- Page 1 Uputstvo za upotrebu (EN) GAMDIAS kućište Argus E4 Elite Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike, potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji. Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike i konkurentne cene proizvoda.
- Page 2 QUICK INSTALLATION GUIDE ARGUS ARGUS M I D - T O W E R C A S E M I D - T O W E R C A S E...
- Page 3 TABLE OF CONTENTS 1 Specifications 2 Exploded View & Parts 3 Accessory 4 Side Panel Removal 5 Motherboard Installation 6 PSU Installation 7 3.5" & 2.5" HDD Installation 8 Air Cooling Compatibility 9 Radiator Compatibility 10 I/O Ports 11 I/O Connectors...
- Page 4 SPECIFICATIONS SERIES LED Strips Series Product Name ARGUS E4 Elite ARGUS E4 Elite WH Case Type MID Tower Dimension (L x W x H) 393 x 230 x 460 mm 15.4 x 9 x 18.1 inch Chassis Dimension (L x W x H) 350 x 230 x 445 mm 13.7 x 9 x 17.5 inch...
- Page 5 EXPLODED VIEW PARTS PARTS PARTS Chassis Body IO Port Tempered Glass Side Panel HDD Cage Right Side Panel Rubber Foot Top Dust Filters 120 MM Fan Front Panel ACCESSORY Parts Name Used for Figure Stand-off 4.75 x 9.5 x 6.5mm Motherboard Screw #6 x 6 mm Screw #6 x 5 mm...
- Page 6 SIDE PANEL REMOVAL English Português Remove the side panel Remova o painel lateral Русский Español Снимите боковую панель Retire el panel lateral Türk dili Deutsch Yan paneli çıkarın Seitenblende entfernen 日本語 Polski サイドパネルを取り外します Usuń panel boczny 한국어 Français Retirez le panneau latéral 사이드...
- Page 7 MOTHERBOARD INSTALLATION English Português Lay down the chassis Deite o chassi Install the motherboard in proper location Instale a placa-mãe no local correto e and secure it with screws prenda-a com parafusos Русский Español Tumbe el chasis Снимите подставку Instale la placa base en la posición adecuada Установите...
- Page 8 PSU INSTALLATION English Português Place the PSU in proper location Coloque a PSU no local adequado Русский Español Coloque la PSU en la posición adecuada Поместите блок питания в нужное место Deutsch Türk dili Netzteil an der richtigen Stelle platzieren PSU’yu uygun konuma yerleştirin Polski 日本語...
- Page 9 3.5" 2.5" HDD INSTALLATION 3.5" HDD 2.5" SSD English Português A. 3.5" HDD A. HDD 3.5" Align the HDD into the mounting holes and screw in. Alinhe o HDD nos orifícios de montagem e aperte-o. B. 2.5" SSD B. HDD 2.5" Align the SSD into the mounting holes and screw in.
- Page 10 AIR COOLING COMPATIBILITY 日本語 English Svensk 上部 120 mm x 2 または140 mm x2 2 x 120mm or 2 x 140mm Ovansida 2 x 120mm eller 2 x 140mm 後部 120 mm x 1または140 mm x1 1 x 120mm or 1 x 140mm Baksida 1 x 120mm eller 1 x 140mm Rear 한국어...
- Page 11 RADIATOR COMPATIBILITY 日本語 English Svensk 上部 280 mm または 240 mm 280 mm or 240 mm Ovansida 280 mm eller 240 mm 140 mm or 120 mm Baksida 140 mm eller 120 mm 後部 140 mm または 120 mm Rear 한국어 Español Italiano 280 mm or 240 mm 280 mm o 240 mm 상단...
- Page 12 I/O PORTS Power Button Fan LED Control USB 2.0 USB 2.0 USB 3.0 Headphone Sync With Motherboard : Press and Hold the Fan LED Control Button for 3 Seconds.
- Page 13 I/O CONNECTORS USB 3.0 USB 2.0 HD AUDIO POWER LED/RGB RESET POWER POWER LED+ LED- English Português See your motherboard's manual for front panel header Veja o manual da sua placa-mãe para localizar locations and pin-outs. os locais e os compartimentos do painel frontal. Русский...
- Page 15 Ovaj dokument je originalno proizveden i objavljen od strane proizvođača, brenda Gamdias, i preuzet je sa njihove zvanične stranice. S obzirom na ovu činjenicu, Tehnoteka ističe da ne preuzima odgovornost za tačnost, celovitost ili pouzdanost informacija, podataka, mišljenja, saveta ili izjava sadržanih u ovom dokumentu.
