Replace the bracket cover on the drive bracket (press in the tabs and align the tabs and four
4.
posts with the openings in the metal shield).
Insert the Zip drive into the empty slot in the drive bracket.
5.

Inserting the Zip drive into the drive bracket slot

6.
Secure the drive with three screws (see the following figure).
A – Zip Drive
Slide the drive bracket into the chassis. The bracket tabs click into place.
7.

Securing the Zip drive

B – Screws
Installing the Zip Drive 3
