Page 1 User Manual RSPS-3060/RSPS-6030 Stock number: 2732613/2732614 rspro.com...
Page 2: Table Of Contents
Table of Contents Table of Contents SAFETY INSTRUCTIONS ............. 5 Safety Symbols ............. 5 Safety Guidelines ............6 Power cord for the United Kingdom ....... 9 OVERVIEW ................10 Introduction ..............11 Key Features ............... 13 Front Panel ..............15 Rear Panel ..............
Page 3 RSPS-3060/RSPS-6030 User Manual SYSTEM SETTINGS ............84 System Information ............. 85 System Settings............86 Firmware Upgrading ........... 88 Description of Using Flash Drive ......... 89 REMOTE CONTROL ............90 Connection Usage ............91 Command Syntax ............98 Command List ............102 Command Details .............
Page 4: Safety Instructions
WARNING could result in injury or loss of life. Caution: Identifies conditions or practices that CAUTION could result in damage to the RSPS-3060/ RSPS- 6030 or to other properties. DANGER High Voltage Attention Refer to the Manual Protective Conductor Terminal...
Page 5: Safety Guidelines
Do not block the cooling fan opening.  Do not perform measurements on circuits that are directly connected to mains power.  Do not disassemble the RSPS-3060/ RSPS- 6030 unless you are qualified.  (Measurement categories) EN 61010-2-030 specifies the measurement categories and their requirements as follows.
Page 6 “addition of foreign matter, solid, liquid, or gaseous (ionized gases), that may produce a reduction of dielectric strength or surface resistivity”. The RSPS-3060/RSPS-6030 falls under Pollution degree 2.  Pollution degree 1: No pollution or only dry, non-conductive pollution occurs.
Page 7 RSPS-3060/RSPS-6030 User Manual  Operation Location: Indoor, no direct sunlight, dust free, Environment almost non-conductive pollution (Note below)  Relative Humidity: < 80%  Altitude: < 2000m  Temperature: 0°C to 40°C  Storage Location: Indoor environment  Relative Humidity: < 70% ...
Page 8: Power Cord For The United Kingdom
SAFETY INSTRUCTIONS Power cord for the United Kingdom When using the power supply in the United Kingdom, make sure the power cord meets the following safety instructions. NOTE: This lead/appliance must only be wired by competent persons WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in this lead are coloured in accordance with the following code: Green/ Yellow:...
Page 9 RSPS-3060/RSPS-6030 User Manual VERVIEW This chapter contains a brief introduction to RSPS-3060/ RSPS-6030 including the main features and an overview of the front and rear panel. Use the Getting Started chapter on page 23 to start up instructions and how to setup the appropriate operation environment.
Page 10: Overview
OVERVIEW Introduction Overview The RSPS-3060/RSPS-6030 regulated DC power supply series are adjustable, multifunctional work stations. It has three independent outputs: two with adjustable voltage levels and one with fixed level selectable from 1.8V, 2.5V, 3.3V and 5V. It can be used for logic circuits where various...
Page 11 (below Function 1Hz). Front and rear For the convenience of customers, RSPS-3060/ output function RSPS-6030 can be operated by the panel menu or remote command, so that it can be output on the front and rear panels, please refer to page 26.
Page 12: Key Features
OVERVIEW Key Features  Multiple Outputs Features  Constant voltage and constant current operation (CV/CC).  Low noise, thermostatically controlled fan.  Compact, lightweight, standard rack mount comformity 3U, half Rack.  4.3 inch TFT display.  Digital panel control. Operation ...
Page 13 RSPS-3060/RSPS-6030 User Manual  Remote Control RS-232 Interface  USB remote control.  Control I/O  LAN remote control...
Page 14: Front Panel
Number Pad Scroll wheel Arrow keys Function keys Power button Front output terminals USB host Display Display Interface Take RSPS-3060 model as example Note Channel Channel number and distribution vary by models distribution with different colors identifications: CH1: Yellow CH2:...
Page 15 RSPS-3060/RSPS-6030 User Manual Single channel Channe Voltage l/Status display display Power Current display display OVP/OCP setting setting area Channel no. Color of channel remains the origanl when not in the state of setting. Color of channel blinks between the original and orange when being set.
Page 16 OVERVIEW Display OVP/OCP settings CH1/CH2: , The CH3 OVP is a fixed value (approx. 5.5V), non-configurable and with only on or off switch available for user. OCP is available only for USB output port (approx. 3.1A) Status Indicator Display the set function/remote control interface : The active channel under setting status : The status of OTP protection mode : The status of USB flash drive connected...
Page 17 RSPS-3060/RSPS-6030 User Manual Number pad For parameter value setting Scroll wheel & Scroll wheel is used to set each Arrow keys parameter value, whilst arrow keys are used for parameter, menu selection and voltage/current fine adjustment. It is used to switch or operate the displayed waveforms under diagram display mode.
Page 18 OVERVIEW Power output terminal or load input terminal CH2 terminal Power output terminal CH3 terminal Power output terminal The output current from the 2 terminals should Warning Not exceed 5A. GND terminal Ground terminal...
Page 19: Rear Panel
RSPS-3060/RSPS-6030 User Manual Rear Panel Rear Output Port LAN Port Alternate Input Switch AC Input Socket and Line Fuse RS-232 Port Control I/O Heat Sink USB Port Terminals Alternate input AC voltage selection: switch 100V/120V/220V/230V ±10%, frequency 50/60Hz AC input socket...
Page 20 OVERVIEW RS-232 port for remote control. See RS-232 port page 91 for details. Heat sink fan It is used to discharge the heat inside the equipment through air flow. Control I/O port 5 ports in all for input/output control.
Page 21: Constant Voltage/Constant Current Crossover Characteristics
RSPS-3060/RSPS-6030 User Manual Constant Voltage/Constant Current Crossover Characteristics Background The unit will switch automatically between constant voltage and constant current according to changes in the load. When the load current is less than the current CV mode setting, the unit operates in constant voltage...
Page 22: Getting Started
GETTING STARTED ETTING STARTED This chapter describes the start up procedures and the preparation that is necessary before operating the power supply. Start Up ..............24 Load Connection ............25 Select front/rear panel output ........26 Turning the Output On/Off ......... 27...
Page 23: Start Up
RSPS-3060/RSPS-6030 User Manual Start Up Checking the Before the power is turned on, AC Voltage confirm that the input power supply meets the following conditions: 100V/120V/220V/230V ±10%， 50/60Hz Connecting the The fuse is a slow-blow fuse. 6.3A (220V/ 230V),12A(100V/ AC power cord...
Page 24: Load Connection
GETTING STARTED Load Connection Front panel Use the 10A test lead cables (provided with the unit) for the wiring front panel source connections. USB Type A only (Greater than 4A) Self distribution wire: Rear panel +/ - need to be equipped with wiring awg12 or above S + / S - can be equipped with awg20, preferably...
Page 25: Select Front/Rear Panel Output
RSPS-3060/RSPS-6030 User Manual Select front/rear panel output Panel Operation 1. Double click the system button. 2. Press F1 (front) key to select front panel output, or press F2 (rear) key to select rear panel output. 3. You can see the switching...
Page 26: Turning The Output On/Off
GETTING STARTED Turning the Output On/Off Panel Operation Press the Output key of each channel individually to turn the output on. The Output key will light-up when the output is on. When the output is turned on, pressing the Output key again will turn the output off.
Page 27 RSPS-3060/RSPS-6030 User Manual ASIC OPERATION This chapter describes how to set various functions. Display Change ............29 Display Area ..............29 Source Function ............32 Independent Output Mode .......... 37 Tracking Series and Tracking Parallel Modes .... 38 Load Function ............44 Sequence Function ............
Page 28: Basic Operation
It is basically equivalent to Source interface with additional Load and OPP status displays. Diverse display screens In order to offer diverse information display of each channel to meet requirements from different users, the RSPS-3060/ RSPS-6030 provide several selections of different display screens as follows:...
Page 29 RSPS-3060/RSPS-6030 User Manual Normal Type Display screens Type Display screens Type1 Type2 Type4 Type5 Waveform Type6 Type7 * Only Type 1, Type 4 and Type 7 have setting value display * Type's selection: Advance key ->F1(Display) key->F1(Normal) key or F2(Waveform) key.
Page 30 BASIC OPERATION through the channel button on the panel. B. Indicates the adjustable items of reference point for voltage/current/power respectively in the active channel. The one with a red triangular arrow is the active item to adjust, which can be toggled through the directional button on the panel.
Page 31: Source Function
RSPS-3060/RSPS-6030 User Manual Source Function Description Each channel is equipped with basic power functions and able to display both settings and read back value of V/I as well as output status Parameter Set output voltage of active channel. Vset The range is as the following:...
Page 32 BASIC OPERATION Parameter Press the F1 key Voltage Setting (CH1 for corresponding to example) Voltage to activate voltage setting area on LCD (red font color with the underline indicator). (a) Input digit with number pad (0-9,.) and press unit key F1(V) or F2(mV) to confirm: Input 6.543V: (b) Step input:...
Page 33 RSPS-3060/RSPS-6030 User Manual (b) Step input: Press the left or right arrow buttons to select high and low level that require fine tune (underline below the corresponding number value), and scroll the scroll wheel to increase or decrease setting value.
Page 34 BASIC OPERATION value. Press F3 key to enter the Protect menu. Press F4 key to open OCP function. OCP display will change from gray to white font. Press the F2 key to enter OCP setting area on LCD, which will be thus activated (red font color with the underline indicator).
Page 35 RSPS-3060/RSPS-6030 User Manual while constant current description displays in red CC. OVP/OCP OVP/OCP displays in white when OVP is not in activation. OVP/OCP displays in red and output is off when OVP is activated. OVP/OCP displays in gray when OVP/OCP functions are off.
Page 36: Independent Output Mode
BASIC OPERATION Independent Output Mode Description Each channel within the models is apart from one another and capable of operations including independent setting and individual output, etc. Front panel connection Load Load Load Load Load Load Rear panel with sense connection Load Load...
Page 37: Tracking Series And Tracking Parallel Modes
Tracking Series and Tracking Parallel Modes Tracking series operation doubles the Voltage Description capacity of the RSPS-3060/ RSPS-6030 by internally connecting CH1 (Master) and CH2 (Slave) in series and combining the output to a single channel. CH1 (Master) controls the combined Voltage output level.
Page 38 Rear panel with sense connection Load Output rating 0 ~ 60V/0 ~A (RSPS-3060) 0 ~ 120V/0 ~ 3A (RSPS-6030) 1. Press F4 or F5 button for operating the Setting corresponding Series to enter the tracking series function. Yellow SER will be shown on the status area.
Page 39 RSPS-3060/RSPS-6030 User Manual Tracking series with common terminal Front panel connection Load Rear panel with sense connection Load 0-30V/0-6A for CH1+ - COM (RSPS-3060) Output rating 0-30V/0-6A for CH2- - COM (RSPS-3060) 0-60V/0-3A for CH1+ - COM (RSPS-6030) 0-60V/0-3A for CH2-...
