- Page 1 5054 DISPLAY UNIT V 3.0.0 Fire alarm solutions technical description www.panasonic-fire-security.com...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION ABBREVIATIONS GENERAL DESCRIPTION 3.1. RS485 3.2. POWER SUPPLY 3.3. USB 3.4. TOUCH SCREEN 3.5. INFORMATION PAGE 3.6. ALARM PRESENTATION 3.7. COMPATIBILITY 3.7.1. UNIT TYPE EXTERNAL PRESENTATION UNIT 4.1. FIRE ALARM 4.2. BUZZER 4.3. DISABLEMENT MESSAGE 4.4. QUIET ALARM 4.5. - Page 3 5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 7.3.3. CONFIGURATION IN EBLWIN 7.4. EVACUATE INPUT SERVICE MENU 8.1. UNIT TYPE 8.2. UNIT ADDRESS 8.3. LANGUAGE / AREA 8.4. DISPLAY BRIGHTNESS 8.5. BUZZER / SOUND VOLUME 8.6. PIN CODE 8.7.
-
Page 4: Introduction
1. INTRODUCTION This document describes the display unit, type number 5054. The document contains information about the product and instructions on how to mount and connect it. -
Page 5: Abbreviations
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 2. ABBREVIATIONS Control and indicating equipment Control unit number (CIE no 00-29) The first control unit number in the sequence The last control unit number in the sequence Decibel... -
Page 6: General Description
3. GENERAL DESCRIPTION The display unit consists of a colour touch display and has multi language support. It is intended to be used for fire alarms and information in the fire alarm system. When a fire alarm is activated in the CIE, the fire alarm information will be sent to the display unit. An alarm text can be presented together with each alarm, if programmed in the CIE or in EBLWin. -
Page 7: Rs485
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 3.1. RS485 The display unit communicate with the CIE via RS485. In system EBL512 G3 the required components are mounted on the main board by delivery. In the last unit on the line, a termination resistor (120R) has to be connected. In the display unit this is done via jumper "J3" for primary or “J7”... -
Page 8: Touch Screen
1000 pixels will automatically be resized to fit the window. Resized images can become blurry. The default image can be created in for example Paint or Illustrator. Illustrator template and background images can be downloaded from www.panasonic-fire-security.com. In Paint a) Open the background image. -
Page 9: Alarm Presentation
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 3.6. ALARM PRESENTATION 1. First zone or alarm point in alarm 2. Latest zone or alarm point in alarm 3. Displayed alarm 4. User definable text 5. Position of displayed alarm in the list 6. -
Page 10: Compatibility
Not used Not used For EBL512 G3 version ≥ 2.5, program as Display unit 5054 – and select unit type in EBLWin. For older version than EBL512 G3 version 2.5, program 5054 (version 1.0.x) as an older display units 1728,... -
Page 11: External Presentation Unit
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 4. EXTERNAL PRESENTATION UNIT 1. Fire alarm indicator 2. Extinguishing symbol 3. Ventilation symbol 4. Fire brigade tx symbol 5. Silence buzzer 6. Alarms queued 4.1. FIRE ALARM When a fire alarm is activated Pre-warnings, co-incidence, fire alarms, and heavy smoke / heat alarms will be presented on the display. -
Page 12: Disablement Message
4.3. DISABLEMENT MESSAGE Disablement in the system will be displayed as "General disablement in system" on the display . When the disablement symbol is activated, the display back-light is turned on for two minutes. The back-light will remain turned on with 10% screen brightness as long as there are disablements in the system. -
Page 13: Alert Annunciation Unit
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 5. ALERT ANNUNCIATION UNIT 1. Fire alarm indicator 2. Acknowledge symbol 3. Acknowledge time 4. Investigation symbol 5. Investigation time 6. Fire brigade alerted symbol 5.1. FIRE ALARM FIRE ALARM WITHOUT ALERT ANNUNCIATION When a fire alarm is activated, fire alarms and heavy smoke / heat alarms will be presented on the display. - Page 14 FIRE ALARM WITH ALERT ANNUNCIATION When an alert annunciation alarm is activated the acknowledge time starts. The fire alarm indicator will start to flash (0.4/0.4 s) and the button Acknowledge is possible to use. When the alarms have been acknowledged, the investigation time starts. The fire alarm indicator will stop flashing and the button Reset is possible to use.
