Item #1011921004
Mode
ER-200-1215-SS
HAMPTON BAY
®
USE AND CARE GUIDE
ASTRO LANDSCAPE TRANSFORMER
Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service
8 a.m. – 7 p.m. PST Monday – Friday and 9 a.m. – 6 p.m., PST, Saturday
1-855-HD-HAMPTON(1-855-434-2678)
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this transformer. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement
needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY ER-200-1215-SS
Summary of Contents for HAMPTON BAY ER-200-1215-SS
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this transformer. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement...
-
Page 3: Table Of Contents
Table of Contents Table of Contents ............2 Installation ..............7 Safety Information ............3 Operation ..............10 Warranty .................4 Astronomical Region Correspondence Map ....13 Pre-installation .............. 5 Troubleshooting ............14 Tools Required ............5 Cable Selection Chart ..........15 Hardware Included ............. 5 Package Contents ............ -
Page 4: Safety Information
Safety Information Proper mounting, wiring, grounding and servicing. WARNING: Make sure there is no wire insulation under the clamping plate. The secondary wiring is intended for shallow burial (less than 6 in. (152 mm).) Risk of fire, do not place insulation under terminal plate. WARNING: Do not coil the cable around the Check connection after installation. -
Page 5: Warranty
Warranty WHAT IS COVERED The manufacturer warrants this transformer to be free from defects in materials and workmanship for a period of two (2) years from date of purchase. This warranty applies only to the original consumer and only to products used in normal use and service. -
Page 6: Pre-Installation
Pre-installation TOOLS REQUIRED Wire Wire Phillips Hammer stripper cutter screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity 4.8X30 Screw Wall Anchor HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON (1-855-434-2678) for further assistance. -
Page 7: Package Contents
Pre-installation (continued) PACKAGE CONTENTS Part Description Quantity Transformer Mounting Template... -
Page 8: Installation
Installation Connecting the Cable to the Preparing the Cable Transformer □ □ Use caution when splitting to avoid exposing copper wire. Lay the transformer (A) on a flat, stable surface and open □ Remove 1/2 in. of insulation from both wires and twist the the terminal connector door flap. - Page 9 Installation (continued) Placing the Fixtures and Routing the Mounting the Transformer Cable □ □ Lay the fixtures (not included) in their desired locations. Be Mount the transformer (A) directly to a wall surface within sure they do not exceed the 200-watt rating of the 12 in.
- Page 10 Installation (continued) Attaching the Fixtures Protecting or Hiding the Cable □ Once all fixtures are in place, the cable may be covered □ Connectors (not included) as shown. Press the connector with mulch or buried up to 6 in. (15 cm) deep. Leave about tight onto the cable until the prongs pierce the cable 12 in.
-
Page 11: Operation
Operation Set to Current Time Voltage Switching □ □ Press the CLOCK button, the green light will light up, and Press the 12V/15V button, the green light will light up, then press the OK button to flash the LCD.Set year, month, day the LCD 12V/15V flash. -
Page 12: Timing Settings
Operation(continued) Timing Settings Astronomical Function Settings □ □ Press the TIME button, the green light will light up, and Press the ASTRO button to turn on the green light, press the press the OK button to flash the LCD, OK button to flash the LCD, then you can choose Zone1 or then you can choose Zone2. - Page 13 Operation (continued) Restore Factory Functions Acceleration Adjustment Function □ □ Press and hold the OK button for 3 seconds to restore Acceleration adjustment function: When adjusting the factory functions, displaying 18:88. Release it for 1 second, time/timing function, press and hold the up and down arrow the display will return to 12:00, and restoring factory buttons for 2 seconds to accelerate the adjustment time (10 functions will clear all previously set functions.
-
Page 14: Astronomical Region Correspondence Map
Astronomical Region Correspondence Map Time Zone State Washington Oregon、Nevada California Montana、North Dakota、South Dakota Wyoming、Idaho、Utah、Colorado Arizona、New Mexico Minnesota Nebraska、Iowa、Kansas、Missouri Kentucky、Oklahoma、Arkansas、Tennessee、Texas、Louisiana、Mississippi、Alabama Wisconsin、New Hampshire、Vermont、Maine Illinois、 Michigan、New York、 Massachusetts、Connecticut、Rhode island、Pennsylvania、New jersey、Ohio、West Virginia、Maryland、Delaware、Virginia、Indiana、Delaware North Carolina、South Carolina、Georgia、Florida NOTE: Hawaii and Alaska are not within the optional range of astronomical function settings. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON (1-855-434-2678) for further assistance. -
Page 15: Troubleshooting
Troubleshooting Guide Problem Possible Cause □ Check that the transformer power is on. □ Check if there is a loose connection at the transformer screw terminal with the All of the lights fail to work cable. □ Check that the power switch is not in an OFF setting. □... -
Page 16: Cable Selection Chart
Cable Selection Chart 12 VOLT Cable Length Total Fixture Wattage 0 – 50 ft. 51 – 100 ft. 101 – 150 ft. 0 – 60 Watts 16 AWG 16 AWG 14 AWG 61 – 120 Watts 16 AWG 14 AWG 12 AWG 121 –... - Page 18 HAMPTON BAY ® Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m. PST Monday – Friday and 9 a.m. – 6 p.m., PST, Saturday at 1-855-HD-HAMPTON(1-855-434-2678) HAMPTONBAY.COM Retain this manual for future use.