Page 40 BASIC OPERATION 1. Press F4 or F5 button for operating the Operation corresponding Series to enter the tracking series function. Yellow SER will be shown on the status area. 2. Press CH1 button to proceed to CH1/CH2 voltage setting and CH1 limit current setting. 3.
Page 41 RSPS-3060/RSPS-6030 User Manual CH1/CH2 Tracking Parallel Mode Front panel connection Load Rear panel with sense connection Load 0-30V/0 -12A(RSPS-3060) Output raing 0 -60V/0 -6A (RSPS-6030) Operation 1. Press F4 or F5 button for operating the corresponding Parallel to enter the tracking parallel function.
Page 42 BASIC OPERATION voltage/current setting. 3. For setting operation of parameter, refer to page 33. Output The button ON/OFF of CH1/CH2 is individually available, while All ON/OFF button is available for all channels. Under tracking parallel mode, CH1 is master, CAUTION whilst CH2 is slave.
Page 43: Load Function
RSPS-3060/RSPS-6030 User Manual Load Function Description CH1/CH2 can be set to the Load Mode function, under which both tracking series and tracking parallel function are Not available. The voltage (≥1V) or --.--- Note (<1V) pertaining to port appears when Output is Off.
Page 44 BASIC OPERATION Others OPP： Fixed 50W of single channel, non-revisable OVP/OCP： indentical to Source Parameter Press F4 or F5 button for operating the Vset setting corresponding (CV) mode followed by F1 button (Vset). The voltage setting area on LCD will be activated and appears (red font color with the underline indicator).
Page 45 RSPS-3060/RSPS-6030 User Manual (b) Step input: Press the left or right arrow buttons to select high and low level that require fine tune (underline below the corresponding number value), and scroll the scroll wheel to increase or decrease setting value.
Page 46 BASIC OPERATION The setting method is identical to Source. Operation ON/OFF The button ON/OFF of CH1/CH2 is individually available, while All ON/OFF button is available for all channels. Mode CV CC Font color appears in orange under Load mode. In CR mode, the external power supply must Note provide the current required for I = V / R, otherwise the output ports V and I will fluctuate.
Page 47: Sequence Function
RSPS-3060/RSPS-6030 User Manual Sequence Function Description This function can be used for practical applications when different voltage waveforms are required to be output. Users can edit the output waveform according to their needs. The amplitude range of the output waveform is the output voltage range of power supply.
Page 48 BASIC OPERATION There are 2 statuses after the State necessary Group and Cycle are executed: output termination or being hold with the last step. Parameter Cycles Press the Advance key on control panel. Setting Select F2 (Sequence) function. Press F1 (Set) button followed by selecting F1 (Cycles).
Page 49: Set Sequence Output
RSPS-3060/RSPS-6030 User Manual what’s called the current status. ON/OFF Press the F5 (SEQ.On) button. When Operation the output is on, the Output key will light up. When the output is off, the Output key will not be lit. SEQ will appear in the status area (yellow for CH1 only, blue for CH2 only, while white for both on).
Page 50 BASIC OPERATION Parameter Press the Advance key on control panel. Cycles Select F2 (Sequence) function. Press Setting F1 (Set) button followed by selecting F1 (Cycles). The setting on LCD is activated and appears in red font color . Use number pad to set the parameters directly and then press the F1 (Done) button to confirm;...
Page 51: Set Group Parameter
RSPS-3060/RSPS-6030 User Manual ON/OFF Press the F5 (SEQ.On) button. When Operation the output is on, the Output key will light up. When the output is off, the Output key will not be lit. SEQ will appear in the status area (yellow for CH1 only, blue for CH2 only, while white for both on).
Page 52: Construct Templet
BASIC OPERATION jump directly to the previous or next page,each 8 groups is a Page. Voltage Under the Sequence function, press F2 (Edit) button followed by selecting F3 (Voltage). The setting on LCD is activated and appears in red font color .
Page 53 RSPS-3060/RSPS-6030 User Manual Exp Rise, Exp Fall waveforms are practical per usage. Parameter Object To edit Voltage or Current Description Select the buit-in waveforms including Type Sine, Pulse, Ramp, Stair Up, Stair Dn, Stair UpDn, Exp Rise, Exp Fall. Set the max. value of waveform...
Page 54 BASIC OPERATION (mV/mA) button to confirm; or use arrow keys along with scroll wheel to complete the setting. Start Press the F5 (More) button and then press the F1 (Start) button. The setting on LCD will be activated and appears in red front color .
Page 55: Menu Tree
RSPS-3060/RSPS-6030 User Manual Menu Tree User is able to understand the overall functions of Description Sequence via menu tree, which is put in proper order by tiers. The Return key is used for back to the parent menu. See the construction below:...
Page 56 BASIC OPERATION Advance Sequence Edit Templet Memory SEQ.On Return Cycles Object Type Restart Done Done Type *.CSV Sync Return PageUp Sine *.SEQ PageDown Pulse Return Ramp Start Time StairUp NewFile SEQ.Off Done Second More Return Last (Stair Dn) Save Return Next (Stair UpDn) Return...
Page 57: Save And Recall
RSPS-3060/RSPS-6030 User Manual Save and Recall Description The RSPS-3060/ RSPS-6030 can save and recall the Sequence data from internal 10 groups or flash drive. Parameter Type Available for *.CSV or *.SEQ file type Description Available for creating new *.CSV or File *.SEQ file type...
Page 58 BASIC OPERATION 3. Rotate the scroll wheel (Encode) to select target file. 4. Press F3 (Save) button to save the settings of Sequence into the corresponding file. 5. Press the F4 (Recall) button to recall the Sequence file of list to the current sequence settings when necessary.
Page 59: Delay Function
RSPS-3060/RSPS-6030 User Manual Delay Function Description It is necessary to output a series of pulse in real applications. This function is available when voltage is constant. Output waveform can be edited per user’s preference. The amplitude range of the output waveform is the output voltage range of power supply.
Page 60 BASIC OPERATION The number to be executed. It can NOT Groups exceed 2048 for Start+Groups. End State There are 3 statuses after the necessary Group and Cycle are executed: output termination or output on or being hold with the last step. Stop Halt the current operation based on the Condition...
Page 61 RSPS-3060/RSPS-6030 User Manual End State Under the Delay function, press the F1 (Set) button followed by selecting the F3 (Groups), and 3 statuses Last/Output on/ Output off will appear in turn on LCD . The one displaying is what’s called the current status.
Page 62: Set Group Parameter
BASIC OPERATION Set Group Parameter Description Each Group consists of Vltage, Current and Time. Therefore, properly confirm parameter of each group is correct before setting Delay output. Parameter Group number. Maximum 2047 Description State Output status of each group: On, Off Execution duration of each group.
Page 63 RSPS-3060/RSPS-6030 User Manual F4 (Last) key for the previous one and the F5 (Next) key for the next one Time Under the Delay function, press the F2 (Edit) button followed by selecting the F3 (Time). The setting on LCD is activated.
Page 64: Menu Tree
BASIC OPERATION Menu Tree Description User is able to understand the overall functions of Delay via menu tree, which is put in proper order by tiers. The Return key is used for back to the parent menu. See the construction below: Level1------------ Advance Delay...
Page 65 RSPS-3060/RSPS-6030 User Manual Advance Delay Edit Stop Memory Delay On Return Cycles None Type Restart Done Done Voltage *.CSV Sync Return PageUp Define *.DLY PageDown Delay Off Return Start State Return NewFile Return Done Return Current Save Inverted Define Last...
Page 66: Save And Recall
BASIC OPERATION Save and Recall Description The RSPS-3060/ RSPS-6030 can save and recall the Delay data from internal 10 groups or flash drive. Parameter Type Available for *.CSV or *.DLY file type Description Available for creating new *.CSV or File *.DLY file type...
Page 67 RSPS-3060/RSPS-6030 User Manual 3. Rotate the scroll wheel (Encode) to select target file. 4. Press F3 (Save) button to save the settings of Delay into the corresponding file. 5. Press the F4 (Recall) button to recall the Delay file of list to the current sequence settings when necessary.
Page 68: Monitor Function
BASIC OPERATION Monitor Function Description In order to monitor the channel under long-term output, the RSPS-3060/RSPS-6030 offers monitor function to maintain the output of the supply based on certain preset conditions. This feature is not applicable to CH3. Warning Set Monitor...
Page 69 RSPS-3060/RSPS-6030 User Manual Parameter Press the Advance key on control panel. Voltage Select the F4 (Monitor) function followed Setting by pressing the F1 (Voltage) button to enter the voltage setting. 1. Press the F1 (Set) button. The setting on LCD is activated and appears in red font color.
Page 70 BASIC OPERATION number pad to set the parameters directly; or use arrow keys along with scroll wheel to complete the setting. 2. Press the F4 (Define) button to define terminated condition. 3. Press the F5 (Logic) button to define logical pattern of other conditions. Stop Press the Advance key on control panel.
Page 71: Recorder Function
Recorder Function Description In order to have well understanding of the channel under long-term output, the RSPS-3060/ RSPS- 6030 has the additional live record function, which saves file via media for further analysis later. This feature is applicable to both CH1 & CH2.
Page 72 BASIC OPERATION Press the Advance key on control panel. Groups Select the F5 (Recorder) function. Press the F2 (Groups) button to enter setting of recorded group number. The setting on LCD is activated and appears in red font color. Use number pad to set the parameters directly and then press the F1 (Done) button to confirm;...
Page 73 RSPS-3060/RSPS-6030 User Manual 2. Press F3 (Save) button to save the temporary data into the corresponding file. 3. Press F4 (Recall) button to save the record data of file into the temporary storage for further saving into flash drive later.
Page 74: External I/O Control
BASIC OPERATION External I/O Control Description The RSPS-3060/ RSPS-6030 provides user with a programmable external trigger port, which is used to dock certain functions control. Function It can turn each Data Line (D0,D1,D2,D3,D4) into input signal respectively to have command of the following four functions: 1.
Page 75: Key Function Description
RSPS-3060/RSPS-6030 User Manual Schematic The control circuit of each port is illustrated as the diagram for diagram below (D1 for example) control signal I/O port Electrical characteristics ≤0.3V Input Low Level DC Voltage ≤3.3V High Level DC Voltage ≤0.3V Output Low Level DC Voltage ≤3.3V...
Page 76 BASIC OPERATION (RiseEdge + FallEdge) Respons Set result after trigger response: F1(Output) sets as ON, OFF or reverse Toggle F2 (PWR.Mode) sets channel as power mode F3 (Load Mode) set channel as load CV/CC/CR mode F4 (Track Mode) sets tracking mode of CH1/CH2. This function will only work if channels CH1 and CH2 are selected simultaneously (only source mode).
Page 77 RSPS-3060/RSPS-6030 User Manual Press the F4 (Channel) button to activate the Channel of this terminal:F1(CH1), F2(CH2), F3(CH3). Key F5 (More) After pressing the F3 (Mode) button, Trigger in and Trigger out will bring about different results individually. Refer to the table above for details.
