ROOMS TO GO Collonade I302-58M Assembly Instructions Manual

ASSEMBLY
INSTRUCTIONS
Thank you for purchasing this quality product. Place all wooden parts on a clean and smooth surface such
as a rug or carpet to avoid the parts from being scratched. Be sure to check all packing materials carefully
for small parts may have come loose inside the carton during shipment, clarify and count all parts and
compare with the parts list below. Do not tighten all screws / bolts until all completely assembled.
Parts List
No. Description
1 Top Panel
2 Bottom Panel
3 Side Panel
4 Upright Panel
5 Upright Rail
Upper Rail
6
7 Bottom Rail
8 Support Leg
9 Shelf
10 Back Panel
11 Left Front Leg
12 Right Front Leg
13 Left Rear Leg
14 Right Rear Leg
NOTE : YOU WILL ALSO NEED A SCREWDRIVER (NOT PROVIDED)
These parts are cumbersome and heavy. Therefore, two ople are recommended in order to prevent person-
al injury and insure the parts are not damaged during the assembly.
Important Notes
*Keep all hardware parts out of reach
of children!
*Tighten screws periodically! With the
use of this product bolts and screws
may become loose over time!
*Don't attempt to modify parts!
Cleaning instruction: Clean using soft cloth
Q.ty
No. Description
1PC A Wood Dowels
1PC B Screws
2PCS C Cam Lock
1PC D Cam Bolts
E Cam Hole Cover
1PC
1PC F Shelf Holder
1PC
1PC
2PCS
2PCS
1PC
1PC
1PC
1PC
10
3
13
11
Page 1/8
ITEM NO.: I302-58M / 58R / 58B
Hardware List
Sketch
M8x 30mm
M4x 45mm
D15mm x T10mm
M6 x 40mm
D15mm
D5mm x 16mm
1
6
10
9
4
5
9
2
TV STAND
Size Q.ty
24pcs
8pcs
22pcs
22pcs
22pcs
8pcs
3
14
12
8
7
Made in Malaysia
