit - Fire brigade panel (1582) - External presentation unit (1582) - External presentation unit (Limited) Select the wanted unit type and press to save the settings. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 17: External Fire Brigade Panel 1582 & External Presentation Unit 1582

    Not used (V=Software version) 1) For EBL512 G3, version ≥ 2.5, program as Display unit 5054 – Fire brigade panel in EBLWin. For others program as FBP 1826, 1828. 2) For EBL512 G3, version ≥ 2.5, program as Display unit 5054 – Alert annunciation unit in EBLWin.
  • Page 18: Unit Address

    Pick a colour from the list to test. The screen is filled with the test colour, and makes it possible for you to find pixels that fail to show the selected colour. NOTE! Pixels are very small so you have to look carefully at all test images. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 19: Selective Alarm Presentation

    Default programming in system EBL512 G3 is: Control units (00, 29). All alarms from all c.i.e:s will be presented in all display units. Default programming in system EBL128: Control units (00, 00). All alarms will be presented in all display units. The programming is done via EBLWin. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 20: User Definable Text Messages

    EBLWin and downloaded when the c.i.e. SSD is downloaded. NOTE! It is also possible to select which fire alarms that shall be presented in the display unit respectively, see chapter 8. SELECTIVE ALARM PRESENTATION TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 21: Fault Messages In The Display Unit

    Something went wrong during the download, or the wrong file was downloaded. Try to download again, see . Make sure that the file system version matches the firmware version. 11.3 FILE SYSTEM DOWNLOAD TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 22: Firmware And File System

    When the download is ready, there will be a pop up dialog window, asking if you want to restart the display unit. Click Yes to restart the display unit. i) Normally a new file system must be downloaded after the firmware is changed, continue with 11.3 FILE SYSTEM DOWNLOAD. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 23: File System Download

    Start the downloading. h) When the download is ready the pop up dialog window ‘Download completed successfully’ is shown and the display unit will restart. Regarding fault messages see chapter 14. RESTART TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 24: Mounting

    Mount the box on the wall, see 12.2 DRILL MEASURES Tip! Use the internal level vial to make sure the display unit is levelled. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 25 Assemble the front of the display unit with the two screws. Be careful not to pinch any cables. NOTE! The screws are mounted at a 45 degree angle. n) Connect the cables to the terminal block J1 in the c.i.e. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 26: Mounting In Display Unit Metal Cabinet

    Remove the ground bar plate from the back cover and mount it inside the cabinet. Use the screws enclosed with the cabinet. e) Remove the ground cable and replace it with the longer ground cable supplied with the cabinet. 3. Frame back 4. Ground bar plate TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 27 Pull the cables through the inlets, and clamp the cables on the ground bar plate. h) Assemble the front of the display unit with the two screws. NOTE! The screws are mounted at a 45 degree angle. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 28: Drill Measures

    12 MOUNTING 12.2. DRILL MEASURES Measures in mm TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 29: Installation And Wiring

    NOTE! “J7” and “J3” must only be shunted if the unit is the last unit on the line. Primary terminal block Secondary terminal block, can be used for redundant connection of communication and power supply, when this is supported by the c.i.e. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 30: Restart

    A fault message will be shown in the c.i.e: • EBL512 G3: “FAULT: Site specific data, display unit xx, control unit xx” • EBL128: “FAULT: Site specific data (SSD), EPU x” TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 31: Commissioning

    During the download, the following will be shown on the display: "SSD download in progress.." l) After the download of the SSD, the unit will restart and then start working in normal operation mode. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 32: Technical Data

    Maximum 93, % RH (Non condensing) Ingress protection rating IP 30 Size: H x W x D 169 x 264 x 56 mm Weight 1400 g Colour Light grey (NCS S 1500-N) TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...
  • Page 33: Approvals

    EN 55032 Class A when mounted in 5055 (Emission) Self declaration EN50130-4 (Immunity) RoHS EN50581 Self declaration 1) Note: Operation of this class A equipment in a residential environment could cause radio interference. TECHNICAL DESCRIPTION 5054 • DOCUMENT NUMBER: MEW02376 • REVISION: 1...

Table of Contents
