- Page 1 QUICK INSTALLATION GUIDE ATLAS E1 ATLAS E1 M I D - T O W E R P C C A S E M I D - T O W E R P C C A S E...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1 Specifications 2 Exploded View & Parts 3 Accessory 4 Side Panel Removal 5 Motherboard Installation 6 PSU Installation 7 3.5" & 2.5" HDD Installation 8 Air Cooling Compatibility 9 Radiator Compatibility 10 I/O Ports 11 I/O Connectors... -
Page 3: 1 Specifications
SPECIFICATIONS ATLAS E1 / ATLAS E1 WH Product Name MID Tower Case Type 360 x 210 x 480mm Dimension (L x W x H) 14.2 x 8.3 x 18.9 inch Chassis Dimension (L x W x H) 358 x 210 x 465 mm 14.1 x 8.3 x 18.3 inch... -
Page 4: 2 Exploded View & Parts
EXPLODED VIEW PARTS PARTS PARTS Chassis Body IO Port & Screen Tempered Glass Side Panel & Screw 120MM ARGB FAN Right Side Panel Rubber Foot Top Dust Filter Glass Front Panel ACCESSORY Parts Name Used for Figure Stand-off 4.75 x 9.5 x 6.5mm Motherboard Screw #6 x 6 mm Screw #6 x 5 mm... -
Page 5: 4 Side Panel Removal
SIDE PANEL REMOVAL English Português Remove the side panel Remova o painel lateral Español Русский Retire el panel lateral Снимите боковую панель Deutsch Türk dili Seitenblende entfernen Yan paneli çıkarın Polski 日本語 サイドパネルを取り外します Usuń panel boczny Français 한국어 Retirez le panneau latéral 사이드... -
Page 6: 5 Motherboard Installation
MOTHERBOARD INSTALLATION English Português Lay down the chassis Deite o chassi Install the motherboard in proper location Instale a placa-mãe no local correto e and secure it with screws prenda-a com parafusos Español Русский Tumbe el chasis Снимите подставку Instale la placa base en la posición adecuada Установите... -
Page 7: 6 Psu Installation
PSU INSTALLATION P S U English Português Place the PSU in proper location Coloque a PSU no local adequado Español Русский Coloque la PSU en la posición adecuada Поместите блок питания в нужное место Deutsch Türk dili Netzteil an der richtigen Stelle platzieren PSU’yu uygun konuma yerleştirin Polski 日本語... - Page 8 3.5" 2.5" HDD INSTALLATION A. 3.5" HDD B. 2.5" SSD English Português A. 3.5" HDD A. HDD 3.5" Align the HDD into the mounting holes and screw in. Alinhe o HDD nos orifícios de montagem e aperte-o. B. 2.5" SSD B.
-
Page 9: 8 Air Cooling Compatibility
AIR COOLING COMPATIBILITY 140MM 120MM 120MM 120MM English Svensk 日本語 上部 120 mm x 2 または140 mm x2 2 x 120mm or 2 x 140mm Ovansida 2 x 120mm eller 2 x 140mm PSUカバー 120 mm x 2 PSU Shroud 2 x 120mm PSU-skydd 2 x 120mm 後部 120 mm x 1 Rear 1 x 120mm Baksida... -
Page 10: Radiator Compatibility
RADIATOR COMPATIBILITY 240 mm 120 mm English Svensk 日本語 上部 240 mm 240mm Ovansida 240mm 後部 120 mm Rear 120mm Baksida 120mm Italiano Español 한국어 Superior 240mm Parte superiore 240mm 상단 240 mm Parte posteriore 120mm Trasero 120mm 후면 120 mm Deutsch Português ภาษาไทย... -
Page 11: O Ports
I/O PORTS Power Button USB 3.0 Screen Control & Reset USB 3.0 Integrated Audio (Headphone & Microphone) -
Page 12: O Connectors
I/O CONNECTORS POWER ARGB USB 3.0 USB 2.0 HD AUDIO POWER POWER LED- LED+ English Português See your motherboard's manual for front panel header Veja o manual da sua placa-mãe para localizar locations and pin-outs. os locais e os compartimentos do painel frontal. Español Русский... -
Page 13: Display Connection
Display Connection Attached switch Motherboard... - Page 14 Software Download: Zeus Cast STEP Visit Gamdias Official Website Visit ATLAS M1 Product Page Stroll down the Page to Find the Download Resource Download Zeus Cast Package...
-
Page 15: Temp Button
Mode Variation and Instruction TEMP button CPU mode GPU mode Press the button to switch ATLAS display information between 4 different modes AMB mode Light-off Note: Zeus Cast is still running in the background in Light-off mode... -
Page 16: Software Instruction
Software Instruction General Settings Temperature Display Auto-Run Minimize to system tray at close Language Note: The Temperature Display switch function can only be changed by Zeus Cast... - Page 17 Software Instruction atlas Digital Display Display Mode Temperature Alarm Note: The Temperature Display switch function can only be changed by Zeus Cast...
