• To avoid hearing loss, do not expose yourself to high volume levels for long periods of time.
• The device complies with current European legislation regarding human exposure to electromagnetic fields.
DISCONNECT DEVICE: The power outlet must be installed near the equipment and be easily accessible.
SONIC GUARD
The boxes of the SLKA-BT series contain Sonic Guard circuitry that protects the tweeter against damages due to
exceptional power peaks from the system. Sonic Guard compresses slightly the signal en deviates the excess
power from the compression driver.

OPERATION

Prior to switching the unit on, turn down the volume to the minimum.
Plug the supplied mains lead into the AC input socket on the rear side. Make sure that the supplied mains vol-
tage is 220-240V~50Hz/60Hz. Set the I/O switch on the rear panel to "I". The switch and the blue LED on the
front panel light up. Insert an SD card or USB stick in the appropriate slot. The LCD lights up. Make the settings
according to your requirements via the controls on the rear panel or the supplied remote control.
PLAY MP3/WMA MUSIC
1. Switch on power. The LED indicator (19) lights up.
2. Insert a USB stick (2) or an SD card (3) into the relevant input
3. Select USB via the MODE button (4)
4. Select a title via the  or  (5) buttons and press ▶ǁ (7)
TO PLAY LINE IN MUSIC
1. Insert an RCA plug into the LINE IN sockets (14) or a jack plug into the LINE/MIC inputs (13).
2. Switch the LINE/MIC selector switch (20) to LINE if you use the LINE inputs, or to MIC if you use the MIC
inputs
3. Adjust the volume (8 & 12)
EN
MIC INPUTS
If you connect one or two microphones to the MIC inputs (13), set the selector switch (20) to MIC.
Control the microphone volume with mic volume control (12).
REC FUNCTION
Disconnect the speakerbox from your Bluetooth device. Insert a USB stick or SD card. The speaker will automa-
tically switch into USB/SD mode. Connect now the speakerbox to your Bluetooth device and start playing your
music. Short press the REC button to record your voice and the music on the inserted USB stick or SD card.
Press again to stop recording. Keep the REC button pressed to play the recorded file.
USE OF THE BLUETOOTH FUNCTION
1. Press the MODE button until BLUETOOTH displays. The BLUETOOTH function is now activated.
2. Activate the Bluetooth function on your smartphone or any other tablet PC.
3. The product appears under the name « IBIZA-PORT » and is ready to be connected to your equipment.
4. Now play your music via the portable sound system. Set the volume via the Master volume button.
5. Don't set the volume of pour smartphone or tablet PC too high. Do not exceed ¾ of the total volume to
avoid distortion.
CONTROLS ON THE REAR PANEL
1. Display
2. USB port
3. SD socket
4. MODE button
5. Previous/next/ volume control
6. REC mode
7. Play/Pause
8. Microphone Volume
9. MIC ECHO control
10. Treble control
11. Bass control
12. Volume control
13. Microphone inputs
14. Line input
15. Mix output
4