Page 78: File Operation
FILE OPERATION ILE OPERATION Save/Recall ............... 80 Restore Factory Default Settings ....... 83...
Page 79: Save/Recall
RSPS-3060/RSPS-6030 User Manual Save/Recall Description System provides user with 4 different files, each of which has 10 groups including parameter setting *.set, use record *.rec, sequence output *.seq and delay output *.dly. Both file folder and name in flash drive are limited Note within 8 characters.
Page 80 FILE OPERATION 3. Press the F3 (Save) button to have the settings of current model saved into the corresponding file. 4. Or press the F4 (Recall) button to recall the corresponding file, whose file name will be shown on the status bar. Recorded file Refer to page 58 for chapter of save and recall operation *.SEQ...
Page 81 RSPS-3060/RSPS-6030 User Manual Power-on In the System Setting menu, the interface parameter settings area shows Power On. There setting are 2 settings to choose from, Last (the last shut down status) and Default (non-modifiable factory default setting). To enter the function, press the System button to enter the interface followed by pressing the F2 (Power on) button.
Page 82: Restore Factory Default Settings
Channel Channel Parameter Parameter item item Voltage Current 00.000V, 5V(CH3) 0.0000A CH1/2: CH1/2: Off, 35V(RSPS-3060) Off, 6.5A (RSPS-3060) Off, 65V(RSPS-6030) Off, 3.5A (RSPS-6030) CH3: CH3 USB port: Off, 5.5V On, 3.1A Disp Type Type1 Vset(Load) 1.500V Model T3PS Iset (Load) 0.000A...
Page 83: System Settings
RSPS-3060/RSPS-6030 User Manual YSTEM SETTINGS System Information ............ 85 System Settings ............86 Firmware Upgrading ..........88 Description of Using Flash Drive ........ 89...
Page 84: System Information
SYSTEM SETTINGS System Information System The picture below shows complete system Information information. Check Press the System button on the panel to show the operation screen as above. System Version Model View the device Model. Firmware View the system software version. Serial Number View the machine serial number.
Page 85: System Settings
RSPS-3060/RSPS-6030 User Manual System Settings Description It can be used to perform system operations for machine. Setting Interface Remote control and relevant data information output setting Power On Power on initial state setting Language Menu language setting BackLight Adjust the LCD brightness.
Page 86 SYSTEM SETTINGS Firmware In the System menu, press the F3 (Setting) button upgrade followed by selecting the F4 (Upgrade) button to upgrade the machine to the latest software version. For more details, refer to page 88. Screenshot In the System menu, press the F3 (Setting) button followed by selecting F5 (Hardcopy) to proceed to operation screenshot operation.
Page 87: Firmware Upgrading
RSPS-3060/RSPS-6030 User Manual Firmware Upgrading When to When the system fails, firmware can requested by Upgrade RS Pro customers. Firmware Upgrade Firmware file Supplied by RS PRO Requirement Operation After plugging in flash drive, the corresponding symbol appears in the status bar.
Page 88: Description Of Using Flash Drive
SYSTEM SETTINGS Description of Using Flash Drive Description It can be used when upgrading the software, screenshot operation and importing or exporting files. Flash drive only support USB2.0/USB3.0, FAT32 file system, 16G MAX. Operation Insert flash driver into the USB Host port. Then the system identifies the flash driver and the indentification appears in the status bar.
Page 89 RSPS-3060/RSPS-6030 User Manual EMOTE CONTROL Connection Usage ............. 91 RS-232 ................ 91 USB ................92 LAN ................94 Command Syntax ............98 Command List............102 Command Details ............ 109 Measurement Commands ......... 109 Output Commands ............ 112 Source and Load Commands ........115 Status Commands .............
Page 90: Remote Control
This chapter describes how to set and enable port, as well as all the required preparations prior to operation. Port type The RSPS-3060/ RSPS-6030 has 3 standard remote control ports (RS-232, USB and LAN). Control the RSPS-3060/ RSPS-6030 by only Port selection single remote control method.
Page 91: Usb
N --->no flow control bit Function check Perform the following query: *IDN? The unit will return the manufacturer, model, serial number and software version. RS PRO, RSPS-3060, SN: xxxxxxxx, Vx.xx  Send a remote command Local from the PC. Disable Remote Control Mode ...
Page 92 115200----> transmission baud rate Function Check Perform the following query: *IDN? The unit will return the manufacturer, model, serial number and software version. RS PRO, RSPS-3060, SN: xxxxxxxxx, Vx.xx  Send a remote command from the PC Disabling Remote Control ...
Page 93: Lan
RSPS-3060/RSPS-6030 User Manual Description When using the LAN port, the relevant parameters are supposed to be set earlier. Select LAN port in the Interface after connecting the Connection LAN cable. The message LAN will appear gray in the status bar when connected, and turns to white color while the first command connects succesfully.
Page 94 REMOTE CONTROL A. Press the System button to enter the system Manual IP interface followed by pressing the F1 (Interface) button to configure port parameter. B. Press the F4 (LAN) button to configure internet port parameter. C. Press the F2 (Config) button to configure relevant parameter.
Page 95 RSPS-3060/RSPS-6030 User Manual Parameter Settings: IP Address: IP address range: 1.0.0.0 to 223.255.255.255 (excluding 127.nnn.nnn.nnn). Subnet Mask: Subnet Mask Range: 1.0.0.0 to 255.255.255.255. Gateway: Gateway range: 1.0.0.0 to 223.255.255.255 (excluding 127.nnn.nnn.nnn). VISA Resource name： TCPIP0::169.254.129.17::1026::SOCKET A. Press the System button to enter the system...
Page 96 4. Click “Modify Configuation” to enter the network configuration setting menu, as shown below. Use the mouse to click on “Save and Restart” to change the remote settings for the RSPS-3060/ RSPS-6030. Click “Undo Edits” to cancel all the edited settings.
Page 97: Command Syntax
RSPS-3060/RSPS-6030 User Manual Command Syntax The commands that are used with the RSPS-3060/ RSPS-6030 meet IEEE488.2 and SCPI standards. SCPI Commands Overview Command Format SCPI is an ASCII based command language designed for test and measurement instruments. SCPI commands uses a hierarchical structure (tree system), and is divided into different subsystems.
Page 98 REMOTE CONTROL Symbol Description SCPI commands have the following conventional symbols. These symbols are not commands but are used to describe the command parameters. 1. Curly Brackets { } Curly Bracket enclose command string parameters, for example: {OFF|ON} 2. Vertical Bars | Vertical bars are used to separate one or more optional parameters.
Page 99 RSPS-3060/RSPS-6030 User Manual Parameters that use consecutive integers, for example: For the command :DISPlay:CONTrast <brightness>, <brightness> is an integer value with a range of 1~3. 3. Continuous Real Number Parameter that must be a continuous real number can have any value within the effective range and accuracy.
Page 100 REMOTE CONTROL Command Terminators When sending a command to the function generator, the command must be terminated with a <new line> character. The IEEE-4888 EOI can also be used as a <new line> character. A command can also be terminated using a carriage return + <new line> character. The command path will always be reset back to the root level after a command has been terminated.
Page 101: Command List
RSPS-3060/RSPS-6030 User Manual Command List Measurement :MEASure[1|2|3] :<function>? ......109 Commands :MEASure[1|2|3]:ALL? ........109 :MEASure:<function>:ALL? ......109 VOUT<X>? ............110 IOUT<X>? ............110 Display :DISPlay:ENABle ........110 Commands :DISPlay:ENABle? ..........110 :DISPlay:BRIGhtness <NRf> ......111 :DISPlay:BRIGhtness? ........111 :DISPlay:TYPE {1|2|4|5|6|7} ......111 :DISPlay:TYPE? ..........
Page 102 REMOTE CONTROL :SOURce[1|2]:CURRent[:LIMit]:STATe?... 116 :SOURce[1|2]:VOLTage < NRf > ...... 117 VSET<X>:<NR2> ..........117 :SOURce[1|2]:VOLTage? ........117 VSET<X>? ............117 :SOURce[1|2]:RESistor < NRf > ....... 118 :SOURce[1|2]:RESistor? ........118 :SOURce:CURRent:ALL? ......... 118 :SOURce:VOLTage:ALL? ......... 118 :OUTPut:SERies{ON|OFF}[,FAST] ....118 :OUTPut:PARallel {ON|OFF}[,FAST] ....119 TRACK<NR1>...
Page 103 RSPS-3060/RSPS-6030 User Manual {0|1|2|3|4|5|6|7|8|9} ........... 127 :DELAy[1|2]:MEMory:LOAD {0|1|2|3|4|5|6|7|8|9} ........... 127 :DELAy[1|2]:USB:SAVE <dest> ....... 127 :DELAy[1|2]:USB:LOAD <dest> ....... 128 :MONItor[1|2]:CURRent:CONDition {<C|>C|=C|NONE},{AND|OR|NONE} ....128 :MONItor[1|2]:CURRent:CONDition? ....129 :MONItor[1|2]:CURRent[:VALue] {<value>|MINimum|MAXimum} ......129 :MONItor[1|2]:CURRent[:VALue]? ....129 :MONItor[1|2]:POWEr:CONDition {<P|>P||=P|NONE} ........... 129 :MONItor[1|2]:POWER:CONDition? ....130 :MONItor[1|2]:POWER[:VALue] {<value>|MINimum|MAXimum} ......
Page 104 REMOTE CONTROL :SEQUence[1|2]:PARAmeter<No>,<volt> ,<curr>,<time> ........... 136 :SEQUence[1|2]:PARAmeter? <No>,< count> . 137 :SEQUence[1|2]:RESTart ......... 138 :SEQUence[1|2]:STARt <value> ....... 138 :SEQUence[1|2]:STARt? ........138 :SEQUence[1|2][:STATe] {ON|OFF} ....138 :SEQUence[1|2] [:STATe]? ....... 139 :SEQUence:SYNChronize {ON|OFF} ....139 :SEQUence[1|2]:TEMPlet:CONSTruct ....139 :SEQUence[1|2]:TEMPlet:FALLRate? ....139 :SEQUence[1|2]:TEMPlet:INTErval <value> ..140 :SEQUence[1|2]:TEMPlet:INTErval? ....
Page 105 RSPS-3060/RSPS-6030 User Manual {ON|OFF} ............146 :TRIGger:IN[:ENABle]?{D0|D1|D2|D3|D4} ..146 :TRIGger:IN:RESPonse{D0|D1|D2|D3|D4},{ON| OFF||TOGGLE|POWER|CV|CC|CR|IND |SER|PAR } ............146 :TRIGger:IN:RESPonse? {D0|D1|D2|D3|D4} ... 147 :TRIGger:IN:SENSitivity? {D0|D1|D2|D3|D4} ... 148 :TRIGger:IN:SOURce {D0|D1|D2|D3|D4} , {CH1|CH2|CH3},{ON|OFF} ....... 148 :TRIGger:IN:SOURce?{D0|D1|D2|D3|D4}..148 :TRIGger:IN:TYPE {D0|D1|D2|D3|D4},{RISE|FALL|HIGH|LOW |STATE} ............149 :TRIGger:IN:TYPE?{D0|D1|D2|D3|D4} .... 149 :TRIGger:OUT:CONDition? {D0|D1|D2|D3|D4} 150 :TRIGger:OUT[:ENABle] {D0|D1|D2|D3|D4},{ON|OFF} ......
Page 106 REMOTE CONTROL :STATus:QUEue:ENABle <list> ......156 :STATus:QUEue:ENABle? ........ 157 :STATus:QUEue:DISable <list> ......157 :STATus:QUEue:DISable? ........ 157 :STATus:QUEue:DISable? ........ 157 :STATus:QUEue:CLEar ........157 System :SYSTem:VERSion? ......... 158 Commands :SYSTem:ERRor? ..........158 :SYSTem:CLEar ..........158 :SYSTem:POSetup <name> ......159 :SYSTem:POSetup? ......... 159 :SYSTem:COMMunicate:LAN:DHCP [:STATe] ...
Page 107 RSPS-3060/RSPS-6030 User Manual BAUD<NR1> ............ 164 HELP? .............. 164 System Related *IDN? ..............165 Commands *RST ..............165 *SAV <NRf> ............165 SAV<NR1> ............166 *RCL <NRf> ............166 RCL<NR1> ............166 Status Byte *SRE <Allowed values> ......... 171 Register *SRE? ...............
Page 108: Command Details
REMOTE CONTROL Command Details When using commands to select a specific channel, [1] stands for CH1, [2] stands for CH2. “1” can be omitted when you want to select CH1 as it is selected by default. However if you wish to select CH2, “2”...
Page 109: Vout
RSPS-3060/RSPS-6030 User Manual Example :MEASure:VOLTage:ALL? Reads back the all channels voltage value. About CH3, The query voltage will return the set Note value, current and power will return zero. Command VOUT<X>? Function Returns the actual output voltage. Description 1= CH1, 2= CH2...

