Introduction ...................................................................... 2
Quick Facts ..................................................................... 2
Preparation ....................................................................... 2
Resources Required ........................................................ 2
Installation ........................................................................ 3
Assembling the Awning ................................................... 4
Mounting the Bottom Mounting Brackets ........................ 4
Mounting the Awning ....................................................... 5
Securing the Fabric ......................................................... 6
Installing the Stop Bolt .................................................... 7
Operation .......................................................................... 7
Extending the Awning ..................................................... 7
Retracting the Awning ..................................................... 7
Fabric Replacement ......................................................... 8
Fabric Removal ............................................................... 8
Installing Replacement Fabric ......................................... 9
Fabric Care ................................................................... 10
Securing the Fabric ....................................................... 10
Troubleshooting chart ....................................................11
lippert.com
432-LIPPERT (432-547-7378)
Solera
®
Awning
Installation and Owner's Manual
(For Aftermarket Applications)
Solera
1000XL Series
Awning
Installation and
Owner's Manual
(For Aftermarket Applications)
Awnbrella Parts List ...................................................... 12
Resources Required ...................................................... 13
Installation ...................................................................... 13
Spacing Awnbrella Arms ........................................... 13
Drilling the Roller Tube .................................................. 14
Mounting Hanger Blocks ............................................... 15
Inserting Awnbrella Arms .............................................. 15
Stabilizers ......................................................... 16
®
Special Notes: ............................................................... 17
Ground Support Introduction ....................................... 18
Installation ...................................................................... 18
Removal of Ground Support ......................................... 20
1
CCD-0001255
1000XL Series
®
Rev: 11.18.24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Solera 1000XL Series and is the answer not in the manual?

Questions and answers

Related Manuals for Lippert Solera 1000XL Series

Summary of Contents for Lippert Solera 1000XL Series

  • Page 1: Table Of Contents

    Fabric Replacement ............8 Fabric Removal ............... 8 Installing Replacement Fabric ......... 9 1000 Series Awnings Fabric Replacement Turn Chart ... 9 Fabric Care ..............10 Securing the Fabric ............10 Troubleshooting chart ............11 lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 2: Introduction

    1. Tape securing the fabric. • Custom hardware color options available 2. Cotter pins in the spring assemblies. Additional information about Lippert products can be obtained from lci1.com /support or by downloading the free myLCI app. Replacement component parts can be ordered...

  • Page 3: Installation

    Awning Width = Head Bolt to Head Bolt 90° Front Facing View Dotted line Dotted line = Vertical = vertical centerline centerline Floor Line Fig.2 Letter Description Awning Rail Support Arm Assembly Roll Tube Assembly Lower Mounting Bracket Upper Mounting Bracket lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 4: Assembling The Awning

    Refer distance is measured from head bolt to head bolt (Fig.2). to unit manufacturer for proper location. 4. Repeat step 3 for the other side of the awning. Fig.3 Fig.5 Fig.4 lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 5: Mounting The Awning

    NOTE: If adjustments need made so the upper mounting brackets straddle the awning rail, loosen the black locking knob on the mount arm upper channel (channel#3) (Fig.7). Slide the mount arm upper channel (channel#3) (Fig.7) up Fig.9 lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 6: Securing The Fabric

    13. Allow the fabric to slowly roll up. FAILURE TO MAINTAIN CONTROL OF THE ROLL TUBE, FABRIC AND SUPPORT ARM ASSEMBLIES MAY RESULT IN SERIOUS PERSONAL INJURY OR PROPERTY DAMAGE. outer edge of fabric Fig.11 lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 7: Installing The Stop Bolt

    Do this for both ends. 2. Take the awning pull strap and return it to the center of the awning roll tube. Fig.14 lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 8: Fabric Replacement

    NOTE: If the awning is 6’ in length it will only need one cotter 12. Mark the cam lock position on the roll tube. pin for the drive side end cap. lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 9: Installing Replacement Fabric

    11. Install the previously removed drive head assembly and idler head assembly retaining bolts into the outer arms to secure the components. fabric 12. Reinstall the previously-removed support arm upper mounting bracket to the unit wall. Fig.18 lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 10: Fabric Care

    OEM supplied #6 x 1/2” hex head screw (Fig. 20E). Install the screw (Fig. 20E) down through the awning rail (Fig. 20B) and polycord (Fig. 20D). " 1" outer edge of fabric Fig.20 lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 11: Troubleshooting Chart

    Awning will not stay in The absence of a clicking noise when the awning is rolled out. the rolled out position. The awning rolling back up after it is placed in the stop position. lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 12: Awnbrella Parts List

    Awnbrella 3-arm package - Part number Letter Description Awnbrella Arms Adjustable from 59” to 106” White Velcro Pads with Adhesive Backing ® Black Velcro Pads with Adhesive Backing ® Hanger Blocks Plastic Tightening Knobs ” Self-Tapping Mounting Screws lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 13: Resources Required

    Awnbrella arms should not be placed sections not exceeding 54”. See example to the right and any closer than 42” from the end of the tube to protect the installations instructions on the next page. roller tube spring. lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 14: Drilling The Roller Tube

    (Fig.24). Fig.23 Fig.24 NOTE: It is important that all the holes drilled on the roller tube are aligned at 1/2" down from the fabric retaining seam. Fig.25 lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 15: Mounting Hanger Blocks

    1- " self-tapping Adjusting the arms now will make it easier Awnbrella arms are secure so they don’t screws. (Fig.26). to properly insert them later. fall down. Fig.26 Fig.27 Fig.28 Fig.29 Fig.30 Fig.31 lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 16: Velcro Stabilizers

    5. Remove the clear protective film from the back of the Velcro (Fig.34). Carefully place the Awnbrella arm back into position, pressing it firmly against the awning fabric. 6. Repeat steps 2 and 4 for each Awnbrella arm. lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 17: Proper Awning Extention For Awnbrella Arms

    This should present no problem in performance. Canvas should be in good condition when using the Awnbrella or it could rip. • Lippert Components is not responsible for damage or injury due to improper use or installation. Never: • Leave the awning out in strong winds. Lippert Components makes no claims regarding the performance of this product in windy conditions.

  • Page 18: Ground Support Introduction

    1. Measure the length of the roll tube (Fig.36). Fig.39 4. Mark the location for the bolt at the center of the roll tube using the Ground Support assembly bracket (Fig.38) as a guide. Fig.37 lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...
  • Page 19 10. Loosen the adjustment knob of the Ground Support assembly (Fig.44) and extend the lower leg of the assembly 7/16 to the ground (Fig.45) to support the roll tube. Re-tighten the ” wrench adjustment knob. adjustment threaded insert knob tool Fig.42 Fig.45 lippert.com 432-LIPPERT (432-547-7378) CCD-0001255 Rev: 11.18.24...

  • Page 20: Removal Of Ground Support

    1. Pull up the stakes from the end of the Ground Support assembly (Fig.47). Manual information may be distributed as a complete document only, unless Lippert provides explicit consent to distribute individual parts. All manual information is subject to change without notice.
