The audio line-out connector is on the side of the APR (see Figure 1-2).

Figure 1-2. Audio Line-Out Connector

APR Controls and Indicators

The controls and indicators on the APR are shown in Figure 1-3.
unlocked
position
eject
position
drive
access
indicator
power
indicator
power button
undock request button
Figure 1-3. Controls and Indicators
locked
position
eject/locking
lever
Dell Inspiron Advanced Port Replicator User's Guide
audio line-out connector
padlock
slot
security
lock slot
docking
indicator
1-3