Page 110: Display:brightness
REMOTE CONTROL Return 0/OFF: Display turned off. 1/ON: Display turned on. Example :DISPlay:ENABle? Returns the state of the display. Command :DISPlay:BRIGhtness <NRf> Function Sets backlight display brightness. Description <NRf> Middle High Example :DISPlay:BRIGhtness Low Sets the backlight to Low. Command :DISPlay:BRIGhtness? Function Queries the brightness of the display.

Page 111: Output Commands
RSPS-3060/RSPS-6030 User Manual Example :DISPlay:TYPE? Returns the TYPE of display screens. Output Commands Command :OUTPut[1|2|3][:STATe] Function Turns the output on or off. Description 0/OFF: Turn off the output 1/ON: Turn on the output Example :OUTPut1:STATe ON Turns on the output of CH1.
Page 112: Route:terminals {Front/Rear
REMOTE CONTROL Example OUT1 Turns on the output. Command ROUTe:TERMinals {FRONt/REAR} Function Set the front or rear terminal output. Example ROUTe:TERMinals REAR Set output from rear terminal. Command ROUTe:TERMinals? Function Query front or rear terminal output. Return FRONt: Output from front terminal. REAR: Output from rear terminal.
Page 113: Output[1|2]:Ovp
RSPS-3060/RSPS-6030 User Manual Return 0/OFF: The channel OVP protection is not triggered. 1/ON: The channel OVP protection has been triggered. Example :OUTPut2:OVP:TRIGer? Return whether the OVP protection function of channel 2 has been triggered. Command :OUTPut[1|2]:OVP <value> Function Sets the OVP level.

