- Page 1 VC-R30 HD Camera (PTZ Video Camera) User Manual - English Version VXF100 [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens https://www.MyLumens.com/support...
-
Page 2: Table Of Contents
Table of Contents Chapter 1 Package Contents ...................2 Chapter 2 Version Description ..................3 Chapter 3 Product Overview and Interface ..............4 3.1 I/O functions Introduction ..................4 3.2 Description of LED indicator .................. 5 Chapter 4 Instruction for installation ................6 4.1 Preparation before installation................6 4.2 Instruction for installation .................. -
Page 3: Chapter 1 Package Contents
Chapter 1 Package Contents Quick Installation VC-R30 Remote Control Guide 3-PIN to 2-PIN Power Cord Power Adapter connector Appearance may vary (For Japan only) depending on country/ region USB 3.0 Cable HDMI cable (2m) (1.5m) English... -
Page 4: Chapter 2 Version Description
Chapter 2 Version Description This chapter specifies the identification method of VC-R30 and VC-R30,V1. Some functions may vary due to different versions. Model VC-R30 VC-R30,V1 Label Black VC1xxxxxx VD4xxxxxx White VCYxxxxxx VD7xxxxxx VWWxxx VXFxxx English... -
Page 5: Chapter 3 Product Overview And Interface
The USB port is for connecting to the USB port of the computer and providing USB signal images HDMI output HDMI output <Remark> Audio output is only applicable to VC-R30,V1 3G-SDI output 3G-SDI output <Remark> Audio output is only applicable to VC-R30,V1 Audio In 3.5 mm LINE IN... -
Page 6: Description Of Led Indicator
Description of LED indicator 3.2.1 VC-R30 Status Standby Power Powered off No indicator No indicator In use Green light Red light In standby mode No indicator Red light Privacy Mode Green light (slow flickering) Red light 3.2.2 VC-R30,V1 Status Standby... -
Page 7: Chapter 4 Instruction For Installation
Chapter 4 Instruction for installation Preparation before installation Installation and connection of HD camera requires special skills. To install by yourself, please follow necessary steps, ensure steady and tight installation of the device, and pay attention to your safety to avoid any accident. 4.1.1 Ensure the safety of the installation environment. - Page 8 Install on the ceiling Install on the wall 4.2.3 Camera Size Length x Width x Height: 190 x 138 x 185 mm Weight: 1.3 Kg English...
-
Page 9: Connecting Devices
4.3.1 USB Image Output Connect to computer with a USB3.0 cable, and use Lumens USB PTZ Camera Controller software to view images and control VC-R30. You can also view images with video software, such as, Skype, Zoom and Microsoft Teams <Remark>... - Page 10 RS-232 pins definition instructions English...
-
Page 11: Chapter 5 Introduction Of Remote Control And Setting Menu
Chapter 5 Introduction of Remote Control and Setting Menu Remote Control The below functions are listed alphabetically Item Description Move the lens ,,, Turn on/off back light compensation Back Light Choose Camera ID 1 ~ 3 Camera select Focus-Manual/ Enable Manual Focus, adjust the focal length in Manual Far/ Near... -
Page 12: Setting Menu
Setting Menu <Remark> Press [MENU] on the remote control to enter the setting menu; the bold underlined values in the following table are defaults. 1st Level 2nd Level 3rd Level Function Descriptions Major Items Minor Items Adjustment Values Full Auto/ Shutter Pri/ Iris Mode Exposure mode setting Pri/ Manual/ White Board... - Page 13 IP Address 192.168.100.100 Ethernet Subnet mask 255.255.255.0 Configurable when DHCP is set to Off Gateway 192.168.100.254 Audio Enable On/Off Turn on/off audio output Audio In Line In/ Mic In <Remark> Only applicable to VC-R30,V1 Audio Audio Volume 0~A~10 Volume Setting English...
- Page 14 Time(ms) Set the encode type and sample rate Encode Sample 48/ 44.1/ 16 KHz(AAC) <Remark> 44.1/16 KHz is only Rate applicable to VC-R30 Turn on/off the prompt information on Prompt On/Off the display Turn on/off the infrared reception When it is Off, the remote control will not be able to control the camera.
