Panasonic WV-CK2020A Specifications

Simple large screen monitor for a cost effective CCTV solution
The WV-CK2020 is a cost effective CRT monitor. The 51 cm viewable size screen allows easier monitoring and multi-
split screen when used with Panasonic digital recorders. With 500 TV lines of horizontal resolution even small details
are clear and faithfully reproduced.
Key Features
• CRT size: 55 cm (21") diagonal
• Viewable size: 51 cm (20") diagonal
• Horizontal Resolution: 500 TV lines at center
• Scanning: Interlace, 8 % over scan (typical)
• Color temperature: 9,300 °K (NTSC), 6,500 °K (PAL)
• Composite Video input: 1x Composite Video Input (BNC) with auto
termination loop through output (BNC)
• S-Video input: 1x S-Video input (NTSC only)
• Audio input: 1x –8 dB / Hi-Z, (RCA pin jack) with loop through output
(RCA pin jack)
• Speaker: 0.7 W
• Adjustment using OSD setup menu: BRIGHT, CONTRAST,
PICTURE, COLOR, TINT (NTSC only) by setup menu
• Multi-language setup menus: English, French, German
• Cost effective plastic cabinet
51 cm (20") Color CRT Monitor
WV-CK2020
WV-CK2020A
(120 V AC)
Standard Accessory
• Operating Instructions .................. 1 pc.
System Example
WV-CW960 Series x 8 WV-CP480 Series x 8
CH1 CH8 CH9
Digital Disk Recorder
WJ-HD316A
(10Base-T/100Base-TX)
System Controller
WV-CU650
Series
WV-CK2020
(220 ~ 240 V AC)
WV-CK1420 Series
CH16
WV-CK2020 Series
VIDEO output
RGB output
WV-LC1900
LAN/WAN
Ethernet
PC
Internet
PC