Page 114: Source And Load Commands
REMOTE CONTROL Return 0/OFF: OCP function is off. 1/ON: OCP function is on. Example :OUTPut2:OCP:STATe? Returns the status of the OCP function on CH2. Command :OUTPut[1|2|3]:OCP:TRIGer? Function Query whether the OCP protection function has been triggered. Return 0/OFF: The channel OCP protection is not triggered.
Page 115: Source[1|2]:Current
RSPS-3060/RSPS-6030 User Manual Command :SOURce[1|2]:CURRent <NRf> Function Sets the current level. Description <NRf> 0.0000-6.2000 (Refer to the specification sheet for MAX value). Example :SOURce2:CURRent 1.0005 Sets the current level to 1.0005A for CH2. About CH3, The current value can not be set.

Page 116: Source[1|2]:Voltage < Nrf
REMOTE CONTROL Example :SOURce2:CURRent:STATe? Return the current limit state of CH2. At output off or Load Mode,The return value of is 0. Note Command :SOURce[1|2]:VOLTage < NRf > Function Sets the output voltage amplitude. Description <NRf> 0.000-MAX Example :SOURce2:VOLTage 5.321 Sets the output voltage to 5.321V for CH2.
Page 117: Source[1|2]:Resistor < Nrf
RSPS-3060/RSPS-6030 User Manual Command :SOURce[1|2]:RESistor < NRf > Function Set the resistor value. Description 1-1000 Example :SOURce2:RESistor 1000 Set the resistor value as 1000Ω for CH2. Command :SOURce[1|2]:RESistor? Function Queries the setting resistor value. Example :SOURce2:RESistor? Queries the setting resistor value and returns the readback value for CH2.
Page 118: Output:parallel {On|Off}[,Fast]
REMOTE CONTROL Example :OUTPut:SERies ON Sets CH1/CH2 as Tracking series mode. Command :OUTPut:PARallel {ON|OFF}[,FAST] Function Sets CH1/CH2 as tracking parallel mode. Description [FAST]: In order to protect the function switching device ”relay”, it is necessary to wait until the voltage and current drop to zero under normal conditions.
Page 119: Load[1|2]:Cr {On|Off
RSPS-3060/RSPS-6030 User Manual Function Sets CH1/CH2 as Load CC mode. Description [FAST]: In order to protect the function switching device ”relay”, it is necessary to wait until the voltage and current drop to zero under normal conditions. When FAST is enabled, this factor will not be considered, but it is easy to damage the “relay”, so it is recommended to use it with caution.
Page 120: Load:display {Low|Middle|High
REMOTE CONTROL Example :LOAD2:RESistor? Return the Load CR level for CH2. Command :LOAD:DISPlay {Low|Middle|High} Function In load mode, set the minimum voltage value that can be displayed. The factory default is high. Below this value, it will display “--.----“. Description Low: 0.5V；Middle: 0.75V；High:1V Example :LOAD:DISPlay Low...
Page 121: Delay[1|2]:Endstate {On|Off|Last
RSPS-3060/RSPS-6030 User Manual Command :DELAy[1|2]:ENDState {ON|OFF|LAST} Function Sets the termination state of Delay. Description ON|OFF|LAST ON: output enabled. OFF: output disabled. LAST: stay at the last group of output state. Example :DELAy2:ENDState OFF Sets the termination state of Delay as output disabled for CH2.
Page 122: Delay[1|2]:Parameter? [,]
REMOTE CONTROL Function Sets the delay parameter of Delay. Description <No> 0-2047 Sets the serial number of delay parameter. Integer 0-2047. {ON|OFF} The output state of the group. <time> 1s-300s The delay duration of the group. Integer 1s-300s. Example :DELAy2:PARAmeter 1,ON,10 Sets the delay parameter of Delay as the 1st group, output ON, delay 10s for CH2.
Page 123: Delay[1|2]:Start
RSPS-3060/RSPS-6030 User Manual Function Sets the sequence number for initial execution. <value>: Integer 0 – 2047. Example :DELAy2:STARt 10 Sets the CH2 sequence output to start from the group 11. Command :DELAy[1|2]:STARt? Function Queries the sequence number for initial execution of the channel delay output.
Page 124: Delay[1|2]:State: Generate
REMOTE CONTROL Description 01P|10P 10P: the automatically generated state will repeat by the sequence of Off and the On. The automatically generated state will repeat by the sequence of On and the Off. Example :DELAy2:STATe:GENE 01P The automatically generated state will repeat by the sequence of Off and the On for CH2.
Page 125: Delay:synchronize {On|Off
RSPS-3060/RSPS-6030 User Manual Example :DELAy2:STOP? Queries the current stop condition, back to NONE or stop condition value. Command :DELAy:SYNChronize {ON|OFF} Function When both CH1 and CH2 are Delay on, turn on or off the delay synchronization between them. Example :DELAy:SYNChronize ON turn on the delay synchronization of CH1 and CH2.
Page 126: Delay[1|2]:Time:generate
REMOTE CONTROL Example :DELAy2:TIME:GENE INC,3,5 Sets the CH2 method of automatically generated time for delay as monotonous increase, base time as 3s, step value as 5s. Command :DELAy[1|2]:TIME:GENErate? Function Queries the method of automatically generated time for delay and the corresponding parameter. Example :DELAy2:TIME:GENE? Queries the CH2 method of automatically...
Page 127: Delay[1|2]:Usb:load
RSPS-3060/RSPS-6030 User Manual Function Saves the delayed file to the designated location of external storage. Parameter <dest> indicates the designated location of external storage with file format in either usb:\<name>.CSV or usb:\<name>.DLY. The file name spans up to the max. 8 alphanumeric characters. .CSV/.DLY represents the suffix of file name.

