Interface Connectors
# Connector Description
1 PoE OUT + DATA Gigabit RJ-45 port for data and Power over Ethernet (PoE) power. Supports a maximum of 12 W.
port
2 DATA port Gigabit RJ-45 port for data.
3 RESET button Press and hold for 20 seconds to factory reset the device.
# Connector
1 LAN (PoE) port

Installation

Using Power over Ethernet (PoE)
1. Use a standard Ethernet cable to connect the LAN (PoE) port on the back of the DAP-2622 to a PoE
power source device such as an 802.3at PoE switch.
Configuration
Using Nuclias Connect
The DAP-2622 is designed to be managed through Nuclias Connect. Refer to the Nuclias Connect Manual
for detailed configuration instructions.
Manual Configuration
Note: D-Link recommends manually configuring the device before mounting it. The management computer,
DHCP server and DAP-2622 must be in the same subnet.
Use one of the following methods to access the web user interface:
Figure 2: Bottom Connectors
Table 2: Interface Description
Figure 3: Rear Connectors
Description
Gigabit RJ-45 port for data and Power over Ethernet (PoE).
Table 3: Interface Description