-
Page 15: Chapter 6 Network Function Settings Description
Chapter 6 Network Function Settings Description Web System Requirements Operating Version Browser System FireFox 7 (64 bits) and above Chrome Windows Edge 10 (64 bits) and FireFox above Chrome Safari 10.14 and above Chrome FireFox Connecting Camera to Network 6.2.1 Connecting to Internet Two common connection methods are shown below 1. - Page 16 Enter administrator’s account and password <Remark> For the first-time login, please refer to to change the default 6.3.9 System Settings - User password Lumens Network Camera Account: admin Password: 9999 (Default) 6.2.3 Using RTSP Player to View the Images...
-
Page 17: Web Page Menu Function Description
Web Page Menu Function Description 6.3.1 Login Screen 錯誤 錯誤 錯誤 錯誤 錯誤 Item Function Descriptions User Login Account Enter user login account (default: admin) Enter user password (default: 9999) User Password <Remark> For the first-time login, please refer to 6.3.9 System Settings - User to change the default password... - Page 18 AF/MF Switch AF/MF Zoom speed Adjust the zoom speed Pan/ Tilt Speed Adjust the horizontal/vertical moving speed of the lens <Remark> Auto Framing is only applicable to VC-R30,V1 Enable smart viewfinder setting ○ ○ ○ Auto Framing 1. Enable/Disable Smart viewfinder 2.
- Page 19 White Balance Mode: Select the color temperature mode Open Push WB: Single color temperature execution adjustment (adjustable only under the “One Push WB” Manual Red/Blue: Manually adjust blue/red color temperature Focus AF Sensitivity: Set automatic focus sensitivity ...
- Page 20 <Remark> Only applicable to VC-R30,V1 Audio Enable Encode sample rate: Set the encode type and sample rate <Remark> 44.1/16 KHz is only applicable to VC-R30 Volume: Adjust Audio Volume Audio Delay After checking the box, set the audio delay time (10 ~ -500 ms)
- Page 21 View the Images Select to enable RTMP/RTMPS RTMP/ RTMPS Enable/Cancel Password Authentication <Remark> Only applicable to VC-R30,V1; Streaming 1 supports SRT Transmission Select to enable SRT The port number must be set in the range above 1024 with a maximum ...
- Page 22 6.3.5.1 Streaming parameter setting Function Streaming 1 Streaming 2 Encode Format H.264 Resolution 1080p / 720p 720p Range 2,000~20,000 2,000~20,000 Bit rate Factory 7,000 3,000 Default Rate Control CBR / VBR Frame Rate Setting according to the supported resolution Group of Pictures Setting according to the supported resolution 6.3.6 System Settings –...
-
Page 23: System Settings - Network
After the function is enabled, when the camera is turned off via the (UVC) remote control or software, the lens will automatically turn to the bottom right to ensure the user’s privacy Apply/Cancel Apply/Cancel Setting 6.3.7 System Settings – Network ○... - Page 24 6.3.8 System Settings - Date & Time Function Descriptions Display the current camera/PC date and time, and set the display format and synchronization way When Manually Set is selected for [Time Settings], Date & Time can be customized 6.3.9 System Settings – User Function Descriptions Add/Modify/Delete user account ...
- Page 25 Reset all configurations to factory default settings. Save setup parameters as a Profile, and users can download and upload Configuration camera setup parameters If the machine operates abnormally, the event log can be exported for Event Log reference of Lumens technicians English...
-
Page 26: Maintenance - Reboot
6.3.12 Maintenance – Reboot ○ ○ ○ ○ ○ Item Function Descriptions Reboot Press the Reboot button to restart the camera. Disable Schedule Disable the Reboot schedule Select the exact time the camera will reboot (00:00~23:00). Daily Reboot Note: This option can only be enabled when synchronized with the Time NTP server. -
Page 27: Chapter 7 Troubleshooting
Chapter 7 Troubleshooting This chapter describes problems you may encounter while using VC-R30. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact your distributors or the service center. -
Page 28: Chapter 8 Safety Instructions
Safety Instructions Chapter 8 Always follow these safety instructions when setting up and using VC-R30 PTZ Video Camera: 1 Operation 1.1 Please use the product in the recommended operating environment, away from water or source of heat 1.2 Do not place the product on a tilted or unstable trolley, stand or table. -
Page 29: Fcc Compliance Statement
Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Manufacturer：Lumens Digital Optics Inc. Product Name：VC-R30 Model Number：PTZ Video Camera Responsible Party – U.S. Contact Information Supplier：Lumens Integration, Inc. 4116 Clipper Court, Fremont, CA 94538, United States e-mail ：support@mylumens.com FCC Compliance Statement This device complies with Part 15 of the FCC Rules. -
Page 30: Copyright Information
Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.