Page 128: Monitor[1|2]:Current:condition
REMOTE CONTROL Command :MONItor[1|2]:CURRent:CONDition? Function Queries the current monitor condition for monitor (active channel). Example :MONItor2:CURRent:CONDition? Queries the CH2 current monitor condition for monitor. Returns to the current monitor condition and logical pattern. Command :MONItor[1|2]:CURRent[:VALue]{<value>|MINimum |MAXimum} Function Queries the current monitor value for monitor (active channel).
Page 129: Monitor[1|2]:Power:condition
RSPS-3060/RSPS-6030 User Manual Command :MONItor[1|2]:POWER:CONDition? Function Queries the power monitor condition of current monitor. Example :MONItor2:POWER:COND? Queries the CH2power monitor condition of current monitor. Command :MONItor[1|2]:POWER[:VALue] {<value>|MINimum|MAXimum} Function Sets the power monitor value for monitor (active channel). Description <value> ranges from 0 to the maximum power value of the active channel.
Page 130: Monitor[1|2]:Stopway {Outoff|Alarm
REMOTE CONTROL Example :MONItor2? Queries whether the current monitor is On or Off of CH2. Returns to ON or OFF. Command :MONItor[1|2]:STOPway {OUTOFF|ALARM |BEEPER},{ON|OFF} Function Sets the stop method of monitor (active channel). Description {OUTOFF|ALARM |BEEPER} Disable output by set stop method (OUTOFF), warning (ALARM) or beep (BEEPER).
Page 131: Monitor[1|2]:Voltage:condition
RSPS-3060/RSPS-6030 User Manual Command :MONItor[1|2]:VOLTage:CONDition? Function Queries the voltage monitor condition for the current monitor (active channel). Example :MONItor2:VOLTage:CONDition? Queries the CH2 voltage monitor condition for the current monitor. Command :MONItor[1|2]:VOLTage[:VALue]{<value>|MINimum |MAXimum} Function Sets the voltage monitor value of monitor (active channel).
Page 132: Recorder[1|2]:Usb
REMOTE CONTROL Example :RECOrder2:MEMory 5 Save the CH2 recorded file to the saving location of recorded file within the internal storage 5. Command :RECOrder[1|2]:USB <dest> Function Save the recorded file to the specified location within the external storage. Description <dest> represents the specified location within the external storage with specific formate usb:\<name>.CSV.

Page 133: Recorder [:State] {On|Off
RSPS-3060/RSPS-6030 User Manual Command :RECOrder [:STATe] {ON|OFF} Function Enable or disable recorder. When recorder is enabled, it is Not allowed to set record period and saving location and instrument will sample and save output of each channel based on the interval of currently set recorded period.
Page 134: Recorder[1|2]:Enable {On|Off
REMOTE CONTROL Command :RECOrder[1|2]:ENABle {ON|OFF} Function Sets the channel recorder ON or OFF. Example :RECOrder2:ENABle ON Enables CH2 recorder. Command :RECOrder[1|2]:ENABle? Function Queries the state of channel recorder. Return ON: Recorder is Enabled. OFF: Recorder is Disabled. Example :RECOrder2:ENABle? Returns the state of CH2 recorder, ON or OFF. Command :SEQUence[1|2]:CYCLEs {N|I}[,<value>] Function...
Page 135: Sequence[1|2]:Endstate
RSPS-3060/RSPS-6030 User Manual Example :SEQUence2:ENDState LAST Sets the terminate state of sequence as “the last group”. Command :SEQUence[1|2]:ENDState? Function Queries the terminate state of the sequence. See previous instruction. Example :SEQUence2:ENDState? Queries the CH2terminate state of the sequence. Returns to OFF or LAST.
Page 136: Sequence[1|2]:Parameter? ,< Count
REMOTE CONTROL Description < No > is the serial number of sequence parameter of the specified group, integer, 0 to 2047. <volt> is the voltage of sequence parameter of the group. Unit is V, number, voltage range of the active channel.
Page 137: Sequence[1|2]:Restart
RSPS-3060/RSPS-6030 User Manual Example :SEQUence2:PARAmeter? 1,2 Queries 2 groups’ sequence parameters from the 1st group for CH2. Command :SEQUence[1|2]:RESTart Function Start output with the first sequence. Example :SEQUence2: RESTart Sets the CH2 output with the first sequence. Command :SEQUence[1|2]:STARt <value>...
Page 138: Sequence[1|2] [:State]
REMOTE CONTROL Example :SEQUence2:STATe ON Enable sequence output for CH2. Command :SEQUence[1|2] [:STATe]? Function Queries the state of sequence output . See previous instruction. Example :SEQUence2:STATe? Queries the CH2 state of sequence output. Returns to ON or OFF. Command :SEQUence:SYNChronize {ON|OFF} Function When both CH1 and CH2 are sequence on, turn on or off the sequence synchronization between them.
Page 139: Sequence[1|2]:Templet:interval
RSPS-3060/RSPS-6030 User Manual Example :SEQUence2:TEMPlet:FALLRate? Queries the CH2 falling degree of the active ExpFall. Returns to an integer ranging from 0 to 10. Command :SEQUence[1|2]:TEMPlet:INTErval <value> Function Sets the time interval. Description <value> integer 1s to 300s. Time interval is the duration period in accord with each time parameter of the active selected templet.

