Codes Table:
F1
℉
F2
℃
F3 Battery type selection H1: ACID H2: NCM H3: LFP
Low voltage protection value setting
F4
Countdown to turn off setting
F5
Restore default settings
F15
www.giandel.com
769-486-2790
support@giandel.com.au
V0.24.04
Model: PS-3000SAR
Warning:
This manual contains important safety and
operating instruction. Please read it carefully before use
the unit.
SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE
Advertisement
Table of Contents
Related Manuals for Giandel PS-3000SAR
Summary of Contents for Giandel PS-3000SAR
- Page 1 Model: PS-3000SAR Codes Table: ℉ ℃ F3 Battery type selection H1: ACID H2: NCM H3: LFP Low voltage protection value setting Countdown to turn off setting Restore default settings Warning: This manual contains important safety and operating instruction. Please read it carefully before use www.giandel.com...
-
Page 2: Specifications
1. SPECIFICATIONS 2. INTRODUCTION The giandel power inverter product line is used for back-up power. The power Item Data inverter transforms DC (direct current) electricity into AC (alternating current) Input voltage 12VDC power that can be used for running a wide variety of tools and appliances. This... - Page 3 ● People with pacemakers should consult their physician(s) before using this ● This inverter is suitable for Electronic systems product. Electromagnetic fields in close proximity to a pacemaker could electronic systems with negative cause interference to or failure of the pacemaker. grounding, and should not be connected to electronic systems ●...
-
Page 4: Parts List
(2. AC Output side) ● Tighten connection needed, Tighten poor connection will cause voltage drop or posts melt. Reversely connect the cables will Type-APort blow the fuses. Do not reverse PD 30W connect cables. Type-C PD 30W Port Wired remote controller interface ●... -
Page 5: Installation
5. INSTALLATION 7.87 inch 7.87 inch 1. Installation guide 20cm 20cm Firstly, sufficient space should be ensured to install the inverter and the installation position must meet the following requirements: (1) Dry: Do not drip water or other liquids onto the inverter (2) Cool: The working environment temperature of the product is -30-60℃, preferably a temperature of -30-60℃, at a temperature as low as possible within this range... - Page 6 3) Installation of remote control box (1) Fixed on the plane with an opening, then fix two screws directly on the position of two installation holes of the remote control box. (2) The remote control box can also be installed on the base of 86X86mm electrical socket.
- Page 7 2. Battery working time WARNING: The using time of battery depends on battery capacity (AH) and the power of 1. Do not connect different brand or different capacity,specification of batteries the connected load (W), the calculating method is: Time (hours) =battery in series or parallel, it it unsafe and may damage the batteries or inverter.
- Page 8 (3) Secure the provided Positive (Red) DC cable to the Positive (+) bolt on the 1. In some fixed available position Connect the ground terminal to the earth inverter, and the other end to the Positive (+) post on the battery. A.
- Page 9 (3) Do not put any combustible material in the location of installation for spark 4) Hard wire block terminals will result when it is connected to the battery. The hard wire block terminals are specially designed for heavy duty loads (4) Keep good ventilation.
- Page 10 ● Fast charging with a maximum output of 24W “H1” ACID indicates lead-acid battery,and its low voltage protection value is 9.5V ● Supports fast charging protocols: QC3.0/QC2.0/BC1.2DCP/AFC/SCP/ CP/PE2.0 “H2” NCM indicates Ternary lithium battery (4 series)and its low voltage protection value is 11.2V. 2) USB Type-C port ×...
- Page 11 ① When flashing, it is in an adjustable state, switching from hour and 9. Soft start technology minute,and switching every 5 seconds. This inverter has soft start technology, which means that after turning on the ② Short press of the button can increase the value, long press of the button inverter switch, the output voltage gradually increases from low to normal value.
- Page 12 ⑤ Battery ⑥ OUTPUT-AC working icon 2. While the inverter working, LCD screen will display input voltage, output voltage,pure sine wave symbol, frequency, bars of load .When the inverter ⑦ pure sine wave symbol enters the protection state, the LCD will display a warning symbol and the current protection state.
-
Page 13: Troubleshooting Tips
(2) Output overload reminder power recovery: load ≤ 3000W 14. TROUBLESHOOTING TIPS (3) Output peak protection power:load ≥ 6100W, buzzer keeps ringing, restart PROBLEM REASON SOLUTIONS after 30 seconds. ● Recharge the battery ● Battery may be too small. Please refer to (4) Test conditions for peak power output: At full load, the input voltage is instruction for recommended battery sizes. -
Page 14: Warranty
Test. Tester indicated in the Earth. It would be GIANDEL will replace any products that are found to be defective due to manufac- ● Refer to the manual to do the Grounding "Open Ground" impossible to do so in a boat or ●...
