- Page 1 LAN/4G swiss made power...
- Page 2 Studer disclaims all responsibility and liability for damage, costs or losses resulting from an installation that does not comply with the instructions, a faulty operation or inadequate maintenance. The use of studer equipment is in any case under the responsibility of the customer.
- Page 3 Content xcom LAN xcom 4G xcom LAN kit SD card xcom 4G kit SD card Ethernet cable (a) Serial cable MF (b) Antenna (a) Serial cable FF (b) Communication Communication Power supply cable (c) Power supply cable (c) cable (d)
- Page 4 Wiring xcom LAN Ethernet cable: Moxa Ethernet gateway <> Router b) Serial cable: Moxa Ethernet gateway <> xcom232i Power supply cable: Moxa Ethernet gateway <> xcom232i d) Communication cable: xcom232i <> xtender/vario All cables you need are provided in the set.
- Page 5 Serial cable: TRB142 <> xcom232i Power supply cable: TRB142 <> xcom232i d) Communication cable: xcom232i <> xtender/vario !xcom LAN/4G must be configured as xcom LAN! SIM card 1. Unscrew two back panel hex bolts and remove the back panel.
-
Page 6: Led States
LED states xcom 232i on - update error or backup blink - updating process blink 2x - micro SD full green on - data logging blink - communication (via RS-232) blink 2x - In operation orange on - Insertion SD card Moxa LAN gateway on - NPort booting up blink - IP conflict... - Page 7 Configuration – xcom LAN/4G SD card – computer xcom configurator Can be downloaded from our website !xcom LAN/4G must be configured as xcom LAN! GUID SD card – xcom 232i rcc – server connection portal – register installation...
- Page 8 Terminations NOT OK Call our specialists +41 27 205 60 80 or visit studer-innotec.com/support Studer Innotec SA rue des Casernes 57 1950 Sion, Switzerland info@studer-innotec.com © All rights reserved Studer Innotec SA – V1.0.5...