Page 140: Sequence[1|2]:Templet:maxvalue {|Minimum|Maximum
REMOTE CONTROL Example :SEQUence2:TEMPlet:INVErt? Returns to the templet of CH2 to check if the invert function is ON or OFF. Command :SEQUence[1|2]:TEMPlet:MAXValue{<value>|MINi mum|MAXimum} Function Sets the maximum voltage or current value of the active selected templet. Description When voltage is the object to edit, it is the maximum voltage to be set.
Page 141: Sequence[1|2]:Templet:minvalue
RSPS-3060/RSPS-6030 User Manual Command :SEQUence[1|2]:TEMPlet:MINValue? Function Queries the minimum voltage or current value of the active selected templet. Example :SEQUence2:TEMPlet:MINValue? Returns to the CH2 minimum voltage or current value of the active selected templet. Command :SEQUence[1|2]:TEMPlet:OBJect {V|C} Function Selects the object to be edited by the active templet.
Page 142: Sequence[1|2]:Templet:riserate
REMOTE CONTROL Command :SEQUence[1|2]:TEMPlet:RISERate <value> Function Sets the rising degree of ExpRise. Description <value> Ranges from 0 to 10. Example :SEQUence2:TEMPlet:RISERate 10 Sets the rising degree of ExpRise as 10 for CH2. Command :SEQUence[1|2]:TEMPlet:RISERate? Function Queries the rising degree of the actively set ExpRise.

Page 143: Sequence[1|2]:Templet:width
RSPS-3060/RSPS-6030 User Manual Example :SEQUence2:TEMPlet:SYMMetry? Returns the symmetry of the actively set RAMP for CH2. Command :SEQUence[1|2]:TEMPlet:WIDTh <value> Function Sets the pulse width of Pulse. Description <value> The available setting range, which is from 1 to (Points-1), is relevant to the actively set period.

Page 144: Sequence[1|2]:Memory:load {0|1|2|3|4|5|6|7|8|9
REMOTE CONTROL Function Saves the channel sequence output file to the designated location of internal storage. {0|1|2|3|4|5|6|7|8|9} represent the storage locations of 10 files within the internal storage individually. Example :SEQUence2:MEMory:SAVE 1 Saves the CH2 sequence output file to the SEQUENCE01 location of internal storage.
Page 145: On|Off
RSPS-3060/RSPS-6030 User Manual Function Recalls the channel sequence output file saved in the designated location from external storage. <dest> indicates the designated location of external storage. Example :SEQUence2:USB:LOAD USB:\R001.CSV Recalls the CH2 sequence output file, R001.CSV, saved in the external storage.
Page 146: Trigger:in:response? {D0|D1|D2|D3|D4
REMOTE CONTROL condition, invert the currently selected controlled channel output. Output Power mode (POWER): when input signal of the specified cable line meets the set triggering condition, set the currently controlled channel in the power mode. Output Load CV mode (CV): when input signal of the specified cable line meets the set triggering condition, set the currently controlled channel in the load CV mode.
Page 147: Trigger:in:sensitivity? {D0|D1|D2|D3|D4
RSPS-3060/RSPS-6030 User Manual Function Queries the output response from the trigger input of the specified data line. Example :TRIGger:IN:RESPonse? D0 Returns the output reponse of the trigger input of the queried D0 data line. Command :TRIGger:IN:SENSitivity {D0|D1|D2|D3|D4},{LOW|MID|HIGH} Function Sets the trigger sensitivity from the trigger input of the specified data line.
Page 148: Trigger:in:type
REMOTE CONTROL Function Queries the controlled channel from the trigger input of the specified data line. Example :TRIGger:IN:SOURce? D0 Returns the controlled channel from the trigger input of D0 data line. Command :TRIGger:IN:TYPE {D0|D1|D2|D3|D4},{RISE|FALL|HIGH|LOW|STATE} Function Sets the trigger type from the trigger input of the specified data line.
Page 149: Trigger:out:condition? {D0|D1|D2|D3|D4
RSPS-3060/RSPS-6030 User Manual output (OUTON), both of which indicate to disable or enable respectively the trigger when the specified controlled channel output. Voltage trigger: greater than voltage (> V), less than voltage (< V), equal to voltage (= V), all of which...
Page 150: Trigger:out[:Enable] {D0|D1|D2|D3|D4},{On|Off
REMOTE CONTROL Command :TRIGger:OUT[:ENABle] {D0|D1|D2|D3|D4},{ON|OFF} Function Enables or disables the trigger output function of the specified data line. Description After enabling trigger output function, the specified data line will, when the output signal of the specified controlled channel meets the set trigger condition, output the specified level or square wave based on the setting of output signal.
Page 151: Trigger:out:source {D0|D1|D2|D3|D4},{Ch1|Ch2|Ch3
RSPS-3060/RSPS-6030 User Manual Example :TRIGger:OUT:POLArity? D0 Returns the polarity of the output signal from the trigger input of D0 data line. Command :TRIGger:OUT:SOURce {D0|D1|D2|D3|D4},{CH1|CH2|CH3} Function Sets the controlled channel from the trigger output of the specified data line. Description CH1|CH2|CH3 Any of the channels, CH1, CH2, CH3 is available for selection as controlled channel of trigger output.
Page 152: Status Commands
REMOTE CONTROL Status Commands Command STATus? Function Returns the Status . Return 8 bytes in the following format parameter Except for the bauds above, bytes 6 and 7 are 11 Note in other states (19200bps, 38400bps, LAN). Example STATus? Command :STATus:PRESet Function Clears the operation event enable registers, the...
Page 153: Status:operation:enable
RSPS-3060/RSPS-6030 User Manual Example :STATus:OPERation:CONDition? Read the contents of the operation condition status register. Command :STATus:OPERation:ENABle <NRf> Function Programs the operation enable status register. Description <NRf> 8: CL (Current enable bit). 16: CLT (Current limit tripped enable bit). 64: PSS (Power supply shutdown enable bit).

Page 154: Status:measurement:condition
REMOTE CONTROL and 1,023, it is certainly valid. If <value> is between 1,024 and 65,535, ensure Cal (bit8) is a valid value for it to work. Example :STATus:MEASurement:ENABle 8 Enables the ROF bit. Command :STATus:MEASurement:ENABle? Function Read the measurement enable status register. Example :STATus:MEASurement:ENABle? Read the contents of the measurement enable...
Page 155: Status:questionable:enable
RSPS-3060/RSPS-6030 User Manual Description <NRf> 256: CAL (Calibration summary enable bit). Register is 16 bits. If <value> is between 256 and 511, it is certainly valid. If <value> is between 512 and 65,535, ensure Cal (bit8) is a valid value.
Page 156: Status:queue:disable
REMOTE CONTROL Command :STATus:QUEue:ENABle? Function Read the error and status messages that have been enabled. Example :STATus:QUEue:ENABle? Returns the contents of the enabled error and status messages. Command :STATus:QUEue:DISable <list> Function Specifies which messages will not be placed in the error queue. Description <list>...

Page 157: System Commands
RSPS-3060/RSPS-6030 User Manual Example :STATus:QUEue:CLEar Empty all the messages from the error queue. System Commands Command :SYSTem:VERSion? Function Query the SCPI version. Example :SYSTem:VERSion? Query the SCPI version. Command :SYSTem:ERRor? Function Read and clear the last error and from the error queue.
Page 158: System:posetup
REMOTE CONTROL Function Clear the error messages. Example :SYSTem:CLEar Clears the error queue. Command :SYSTem:POSetup <name> Function Set the power on configuration. Description <name> RST: Machine default settings. Last: Machine last settings. Example :SYSTem:POSetup RST Set the power on configuration to RST. Command :SYSTem:POSetup? Function...