-
Page 15: Alert Annunciation Function
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 5.2. ALERT ANNUNCIATION FUNCTION The alert annunciation function can be used to avoid nuisance alarms to the fire brigade. The alert annunciation function is pro- grammed via EBLWin, and normally analog smoke detectors and zones with smoke detectors only are programmed. Heat detectors and manual call point should normally not be programmed for alert annunciation. -
Page 16: Buzzer
5.3. BUZZER The unit has a built-in buzzer that will sound (0.4/5 s) when an alert annunciation alarm is activated. The buzzer will be silent when the acknowledge button is pressed or when the alert annunciation alarm turns into a real fire alarm. If the buzzer is programmed as "disabled"... -
Page 17: Fire Brigade Panel
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 6. FIRE BRIGADE PANEL 1. Fire alarm indicator 2. Extinguishing symbol 3. Ventilation symbol 4. Fire brigade tx symbol 5. Silence buzzer 6. Silence alarm devices 7. Reset 8. Alarms queued 6.1. -
Page 18: Fault
6.3. FAULT Fault in the system will be displayed as "General faults in system" on the display. When the fault symbol is activated, the display back-light is turned on for two minutes. The back-light will remain turned on with 10% screen brightness as long as there are faults in the system. -
Page 19: General Control Panel
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 7. GENERAL CONTROL PANEL The general control panel has 8 inputs that can be programmed via EBLWin, as one of the following types: • Input • Fan/Damper Control •... -
Page 20: Input
7.1. INPUT Input switch off Input switch on The following programmable input trigger conditions can be used: • Activate output • Evacuate • External time channel • Technical warning... -
Page 21: Fan/Damper Control
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 7.2. FAN/DAMPER CONTROL Green fan = Normal state Red fan = Not normal state The Fan/Damper Control module has a normal function for a "Supply air fan" or a "Standard fan". There is also an enhanced func- tion for a "Smoke exhaust", "Smoke spill", "Stair pressurization"... -
Page 22: Fault
7.2.1. FAULT Fault for the fan will be displayed in the lower part of the module. The fault symbol is displayed when: • The fan has been activated either via the button On or by the CIE in Auto mode, but the 4461 input has not been activated within 30 seconds after the activation of the 4461 output. -
Page 23: Fan Control Via 4461
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 7.2.3. FAN CONTROL VIA 4461 The fan is activated via the relay output Re0 on the I/O unit, and the feedback signal is connected to input In0. Input In0 can be programmed as supervised or not supervised in EBLWin. - Page 24 TEST APPLICATION FOR ENHANCED FAN CONTROL The following figure is an example of how the Mechanical service switch board (MSSB) contacts might be used for testing of the fan control function. (Enhanced fan control). Mechanical service switch board (MSSB) Ext. control (Time clock) MSSB MSSB...
-
Page 25: Applications
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 7.3. APPLICATIONS The fan control panel can be used for Supply air fans (normally ON) and/or Smoke exhaust, smoke spill and Stairs pressurization fans (normally OFF). 7.3.1. SUPPLY AIR FAN... -
Page 26: Smoke Exhaust, Smoke Spill, And Stairs Pressurisation Fans
7.3.2. SMOKE EXHAUST, SMOKE SPILL, AND STAIRS PRESSURISA- TION FANS Fan status Fire alarm from detector / Reset of the alarm(s) that have Time zone programmed to control activated the fan. Fan stops the fan. Fan starts DETECTOR TYPE Both analog addressable smoke detectors and conventional zones can be programmed to control the fan. -
Page 27: Configuration In Eblwin
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 7.3.3. CONFIGURATION IN EBLWIN a) Add a Fan/Damper input b) Add one 4461 for each Fan/Damper Control input. c) In the “4461 I/O unit for fan/damper control”. dialog box, connect the 4461 to the Fan/Damper Control input. - Page 28 d) In the “4461 I/O unit for fan/damper control”. dialog box, configure: • Technical address (COM loop address 1-253) • Name (Fan control I/O unit - normally not changed) • Fan control information • I/O Matrix fan control. Select by its customized name. •...
-
Page 29: Evacuate Input
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 7.4. EVACUATE INPUT Evacuate input switch off Evacuate input switch on The evacuate input can be used to manually activate the siren to start evacuate zones or the whole building. -
Page 30: Service Menu
8. SERVICE MENU A new display unit has no unit type, address, or language selected, it is factory set to "Not selected". When the display unit is pow- ered for the first time it will automatically show the service menu. For a display unit in operation, the service menu can be opened via the jumper "J4"... -
Page 31: Unit Address
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 8.2. UNIT ADDRESS The unit shall have a unique address on the RS485 line. The address can be set to 00-29 (Default is "00".) Set the address with the arrow buttons, and press to save the settings. -
Page 32: Selective Alarm Presentation
9. SELECTIVE ALARM PRESENTATION Normally all fire alarms will be presented in the CIE and the display unit. It is possible to select which alarms that shall be presented in the display unit. For example if there are many buildings in an installation, the units in one specific building shall only present alarms activated within this building. -
Page 33: User Definable Text Messages
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 10. USER DEFINABLE TEXT MESSAGES The user definable text messages (alarm texts) are depending on which unit type the display unit is running in. Each alarm text (up to 40 alphanumeric characters) will be shown on the second row. The texts are created and downloaded via EBLWin. -
Page 34: Fault Messages In The Display Unit
11. FAULT MESSAGES IN THE DISPLAY UNIT "General fault in system" Any not corrected / serviced fault in the system and any not acknowledged fault in the system. To see the fault(s), use any CIE in the system. "No contact with control unit" The contact with the CIE is interrupted for >... -
Page 35: Ip Camera And Drawing
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 12. IP CAMERA AND DRAWING In EBL Graphics it is possible to connect an IP camera and / or overview drawing to one or several alarm points. The camera picture and the drawing is sent to the display unit over TCP/IP, by using EBL Service. -
Page 36: Ebl Service
EBL Service is dependent on Visual Studio 2015 run-time components (both x64 and x86 versions). These can be downloaded from https://www.microsoft.com/en-us/download/details.aspx?id=48145. The settings are saved in the `Panasonic Fire And Security` folder. The user account that the EBL Service is running under must have at least read access to the folder where the EBL Graphics configuration is located”. - Page 37 5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION The IP address of the PC with EBL Service installed also need to be set in EBLWin. j) Open the Display unit 5054 properties window in EBLWin k) Enter the Server IP address and Server port.
-
Page 38: Firmware And File System
The procedures below describes the EBL Firmware manager version 1.3.0. Some Microsoft Windows versions may require the USB driver for Display unit 5054 to be installed on your computer before using the EBL Firmware manager. The driver can be downloaded from www.panasonic-fire-security.com. -
Page 39: Download Firmware In Boot Mode
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 13.2.1. DOWNLOAD FIRMWARE IN BOOT MODE If the display unit cannot be restarted, it can be forced into boot mode to be able to download new firmware. A Display unit driver is needed for downloading when the unit is in boot mode. -
Page 40: File System Download
Connect the PC to the display unit via USB. c) In EBLWin, click Tool / Download software to open the EBL Firmware Manager. d) Select the Display unit (5054) file system tab. e) Browse to the file system file to be downloaded, DU5054_x.x.x_FS.bin. -
Page 41: Mounting
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 14. MOUNTING The display unit must be mounted on the wall. Screws for wall mounting are not supplied. a) Remove the two screws (Torx T10) at the bottom of the display unit and open it. - Page 42 f) Remove the insulating cover on the cables. The remaining strip of the shield shall be about 15 mm. g) Bend the shield backwards over the insulating cover. Ground bar The cable cover is removed Ground bar plate with cables and one ground cable The shield is bent backwards (Measure in mm) h) Clamp the cables on the ground bar plate.
-
Page 43: Mounting In Display Unit Metal Cabinet
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 14.1. MOUNTING IN DISPLAY UNIT METAL CABINET The display unit can be mounted in the display unit metal cabinet 5055. a) Remove the two screws (Torx T10) at the bottom of the display unit and open it. - Page 44 f) The cabinet has several knock-outs for cable inlets, four knock-outs on the top, bottom, and back. Four compression glands are supplied with the cabinet. g) Pull the cables through the inlets, and clamp the cables on the ground bar plate. h) Assemble the front of the display unit with the two screws.
-
Page 45: Drill Measure
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 14.2. DRILL MEASURE (Measure in mm) -
Page 46: Installation And Wiring
15. INSTALLATION AND WIRING Up to 1200 m communication cable can be used. Ø (mm) Area (mm Wire size (Min) 0.65 0.33 Wire size (Max) 1.85 2.08 RS485 REDUNDANCY... - Page 47 5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION Jumper “J3, J7” for end-of-line resistor 120 R J3, J7 SECONDARY PRIMARY ETHERNET When the unit is the last unit on the line. J3, J7 RESET BOOT ADDR When the unit is not the last unit on the line.
-
Page 48: Restart
16. RESTART The display unit will restart: • When it is powered up • After address setting • If the contact with the control unit is OK again after the message: “No contact with Control unit” If there is a program memory fault, there will be a fault message in the display unit: “Memory fault in program area (n)”... -
Page 49: Commissioning
During the download, the following will be shown on the display: "SSD download in progress.." The first time you download an SSD to 5054, or if an updated default image is to be downloaded to the dis- play unit, the check box 'Download display unit image' must be selected. -
Page 50: Technical Data
18. TECHNICAL DATA All current consumptions are valid by nominal voltage and by 25 °C. Voltage: Allowed 12 – 30V DC Normal 24V DC Current: 12V DC 24V DC Quiescent 80 mA 45 mA Active 350 mA 180 mA Address range 00-29 Address setting See chapter 8.2. -
Page 51: Approvals
5054 DISPLAY UNIT V. 3.0.0 - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 19. APPROVALS Applicable directive/ Approval Applicable standards Notified body EN 55032 Class B (Emission) EN 55032 Class A when mounted in 5055 (Emission) 1) Self declaration EN50130-4 (Immunity) RoHS... - Page 52 DOCUMENT NAME: TECHNICAL DESCRIPTION 5054 DOCUMENT NUMBER: MEW02763 EN DATE OF ISSUE: 2022-03-08 REV: 1 DATE OF REVISION: 2023-10-17 Panasonic Fire & Security Europe AB Jungmansgatan 12 SE-211 11 Malmö Tel: +46 (0)40 697 70 00 www.panasonic-fire-security.com...
