INTRODUCING THE AKAT PRO-200 SERIES COMPONENTS
The PRO-A200 components are microcomputer controlled for easy (Direct Function) operation and
convenient recording. The direct connection plugs on the Tuner, Amplifier, and Cassette deck sections make
connection simple. The PRO-A200 components will provide you with years of high quality Hi-Fi, for your
listening pleasure.
1. PRO-A200 SERIES LINE-UP
PRO-A200 | _ PRO-A200D PRO-A200W PRO-A200WD
Turntable | __AP-A100/C | __AP-A200/C AP-A100/C AP-A200/C
Tuner | AT-A200/L
| Amplifier AM-A200
Cassette Deck HX-A200 HX-A300W
OPTIONAL
Timer DT-A2
Audio Rack RV-A100
2. FEATURES
1) AP-A100/C
@ Semi automatic player system
Set the record speed, then use the damped cue
control arm to lift and lower the tone arm.
The Akai AP-A100 will automatically locate the
end of each record and return to the tone arm
rest when the selection is finished. If you want
to lift the tone arm from one section and start
another, the tone arm Cue Control Damper
eliminates the possibility of accidental scratches
to your records.
@ Low resonant cabinet which helps prevent distor-
tion
e Sensitive straight tone arm
e type plug in cartridge (AP-A100C only)
e DIRECT FUNCTION control makes playback and
recording operations simple, when combined with
the Akai AC-A100/L.
2) AP-A200/C
@ Low mass straight tone arm
e@ Low resonant cabinet which helps prevent distor-
tion
e Semi automatic Direct Drive player system
Set the record speed, then use the damped cue
control arm to lift and lower the tone arm. The
Akai AP-A200 will automatically locate the end of
each record and return to the tone arm rest when
the selection is finished. If you want to lift the
tone arm from one section and start another, the
tone arm Cue Control Damper eliminates the
possibility of accidental scratches to your records.
e (TaD) type plug in cartridge (AP-A200C only)
e DIRECT FUNCTION control makes playback and
recording operations simple, when combined with
the Akai PRO-A200.
SERVICE MANUAL
3) AT-A200/L
@ Microcomputer controlled Tuner for accurate
tuning.
e@ Up to 12 stations can be memorized (6 AM band,
and 6 FM band)
e FL digital display panel
4) AM-A200
Features of the AM-A200 Stereo Integrated Amplifier
e Nine band graphic equalizer for adjusting the
sound to suit your taste, can be used during
playback and recording operations.
e DIRECT FUNCTION control automatically act-
ivates the tuner, tape deck and Phono.
e BALANCE control and large VOLUME control
dial
e CD/VTR input mode selector button for use when
you want to playback another audio component
connected to the rear panel CD/VTR jacks
5) HX-A200
e Direct Function recording with the tuner, phono,
or other connected audio component
e@ Automatic Recording Level Control (ALC) for
convenient recording.
e DOLBY NR (B) switch for use of the Dolby Noise
Reduction System
e Full auto stop, the tape will automatically stop
during all tape functions, when the end of the tape
is reached. '
e@ One touch recording button for easy recording
e Timer (optional) can be used for Timed Playback
or Absentee Recording purposes.