Page 159: System:communicate:lan:ipaddress
RSPS-3060/RSPS-6030 User Manual Function Sets the IP address. Description <IP ASCII string, within the range of 1.0.0.0 to 223.255.255.255 (excluding address> 127.nnn.nnn.nnn). This command is only applicable if for the manual Note IP mode. The SYSTem:COMMunicate:LAN:APPLy command needs to be executed before the IP address settings can take effect.
Page 160: System:communicate:lan:gateway
REMOTE CONTROL Function Sets the gateway IP address. Description <IP address> ASCII string, within the range of 1.0.0.0 to 223.255.255.255 (excluding 127.nnn.nnn.nnn). The SYSTem:COMMunicate:LAN:APPLy command needs to be executed before the gateway IP address setting can take effect. Example :SYSTem:COMMunicate:LAN:GATEway 172.16.3.1 Sets the gateway IP to 172.16.3.1.
Page 161: System:remote
RSPS-3060/RSPS-6030 User Manual Example :SYSTem:COMMunicate:LAN:APPLy Applies all the LAN settings. Command :SYSTem:REMote Function Sets the unit to remote control. Example :SYSTem:REMote Sets to remote control mode. Command REMOTE Function Sets the unit to remote control. Example REMOTE Command :SYSTem:BEEPer:STATe ...
Page 162: Local
REMOTE CONTROL Example :SYSTem:LOCal Disables remote control mode. Command LOCAL Function Exits remote mode and sets the instrument to local mode. Example LOCAL Command :SYSTem:INTerface [USB|RS232|LAN] Function Sets the interface type. Example :SYSTem:INTerface USB Sets the interface type to USB. Command :SYSTem:LANGuage [CHINese|ENGlish] Function...
Page 163: System:baudrate:rs232
RSPS-3060/RSPS-6030 User Manual Function Sets the RS232 baud rate. Example :SYSTem:BAUDrate:RS232 9600 Sets the RS232 baud rate to 9600. Command :SYSTem:BAUDrate:RS232? Function Query the RS232 baud rate. Example :SYSTem:BAUDrate:RS232? Command BAUD<NR1> Function Sets the baud rate to 9600 / 57600 / 115200.
Page 164: System Related Commands
The first field is the manufacturer, followed by the model name, serial number and the version number. Example *IDN? Returns the RSPS-3060 identification: RS PRO,RSPS-3060,XXXXXXXXX,V1.00 RS PRO: Manufacturer, RSPS-3060: Model name, XXXXXXXXX: Serial number, V1.00: version number.
Page 165: Sav
RSPS-3060/RSPS-6030 User Manual Description <NRf>: 0 - 9, Corresponding to STATE00-STATE09. Example *SAV 1 Stores the setting in memory 1(STATE01). Command SAV<NR1> Function Save the current setup to the selected save location. Description <NR1> : 0–9, Corresponding to STATE00- STATE09.

Page 166: Scpi Status Registers Scpi
REMOTE CONTROL SCPI Status Registers SCPI The SCPI instrument configuration is controlled by the status registers. The Status system records various instrument conditions into three main register groups: The status byte register, the standard event register group and the questionable data register group.
Page 167: Event Registers
RSPS-3060/RSPS-6030 User Manual * Note: URQ indicates that the "Lock" key on the panel has been used. (Entering lock from unlock or Entering unlock from lock). Event Registers The operation, measurement and questionable status register groups all have event registers. The event registers are read only registers that reflect the status of the unit.
Page 168 REMOTE CONTROL Bit Definition for the Status Byte Register Bit number Decimal value Definition Not used, returns “0” 0 Not used Not used, returns “0” 1 Not used 2 Error Queue Indicates that one or more errors are stored in the error queue. 3 Questionable One or more bits are set in the Summary bit...
Page 169: Standard Event Register
RSPS-3060/RSPS-6030 User Manual Complete Bit can be used to determine when the information can be used. However if too many commands/queries are executed prior to the execution of the *OPC command, the output buffer could become saturated and the unit will stop taking readings.
Page 170: Status Byte Register Commands
REMOTE CONTROL The following will clear the standard event register:  The *CLS command is executed.  The *ESR? command is used to query the event register. The following will clear the standard event enable register.  The *ESE command is executed. Status Byte Register Commands Command *SRE <Allowed values>...
Page 171: Standard Event Register Commands
RSPS-3060/RSPS-6030 User Manual Command *STB? Function Query the status byte register. This is the same as performing a serial poll, however the master summary bit (MSS, bit 6) will not be cleared by the *STB command. The return value range is from 0 to 255.
Page 172: Other Status Register Commands
REMOTE CONTROL Other Status Register Commands Command *CLS Function Clears the status byte summary registers and the all event registers. Example *CLS Clears all the event registers, which include Standard event registers, Operation event registers, Measurement event registers, Questionable event registers. Command *OPC Function...
Page 173: Errors
RSPS-3060/RSPS-6030 User Manual Errors Error Message •Errors are stored in a first in-first out (FIFO) order. The first error message that is returned is the first error message that was stored. When an error is read it is also cleared from the queue.
Page 174 REMOTE CONTROL -224 Out of memory -223 Illegal parameter value -222 Too much data -221 Parameter data out of range -220 Settings confiict -200 Parameter error -178 Execution error -171 Expression data not allowed -170 Invalid expression -161 Expression error -160 Invalid block data -158...
Page 175 RSPS-3060/RSPS-6030 User Manual -104 Data type error -103 Invalid separator -102 Syntax error -101 Invalid character -100 Command error +000 No error +101 Operation complete +301 Reading overﬂow +302 Pulse trigger detection timeout +306 Reading available +310 Buffer full +320...
Page 176: Appendix
APPENDIX PPENDIX Replacing the Fuse............178 Specifications ............179...
Page 177: Replacing The Fuse
RSPS-3060/RSPS-6030 User Manual Replacing the Fuse Steps Remove the power cord and then take out the box using a small screw driver. The fuse is stored in the housing.  Rating T6.3A/250V(220V/230V)  T12A/250V (100V/120V)
Page 178: Specifications
APPENDIX Specifications The specifications apply under the following conditions: The RSPS- 3060/ RSPS-6030 is powered on for at least 30 minutes, within +20°C-+30°C. Power Mode Output Rating CH1/CH2 0 ~ 30.000V, 0 ~ 6.0000A (RSPS- Independent 3060) 0 ~ 60.000V, 0 ~ 3.0000A (RSPS- 6030) CH1, CH2 0 ~ 60.000V, 0 ~ 6.0000A (RSPS-...
Page 179 RSPS-3060/RSPS-6030 User Manual Line: ≤ 0.01% + 3mV Parallel Load: ≤ 0.01% + 5mV(rating current ≤ regulation 10A) ≤ 0.02% + 5mV(rating current > 10A) Line: ≤ 0.01% + 5mV Series Load: ≤ 200mV regulation ≤ 2mVrms(5Hz ~ 1MHz) Ripple &...
Page 180 1.8V/2.5V/3.3V/5.0V, ± 0.35V, 3A The output current from the 2 terminals should Not Warning exceed 5A. Load Mode Display Voltage 1 ~ 32.00V (RSPS-3060) 1 ~ 62.00V (RSPS-6030) Current 0 ~ 6.200A (RSPS-3060) 0 ~ 3.200A (RSPS-6030) Power 0 ~ 50.00W(CH1/CH2)
Page 181 RSPS-3060/RSPS-6030 User Manual Power/Load CH1/CH2: mode OFF,ON(0.05A ~ 6.50A)(RSPS- 3060) OFF,ON(0.05A ~ 3.50A)(RSPS- 6030) CH3:3.1A(USB port) Setting accuracy ≤ ±20mA Resolution 10mA 20MΩ or above (DC 500V) Insulation Between chassis resistance and terminal 30MΩ or above (DC 500V) Between chassis...

This manual is also suitable for:

Rsps-6030 2732613 2732614

RS PRO RSPS-3060 User Manual

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RS PRO RSPS-3060

Summary of Contents for RS PRO RSPS-3060

This manual is also suitable for:
